Dacor HWDF30S Technical manual

PLANNING
GUIDE
All specications subject to change without notice. www.dacor.com Ph. 800.793.0093
Heritage®24”, 27”, 30” Wide
Warming Drawer
Doc #: PGH-HWD.01 Revised14 May 2018 Page1 of 2
All tolerances: ±¹/₁₆” (±1.6 mm), unless otherwise stated.
HWDxxPS, HWDF30S
Electrical Circuit Required Total Connected Load Min. Ambient
Operating Temp.
120Vac, 60 Hz, 15 Amp
grounded, dedicated circuit
4.0 Amp. @
120Vac, 60 Hz 32°F (0°C)
Handle Dimensions
Warming Drawer Overall Dimensions
Model (A) Drawer Face
Width
(B) Chassis Face
Width
(C) Chassis Width
HWD24PS 24” (61.0 cm) 23 ” (60.0 cm) 22 ” (56.5 cm)
HWD27PS 27” (68.6 cm) 26 ” (67.6 cm) 25 ” (64.1 cm)
HWD30PS
HWDF30S 30” (76.2 cm) 29 ” (75.2 cm) 28 ” (71.8 cm)
WARNING
• Observe all governing codes and ordinances during planning/
installation. Contact your local building department for details.
• The drawer must be installed as directed in its installation
instructions.
HWDxxPS shown
(height/width typical)

PLANNING
GUIDE
All specications subject to change without notice. www.dacor.com Ph. 800.793.0093
Heritage®24”, 27”, 30” Wide
Warming Drawer
Page 2 of 2
All tolerances: ±¹/₁₆” (±1.6 mm), unless otherwise stated.
HWDxxPS, HWDF30S
Model (A) Cutout Width (B) Min. Width to
Adjacent Doors/Drawers
(C) Cutout
Height
(D) Minimum Vertical
Gap Between Cutouts
(E) Min. Vertical Gap Betw.
Drawer and Cabinet
Minimum
Cutout Depth
HWD24PS 22 ” (57.2 cm) 24 ” (61.6 cm)*
9 ” (23.2 cm) 1 ” (3.2 cm) ¾” (1.9 cm)* 24” (61.0 cm)
HWD27PS 25 ” (64.8 cm) 27 ” (69.2 cm)*
HWD30PS 28 ” (72.4 cm) 30 ” (76.8 cm)*
HWDF30S 28 ” (72.4 cm) 30 ” (76.8 cm)*
*Minimum spacing for ventilation and to avoid scraping.
Mounting platform must be
¾" (1.9 cm) thick and able to
support 100 lbs. (45.4 kilos)
