Dacor Modernist DWR30M977WIP Technical manual

PLANNING
GUIDE
All specications subject to change without notice. www.dacor.com Ph. 800.793.0093
Modernist®Warming Drawer
Doc #:PGM-DWR.01 Revised 29 Jan 2019 Page1 of 4
All tolerances: ±¹/₁₆” (±1.6 mm), unless otherwise stated.
DWR30M977WIP/WIM/WIS
Electrical Circuit Required Total Connected Load Min. Ambient
Operating Temp.
120Vac, 60 Hz, 15 Amp
grounded, dedicated circuit
4.0 Amp. @
120Vac, 60 Hz 32°F (0°C)
WARNING
• Observe all governing codes and ordinances during planning/
installation. Contact your local building department for details.
• The drawer must be installed as directed in its installation
instructions.
Front Panel for WIM/WIS Shown
Model No.
(A)
Chassis Face
Width
(B)
Chassis
Width
(C)
Chassis
Depth
(D)
Drawer Depth
(without panel)
(D)
Drawer Depth
(with 3/4” panel)
(E)
Chassis Height
(with feet)
DWR30M977 29 5/8”
(75.2 cm)
27 7/8”
(70.8 cm)
20 15/16”
(53.1 cm)
19 3/4”
(50.2 cm)
20 1/2”
(52.1 cm)
9 3/4”
(24.8 cm)
Front Panel forWIP Front Panel forWIM/WIS

PLANNING
GUIDE
All specications subject to change without notice. www.dacor.com Ph. 800.793.0093
Modernist®Warming Drawer
Page 2 of 4
All tolerances: ±¹/₁₆” (±1.6 mm), unless otherwise stated.
DWR30M977WIP/WIM/WIS
Mounting platform must be ¾" (1.9 cm) thick and able to support
100 lbs. (45.4 kilos)
Measurement DWR30M977
(A) Cutout Width 30 1/4” (76.8 cm)
(B) Min. Width to Adjacent Doors/
Drawer 30 1/4” (76.8 cm)
(C) Cutout Height 10 1/2” (26.7 cm)
(D1) Min. Vertical Gap Betw. Warm-
ing Drawer Cutouts 1 1/4” (3.2 cm)
(D2) Min. Vertical Gap Betw.
Dacor Wall Oven 1 1/2” (3.8 cm)
(E1) Flush to Drawer Front 1 5/64” (2.7 cm)
(E2) Flush to Cab’t Frame /
Drawer with Panel Flush to
Drawer Front
1 53/64” (4.6 cm)
(E3) Drawer with Panel
Flush to Cab’t Frame 2 37/64” (6.5 cm)
(E4) Drawer with Oversized
Panel 1 37/64” (4.0 cm)
(F) Min. Width Inside Cleats 28” (71.0 cm)
(G) Min. Cutout Depth 24” (61.0 cm)

PLANNING
GUIDE
All specications subject to change without notice. www.dacor.com Ph. 800.793.0093
Modernist®Warming Drawer
Page 3 of 4
All tolerances: ±¹/₁₆” (±1.6 mm), unless otherwise stated.
DWR30M977WIP/WIM/WIS
WIP Installation Scenarios

PLANNING
GUIDE
All specications subject to change without notice. www.dacor.com Ph. 800.793.0093
Modernist®Warming Drawer
Page 4 of 4
All tolerances: ±¹/₁₆” (±1.6 mm), unless otherwise stated.
DWR30M977WIP/WIM/WIS
Bracket Location (rearview) Minimum Clearances (side view)
WIP Panel Mounting Information
WIM/WIS Installations Scenarios
