Daewoo DPC3000N User manual

DPC3000N

IMPORTANT
The lighting flash with arrowhead
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of unisulated dangerous
voltage within the product's enclosure
that may be of sufficient magnitude to
constitute a risk of electric shock to
persons.
CAUTION: TO PREVENT THE RISK
OF ELECTRIC SHOCK DO NOT
REMOVE COVER (OR BACK). NO
USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing
instructions in the literature
accompanying the appliance.
Note : This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for
help.
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
This product incorporates copyright protection technology that is protected by method claims of certain U. S .Patents
and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this
copyright protection technology must be authorised by Macrovision Corporation, and is intended for home and other
limited viewing uses only unless otherwise authorised by Macrovision corporation. Reverse engineering or
disassembly is prohibited.
Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby
Laboratories.
"DTS" and "DTS Digital Surround" are trademarks of Digital Theater Systems, Inc.
CAUTION VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN. AVOID DIRECT EXPOSURE TO BEAM
(WARNING LOCATION : INSIDE ON LASER COVER SHIELD)
This instrument is listed by Underwriter’s Laboratories, Inc. It is designed and manufactured to meet
rigid U.L. safety standards against X-radiation, fire, casualty and electrical hazards.
CAUTION
This product satisfies FCC regulations
when shielded cables and connectors are
used to connect the unit to other
equipment. To present electromagnetic
interference with electric appliances such
as radios and televisions, use shielded
cables and connectors for connections.
CAUTION
This product contains a laser diode of higher class than 1. To
ensure continued safety, do not remove any covers.
Refer all servicing to qualified personnel.
The following caution appears on rear of the unit.
CAUTION : LASER RADIATION WHEN OPEN.
AVOID EXPOSURE TO BEAM.
VORSICHT : SICHTBARE UND UNSICHTBARE
LASERSTRAHLUNG. WENN
ABDECKUNG GEÖFFNET. NICHT
DEM STRAHL AUSETZEN.
ADVARSEL : LASERSTRÄLING VEDÃ ÃBNING
UNDGÃ UDSÆ TTEL SE FOR
STRÃLING.
VARNING : LASERSTRÃL NING NÃR DENNA DEL
ÃR ÖPPNAD BETRAKTA EJ STRÃLEN.
VARO! : AVATTAESSA ALTISTUT LASERSÃTBL
YLLE ÃLÃ KATSO SÃTEESEN
CAUTION
•Use of controls or adjustments or
performance of procedures other than
those specified here in may result in
hazardous radiation exposure.
• The use of Optical instruments with this
product will increase eye hazard.
1
Before you start
Precaution

2
Important Safety Instructions
WARNING
Plug the cigar jack tightly
so that it does not move.
This will prevent the danger
caused by bad connection or
fire.
Do not use the cigar jack
if it is damaged.
Using such a jack may result
in danger due to bad
connection and fire.
Never touch the cigar jack
with a wet hand.
Doing so may cause fire or
electric shock.
Do not move the product
while a disc is playing.
This may cause the
breakdown of the disc or the
product.
While driving, see to it the
cigar jack cable does not
entangle your hand.
This may cause traffic
accidents.
Never attempt to extend
the cigar jack excessively.
In use under unsteady voltage
conditions, the battery may
easily be discharged.
Hold the cigar jack fast
when you disconnect it.
This prevents overheating or
fire.
Refrain from watching or
operating DVD.
Traffic accidents may be
caused.
Use the product only with 12V vehicles.
Used under other voltage conditions, the
product may break down.
Do not install the product to block your
vision.
Doing so may cause traffic accidents.
CAUTION
Do not place a book or
water- holding container
on the surface.
This may cause a defect.
Do not install the product
to expose it to direct
sunlight.
This may cause overheating
or fire.
Install the product on an
even and solid surface.
Doing so prevents error.
Do not keep or use
inflammable sprays or
other inflammable
materials near the DVD
player.
Doing so may cause
explosion or fire.
When installing, make
sure you install it far from
the steering wheel knob.
Doing so prevents traffic
accidents.
Make sure your brake
pedal use does not damage
the remote control.
Make sure your brake pedal
use does not damage the
remote control.
Do not dissemble or
transform the product
arbitrarily.
This may result in
breakdown.
Maintain the volume on a
reasonable level.
Doing so will help you avoid
interfering with other drivers
and become aware of the
situation around you.

3
Before you start
Important Safety Instructions
READ INSTRUCTIONS - All the safety
and operating instructions should be
read before the product is operated.
RETAIN INSTRUCTIONS - The safety
and operating instructions should be
retained for future reference.
HEED WARNINGS - All warnings on the
product and in the operating instructions
should be adhered to.
FOLLOW INSTRUCTIONS - All
operating and use instructions should be
followed.
CLEANING - Unplug this product from
the wall outlet before cleaning. The
product should be cleaned only with a
polishing cloth or a soft dry cloth. Never
clean with furniture wax, benzenes
ecticides or other volatile liquids as they
may corrode the cabinet.
ATTACHMENTS - Do not use
attachments not recommended by the
product manufacturer as they may cause
hazards .
WATER AND MOISTURE - Do not use
this product near water - for example,
near a bathtub, washbowl, kitchen sink,
or laundry tub; in a wet basement; or
near a swimming pool; and the like.
ACCESSORIES - Do not place this
product on an unstable cart, stand,
tripod, bracket, or table. The product
may fall, causing serious injury to a
child or adult, and serious damage to the
product. Us e only with a cart, stand,
tripod, bracket, or table recommended
by the manufacturer, or sold with the
product. Any mounting of the product
should follow the manufacturer's
instructions , and should use a mounting
accessory recommended by the
manufacturer.
CART - A product and cart combination
should be moved with care.
Quick stops, excessive force,
and uneven surfaces may
cause the product and cart
combination to overturn.
VENTILATION - Slots and
openings in the cabinet are provided for
ventilation, to ensure reliable operation
of the product and to protect it from
overheating, these openings must not be
blocked or covered. The openings
should never be blocked by placing the
product on a bed, sofa, rug, or other
similar surface. This product should not
be placed in a built-in installation such
as a bookcase or rack unless proper
ventilation is provided or the
manufacturer's instructions have been
adhered to.
POWER SOURCES - This product should
be operated only from the type of power
source indicated on the marking label. If
you are not sure of the type of power
supply to your home, consult your
product dealer or local power company.
LOCATION - The appliance should be
installed in a stable location.
NONUSE PERIODS - The power cord of
the appliance should be unplugged from
the outlet when left unused for a long
period of time.
GROUNDING OR POLARISATION
- If this product is equipped with a
polarised alternating current line plug
(a plug having one blade wider than
the other), it will fit into the outlet only
one way. This is a safety feature. If you
are unable to insert the plug fully into
the outlet, try revers ing the plug. If the
plug should still fail to fit, contact your
electrician to replace your obsolete
outlet. Do not defeat the safety purpose
of the polarised plug.
- If this product is equipped with a three-
wire grounding type plug, a plug
having a third (grounding) pin, it will
only fit into a grounding type power
outlet. This is a safety feature. If you
are unable to insert the plug into the
outlet, contact your electrician to
replace your obsolete outlet. Do not
defeat the safety purpose of the
grounding type plug.
POWER -CORD PROTECTION - Power-
supply cords should be routed so that
they are not likely to be walked on or
pinched by items placed upon or against
them, paying particular attention to
cords at plugs, convenience receptacles,
and the point where they exit from the
product.
OUTDOOR ANTENNA GROUNDING -
If an outside antenna or cable system is
connected to the product, be sure the
antenna or cable system is grounded so
as to provide some protection against
voltage surges and built-up static
charges. Article 810 of the National
Electrical Code, ANSI/NFPA 70,
provides information with regard to
proper grounding of the mast and
supporting structure, grounding of the
lead-in wire to an antenna discharge
unit, size of grounding conductors,
location of antenna-discharge unit,
connection to grounding electrodes, and
requirements for the grounding
electrode.
LIGHTNING - For added protection for
this product during a lightning storm, or
when it is left unattended and unused for
long periods of time, unplug it from the
wall outlet and disconnect the antenna
or cable system. This will prevent
damage to the product due to lightning
and power-lines urges.
POWER LINES - An outside antenna
system should not be located in the
vicinity of overhead power lines or other
electric light or power circuits, or where
it can fall into such power lines or
circuits. When installing an outside
antenna system, extreme care should be
taken to keep from touching such power
lines or circuits as contact with them
might be fatal.
OVER LOADING - Do not overload wall
outlets, extension cords, or integral
convenience receptacles as this can
result in risk of fire or electric shock.
OBJECT AND LIQUID ENTRY - Never
push objects of any kind into this
product through openings as they may
touch dangerous voltage points or short-
out parts that could result in a fire or
electric shock. Never spill liquid of any
kind on the product.
SERVICING - Do not attempt to service
this product yourself as opening or
removing covers may expose you to
dangerous voltage or other hazards .
Refer all servicing to qualified service
personnel.
DAMAGE REQUIRING SERVICE -
Unplug this product from the wall outlet
and refer servicing to qualified service
personnel under the following
conditions :
- When the power-supply cord or plug is
damaged.
- If liquid has been spilled, or objects
have fallen into the product.
- If the product has been exposed to rain
or water.
- If the product does not operate
normally by following the operating
instructions. Adjust only those controls
that are covered by the operating
instructions as an improper adjustment
of other controls may result in damage
and will often require extensive work
by a qualified technician to restore the
product to its normal operation.
- If the product has been dropped or
damaged in any way.
- When the product exhibits a distinct
change in performance - this indicates
a need for service.
REPLACEMENT PARTS - When
replacement parts are required, be sure
the service technician has used
replacement parts specified by the
manufacturer or have the same
characteristics as the original part.
Unauthorised substitutions may result in
fire, electric shock, or other hazards .
SAFETY CHECK - Upon completion of
any service or repairs to this product, ask
the service technician to perform safety
checks to determine that the product is
in proper operating condition.
WALL OR CEILING MOUNTING - The
product should not be mounted to a wall
or ceiling.
HEAT - The product should be situated
away from heat sources such as
radiators, heat registers, stoves, or other
products (including amplifiers ) that
produce heat.
Warning
Watch out for using your Mobile DVD Player while
driving (Watching TV while driving is prohibited)

4
Table of contents
Before You Start
Cautions on handling discs ________ 5
Compatible Discs ________________ 6
What's in the box ________________ 8
Preparing the Remote Control ______ 8
Using the remote control __________ 9
How to install __________________ 10
Wiring diagram ________________ 11
7" TFT LCD Monitor _____________ 12
Control & Display
Front Panel Control ______________ 13
Display ________________________ 14
Rear Panel _____________________ 15
Remote Control _________________ 16
Getting Started
Power Connections _____________ 18
Connecting to a TV ______________ 19
Connecting to a Car Audio System _ 20
Connecting to a Dolby Digital System21
Basic Operation
Playing DVD's __________________ 22
Playing MP3 discs _______________ 24
Playing Kodak picture CD and
JPEG file play ___________________ 25
Fast Forward / Reverse ___________ 26
Skip Forward / Reverse ___________ 26
Slow Forward / Reverse __________ 27
Frame-by-Frame Playback ________ 27
Advanced Operation
OSD (On-screen Display) ________ 28
Selecting Audio Language ________ 28
Selecting Subtitles _______________ 29
Repeating a Title, Chapter (DVD),
Track (CD-DA) _________________ 30
Repeating a Specific Section ______ 30
Program Play ___________________ 31
Zooming a Picture ______________ 32
Switching the Camera Angle ______ 33
DIRECT Search (GO TO) _________ 34
Using the Setup Menu
Basic Operations ________________ 35
General Setup __________________ 36
Audio Setup ____________________ 38
Video Setup ____________________ 40
Preference Setup ________________ 41
Password Setup _________________ 43
Additional Information
Specifications __________________ 44
Troubleshooting ________________ 45
Warranty ______________________ 47

5
Before you start
Before You Start
Cautions on handling discs
Playing Discs
Only discs displaying the mark shown on page 9 can be played on the DVD player.
Note, however, that discs with special shapes (heart-shaped discs, hexagonal discs,
irregular discs, etc.) cannot be played on the DVD player. Do not attempt to play such
discs, as they may damage the player.
Holding Discs
Avoid touching the surface of discs when loading and unloading them.
Be careful not to get fingerprints on the signal surface (the side
which shines in rainbow colours.)
Cleaning Discs
- Fingerprints or dirt on the disc may lower sound and picture quality or cause breaks
in playback. Wipe off fingerprints or dirt.
- Use a commercially available disc cleaning set or a soft cloth to wipe off
fingerprints or dirt.
Wipe gently from the middle outwards Do not wipe with a circular motion
Note
Do not use record spray or antistatic. Also, do not use volatile chemicals such as benzene or
thinner.

6
Before You Start
Caution on handling discs
- Do not get fingerprints, grease or dirt on discs.
- Be especially careful not to scratch discs when removing them from their cases.
- Do not bend discs.
- Do not heat discs.
- Do not enlarge the center hole.
- Do not write on the labeled (printed) side with a ball-point pen or pencil.
- Water droplets may form on the surface if the disc is moved suddenly from a cold
place to a warm one. Do not use a hairdryer, etc. to dry the disc.
Caution on loading discs
- Only load one disc at a time. Loading one disc on top of another may result in
damage or scratch the discs.
- Do not load cracked or warped discs or discs that have been fixed with adhesive,
etc.
- Do not use discs on which the adhesive part of cellophane tape or glue used to
attach the label is exposed, or discs with traces of tape or labels that have been
peeled, or discs with traces of tape or label that have been peeled off. Such discs
may get stuck inside the player, resulting in damage.
Compatible Discs
The types of discs listed on the table below can be used in the DVD player. The marks
are indicated on the disc labels or jackets.
Digital Video Discs
- Single sided or double sided discs.
- Single layer or dual layer discs.
- Dolby Digital, DTS, MPEG or Linear PCM digital audio.
- MPEG-2 Digital Video Discs are generally divided into one or more
titles. Titles may be further subdivided into chapters.
DVD-R , DVD-RW , DVD+R , DVD+RW
- This unit can play DVD-R/ -RW/ +R/ +RW discs recorded in DVD video format.

7
Before you start
CD-Audio, CD-R, CD-RW
- 12cm or 8cm discs.
- Linear PCM digital audio
- CD-Audio, CD-R and CD-RW formatted CDs are divided into tracks. (This unit can
play CD-R and CD-RW discs recorded on CD Audio or with MP3 audio files)
MP3 compatibility information
- The CD-ROM must be ISO 9660 compatible.
- Mono or stereo MPEG-1 Audio Layer 3 format, 32 or 44.1 or 48kHz fixed bit-rate.
Incompatible files will not play.
- Compatible with variable bit-rate (VBR) files.
- This player is compatible with multi-session discs.
- Audio encoded at 128Kbps should sound close to regular audio CD quality.
Although this player will play 48K to 320k bit-rate.
- MP3 tracks, the sound quality becomes noticeably worse at lower bit rates.
- The maximun character of file name in mp3 or jpg should not exceed 46.
- Fold is included among the display file number.
Region code
Your DVD player is designed and manufactured to respond to the region management
information that is recorded on a DVD.
All DVD's discs carry a region mark on the case somewhere that indicates which region
of the world the disc is compatible with. Your DVD player also has a region mark,
which you can find on the rear panel. Discs from incompatible regions will not play in
this player. Discs marked ALL will play in any player.

8
Preparing the Remote Control
Insert the batteries into the remote control so you can use it to operate the DVD player.
1Open the battery cover.
2Insert batteries. (AAA size)
- Make sure to match the + and - on the batteries to the
marks inside the battery compartment.
3Close the cover.
What's in the box
Thank you for buying this product. Please confirm that the following accessories are in
the box when you open it.
Accessories
Warning : DC cable must be connected to cigar lighter socket.
Monitor
DVD player/Remote control/Batteries DIN cable User’s manual
Bag and s traps
Pouch and
headrest strap DC power cable

9
Before you start
Before You Start
Warning
- Improper use of batteries may cause battery leakage and corrosion.
- To operate the remote control correctly, follow the instructions.
- Don't insert the batteries into the remote control in the wrong direction.
- Don't charge, heat, open, or short-circuit the batteries.
- Don't throw the batteries into fire.
- Don't leave dead or exhausted batteries in the remote control.
- Don't use different types of batteries together, or mix old and new batteries.
- If you do not use the remote control for a long period of time, remove the batteries to avoid
possible damage from battery corrosion.
- If the remote control does not function correctly or if the operating range becomes reduced,
replace all batteries with new ones.
- If battery leakage occurs, wipe the battery liquid from the battery compartment, then insert
new batteries.
Note
- Direct the remote control at the IR receiver of the DVD player.
- DO NOT drop or give the remote control a shock.
- DO NOT leave the remote control near extremely heat or humidity.
- DO NOT spill water or put anything wet on the remote control.
- DO NOT open the remote control.
Using the remote control
The effective operating range of the remote control
is 5~7m, and 30 left and right degrees from the IR
receiver.

10
Before You Start
How to install
Installing the bag between the driver and passenger seats
1Take one of the supplied straps and connect the latch to
the upper front metal ring on the left side of bag. Hook the
"S" connector to the middle metal ring on the left side of
bag after looping the strap around the headrest of the
driver's seat. Repeat this process for the right side with the
passenger seat.
2Take another strap and connect the latch to lower metal ring on the left side of the
bag. Hook the "S" connector to the same ring after looping the strap around the
driver's seat rail. In some vehicles, the "S" connector may be hooked directly to the rail
as it may not be long enough to reach back the ring.
3Make the straps tightly so that the bag is installed securely.
4Unzip the bag and adjust the monitor for desired viewing angle with using Velcro
on the back.
5Take the DC power cable from the lower compartment of the bag. Plug one end
into the cigar lighter socket.
6Power on LCD monitor.
7Power on DVD player.

11
Before you start
Before You Start
Wiring diagram
DC IN
2.5A, 12V
DC OUT EXTERNAL
REMOTE
MAX.1.5A, 12V DIN S-VIDEO OUT VIDEO
DIGITAL
OUT
1
2
AUDIO
L
R
Install the detached monitor onto the seat back
1Take the pouch with monitor from the
bag.
2Loop the strap around the headrest and
adjust it tightly. Connect the pouch with
monitor. Please check if the DIN cable is connected well.
To cigar lighter
socket To DIN Input

12
Before You Start
7" TFT LCD Monitor
!SCREEN
@SPEAKER (LEFT)
#POWER ON LED
POWER ON : LED Green
Lighting
POWER OFF : LED Off
$SPEAKER (RIGHT)
Front view
!
$@ #
%EARPHONE 1
^VIDEO INPUT
&AUDIO INPUT
*DIN A/V INPUT
Side views
(Jacks)
%
&
*
^
(EARPHONE 2
)VOLUME
1COLOR
2BRIGHT
3POWER ON/OFF
4DC 12V INPUT
()
12
3
4
Side views
(Control knobs)
Caution on 7” LCD Monitor
1 Do not store in places where there temperatures changed sharply.
- Do not place in direct sunlight, near air conditioners and heaters
- Storage Temperature Range : -20°C ~ 60°C
- Operating Temperature Range : 5°C ~ 35°C
2 Clean the LCD screen, use a soft dry cloth to lightly wipe off the dust.
3 Do not drop LCD Monitor. Protect from any strong shocks.
4 Do not use adapters other than the standard (car cord) car adapter recommended by
the manufacturer.
5 Do not open or disassemble LCD Monitor.
6 Do not store in areas exposed to dust or other foreign material.
7 When you sound the the volume of speaker too low ,use car audio pack or FM
transmitter.

13
Control & Display
Control & Display
!POWER
Turns the power on/off.
@DISC IN / OUT HOLE
Discs are inserted and ejected here.
#EJECT
Press EJECT to eject the discs.
$PLAY/PAUSE
Starts disc play and pause.
%SKIP Forward/Reverse
Plays skip forward/reverse.
^DISPLAY WINDOW
Display information about the current
state of the player and the disc. (See
next page.)
&MUTE
Turns the audio outputs on/off.
*STEREO JACK FOR CAR PACK /
AV IN
Plug-in car pack jack for stereo audio
output.
Plug-in video and stereo audio input.
Front Panel Control
!
& ^*
@ #
% $

14
Control & Display
!DVD/SVCD/MP3/PBC
Illuminates the type of the disc
loaded.
@ROTATION
Rotates when the disc is spinning.
#PLAY/PAUSE
Indicates the current operation mode.
$DTS
Indicates that the audio type of the
disc under play is DTS.
%Repeat/ALL
Indicates the current repeat play
mode.
^TIME
Indicates time information and
displays information about operation
such as PLAY, STOP, LOAD, NO
DISC, etc.
&Dolby
Indicates that the audio format of the
disc under play is Dolby Digital.
Display
!
%
@ $
^ &
#

15
Control & Display
Control & Display
!DC INPUT
Use the cigarette cable adaptor to
connect to the cigarette light socket.
Use the AC adapter to connect the AC
Power. (optional)
@DC OUT
Use the DC cable to connect the only
12V battery.
#EXTERNAL REMOTE
CONNECTOR
Use the external remote control to
connect the IR module.
$DIGITAL AUDIO OUT (Coaxial)
Use the coaxial digital cable to
connect to a compatible Dolby Digital
receiver.
%VIDEO OUT
Use a video cable to connect one of
these jacks to the video input on your
TV.
^AUDIO OUT (L/R)
Connect to the audio input jacks of
your TV, audio/video receiver
&S-VIDEO OUT
Use the S-VIDEO cable to connect
this jack to the S-VIDEO.
*DIN A/V OUT
Use the DIN cable to connect this
jack to the DIN A/V of LCD Monitor.
Rear Panel
DC IN
2.5A, 12V
DC OUT EXTERNAL
REMOTE
MAX.1.5A, 12V DIN S-VIDEO OUT VIDEO
DIGITAL
OUT
1
2
AUDIO
L
R
!
&*
@ # $ % ^

16
Control & Display
Remote Control
OPEN / CLOSE
Ejects the disc
SETUP
Use to set various functions according to
individual preference
POWER
Turns on or off the DVD player.
NUMBER
Press the number button. Use the +10
button to input numbers of 10 or over.
TITLE
Use the TITLE button to display the title
screen included on DVD discs.
MENU
Use the MENU button to display the menu
screen included on a DVD discs.
RETURN
Use the RETURN button to return to the
previous menu screen.
MUTE
Turns on/off audio outputs.
ARROW BUTTONS
Use to move to the desired menu.
CL(CLEAR)
Press this to clear numbers that you have
input.
ENTER
Selects menu items and begins disc play.
STOP
Stop video playback in DVD and Video
CD mode.
PLAY/PAUSE
Play or pause video and audio media.

17
Control & Display
Control & Display
STEP
Play one frame at a time during
pause.
SKIP
Select previous or next track, title,
chapter or index, or select the
beginning of current track, title,
chapter or index.
SEARCH
Press for fast reverse scanning
during playback.
Press for fast forward scanning
during playback.
SLOW MOTION
Press for slow reverse scanning
during pause.
Press for slow forward scanning
during pause.
GO TO
Used to go to the chapter, track or
song on the disc you want.
SUB-T
Changes the subtitle language to
another available language or sets
OFF (if the disc supports multiple
subtitle languages).
AUDIO
Changes the audio language to
another available language (if the
disc supports multiple audio
languages).
ANGLE
View with a different frame angle.
(This button is available only on
multiple angle DVDs.)
DISPLAY
Shows the information about time
and play state.
A-B
Repeating a specific section.
PROGRAM
Programs the desired titles and
tracks of DVD and CD-DA.
ZOOM
Press this to enlarge the image.
TV MODE
Changes the NTSC/PAL/MULTI
mode.
PLAY MODE
Repeats part or all of a chapter,
title, track, or an entire disc
PBC (Option key)
Turn on and off the PBC function in
video CD mode
3D
Virtual 3D Sound Control
AUX (Option key)
Changes the DVD mode and
external A/V input mode
AUDIO ONLY
Turns off the screen for audio only
mode (For the protection of LCD
Monitor in Audio CD or MP3)
DIMMER
Set the display brightness (HALF,
FULL, OFF).
VOL+/VOL -
Increases and decreases the
volume.

18
Getting Started
Power Connections
1When using the Cigarette cable adaptor supplied.
- Make sure that input voltage is only 12V
- Connect to DC INPUT.
2When connecting the DC power cable.
- DC cable - This installation should be made by a qualified service person and
should confirm to all local codes.
- Connect the terminal of red cable to DC only 12V, and the terminal of black cable
to ground.
3When using the DVD player at home
- Connect to DC INPUT using an AC/DC adapter. *(optional)
Note
- When you connect the DVD player to your TV, be sure to turn off the power and unplug
both units from the wall outlet before making any connections.
- Connect the DVD player to your TV directly. If you connect the DVD player to a VCR, the
playback picture will be distorted because DVD's video discs are copy protected.
- Fuse Replacement Marking - Replace only with same type (3 A, 250 V) and ratings of fuse for
continued protection against fire hazard.
DC IN
2.5A, 12V
DC OUT EXTERNAL
REMOTE
MAX.1.5A, 12V DIN S-VIDEO OUT VIDEO
DIGITAL
OUT
1
2
AUDIO
L
R

19
Getting Started
Getting Started
Connecting to a TV
Connect the DVD player to your TV
1Connect the AUDIO CABLES between the AUDIO OUT L and R jacks on the back
of your DVD player and the corresponding AUDIO INPUT jacks on your TV.
2Connect the VIDEO CABLE between the VIDEO OUT jack on the back of your
DVD player and the corresponding VIDEO INPUT jack on your TV. (have a S-
VIDEO jack on your TV, connect to the S-VIDEO jack on your player.
DC IN
2.5A, 12V
DC OUT EXTERNAL
REMOTE
MAX.1.5A, 12V DIN S-VIDEO OUT VIDEO
DIGITAL
OUT
1
2
AUDIO
L
R
L (White)
Audio Output
Audio Input
Video Input
R (Red)
R
L
Video Output (Yellow)
S-Video Output
S-Video Input
Warning
Do not set the Digital Audio Output of this DVD player to "SPDIF/PCM" unless you are
connecting the DIGITAL AUDIO jack of this DVD player to an AV decoder that has
Dolby Digital decoding function. High volume sound may damage your hearing as well
as speakers.
