Daewoo DVG-9500N User manual

INSTRUCTION MANUAL
DG-K514
INSTRUCTION MANUAL
DVG-9500N
DVD PLAYER
DVD PLAYER
Progressive Scan
DVG-9500N 2005.8.10 6:4 PM ˘`a

1
IMPORTANT SAFETY PRECAUTIONS .... 2
FEATURES ............................................. 5
ABOUT DISC ......................................... 6
BEFORE OPERATION............................. 8
PREPARATIONS BEFORE OPERATION. 10
Front Panel..................................................... 10
Rear Panel...................................................... 11
Display (VFD).................................................. 12
Names and Layout of Remote Controls ......... 13
CONNECTIONS ................................... 14
BASIC OPERATIONS............................ 15
Play Discs ....................................................... 15
System Setting................................................ 16
V-Mode .......................................................... 16
Display............................................................ 16
Fast Play......................................................... 17
Slow Play........................................................ 17
Pause/ Step..................................................... 17
Select Audio Language................................... 18
Select Channels.............................................. 18
PLAYING A DESIRED SCENE............... 19
To skip scenes in a disc................................... 19
Directly moving to a desired title (DVD/VCD) . 19
Playing a disc containing MP3 files................ 20
Repeat Play .................................................... 20
Repeating a defined period from A to B (DVD) .. 21
Select a Subtitle Language............................. 21
Searching.........................................................22
PLAY DISCS IN VARIOUS WAYS.......... 23
Select Angle.................................................... 23
Zoom Play....................................................... 23
Book Mark...................................................... 23
Program Play (DVD)........................................ 24
Program Play (VCD)........................................ 25
Play MP3, CD, JPEG or PICTURE CD............... 26
FUNCTION SETTING ........................... 28
Menu Setting.................................................. 28
Language........................................................ 30
Video.............................................................. 31
Audio.............................................................. 32
Preference ...................................................... 33
OTHERS............................................... 35
Troubleshooting ............................................. 35
Technical Specifications.................................. 36
TABLE OF CONTENTS
DVG-9500N 2005.8.10 6:4 PM ˘`1

2
IMPORTANT SAFETY PRECAUTIONS
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosurethatmay beof sufficientmagnitudeto
constitute a risk of electric shock.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and servicing
instructions in the literature accompanying the
appliance.
WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE.
CAUTION : TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
IMPORTANT FOR LASER PRODUCTS
• LASER : This Digital Video Disc Player employs a Laser System. To ensure proper use of this
product please read this owner’s manual carefully and retain for future reference. Should
the unit require maintenance, contact an authorized service location - see service
procedure.
Use of control adjustments or the performance of procedures other than those specified
may result in hazardous radiation exposure.
To prevent direct exposure to the laser beam, do not try to open
the enclosure. Visible laser radiation when open and interlocks
defeated.
DO NOT STARE INTO THE BEAM.
• DANGER : Visible laser radiation when open and interlock failed or
defeated. Avoid direct exposure to beam.
• CAUTION : Do not open the top cover. There are no user serviceable parts inside the Unit; leave all
servicing to qualified service personnel.
CLASS 1
LASER PRODUCT
CAUTION: Any changes or modification in construction of this device which are not
expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
ATTENTION: KEEPING THE STATUS OF STOP MORE THAN 5 MINUTES ENTERS SCREEN SAVE MODE. WHEN
THE SCREEN SAVE MODE IS KEPT MORE THAN AN HOUR, THE SET ENTERS STAND-BY MODE.
CAUTION: Apparatus shall not be exposed to dripping or splashing and no objects filled
with liquids, such as vases, shall be placed on the apparatus.
DVG-9500N 2005.8.10 6:4 PM ˘`2

3
IMPORTANT SAFETY PRECAUTIONS
This set has been designed and manufactured to assure
personal safety. Improper use can result in electric shock or
fire hazard. The safeguards incorporated in this unit will
protect you if you observe the following procedures for
installation, use and servicing. This unit is fully transistorized
and does not contain any parts that can be repaired by the
user.
1 READ INSTRUCTIONS
All the safety and operating instructions should be read
before the unit is operated.
2 RETAIN INSTRUCTIONS
Thesafety and operating instructions should beretained
for future reference.
3 HEED WARNINGS
All warnings on the unit and in the operating
instructions should be adhered to.
4 FOLLOW INSTRUCTIONS
All operating and use instructions should be followed.
5 CLEANING
Unplugthis unitfrom thewall outletbeforecleaning.Do
not use liquid cleaners or aerosol cleaners. Use a damp
cloth for cleaning.
6 ATTACHMENTS/ACCESSORIES
Do not use attachments unless recommended by the
unit’s manufacturer as they may cause hazards.
Caution : Apparatus shall not be exposed to dripping
or splashing and no objects filled with liquids, such as
vases, shall be placed on the appratus.
7 WATER AND MOISTURE
Donotusethisunitnearwater-forexample, nearabath
tub, wash bowl, kitchen sink or laundry tub, in a wet
basement, or near a swimming pool.
8 PLACEMENT
Do not place this unit on an unstable cart, stand,
tripod, bracket, or table. The unit may fall, causing
serious injury to a child or adult as well as serious
damage to the unit. Use this
unit only with a cart, stand ,
tripod, bracket, or table
recommended by the
manufacturer.
8A A unit and cart combination
should be moved with care. Quick stops, excessive
force,anduneven surfaces maycausethe videoproduct
and cart combination to overturn.
9 VENTILATION
Slots and openings in the case are provided for
ventilationtoensurereliableoperationofthe unitandto
protectit from overheating. These openingsmust not be
blockedorcovered.Theseopeningsmustnotbeblocked
by placing the unit on a bed, sofa, rug, or other similar
surface. This unit should never be placed near or over a
radiator or heat radiator. This unit should not be placed
in a built-in installation such as a bookcase or rack
unless proper ventilation is provided or the
manufacturer’s instructions have been adhered to.
10 POWER SOURCES
Thisunitshouldbeoperatedonlyfromthetypeofpower
sourceindicatedonthemarkinglabel.Ifyouarenotsure
of the type of power supply to your home, consult
your video dealer or local power company. For units
intended to operate from battery power, or other
sources, refer to the operating instructions.
11 GROUNDING OR POLARIZATION
This unit is equipped with a polarized alternating -
current line plug (a plug having one blade wider than
the other). This plug will fit into the power outlet only
one way.
This is a safety feature. If you are unable to insert the
plug fully into the outlet, try reversing the plug. If the
plug still fails to fit, contact your electrician to replace
your obsolete outlet.To prevent electric shock, do not
use this polarized plug with an extension cord,
receptacle,orother outlet unless the blades can be fully
inserted without blade exposure. If you need an
extension cord, use a polarized cord.
12 POWER-CORD PROTECTION
Power-supply cords should be routed so that they are
not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to
cords at plugs and the point where they exit from the
unit.
13 LIGHTNING
For added protection for this unit during a lightning
storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and
disconnect the antenna or cable system.
PORTABLE CART WARNING
(symbol provided by
RETAC)
DVG-9500N 2005.8.10 6:4 PM ˘`3

4
Thiswillpreventdamagetotheunitduetolightningand
power line surges.
14 DISC TRAY
Keep your fingers well clear of the disc as it is closing. It
may cause serious personal injury.
15 OVERLOADING
Do not overload wall outlets or extension cords as this
can result in a risk of fire or electric shock.
16 OBJECT AND LIQUID ENTRY
Never press objects of any kind into this unit through
openingsastheymaytouchdangerousvoltage pointsor
“short-out” parts that could result in a fire or electric
shock. Never spill liquid of any kind on the unit.
17 BURDEN
Do not place a heavy object on or step on the product.
The object may fall, causing serious personal injury and
serious damage to the product.
18 DISC
Do not use a cracked, deformed or repaired disc. These
discs are easily broken and may cause serious personal
injury and product malfunction.
19 SERVICING
Do not attempt to service this unit yourself as opening
or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified
service personnel.
20 DAMAGE REQUIRING SERVICE
Unplug this unit from the wall outlet and refer
servicing to qualified service personnel under the
following conditions.
A. When the power-supply cord or plug is damaged.
B. If liquid has been spilled, or objects have fallen into
the unit.
C. If the unit has been exposed to rain or water.
D. If theunit doesnot operate normallyby followingthe
operating instructions. Adjust only those controls
that are covered by the operating instructions.
Improper adjustment of other controls may result in
damage and will often require extensive work by a
qualified technician to restore the unit to its normal
operation.
E. If the product has been dropped or the cabinet has
been damaged.
F. When the unit exhibits a distinct change in
performance-this indicates a need for service.
21 REPLACEMENT PARTS
When replacement parts are required, have the service
technician verify that the replacements he uses have the
same safety characteristics as the original parts. Use of
replacements specified by the unit manufacturer can
prevent fire, electric shock, or other hazards.
22 SAFETY CHECK
Upon completion of any service or repairs to this unit,
ask the service technician to perform safety checks
recommended by the manufacturer to determine that
the unit is in safe operating condition.
23 WALL OR CEILING MOUNTING
The product should be mounted to a wall or ceiling only
as recommended by the manufacturer.
24 HEAT
The product should be situated away from heat sources
such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.
IMPORTANT SAFETY PRECAUTIONS
FCC NOTICE :
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rule. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio
or television reception; which can be determined by
turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the
following measures:
• Reorientate or relocate the receiving antenna.
• Increasethe separationbetweentheequipment
and receiver.
• Connect the equipment to an outlet on a circuit
different from that to which the receiver is
connected.
• Consult the dealer or an experience radio/TV
technical for help.
DVG-9500N 2005.8.10 6:4 PM ˘`4
