Daewoo DV-3500H User manual

Progressive Scan
DVD PLAYER
INSTRUCTION MANUAL
DV-3500H
ENGLISH
EasternDV- 3500H Eng 2008.9.20 6:37 PM ˘`a

1
IMPORTANT SAFETY PRECAUTIONS .... 2
FEATURES ............................................. 5
ABOUT DISCS ....................................... 6
BEFORE OPERATION............................. 8
PREPARATIONS BEFORE OPERATION. 10
Front Panel ..................................................... 10
Rear Panel ...................................................... 11
LED Display..................................................... 12
Names and Layout of Remote Controls ......... 13
CONNECTIONS ................................... 14
BASIC OPERATIONS............................ 16
Play Discs ....................................................... 16
System Setting................................................ 17
V-Mode .......................................................... 17
Display............................................................ 18
Fast Play ......................................................... 19
Slow Play........................................................ 19
Pause/ Step..................................................... 19
USB function supported.................................. 20
Select Audio Language................................... 20
Select Channels .............................................. 21
MICROPHONE CONTROL.................... 22
Microphone Set up ......................................... 22
PLAYING A DESIRED SCENE............... 23
To skip scenes in a disc................................... 23
Directly moving to a desired title (DVD/VCD) . 23
Playing a disc containing MP3 (or CD) files .... 24
Playing DivX disc on CD-R (W) ....................... 25
Repeat Play .................................................... 26
Repeating a defined period from A to B ........ 26
Select a Subtitle Language ............................. 27
Searching.........................................................27
PLAY DISCS IN VARIOUS WAYS.......... 29
Select Angle.................................................... 29
Zoom Play....................................................... 29
Book Mark...................................................... 30
Program Play (DVD)........................................ 31
Program Play (VCD).........................................32
Program Play (CD, MP3, JPEG, MPEG4) ......... 33
FUNCTION SETTING ........................... 34
Menu Setting...................................................34
Language........................................................ 36
Video .............................................................. 38
Audio ............................................................. 39
Parental...........................................................41
OTHERS............................................... 42
Troubleshooting ............................................. 42
Technical Specifications.................................. 43
TABLE OF CONTENTS
EasternDV- 3500H Eng 2008.9.20 6:37 PM ˘`1

2
IMPORTANT SAFETY PRECAUTIONS
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude
to constitute a risk of electric shock.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and servicing
instructions in the literature accompanying the
appliance.
WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE.
CAUTION : TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
IMPORTANT FOR LASER PRODUCTS
• LASER : This Digital Video Disc Player employs a Laser System. To ensure proper use of this
product please read this owner’s manual carefully and retain for future reference. Should
the unit require maintenance, contact an authorized service location - see service
procedure.
Use of control adjustments or the performance of procedures other than those specified
may result in hazardous radiation exposure.
To prevent direct exposure to the laser beam, do not try to open the enclosure. Visible
laser radiation when open and interlocks defeated.
DO NOT STARE INTO THE BEAM.
• DANGER : Visible laser radiation when open and interlock failed or
defeated. Avoid direct exposure to beam.
• CAUTION : Do not open the top cover. There are no user serviceable parts
inside the Unit; leave all servicing to qualified service personnel.
CLASS 1
LASER PRODUCT
CAUTION: Any changes or modification in construction of this device which are not
expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
ATTENTION: KEEPING THE STATUS OF STOP MORE THAN 5 MINUTES ENTERS SCREEN SAVE MODE. WHEN
THE SCREEN SAVE MODE IS KEPT MORE THAN AN HOUR, THE SET ENTERS STAND-BY MODE.
MACROVISION
This product incorporates copyright protection technology that is protected by U.S patents and
other intellectual property rights. Use of this copyright protection technology must be
authorized by Macrovision, and is intended for home and other limited viewing uses only unless
otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.
EasternDV- 3500H Eng 2008.9.20 6:37 PM ˘`2

3
IMPORTANT SAFETY PRECAUTIONS
This set has been designed and manufactured to assure
personal safety. Improper use can result in electric shock or
fire hazard. The safeguards incorporated in this unit will
protect you if you observe the following procedures for
installation, use and servicing. This unit is fully
transistorized and does not contain any parts that can be
repaired by the user.
1 READ INSTRUCTIONS
All the safety and operating instructions should be read
before the unit is operated.
2 RETAIN INSTRUCTIONS
The safety and operating instructions should be retained
for future reference.
3 HEED WARNINGS
All warnings on the unit and in the operating
instructions should be adhered to.
4 FOLLOW INSTRUCTIONS
All operating and use instructions should be followed.
5 CLEANING
Unplug this unit from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
6 ATTACHMENTS/ACCESSORIES
Do not use attachments unless recommended by the
unit’s manufacturer as they may cause hazards.
Caution : Apparatus shall not be exposed to dripping
or splashing and no objects filled with liquids, such as
vases, shall be placed on the apparatus.
Caution : Apparatus shall not be exposed to
dripping or splashing and no objects filled
with liquids, such as vases, shall be placed on
the apparatus.
7 WATER AND MOISTURE
Do not use this unit near water- for example, near a
bath tub, wash bowl, kitchen sink or laundry tub, in a
wet basement, or near a swimming pool.
8 PLACEMENT
Do not place this unit on an unstable cart, stand,
tripod, bracket, or table. The unit may fall, causing
serious injury to a child or adult as well as serious
damage to the unit. Use this unit only with a cart,
stand , tripod, bracket, or table recommended by the
manufacturer.
9 VENTILATION
Slots and openings in the case are provided for
ventilation to ensure reliable operation of the unit and
to protect it from overheating. These openings must not
be blocked or covered. These openings must not be
blocked by placing the unit on a bed, sofa, rug, or other
similar surface. This unit should never be placed near or
over a radiator or heat radiator. This unit should not be
placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the
manufacturer’s instructions have been adhered to.
10 POWER SOURCES
This unit should be operated only from the type of
power source indicated on the marking label. If you are
not sure of the type of power supply to your home,
consult your video dealer or local power company. For
units intended to operate from battery power, or other
sources, refer to the operating instructions.
11 GROUNDING OR POLARIZATION
This unit is equipped with a polarized alternating -
current line plug (a plug having one blade wider than
the other). This plug will fit into the power outlet only
one way.
This is a safety feature. If you are unable to insert the
plug fully into the outlet, try reversing the plug. If the
plug still fails to fit, contact your electrician to replace
your obsolete outlet.To prevent electric shock, do not
use this polarized plug with an extension cord,
receptacle, or other outlet unless the blades can be fully
inserted without blade exposure. If you need an
extension cord, use a polarized cord.
12 POWER-CORD PROTECTION
Power-supply cords should be routed so that they are
not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to
cords at plugs and the point where they exit from the
unit.
Mains plug is used as the disconnect
device, the disconnect device shall remain
readily operable.
13 LIGHTNING
For added protection for this unit during a lightning
storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and
disconnect the antenna or cable system. This will
EasternDV- 3500H Eng 2008.9.20 6:37 PM ˘`3

4
prevent damage to the unit due to lightning and power
line surges.
14 DISC TRAY
Keep your fingers well clear of the disc as it is closing. It
may cause serious personal injury.
15 OVERLOADING
Do not overload wall outlets or extension cords as this
can result in a risk of fire or electric shock.
16 OBJECT AND LIQUID ENTRY
Never press objects of any kind into this unit through
openings as they may touch dangerous voltage points
or “short-out” parts that could result in a fire or electric
shock. Never spill liquid of any kind on the unit.
17 BURDEN
Do not place a heavy object on or step on the product.
The object may fall, causing serious personal injury and
serious damage to the product.
18 DISC
Do not use a cracked, deformed or repaired disc. These
discs are easily broken and may cause serious personal
injury and product malfunction.
19 SERVICING
Do not attempt to service this unit yourself as opening
or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified
service personnel.
20 DAMAGE REQUIRING SERVICE
Unplug this unit from the wall outlet and refer
servicing to qualified service personnel under the
following conditions.
A. When the power-supply cord or plug is damaged.
B. If liquid has been spilled, or objects have fallen into
the unit.
C. If the unit has been exposed to rain or water.
D. If the unit does not operate normally by following the
operating instructions. Adjust only those controls
that are covered by the operating instructions.
Improper adjustment of other controls may result in
damage and will often require extensive work by a
qualified technician to restore the unit to its normal
operation.
E. If the product has been dropped or the cabinet has
been damaged.
F. When the unit exhibits a distinct change in
performance-this indicates a need for service.
21 REPLACEMENT PARTS
When replacement parts are required, have the service
technician verify that the replacements he uses have the
same safety characteristics as the original parts. Use of
replacements specified by the unit manufacturer can
prevent fire, electric shock, or other hazards.
22 SAFETY CHECK
Upon completion of any service or repairs to this unit,
ask the service technician to perform safety checks
recommended by the manufacturer to determine that
the unit is in safe operating condition.
23 WALL OR CEILING MOUNTING
The product should be mounted to a wall or ceiling only
as recommended by the manufacturer.
24 HEAT
The product should be situated away from heat sources
such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.
IMPORTANT SAFETY PRECAUTIONS
✔ RoHS (Directive 2002/95/EC) Compliant
This environment-friendly product
does not contain the EU RoHS
restricted substances (Pb, Hg, Cd,
Cr6+, PBB, and PBDE).
EasternDV- 3500H Eng 2008.9.20 6:37 PM ˘`4

5
FEATURES
HDMI
Audio/Video Digital output
support 1080I ( Interlace), 720P (Progressive) and 480P/576P Video out.
OUTSTANDING SOUND QUALITY
Dolby Digital system developed by Dolby Laboratories and DTS
developed by DTS Inc., features high quality surround sound which can be played
in DVD or CD disc at home, to reproduce high quality sound effects.
HIGH DEFINITION
The unit adopts MPEG2 coding format and brings the high horizontal resolution.
UNIQUE FUNCTIONS
Multi-angle and multi-language bring unique trick functions.
Parent lock makes it easy to control the content of discs.
SCREEN
Ordinary screen and wide screen (16:9) are available.
COMPATIBILITY
The unit can play DVD-video discs, and is compatible with CD, CD-G, CD-R, CD-RW,
PIC-CD, MP3, DVD-R, DVD-RW, DVD+RW.
ZOOM
It can enlarge pictures.
MULTI-FUNCTIONS
Fast forward, fast reverse, forward and reverse slow, frame play, repeat play and
program play.
TIME SEARCH
It can search a specific part on a disc, especially good for watching movies.
RESUME PLAY
It can memorize the position where the disc is stopped and resume playback.
VIDEO OUTPUT
Scart (RGB), Composite (Standard video), Component (Y,Pb, Pr), S-video, HDMI
AUDIO OUTPUT
HDMI/ Analog audio output, coaxial digital audio output, can be connected with
the appropriate amplifier to enjoy high-quality sound effects.
KARAOKE
Sing along with the music! Dual-Microphone input, KARAOKE channel selection.
USB
There is a USB port on the player. You can choose between USB and disc.
EasternDV- 3500H Eng 2008.9.20 6:37 PM ˘`5

6
ABOUT DISCS
PRINCIPLES FOR WRITING
PLAYABLE DISCS
This manual mainly introduces how to use buttons on the remote control.
You may operate the unit if the buttons on the unit have the same or similar names
as or to those on the remote control.
TITLE
The images or music of a DVD are divided into some units, among which title is the
biggest one.
When playing a DVD, the movie is the title.
When playing a CD, the combined tracks make up the title.
STRUCTURE OF DVD STRUCTURE OF CD
DISC
TITLE
CHAPTER
DISC
TRACK
DVD-video Region number 2 or Region number ALL
DVD-R/+R DVD video
DVD-RW/+RW DVD video
DVD-ROM DVD video
CD-G Playback audio/ graphic files
CD-DA Digital audio files
CD-R/ CD-RW Digital audio/ MP3/ JPEG format files
CD-DA/JPEG/MP3 Total disc capacity : over 4M, Each file : under 1M
CD-ROM Digital audio/ MP3/ JPEG format files
NONE PLAYABLE DISCS
DVD-video Different region number
DVD-ROM Files for PC application / Data files
CD-ROM Files for PC application / Data files
CD-MP3 Files under windows format
DVD-RAM All format
EasternDV- 3500H Eng 2008.9.20 6:37 PM ˘`6

7
ABOUT DISCS
CHAPTER
It is smaller than title among the units of a DVD. A title is made up of several
chapters , and each chapter has a number for search. But some discs may not
have numbered chapters.
TRACK
In a CD, each track has a number to enable search functions.
REGION MANAGEMENT INFORMATION
This unit is designed and manufactured to respond to the Region Management
information that is recorded on a DVD disc. The region number of this player is
“2”. If the region number described on the DVD discs does not correspond to the
Region number of this player, the player will not play this disc. This player will
play DVD discs made for “ALL” regions. Therefore, this player will play DVD discs
marked with labels containing the region number “2” or “ALL”.
(Region 2) (Region ALL)
2
SCENE
The menu pictures, motion and motionless pictures of a CD can be divided into some
parts, these parts are scenes. Each scene has a number for search.
✔DISPOSAL OF USED ELECTRICAL &ELECTRONIC EQUIPMENT
The meaning of the symbol on the product, its accessory or packaging
indicates that thisproduct shall not be treated as household waste. Please,
dispose of this equipment at your applicable collection point for the
recycling of electrical & electronic equipments waste. In the European
Union and Other European countries which there are separate collection
systems for used electrical and electronic product. By ensuring the correct
disposal of this product, you will help prevent potential hazards to the
environment and to human health, which could otherwise be caused by
unsuitable waste handling of this product. The recycling of materials will help conserve natural
resources. Please do not therefore dispose of your old electrical and electronic equipment with
your household waste. For more detailed information about recycling of this product, please
contact your local city office, your household waste disposal service or the shop where you
purchased the product.
EasternDV- 3500H Eng 2008.9.20 6:37 PM ˘`7

8
BEFORE OPERATION
SECURITY
• Before operation, check if the voltage of the unit is in line with the local voltage.
• Hold the plug to disconnect it from the mains outlet. Do not pull the power cord.
• When the plug of the unit is connected to the mains outlet, the unit will be still
connected to AC even if the power is turned off.
• Disconnect the plug as soon as liquid or objects enter the unit. The unit can not be
used until being checked by experts.
• Do not open the cabinet as laser rays employed by the unit may damage eyes. Any
servicing should be done by qualified service personnel.
PLACEMENT
• Put the unit where ventilation is good enough to prevent overheating.
• Never put the unit in direct sunlight or near heat sources.
• Put the unit horizontally, never put any heavy object on the unit.
• To protect the pickup, do not put the unit where there is dust. If there is dust on
the pickup, use a cleaning disc to clean it. Paying particular attention to the
operating instructions of the cleaning disc.
CONDENSATION
Moisture will appear on the pickup lens in the following cases:
• The unit is suddenly moved from a cold place to a warm place.
• The unit is put in a room with a heater, or in cold air from an air-conditioner.
• Using the unit in a humid place. In these cases, the unit can not work. Unload the
disc and leave the unit on for about one hour to evaporate the moisture.
CLEANING
• Use a soft cloth with a little neutral detergent to wipe the cabinet, panel and
controls.
Never use abrasive paper, polishing powder, solvent like alcohol or gasoline.
HANDLING DISC
CLEANING DISC
• To keep the disc clean, do not touch the playsides of the disc.
• Do not attach paper or tape to the disc.
• Keep the disc away from direct sunlight or heat sources.
• Store the disc in a disc case after playback.
• Before playback, wipe the disc outward from the centre with clean cloth.
• Do not use any type of solvent such as thinner, benzine, commercially available
cleaners or antistatic spray.
EasternDV- 3500H Eng 2008.9.20 6:37 PM ˘`8

9
BEFORE OPERATION
CHECK ACCESSORIES
USE REMOTE CONTROL
Check if you have all the accessories after the carton is opened.
1 Open the battery compartment.
2 Insert two AAA batteries, make sure to match "+" and "-" of the batteries to
the marks in the battery compartment.
3 Close the battery compartment.
4 Point the remote control at the remote sensor.
Remote control
Video/Audio cord Instruction manual
1. Batteries can last for about 6 months generally. Change the batteries if that does not
work.
2. If the remote control is not used for a long time, remove the batteries to prevent
battery leakage.
- UM-4 +
N
Note:
HDMI-cable
EasternDV- 3500H Eng 2008.9.20 6:37 PM ˘`9

10
PREPARATIONS BEFORE OPERATION
FRONT PANEL
!STANDBY/ON button
To switch the unit On or Off when connected to AC power outlet.
@Microphone Jack 1& 2
#Microphone Volume adjustment knob
$Microphone Echo adjustment knob
%PLAY button
To play the loaded disc. Press this button to go to the preferred item when the menu is
displayed on the TV screen.
^PREV button
To skip back from the current chapter or track.
&NEXT button
To skip forward to the next chapter or track.
*STOP
(L/R button
You may select the right channel or left channel or stereo from a multi-channel.
)N/P button
You may select according to the colour system of the TV to be connected.
(PAL -> AUTO -> NTSC)
1OPEN/CLOSE button
To open or close the disc tray.
2REMOTE SENSOR
Receives a light signal from the remote control.
3DISPLAY
Displays operation status.
4USB port
!@ # $ % ^ & * ( ) 1 2 3 4
EasternDV- 3500H Eng 2008.9.20 6:37 PM ˘`10

11
PREPARATIONS BEFORE OPERATION
REAR PANEL
!VIDEO OUT
Connects composite video signal to input AV or PHONO sockets of TV or monitor to
achieve high fidelity colour reproduction.
@COMPONENT (Y.Pb.Pr)
Connects to TV or monitor equipped with Component input . In order to achieve a
sharper and cleaner picture than when connected via VIDEO OUT (composite video).
#EURO AV JACK
If VIDEO OUT phono is not utilized, the SCART socket can be used to connect to a TV set,
monitor or VCR.
When you use the SCART connection together with the S-Video connection or the
Component (Y, Pb, Pr) connection, the picture of RGB (Scart) mode may dim.
$POWER SUPPLY SOCKET WIRE
Creates POWER between wall outlet and the unit.
%S-VIDEO OUTPUT
Connects to TV or monitor equipped with S-VIDEO input. In order to achieve a sharper
and cleaner picture than when connected via VIDEO OUT (composite video).
^HDMI
Audio/Video High definition multimedia digital output terminal.
&AUDIO OUT (L/R TRACK)
Two phono sockets for analogue 2 Channel audio in order to a TV or stereo amplifier.
*DIGITAL AUDIO COAXIAL OUT
Connects digital audio under play mode into an AV amplifier or a receiver equipped with
digital audio decoder for you to enjoy the theatre-quality sound in your home.
&*
% ^
$#! @
EasternDV- 3500H Eng 2008.9.20 6:37 PM ˘`11

12
PREPARATIONS BEFORE OPERATION
LED DISPLAY
!Recognized DISC TYPE indicator
: DVD
@Recognized DISC TYPE indicator
: VCD
#PLAY indicator
$PAUSE indicator
%DISC LOAD/PLAY indicator
This indicator is lit up after
recognizing the disc.
^DVD/CD/MP3 indicator
Indicates the hour.
&DVD/CD/MP3 indicator
Indicates the minutes.
*DVD/CD/MP3 indicator
Indicates the seconds.
(DVD/CD/MP3 indicator
Indicates the title, chapter or track
number.
)Recognized DISC TYPE indicator
: MP3
1DVD AUDIO STREAM indicator
: dts digital out
2DVD AUDIO STREAM indicator
Indicates the audio type of the
disc under playing is DOLBY
DIGITAL.
3Recognized DISC TYPE indicator
: MP4
4NUMBER/ CHARACTER indicator
Chapter, track number, and time are
displayed in loading DVD/CD disc,
while track number and time are
displayed in loading MP3.
: Tray is opened
: Tray is closed
: Disc is loaded
: There is no disc in tray
43
(2$
! #@ % ^ 1)& *
EasternDV- 3500H Eng 2008.9.20 6:37 PM ˘`12

13
PREPARATIONS BEFORE OPERATION
NAMES AND LAYOUT OF REMOTE CONTROLS
* After setting the mode by using SETUP menu (for example, PAL select in NTSC/PAL/AUTO
setup), the setting is kept though you switch the unit off and turn it on.
POWER BUTTON
DISPLAY BUTTON
ANGLE BUTTON
SETUP BUTTON
TITLE/PBC BUTTON
UP/DOWN/LEFT/
RIGHT DIRECTION
BUTTON
SEARCH BUTTON
MARK BUTTON
PAUSE BUTTON
STEP BUTTON
AUDIO BUTTON
REPEAT BUTTON
CHANNEL BUTTON
VOLUME “+/-” BUTTON
ONE CHAPTER/TRACK
BACKWARD BUTTON
FAST BACKWARD
SEARCH BUTTON
SUBTITLE BUTTON
A-B REPEAT BUTTON
OPEN/CLOSE BUTTON
NUMBER BUTTON
MENU BUTTON
RETURN BUTTON
STOP BUTTON
SYSTEM BUTTON
INTRO BUTTON
(This button has no function
for this DVD player)
ZOOM BUTTON
PROGRAM BUTTON
ONE CHAPTER/TRACK
FORWARD BUTTON
PLAY/ENTER BUTTON
MUTE BUTTON
3D SURROUND BUTTON
(This button has no function
for this DVD player)
FAST FORWARD
SEARCH BUTTON
SLOW BUTTON
Select one of USB/Disc
V-MODE BUTTON
EasternDV- 3500H Eng 2008.9.20 6:37 PM ˘`13

14
CONNECTIONS
CONNECTED TO A TV AND AN AUDIO AMPLIFIER
Turn off all equipment before operation.
The unit has many kinds of output modes like A/V output, S-VIDEO output and digital
signal output (COAXIAL). You may select as you need.
Connects either
! , @ , # , $ +, % +, $ +, % +, $ + or % +.
Manufactured under license from Dolby Laboratories. ‘Dolby‘ and the double-D
symbol are trademarks of Dolby Laboratories.
Manufactured under license under U.S. Patent #: 5,451,942 and other U.S. and
worldwide patents issued and pending. DTS and DTS Digital Out are registered
trademarks and the DTS logos and Symbol are trademarks of DTS, Inc. © 1996-
2007 DTS, Inc. All Rights Reserved.
#!
TV
Amplifier
$
2 Speakers
@
%
EasternDV- 3500H Eng 2008.9.20 6:37 PM ˘`14

CONNECTIONS
15
• When you connect your player to the TV through the HDMI cable, you have to change
the video output mode to HD mode by pressing [V-MODE] button on the remote
control.
• Except HD Mode, the other modes (for example, Interlace, Progressive, S-video, RGB
mode) may happen abnormal picture and sound.
• Read Time of HDMI signal may take 10 seconds. (It depends on TV)
Wait a little while, please!
HDMI (High Definition Multimedia Interface) supports both video and audio on a
single digital connection for use with DVD Players, Set-Top Boxes, and other AV
devices. HDMI was developed to provide the technologies of HDCP (High
Definition Contents Protection). HDCP is used to protect digital content
transmitted and received.
HDMI has the capability to support standard, enhanced, or high-definition video
plus standard to multi-channel surround-sound audio, HDMI features include
uncompressed digital video, a bandwidth of up to 5 gigabytes per second, one
connector (instead of several cables and connectors), and communication
between the AV source and AV devices such as DTVs.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks
or registered trademarks of HDMI licensing LLC.
About HDMI
TV
HDMI cable
(supplied)
EasternDV- 3500H Eng 2008.9.20 6:37 PM ˘`15

16
BASIC OPERATIONS
PLAY DISCS
Press "POWER" button on the TV and audio
system, Press "TV/VIDEO" button on the TV, select
VIDEO mode (TV).
Select S-Video mode if using an S-VIDEO
connection.
1
Select the correct audio input on the amplifier.
• Each amplifier is different from another, please
refer to the manual for the amplifier. (e.g.,
connect the audio output of the DVD player to
the DVD audio input of an amplifier.)
2
Press "STAND BY/ON" button on the front panel or " " button on the
remote control to turn the unit on.
3
Press "OPEN/CLOSE " button to open the disc tray and insert the disc
with its label upward. Press "OPEN/CLOSE " button again to close
the disc tray. The unit begins to read the disc. The TV screen shows the
DVD menu and title menu.
• When playing a DVD, DVD menus and titles are displayed on TV
screen.
• In the case of CD, the disc plays in order of its track number.
4
Stop playback.
Press .
5
Press to remove the disc.
6
TV/VIDEO
DVD/LD
The Step2 can be
cancelled if you
do not
connect it to the
amplifier.
N
Note:
EasternDV- 3500H Eng 2008.9.20 6:37 PM ˘`16

17
BASIC OPERATIONS
SYSTEM SETTING
• When you press the [SYSTEM] button, the TV screen shows
the information as : “If you want to change, press
[SYSTEM] again.” Press the [SYSTEM] button again, the
video out system changes as follows.
According to the system of the TV to be connected, set the system of the unit to
make it match the TV.
In STOP mode, press SYSTEM button on the remote control, then choose TV TYPE.
SYSTEM
PAL
Auto NTSC
V-MODE (WHEN SELECTING S-VIDEO/INTERLACE/RGB/PROGRESSIVE/HD mode)
V-MODE
There are variety of ways to connect the DVD player to your TV.
(refer to 14page)
Choose one of the following video output modes by pressing
[V-MODE] button, depending on the connection from DVD
player to your TV.
• Scart connection - RGB mode
• Component connection - Progressive mode or Interlace mode
Check whether your TV has the function of progressive before selecting
progressive mode. If your TV does not accept the progressive, you can select
the Interlace mode.
• S-Video connection - S-video mode
• Composite connection - Interlace mode
• HDMI connection - HD mode (For more details, refer to 15page)
When video output mode is not proper for the connection, no picture or no
sound may occur.
N
Note:
When you use the SCART connection together with the S-Video connection or
the Component (Y, Pb, Pr) connection, the picture of RGB (Scart) mode may
dim.
EasternDV- 3500H Eng 2008.9.20 6:37 PM ˘`17

18
BASIC OPERATIONS
DISPLAY
Press the “DISPLAY” button when playing a disc, the TV screen shows the
information as :
DISPLAY
DVD
VCD 2.0 00:00:41 00:50:28
Track 1/1
VCD
DVD Video 00:00:35 01:55:28
Title 1/5 Chapter 1/16
Audio 1/2 6Ch E g
Subtitle Off
A gle 1/1
Remain TimeRunning Time
Remain TimeRunning Time
EasternDV- 3500H Eng 2008.9.20 6:37 PM ˘`18

19
BASIC OPERATIONS
FAST PLAY
When playing disc, you may play it forward fast or reverse it fast to find what you need.
Press to play forward fast. Each
time you press the button, the speed of
picture changes like the right sides.
1
Press to reverse the disc fast.
Each time you press the button, the
speed of picture changes like the
right sides.
2
Press PLAY to play
normally when
playing fast.
The marked FAST
PLAY speed on
owner’s manual
and real fast play
speed can be
different
depending on
which disc you
play.
Press PLAY to
play normally .
SLOW PLAY
Enjoy slow motions by the following steps.
Press "SLOW" button to play slowly.
SLOW
N
Note:
N
Note:
N
Note:
Press PLAY to
play normally .
PAUSE/ STEP
Press PAUSE on the remote control to make the playback pause.
Pressing STEP again moves the picture forward frame by frame.
N
Note:
X2
X4
X8
X16
Play
1
2
3
4
5
X2
X4
X8
X16
Play
1
2
3
4
5
EasternDV- 3500H Eng 2008.9.20 6:37 PM ˘`19
