1
Bluetooth Headphones
AVS1326, 1392, 1393 & 1394
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Bluetooth Headphones
AVS1326, 1392, 1393 & 1394
User Manual

2
Bluetooth Headphones
AVS1326, 1392, 1393 & 1394
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed. These instructions should be saved for future
reference:
•Read and familiarise yourself with all operating instructions before
using your Bluetooth Headphones.
•Before using your Bluetooth Headphones, visually check that the unit is
intact and has not suffered any transit damage.
•Only charge the headphones from a suitable USB outlet, any other
power source may cause permanent damage to the headphones.
•The headphones must be fully charged via the USB port before use.
•Do not operate this speaker after a malfunction or after being dropped
or damaged in any way.
•Never allow children to play with the headphones. Small parts may be a
choking hazard.
•Do not allow the USB charging cable to hang over sharp edges or come
in contact with hot surfaces.
•These headphones are intended for household use only and should not
be used for industrial purposes.
•Do not use these headphones for anything other than its intended use.
•Do not immerse the headphones in water or any other liquids.
•Do not expose the headphones to moisture, rain or humidity, as it is
not waterproof.
•Before cleaning, ensure the earphones are not connected to the USB
supply.
•Never clean the headphones with solvents or harsh or abrasive
cleaners.
•Do not attempt to dismantle the earphones, it does not contain any
user serviceable parts.
•Whilst not in use, store the earphones in a cool dry place free from
extreme temperatures, humidity or dust.

3
Bluetooth Headphones
AVS1326, 1392, 1393 & 1394
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts
Charging Your Bluetooth Headphones
Before first using your headphones ensure they are fully charged as follows:
1. Insert the Micro USB plug of the USB to Micro USB Charging Cable (11) into the Micro USB
Charging Port (9) in the Headphones.
2. Insert the large USB plug into a suitable USB charger rated to at least 1 Amp. (most
chargers are rated 1 Amp or above).
3. Whilst the Headphones are on charge, the LED (6) in the headphones will glow red, once
the internal battery is fully charged the LED (6) will go out.
4. NB Charging time will take approximately 2-3 hours – remove the charging cable once the
headphones are fully charged.
Using Your Bluetooth Headphones
Powering Your Headphones On and Off
1. Power On: Press the Power/Play/Pause button (5) for 3 seconds and the LED (6) will flash
with Red/Blue colour sequence showing the headphones are ready to pair.
2. Power Off: Press the Power/Play/Pause button (5) for 3 seconds and the headphones will
power down.
9
8
7
6
5
4
3
2
10
1
1. Micro SD Player
2. Volume Up/Next Track Button
3. Volume Down/Previous Track Button
4. Mode/Phone Button
5. Power/Play/Pause Button
6. LED
7. 3.5mm Input Jack
8. Microphone
9. Micro USB Charging Port
10. 3.5mm Jack to Jack Audio Cable
11. USB to Micro USB Charging Cable
11

4
Bluetooth Headphones
AVS1326, 1392, 1393 & 1394
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Bluetooth Pairing Your Headphones
1. Power up the headphones as described above and the LED (6) will flash Red/Blue.
2. If wearing headphones during power up, a chime will be heard to indicate they are
powering up.
3. Enable the Bluetooth mode on your Phone, Tablet or other Bluetooth compatible device
and set it to search.
4. Select ‘AVS1394’ from the search results and the headphones will now pair with your
device.
5. Once the two are paired successfully you will hear another chiming tone to confirm pairing
and the LED (6) will now illuminate a steady blue colour.
NB The Bluetooth Headphones will reconnect automatically after power up if your device has
previously paired with the headphones and the pairing process will not be needed.
Playing Music after Pairing
1. Press the Power/Play/Pause button (5) to start playing music, press the button again to
pause playing music.
2. Press and hold down the Volume Up/Next Track button (2) to increase the volume level.*
3. Press and hold down the Volume Down/Previous Track (3) button to decrease the volume
level.
4. Briefly Press the Volume Up/Next Track button (2) to skip to the next music track.
5. Briefly Press the Volume Down/Previous Track button (3) to skip back to the previous
music track.
Playing Music from a Micro SD/TF Card
1. Insert a Micro SD or TF card (pre-loaded with audio tracks –Mp3, WAV, files etc.) into the
MICRO SD Player (1). NB the Micro SD/TF card player supports cards up to 32GB capacity
max.
2. The tracks on the card will begin to play automatically.
3. Press the Power/Play/Pause (5) button to start playing music, press the button again to
pause playing music.
4. Press and hold down the Volume Up/Next Track (2) button to increase the volume level.*
5. Press and hold down the Volume Down/Previous Track (3) button to decrease the volume
level.
6. Briefly Press the Volume Up/Next Track (2) button to skip to the next music track.
7. Briefly Press the Volume Down/Previous Track button (3) to skip back to the previous
music track.
NB Pressing the Mode/Phone button (4) whilst listening to the Micro SD card will change
the listening mode to Bluetooth. Press the Mode/Phone button again will return to the
Micro SD card.
Handling Telephone Calls
Answering a Call
1. A call coming in will mute (cut) the music you are listening to.
2. Briefly press the Mode/Phone button (4) to answer the call.
3. Press and hold down the Volume Up/Next Track (2) button to increase the call volume
level.*
4. Press and hold down the Volume Down/Previous Track (3) button to decrease the call
volume level.
5. Briefly press the Mode/Phone button (4) again to end the call.

5
Bluetooth Headphones
AVS1326, 1392, 1393 & 1394
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
6. The callers voice will be heard in the headphones and your voice will be picked up be the
built in Microphone (8) in the headphones.
Rejecting a Call
1. A call coming in will mute (cut) the music you are listening to.
2. Press and hold the Mode/Phone button (4) for two seconds to reject the call.
Redialling the Last Call
1. Whilst listening to music, press and hold the Mode/Phone button (4) for two seconds to
dial the last call made.
2. Press and hold down the Volume Up/Next Track button (2) to increase the call volume
level.*
3. Press and hold down the Volume Down/Previous Track button (3) to decrease the call
volume level.
*Two high pitched beeps will be heard warning when the maximum volume setting has been
reached.
Using Your Headphones 3.5mm Input Jack
If the Headphone battery goes flat whilst in use or the device you are using has no Bluetooth
output, plugging your device or audio source into the 3.5mm Input Jack (7) via the supplied
3.5mm Jack to Jack Audio Cable (10) will allow normal playback through the headphones.
NB the Bluetooth and handsfree functions will not function whilst using a wired connection.
Technical Specification
Model Numbers
AVS1326, AVS1392, AVS1393 & AVS1394
Battery
300mAh Lithium-Ion Rechargeable Battery
Power Rating
10mW RMS
Headphone Impedance
32Ω
Unpacked Weight
Approx. 168g
Dimensions (Approx.)
Approx. 160 (w) x 70 (d) x 180 (h) mm
Operating Temperature Range
0°C to + 40°C
This product conforms to Radio Equipment Directive 2014/53/EU

6
Bluetooth Headphones
AVS1326, 1392, 1393 & 1394
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist. Check with your Local Authority or retailer for recycling
advice.
Waste batteries should not be disposed of with household waste. Please
recycle where facilities exist. Check with your Local Authority or retailer for recycling
advice.

7
Bluetooth Headphones
AVS1326, 1392, 1393 & 1394
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
GUARANTEE
This product is guaranteed for twenty-four months from the date of original
purchase.If any defect should occur due to faulty materials or workmanship, please
return it to the store it was purchased from.
You will need to have your receipt of purchase to hand. The guarantee is subject to
the following provisions:
•
It is only valid within the boundaries of the country of purchase.
•
The product must be correctly installed and operated in accordance with the
instructions contained in the
User Manual.
•
The product must be used solely for domestic purposes.
•
The guarantee will berendered invalid if the product is re-sold or has been
damaged by inexpert repair.
•
The manufacturer disclaims any liability for incidental or consequential damages.
•
The guarantee is in addition to, anddoes not diminish, your statutory or legal
rights.
Daewoo Electricals is a registered trademark.
Produced and imported under licence by ESG Ltd
Manchester M3 1JS www.esgltd.com
