Daewoo RNH3210WCH Installation instructions

User Instruction
Combi Fridge Freezer
No-Frost
Content
1. Safety Information Page 1~5
2. Overview Page 6
3. Installation Page 7~11
4. Daily Use 12~17Page
Моdel:RNH3210WCH
RNH3210SCH
RNH3210WCHL
RNH3210SCHL

In the interest of your safety and to ensure the correct use, before
installing and first using the appliance, read this user manual carefully,
including its hints and warnings. To avoid unnecessary mistakes and
accidents, it is important to ensure that all people using the appliance
are thoroughly familiar with its operation and safety features. Save
these instructions and make sure that they remain with the appliance if
it is moved or sold, so that everyone using it through its life will be
properly informed on appliance use and safety.
For the safety of life and property keep the precautions of these user’s
instructions as the manufacturer is not responsible for damages
caused by omission.
yThis appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given super
vision or instruction concerning use of the appliance in a safe way
and understand the hazards involved.
yChildren should be supervised to ensure that they do not play with
the appliance.
yCleaning and user maintenance shall not be made by children unless
they are aged from 8 years and above and supervised.
yKeep all packaging well away from children. There is risk of
suffocation.
yIf you are discarding the appliance pull the plug out of the socket, cut
the connection cable (as close to the appliance as you can) and
remove the door to prevent playing children to suffer electric shock or
to close themselves into it.
yIf this appliance featuring magnetic door seals is to replace an older
appliance having a spring lock (latch) on the door or lid, be sure to
make that spring lack unusable before you discard the old appliance.
This will prevent it from becoming a death trap for a child.
Safety information
Childrenandvulnerablepeoplesafety
General safety
WARNING! Keep ventilation openings, in the appliance enclosure
or in the built-in structure, clear of obstruction.
WARNING! Do not use mechanical devices or other means to
accelerate the defrosting process, other than those recommended
by the manufacturer.
WARNING! Do not damage the refrigerant circuit.
1

yDo not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
yThe refrigerant isobutane (R600a) is contained within the refrigerant
circuit of the appliance, a natural gas with a high level of
environmental compatibility, which is nevertheless flammable.
yDuring transportation and installation of the appliance, be certain
that none of the components of the refrigerant circuit become
damaged.
- avoid open flames and sources of ignition
- thoroughly ventilate the room in which the appliance is situated
yIt is dangerous to alter the specifications or modify this product in any
way. Any damage to the cord may cause a short circuit, fire and/or
electric shock.
yThis appliance is intended to be used in household and similar
applications such as
- staff kitchen areas in shops, offices and other working
environments;
- farm houses and by clients in hotels, motels and other residential
type environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
WARNING! Do not use other electrical appliances (such as ice
cream makers) inside of refrigerating appliances, unless they are
approved for this purpose by the manufacture.
WARNING! Any electrical components(plug, power cord,
compressor and etc.) must be replaced by a certified service agent
or qualified service personnel.
Safety information
WARNING! The light bulb supplied with this appliance is a “special
use lamp bulb” usable only with the appliance supplied. This “special
1)
use lamp” is not usable for domestic lighting.
1) If there is a light in the compartment.
WARNING! Do not touch the light bulb if it has been on for a long
1)
period of time because it could be very hot.
2

yDo not put hot on the plastic parts in the appliance.
yDo not place food products directly against the rear wall.
1)
yFrozen food must not be re-frozen once it has been thawed out.
yStore pre-packed frozen food in accordance with the frozen food
,1)
manufacture s instructions.
,
yAppliance s manufactures storage recommendations should be
strictly adhered to. Refer to relevant instructions.
yDo not place carbonated of fizzy drinks in the freezer compartment as
it creates pressure on the container, which may cause it to explode,
1)
resulting in damage to the appliance.
yIce lollies can cause frost burns if consumed straight from the
1)
appliance.
Daily use
1) If there is a freezer compartment.
2) If there is a fresh-food storage compartment.
Care and cleaning
yBefore maintenance, switch off the appliance and disconnect the
mains plug from the mains socket.
yDo not clean the appliance with metal objects.
yDo not use sharp objects to remove frost from the appliance. Use a
1)
plastic scraper.
yRegularly examine the drain in the refrigerator for defrosted water. If
necessary, clean the drain. If the drain is blocked, water will collect in
2)
te bottom of the appliance.
Safety information
yPower cord must not be lengthened.
yMake sure that the power plug is not squashed or damaged by the
back of the appliance. A squashed or damaged power plug may
overheat and cause a fire.
yMake sure that you can come to the mains plug of the appliance.
yDo not pull the mains cable.
yIf the power plug socket is loose, do not insert the power plug. There
is a risk of electric shock or fire.
yYou must not operate the appliance without the lamp.
yThis appliance is heavy. Care should be taken when moving it.
yDo not remove nor touch items from the freezer compartment if you
hands are damp/wet, as this could cause skin abrasions or
frost/freezer burns.
yAvoid prolonged exposure of the appliance to direct sunlight.
3

Service
yAny electrical work required to do the servicing of the appliance
should be carried out by a qualified electrician or competent person.
yThis product must be serviced by an authorized Service Center, and
only genuine spare parts must be used.
Energy saving
yDon’t put hot food in the appliance;
yDon’t pack food close together as this prevents air circulating;
yMake sure food don’t touch the back of the compartment(s);
yIf electricity goes off, don’t open the door(s);
yDon’t open the door(s) frequently;
yDon’t keep the door(s) open for too long time;
yDon’t set the thermostat on exceeding cold temperatures;
ySome accessaries, such as drawers, can be removed to get larger
storage volume and lower energy consumption.
Safety information
Installation
Important! For electrical connection carefully follow the instructions
given in specific paragraphs.
yUnpack the appliance and check if there are damages on it. Do not
connect the appliance if it is damaged. Report possible damages
immediately to the place you bought it. In that case retain packing.
yIt is advisable to wait at least four hours before connecting the
appliance to allow the oil to flow back in the compressor.
yAdequate air circulation should be around the appliance, lacking this
leads to overheating. To achieve sufficient ventilation follow the
instructions relevant to installation.
yWherever possible the spacers of the product should be against a
wall to avoid touching or catching warm parts (compressor, con-
denser) to prevent possible burn.
yThe appliance must not be located close to radiators or cookers.
yMake sure that the mains plug is accessible after the installation of
the appliance.
4

This appliance does not contain gasses which could damage the
ozone layer, in either its refrigerant circuit or insulation materials. The
appliance shall not be discarded together with the urban refuse and
rubbish. The insulation foam contains flammable gases: the appliance
shall be disposed according to the appliance regulations to obtain from
your local authorities. Avoid damaging the cooling unit, especially the
heat exchanger. The materials used on this appliance marked by the
symbol are recyclable.
Environment Protection
The materials with the symbol are recyclable. Dispose the packaging in
a suitable collection containers to recycle it.
Packaging materials
Disposal of the appliance
Safety information
1. Disconnect the mains plug from the mains socket.
2. Cut off the mains cable and discard it.
The symbol on the product or on its packaging indicates that this
product may not be treated as household waste. Instead it
should be taken to the appropriate collection point for the
recycling of electrical and electronic equipment. By ensuring this
product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which
could otherwise be caused by inappropriate waste handling of this
product. For more detailed information about recycling of this product,
please contact your local council, your household waste disposal
service or the shop where you purchased the product.
5

Overview
Note: Above picture is for reference only. Real appliance probably is different.
Freezer
Drawers
Fridge
Balconies
Fridge
Shelves
Crisper
6
Моdel:RNH3210WCH
RNH3210SCH
RNH3210WCHL
RNH3210SCHL

Installation
SpaceRequirement
ySelect a location without direct exposure to sunlight;
ySelect a location with enough space for the refrigerator doors to open
easily;
ySelect a location with level (or nearly level) flooring;
yAllow sufficient space to install the refrigerator on a flat surface;
yAllow clearance to the right, left, back and top when installing. This
yKeep at lest 50mm gap at two sides and back.
will help reduce power consumption and keep your energy bills lower.
Install this appliance at a location where the ambient temperature corresponds to the climate class
indicated on the rating plate of the appliance:
Positioning
Climate class Ambient temperature
SN
N
ST
T
oo
+10 C to +32 C
oo
+16 C to +32 C
oo
+16 C to +38 C
oo
+16 C to +43 C
The appliance should be installed well away from sources of heat such as radiators, boilers, direct sunlight
etc. Ensure that air can circulate freely around the back of the cabinet. To ensure best performance, if the
appliance is positioned below an overhanging wall unit, the minimum distance between the top of the cabi-
net and the wall unit must be at least 100 mm. Ideally, however, the appliance should not be positioned
below overhanging wall units. Accurate leveling is ensured by one or more adjustable feet at the base of
the cabinet.
Location
Warning! It must be possible to disconnect the appliance from the mains power supply; the plug must
therefore be easily accessible after installation.
Before plugging in, ensure that the voltage and frequency shown on the rating plate correspond to your
domestic power supply. The appliance must be earthed. The power supply cable plug is provided with a
contact for this purpose. If the domestic power supply socket is not earthed, connect the appliance to a
separate earth in compliance with current regulations, consulting a qualified electrician.
The manufacturer declines all responsibility if the above safety precautions are not observed.
This appliance complies with the E.E.C. Directives.
Electrical connection
7

Installation
Before reversing the door, please be prepared below tools and material: straight screwdriver, cross
screwdriver, spanner and the components included in the poly bag:
Decorative Cover of Right Door x1 Left Door Hinge Cover x 1
Door Reversibility
1. Please upwarp and take off plastic cover by straight screwdriver after opening the door. Please
be careful of the wire inside.
2. Close the door, take out the screw from the top cover by cross screwdriver.
Take off front top cover and hinge cover, unplug the terminal, then take out the screw from the
hinge. Make sure door are closed when operation.
Zoom in
3. Take off the upper door, take out the screw from the middle hinge by cross screwdriver,
then take off the lower door.
8
