Part 1 Brief Introduction Of The DSL19M1TC
Specification
hank you for buying ALBA LCD-TV Product. As a high-resolution LCD-TV with a 19-inch
screen, the DSL19M1TC incorporates DVD player, LCD display and TV receiver in one
system. It adopts an MPEG2 decoding format to achieve horizontal resolution more than
500 lines. Designed with USB and SD/MS/MMC card port, it can be connected to USB device
or SD/MS/MMC Card. It has several special functions such as sleep time setting, V-Chip and
CCD support, auto TV searching and the picture enlargement. The product can not only be
connected to external audio and video signal source and PC, but also features an AV output
to extern audio and video device. It also supports multi-angle, multi-language and
multi-subtitle playback.
Specifications
Brand ALBA DSL19M1TC
TV Type TV With LCD Screen
Dimension
Depth 184mm
Height 412mm
Width 494mm
Weight About 8.26 kg
General
Exterior Color Black and Silver
Screen Size 19 in.
TFT-LCD Resolution 1440 x 900
Video Inputs AV, S-Video, Component, VGA, TV, DVD
Video Outputs Composite
Audio Inputs L/R audio input (AV audio inputs share with S-Video and
Component), PC audio input
Video system NTSC
Number of Discs 1
Discs Formats DVD, CD, JPEG
Ambient Temperature 10～45℃
Power Supply AC 100-240V 50/60 Hz
DC 12V 5A
Power Consummation ＜60W
T
