Dahua Technology DHI-IPMECD-3021 Series User manual

Parking Barrier
User's Manual
ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. V1.0.1

User's Manual
I
Foreword
General
This manual introduces the structure, installation, and maintenance of the parking barrier
(hereinafter referred to as the "Barrier"). Read carefully before using the device, and keep the manual
safe for future reference.
Models
Series Model
DHI-IPMECD-3021
DHI-IPMECD-3021-RM1515-T09
DHI-IPMECD-3021-LM1515-T09
DHI-IPMECD-3021-RM1525-T20
DHI-IPMECD-3011-LM1525-T20
DHI-IPMECD-3021-RM1515-T09-AC110
DHI-IPMECD-3021-LM1515-T09-AC110
DHI-IPMECD-3021-RM1525-T20-AC110
DHI-IPMECD-3021-LM1525-T20-AC110
DHI-IPMECD-3022
DHI-IPMECD-3022-RM30-T09
DHI-IPMECD-3022-LM30-T09
DHI-IPMECD-3022-RM40-T20
DHI-IPMECD-3022-LM40-T20
DHI-IPMECD-3022-RM50-T30
DHI-IPMECD-3022-LM50-T30
DHI-IPMECD-3022-RM60-T30
DHI-IPMECD-3022-LM60-T30
DHI-IPMECD-3022-RM30-T09-AC110
DHI-IPMECD-3022-LM30-T09-AC110
DHI-IPMECD-3022-RM40-T20-AC110
DHI-IPMECD-3022-LM40-T20-AC110
DHI-IPMECD-3022-RM50-T30-AC110
DHI-IPMECD-3022-LM50-T30-AC110
DHI-IPMECD-3022-RM60-T30-AC110
DHI-IPMECD-3022-LM60-T30-AC110
Safety Instructions
The following signal words might appear in the manual.

User's Manual
II
Signal Words Meaning
Indicates a high potential hazard which, if not avoided, will result in
death or serious injury.
Indicates a medium or low potential hazard which, if not avoided,
could result in slight or moderate injury.
Indicates a potential risk which, if not avoided, could result in
property damage, data loss, reductions in performance, or
unpredictable results.
Provides methods to help you solve a problem or save time.
Provides additional information as a supplement to the text.
Revision History
Version Revision Content Release Date
V1.0.1 Updated wiring diagram and inverter descriptions. January 2022
V1.0.0 First release. December 2021
Privacy Protection Notice
As the device user or data controller, you might collect the personal data of others such as their face,
fingerprints, and license plate number. You need to be in compliance with your local privacy
protection laws and regulations to protect the legitimate rights and interests of other people by
implementing measures which include but are not limited: Providing clear and visible identification
to inform people of the existence of the surveillance area and provide required contact information.
About the Manual
●The manual is for reference only. Slight differences might be found between the manual and the
product.
●We are not liable for losses incurred due to operating the product in ways that are not in
compliance with the manual.
●The manual will be updated according to the latest laws and regulations of related jurisdictions.
For detailed information, see the paper user’s manual, use our CD-ROM, scan the QR code or visit
our official website. The manual is for reference only. Slight differences might be found between
the electronic version and the paper version.
●All designs and software are subject to change without prior written notice. Product updates
might result in some differences appearing between the actual product and the manual. Please
contact customer service for the latest program and supplementary documentation.
●There might be errors in the print or deviations in the description of the functions, operations
and technical data. If there is any doubt or dispute, we reserve the right of final explanation.
●Upgrade the reader software or try other mainstream reader software if the manual (in PDF
format) cannot be opened.
●All trademarks, registered trademarks and company names in the manual are properties of their
respective owners.
●Please visit our website, contact the supplier or customer service if any problems occur while

User's Manual
III
using the device.
●If there is any uncertainty or controversy, we reserve the right of final explanation.

User's Manual
IV
Important Safeguards and Warnings
This section introduces content covering the proper handling of the device, hazard prevention, and
prevention of property damage. Read carefully before using the device, comply with the guidelines
when using it, and keep the manual safe for future reference.
Transportation Requirements
Transport the device under allowed humidity and temperature conditions.
Storage Requirements
Store the device under allowed humidity and temperature conditions.
Installation Requirements
●Do not connect the power adapter to the device while the adapter is powered on.
●Strictly comply with the local electric safety code and standards. Make sure the ambient voltage
is stable and meets the power supply requirements of the device.
●Do not connect the device to two or more kinds of power supplies, to avoid damage to the
device.
●Personnel working at heights must take all necessary measures to ensure personal safety
including wearing a helmet and safety belts.
●Do not place the device in a place exposed to sunlight or near heat sources.
●Keep the device away from dampness, dust, and soot.
●Put the device in a well-ventilated place, and do not block its ventilation.
●Use an adapter or cabinet power supply provided by the manufacturer.
●The power supply must conform to the requirements of ES1 in IEC 62368-1 standard and be no
higher than PS2. Please note that the power supply requirements are subject to the device label.
●The device is a class I electrical appliance. Make sure that the power supply of the device is
connected to a power socket with protective earthing.
Operation Requirements
●Check whether the power supply is correct before use.
●Do not unplug the power cord on the side of the device while the adapter is powered on.
●Operate the device within the rated range of power input and output.
●Use the device under allowed humidity and temperature conditions.
●Do not drop or splash liquid onto the device, and make sure that there is no object filled with
liquid on the device to prevent liquid from flowing into it.

User's Manual
V
●Do not disassemble the device without professional instruction.

User's Manual
VI
Table of Contents
Foreword ........................................................................................................................................................................................................I
Important Safeguards and Warnings............................................................................................................................................IV
1 Introduction ............................................................................................................................................................................................ 1
1.1 Overview........................................................................................................................................................................................ 1
1.2 Features.......................................................................................................................................................................................... 1
2 Structure ................................................................................................................................................................................................... 3
2.1 Appearance................................................................................................................................................................................... 3
2.2 Dimensions ................................................................................................................................................................................... 4
2.3 Components................................................................................................................................................................................. 4
3 Installation............................................................................................................................................................................................... 6
3.1 Installation Preparation ......................................................................................................................................................... 6
3.2 Installing the Barrier ................................................................................................................................................................ 8
3.2.1 Installing the Casing...................................................................................................................................................... 8
3.2.2 Installing the Folding Arm ......................................................................................................................................... 9
3.2.3 Installing the Straight Arm ........................................................................................................................................ 9
3.2.3.1 Installing the Anti-smashing Arm..............................................................................................................10
3.2.3.2 Installing the Regular Arm ............................................................................................................................10
3.2.4 Opening the Top Cover..............................................................................................................................................11
3.3 Cable Connection.....................................................................................................................................................................11
3.3.1 Barrier Inverter Description ....................................................................................................................................11
3.3.2 Remote Matching Description ...............................................................................................................................13
3.3.3 Wiring Instructions ......................................................................................................................................................14
4 Maintenance .........................................................................................................................................................................................15
4.1 Notes on Using the Barrier..................................................................................................................................................15
4.2 Regular Maintenance.............................................................................................................................................................15
4.3 Maintenance Methods ..........................................................................................................................................................15
4.3.1 Replacing the Rubber Buffer...................................................................................................................................15
4.3.2 Maintaining the Drive Unit ......................................................................................................................................15
4.3.3 Maintaining the Angle Sensor................................................................................................................................16
4.3.4 Adjusting the Balance Spring.................................................................................................................................16
Appendix 1 Cybersecurity Recommendations........................................................................................................................18

User's Manual
1
1 Introduction
1.1 Overview
The Barrier can be used together with a radar for access control in parking lots, and it primarily
consists of a top cover, casing, drive unit, control box, and barrier arm. The Barrier can be divided
into 2 categories depending on its arm position (right or left) when facing it.
Straight arm barrier and folding arm barriers are available.
Table 1-1 Barrier type
Type Description Remark
Straight arm barrier
●Barrier with 3 m (9.84 ft) straight arm with an
opening/closing time of 0.9 s.
●Barrier with 4 m (13.12 ft) straight arm with
an opening/closing time of 2 s.
●Barrier with 5 m (16.40 ft) straight arm with
an opening/closing time of 3 s.
●Barrier with 6 m (19.69 ft) straight arm with
an opening/closing time of 3 s.
Contact technical
support for specific
needs.
Folding arm barrier
●For barriers with 3 m (9.84 ft) arms, each of
the two sections of the arm is 1.5 m (4.92 ft),
and has an opening/closing speed of 0.9 s.
●For barriers with 4 m (13.12 ft) arms, the
main arm is 1.5 m (4.92 ft) and the sub arm is
2 m (6.56 ft). It has an opening/closing time
of 2 s.
1.2 Features
●With its AC variable frequency motor, drive unit and balance spring, the Barrier has highly stable
and reliable operations. Its motor and spring can sustain up to 5 million uses.
●The sheet metal casing makes it resistant to corrosion for up to 10 years.
●Designed with a buffer strip on its arm for enhanced safety. The buffer strip is made of
high-molecular-weight polyurethane (PU) which remains soft and not stiff in cold environments.
It has a lifespan for more than 10 years.
●Automatically rises when the barrier arm makes contact with an object.
●Barriers with 3 m (9.84 ft) or 4 m (13.12 ft) straight arms support the anti-collision function. A
turning gear is installed between the arm and the main shaft, allowing the arm to swing back
from a collision to avoid mechanical damage.
●The arm automatically rises at 90° in case of power failure. You can contact technical support to
customize the angle.
●Anti-drop function activates through its connection with the radar, loop, or IR sensor.
●12 VDC power adapter that is capable of supplying power to the connected radar.

User's Manual
2
●Supports remote control at a maximum distance of 50 m (164 ft) with no interference.

User's Manual
3
2 Structure
2.1 Appearance
Straight Arm Barrier
Figure 2-1 Straight arm barrier
Folding Arm Barrier
Figure 2-2 Folding arm barrier

User's Manual
4
2.2 Dimensions
Figure 2-3 Dimensions (mm [inch])
2.3 Components
Figure 2-4 Components

User's Manual
5
Table 2-1 Components description
No. Name Description
1 Top cover Fixed to the casing by a lock, which can be unlocked
with a key.
2 Drive unit Driven by a torque motor, it controls the arm to rise or
fall.
3 Control box Contains the control board, on which the barrier inverter
and connection terminals are installed.
4 Casing Applied with a plastic spray.
5 Barrier arm
●Straight arms with light bars.
●Folding arms.

User's Manual
6
3 Installation
3.1 Installation Preparation
●This section introduces basic requirements for selecting and constructing the foundation. For
details on installing the Barrier, see the construction guide.
●The foundation must be constructed before the Barrier is installed.
Selecting Construction Site
The center of the foundation should be more than 300 mm (11.81'') away from the road side. The
barrier arm can open at a 90° angle vertical to the ground.
Figure 3-1 Installation site of foundation (mm [inch])
●1: Barrier (installed on the foundation).
●2: Vehicle movement direction.

User's Manual
7
Foundation Construction Requirements
Figure 3-2 Foundation construction requirements (mm [inch])
Table 3-1 Foundation description
No. Name
1 Foundation bolt
2 Foundation surface
3 PVC pipe
●Pour concrete to construct a foundation of 500 mm× 500 mm (19.69''× 19.69'') (L × W), and make
sure that the depth is between 150 mm–200 mm (5.91''–7.87''). Depths that do not fall within this
range will greatly influence the accuracy of radar detection.
●Use concrete of at least grade C15.
●Bury foundation bolts in the foundation. Make sure that the bolts are exposed 100 mm (3.94'')
above the foundation.
Figure 3-3 Foundation bolt (mm [inch])
●(Optional) If no foundation bolts are buried, you can use the expansion bolts provided in the
accessories of the Barrier.

User's Manual
8
◇After the concrete foundation hardens, drill 4 holes with a diameter of 16 mm (0.63'') to install
the Barrier.
◇Use M12 expansion bolts. Make sure that the thread length of the expansion bolt is longer
than 80 mm (3.15''), and its total length is more than 150 mm (5.91'').
◇The drilled holes and the installation position should meet the requirements shown in Figure
3-4 to facilitate installing the metal plates and fixing the Barrier.
Figure 3-4 Install expansion bolt (top view) (mm [inch])
●Thread the power cable and the signal cable separately through two 1-inch PVC pipes (buried in
the foundation) to the cable holes next to the foundation.
●After installation, make sure that when opening the Barrier, there are no obstacles within a 90°
vertical range.
3.2 Installing the Barrier
3.2.1 Installing the Casing
Prerequisites
●Read the manual carefully before installation. Refer to the barrier drawing attached to the casing
to know how the Barrier works and how to wire it.
●Check whether the power cable, signal cable, or internal wiring is loose or disconnected. If yes,
securely connect the cables before installation.
Procedure
Step 1 Unpack the packaging box.
Step 2 Place the casing on the foundation, and set the working direction of the arm vertical to the
vehicle movement direction (we recommend placing a layer of 3mm rubber under the
casing to reduce vibrations).
Step 3 Use the key to open the door, and then place metal plates on the foundation bolts.
Step 4 Adjust the horizontal and vertical positions of the casing, and then tighten the nuts with a
wrench.

User's Manual
9
3.2.2 Installing the Folding Arm
Figure 3-5 Example of a successful installation
Table 3-2 Parts description
No. Description No. Description
1 Mounting plate 3 M14 nut and spring washer
2 M14 × 140 hex head bolt and plain washer 4 Fixing plate
Step 1 Align the arm with the mounting plate, and fix the mounting plate to the arm with M14 ×
140 hex head bolt.
Step 2 Push the arm to make it fit with the mounting plate completely.
Step 3 Install the control arm (right above the barrier arm) and then attach the plate.
3.2.3 Installing the Straight Arm
Different arm lengths require different installation methods.

User's Manual
10
Arms shorter than 4 m (included) are anti-smashing.
3.2.3.1 Installing the Anti-smashing Arm
Figure 3-6 Install the anti-smashing arm
Step 1 Connect the LED light bar that is fed through the arm to the cable that comes out of the
mounting plate.
The cable coming out of the mounting plate needs to be fixed to the plate surface with
fixing screws, in a way that allows the fixed cable to fit into the cable groove on the arm.
This will ensure the LED connector remains intact when the arm is attached to the
mounting plate.
Step 2 Place the arm in the mounting plate, and align the holes of the arm with those of the plate.
Step 3 Thread the M14 × 140 hex head bolt through the plate and the arm, and fix the bolt with
M14 nut, plain washer and spring washer.
Step 4 Push the arm to make it fit in the mounting plate completely.
3.2.3.2 Installing the Regular Arm
Figure 3-7 Install the regular arm

User's Manual
11
Step 1 Thread four M10 × 75 bolts and plain washers through parts 1, 2, and 3.
Step 2 Fix the bolts with four M10 nuts and spring washers.
3.2.4 Opening the Top Cover
Step 1 Lift the arm up to its vertical state.
Step 2 Use your key to unlock the top cover, wait until the side of the cover near the arm is tilted,
and then push the cover forward to open it.
3.3 Cable Connection
3.3.1 Barrier Inverter Description
Figure 3-8 Barrier inverter
Table 3-3 Barrier inverter description
Parameter Description
Ports for adjusting parameters.

User's Manual
12
Parameter Description
1
●ON: Enable automatic arm lifting during power failure.
●OFF: Disable automatic arm lifting during power failure.
2
Counting mode: Under this mode, when the Barrier is powered on,
and there is no anti-smashing signal triggered, the arm
automatically falls.
●2 and 3 are ON: Enable counting mode.
When the Barrier receives N signals (N ≤ 5) of opening,
including from camera and remote control, the arm will fall
after receiving N signals of vehicle passing, and the interval
between signals is longer than 1 second.
●OFF: Disable the counting mode.
3
●ON: Enable the function of auto-falling when vehicle passing.
●OFF: Disable the function of auto-falling when vehicle passing.
4
●ON: The Always on point of the anti-smashing vehicle
detector output is connected between the inverter VD port
and +24 V port (VD connects to NO and +24 V to COM).
●OFF: The Always off point of the anti-smashing vehicle
detector output is connected between the inverter VD port
and +24 V port (VD connects to NC and +24 V to COM).
When the vehicle detector detects vehicle passing, the inverter
keeps the arm lifted and lifts the arm that is falling, and the arm
falls after the vehicle passed.
Brake
position
adjustment
DIP (0–9)
●0: Switch the DIP to 0 after adjusting arm stability.
●1: Invalid position.
●2–9: Adjust the brake position of the arm during rising or
falling while adjusting arm stability. The larger the number,
the later the arm starts decelerating.
Buttons Open and close the Barrier.
Ports
–24 V Ground.
COM Feedback signal common port.
LDUP Barrier open feedback signal.
LDDN Barrier close feedback signal.
BOOM Auxiliary anti-smashing port, which only triggers anti-smashing. It
does not control automatic close of barrier.
VD Common anti-smashing port. The barrier automatically closes
after the anti-smashing signal disappears.
GOUP Ports for controlling open and close of the Barrier.
●GOUP: Open.
GODN

User's Manual
13
Parameter Description
+24V
●GODN: Close.
●+24 V: Common signal port.
VRV
Angle sensor ports.
VRG
VRS
PE
Drive motor ports.
U
V
W
L
220 VAC power supply ports for the barrier inverter.
N
PE
3.3.2 Remote Matching Description
Figure 3-9 Receiver
●Match the remote information
◇Successful matching: Press and hold the learning button on the receiver for 2 s, press the
remote handle at least twice and then you can press keys on the remote to control the arm.
◇Failed matching: The remote handle is not pressed a while after pressing the learning button
on the receiver, and the receiver indicator does not flash 3 times immediately, but flashes 7
times after about 8 seconds.
●Clear the remote information: Press and hold the learning button on the receiver for more than 3
seconds, and then the remote cannot control the arm. This means the matching information has
