Dahua Technology DHI-ITC237-PW6M-LZF1050 User manual

Access ANPR Camera
User's Manual
ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD.
V1.0.3

User's Manual
I
Foreword
General
The manual introduces the structure, installation, functions, and operations of the access ANPR
camera (hereinafter referred to as "the Camera").
Models
Model Description Focal Length Pixel
DHI-ITC237-PW6M-LZF1050
Long Range Access
ANPR Camera
10 mm–50 mm 2 MP
DHI-ITC237-PW6M-IRLZF1050
DHI-ITC237-PW6M-IRLZF1050-B
DHI-ITC237-PW6M-LZF1050-B
DHI-ITC437-PW6M-IZ
10 mm–50 mm 4 MP
DHI-ITC437-PW6M-LZ
DHI-ITC437-PW6M-IZ-GN
DHI-ITC437-PW6M-LZ-GN
DHI-ITC215-PW6M-IRLZF
Short Range Access
ANPR Camera
3.2 mm–10.5 mm 2 MP
DHI-ITC215-PW6M-LZF
DHI-ITC215-PW6M-IRLZF-B
DHI-ITC215-PW6M-LZF-B
DHI-ITC215-PW6M-IRLZF-O
DHI-ITC215-PW6M-LZF-O
DHI-ITC415-PW6M-LZ
2.7 mm–12 mm 4 MP
DHI-ITC415-PW6M-IZ
DHI-ITC415-PW6M-LZ-GN
DHI-ITC415-PW6M-IZ-GN
DHI-ITC415-PW6M-LZ-BH
DHI-ITC415-PW6M-IZ-BH
Safety Instructions
The following signal words might appear in the manual.
Signal Words Meaning
Indicates a high potential hazard which, if not avoided, will result in
death or serious injury.
Indicates a potential risk which, if not avoided, could result in
property damage, data loss, reductions in performance, or
unpredictable results.

User's Manual
II
Signal Words Meaning
Provides methods to help you solve a problem or save time.
Provides additional information as a supplement to the text.
Revision History
Revision Content Release Time Revision Content
V1.0.3 Updated manual format. October 2021
V1.0.2 Updated the focal length of 437 and 415
models of camera. July 2021
V1.0.1 Added more models. March 2021
V1.0.0 First release. November 2019
Privacy Protection Notice
As the device user or data controller, you might collect the personal data of others such as their face,
fingerprints, and license plate number. You need to be in compliance with your local privacy
protection laws and regulations to protect the legitimate rights and interests of other people by
implementing measures which include but are not limited: Providing clear and visible identification
to inform people of the existence of the surveillance area and provide required contact information.
About the Manual
●The manual is for reference only. Slight differences might be found between the manual and the
product.
●We are not liable for losses incurred due to operating the product in ways that are not in
compliance with the manual.
●The manual will be updated according to the latest laws and regulations of related jurisdictions.
For detailed information, see the paper user’s manual, use our CD-ROM, scan the QR code or visit
our official website. The manual is for reference only. Slight differences might be found between
the electronic version and the paper version.
●All designs and software are subject to change without prior written notice. Product updates
might result in some differences appearing between the actual product and the manual. Please
contact customer service for the latest program and supplementary documentation.
●There might be errors in the print or deviations in the description of the functions, operations
and technical data. If there is any doubt or dispute, we reserve the right of final explanation.
●Upgrade the reader software or try other mainstream reader software if the manual (in PDF
format) cannot be opened.
●All trademarks, registered trademarks and company names in the manual are properties of their
respective owners.
●Please visit our website, contact the supplier or customer service if any problems occur while
using the device.
●If there is any uncertainty or controversy, we reserve the right of final explanation.

User's Manual
III
Important Safeguards and Warnings
This section introduces content covering the proper handling of the device, hazard prevention, and
prevention of property damage. Read carefully before using the device, comply with the guidelines
when using it, and keep the manual safe for future reference.
Transportation Requirements
Transport the device under allowed humidity and temperature conditions.
Storage Requirements
Store the device under allowed humidity and temperature conditions.
Installation Requirements
●Do not connect the power adapter to the device while the adapter is powered on.
●Strictly comply with the local electrical safety code and standards. Make sure the ambient voltage
is stable and meets the power supply requirements of the device.
●Do not connect the device to two or more kinds of power supplies, to avoid damage to the
device.
●Personnel working at heights must take all necessary measures to ensure personal safety
including wearing a helmet and safety belts.
●Do not place the device in a place exposed to sunlight or near heat sources.
●Keep the device away from dampness, dust, and soot.
●Put the device in a well-ventilated place, and do not block its ventilation.
●Use an adapter or cabinet power supply provided by the manufacturer.
●The power supply must conform to the requirements of ES1 in IEC 62368-1 standard and be no
higher than PS2. Please note that the power supply requirements are subject to the device label.
●The device is a class I electrical appliance. Make sure that the power supply of the device is
connected to a power socket with protective earthing.
●An emergency disconnect device must be installed during installation and wiring at a readily
accessible location for emergency power cut-off.
●Disconnect the device when installing and connecting the lens.
Operation Requirements
●Make sure that the power supply is correct before use.
●Do not unplug the power cord on the side of the device while the adapter is powered on.
●Operate the device within the rated range of power input and output.

User's Manual
IV
●Use the device under allowed humidity and temperature conditions.
●Do not drop or splash liquid onto the device, and make sure that there is no object filled with
liquid on the device to prevent liquid from flowing into it.
●Do not disassemble the device.
●Do not aim the device at strong light sources (such as lamplight, and sunlight) when focusing it.
●Do not vibrate, squeeze or immerse the device in liquid during transportation, storage or
installation.
●Do not block the ventilation near the device.
●We recommend you use the device with a lightning protection device for stronger protection
against lightning. For outdoor scenarios, strictly comply with the lightning protection
regulations.
●Ground the function earthing portion of the device (grounding cable or lightning surge protector)
to improve its reliability. The device is a class I electrical appliance. Make sure that the power
supply of the device is connected to a power socket with protective earthing.
●The device must be used with the protective cover for outdoor scenarios to avoid the risk of
water damage to the device.
●Protect the line cord and wires from being walked on or squeezed particularly at plugs, power
sockets, and the point where they exit from the device.
●Modify the default password of the device after first-time login to prevent the device from being
stolen.
Maintenance Requirements
●Pack the device with packaging provided by its manufacturer or packaging of the same quality
before sending it back for repair.
●Please do not touch the photosensitive device with your hands. Use an air blower to clean off the
dust and filth on the lens.
●Clean the surface of the device with a soft dry cloth or a clean soft cloth dipped in neutral
detergent.
●Use the accessories suggested by the manufacturer. Installation and maintenance must be
performed by qualified professionals.

User's Manual
V
