Dahua Technology DH-IPC-HFW3849T1P-AS-PV-S3-BLK User manual

Eyeball Network Camera
Quick Start Guide
V1.0.
2ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD.

Quick Start Guide
I
Foreword
General
This manual introduces the functions and operations of the camera.
Safety Instructions
The following categorized signal words with defined meaning might appear in the manual.
Signal Words Meaning
Indicates a medium or low potential hazard which, if not avoided,
could result in slight or moderate injury.
Indicates a potential risk which, if not avoided, may result in
property damage, data loss, lower performance, or unpredictable
result.
Provides additional information as the emphasis and supplement to
the text.
Revision History
Version Revision Content Release Time
V1.0.2 Updated "Important Safeguards and Warnings." April 2021
V1.0.1 Change the pictures in "3.3 Installing Device." November 2019
V1.0.0 First release. July 2019
About the Manual
The manual is for reference only. If there is inconsistency between the manual and the actual
product, the actual product shall prevail.
We are not liable for any loss caused by the operations that do not comply with the manual.
The manual would be updated according to the latest laws and regulations of related regions.
For detailed information, see the paper manual, CD-ROM, QR code or our official website. If
there is inconsistency between paper manual and the electronic version, the electronic version
shall prevail.
All the designs and software are subject to change without prior written notice. The product
updates might cause some differences between the actual product and the manual. Please
contact the customer service for the latest program and supplementary documentation.
There still might be deviation in technical data, functions and operations description, or errors
in print. If there is any doubt or dispute, please refer to our final explanation.
Upgrade the reader software or try other mainstream reader software if the manual (in PDF
format) cannot be opened.

Quick Start Guide
II
All trademarks, registered trademarks and the company names in the manual are the properties
of their respective owners.
Please visit our website, contact the supplier or customer service if there is any problem
occurred when using the device.
If there is any uncertainty or controversy, please refer to our final explanation.

Quick Start Guide
III
Important Safeguards and Warnings
Electrical Safety
All installation and operation shall conform to your local electrical safety codes.
The power source shall conform to the Safety Extra Low Voltage (SELV) standard, and supply
power with rated voltage which conforms to Limited Power Source requirement according to
IEC60950-1. Note that the power supply requirement is subject to the device label.
Make sure that the power supply is correct before operating the device.
A readily accessible disconnecting device shall be incorporated in the building installation
wiring.
Prevent the power cable from being trampled or pressed, especially the plug, power socket and
the junction extruded from the device.
Environment
Do not aim the device at strong light to focus, such as lamp light and sun light; otherwise it
might cause over brightness or light marks, which are not the device malfunction, and affect the
longevity of Complementary Metal-Oxide Semiconductor (CMOS).
Do not place the device in a damp, dusty extremely hot or cold environment, or the locations
with strong electromagnetic radiation or unstable lighting.
Keep the device away from any liquid to avoid damage to the internal components.
Keep the indoor device away from rain or damp to avoid fire or lightning.
Keep sound ventilation to avoid heat accumulation.
Transport, use and store the device within the range of allowed humidity and temperature.
Heavy stress, violent vibration or water splash are not allowed during transportation, storage
and installation.
Pack the device with standard factory packaging or the equivalent material when transporting
the device.
Install the device in the location where only the professional staff with relevant knowledge of
safety guards and warnings can access. The accidental injury might happen to the
non-professionals who enter the installation area when the device is operating normally.
Operation and Daily Maintenance
Do not touch the heat dissipation component of the device to avoid scald.
Carefully follow the instructions in the manual when performing any disassembly operation
about the device; otherwise, it might cause water leakage or poor image quality due to
unprofessional disassembly. Please make sure that the gasket ring is flat and properly installed
in the groove before installing the cover. Please contact after-sale service for desiccant
replacement if there is condensed fog on the lens after unpacking or when the desiccant turns
green (Not all models are included with the desiccant).

Quick Start Guide
IV
It is recommended to use the device together with lightning arrester to improve lightning
protection effect.
It is recommended to ground the device to enhance reliability.
Do not touch the image sensor (CMOS) directly. Dust and dirt could be removed with air blower,
or you can wipe the lens gently with soft cloth that is moistened with alcohol.
You can clean the device body with soft dry cloth, and for stubborn stains, use the cloth with
mild detergent. To avoid possible damage on device body coating which could cause
performance decrease, do not use volatile solvent such as alcohol, benzene, diluent and so on
to clean the device body, nor can strong, abrasive detergent be used.
Dome cover is an optical component. Do not touch or wipe the cover with your hands directly
during installation or operation. For removing dust, grease or fingerprints, wipe gently with
moistened oil-free cotton with diethyl or moisten soft cloth. You can also remove dust with an
air blower.
WARNING
Strengthen the protection of network, device data and personal information by adopting
measures which include but not limited to using strong password, modifying password
regularly, upgrading firmware to the latest version, and isolating computer network. For some
device with old firmware versions, the ONVIF password will not be modified automatically along
with the modification of the system password, and you need to upgrade the firmware or
manually update the ONVIF password.
Use standard components or accessories provided by manufacturer and make sure that the
device is installed and maintained by professional engineers.
The surface of the image sensor should not be exposed to laser beam radiation in an
environment where a laser beam device is used.
Do not provide two or more power supply sources for the device unless otherwise specified. A
failure to follow this instruction might cause damage to the device.

Quick Start Guide
V
Table of Contents
Foreword............................................................................................................................................................ I
Important Safeguards and Warnings............................................................................................................. III
1 Cable............................................................................................................................................................... 1
2 Network Configuration ................................................................................................................................. 2
Initializing Device....................................................................................................................................................................... 22.1
Modifying Device IP Address................................................................................................................................................. 32.2
Logging in to Web Interface................................................................................................................................................... 42.3
3 Installation..................................................................................................................................................... 6
Packing List................................................................................................................................................................................... 63.1
Dimensions................................................................................................................................................................................... 63.2
Installing Device ......................................................................................................................................................................... 73.3
3.3.1 Installation Method...................................................................................................................................................... 7
3.3.2 Attaching Device........................................................................................................................................................... 7
3.3.3 Installing Waterproof Connector (Optional) ....................................................................................................... 9
3.3.4 Adjusting Lens Angle ................................................................................................................................................10

Quick Start Guide
1
1Cable
Cable type might vary with different devices, and the actual product shall prevail.
Waterproof all the cable joints with insulating tape and waterproof tape to avoid short circuit
and water damage. For the detailed operation, see the FAQ Manual.
Cable listFigure 1-1
For more information about cable ports, see Table 1-1.
Table 1-1 Cable information
No. Port Name Description
1 Ethernet
Connects to network with network cable.
Provides power to the device with PoE.
PoE is available on select models.
2 12V DC power
input
Inputs 12V DC power. Be sure to supply power as instructed in the
manual.
Device abnormity or damage could occur if power is not supplied
correctly.

Quick Start Guide
2
2Network Configuration
Device initialization and IP address setting can be finished with the "ConfigTool" or on web interface.
For more information, see the Web Operation Manual.
Device initialization is available on select models, and it is required for the first use or after the
device is reset.
Device initialization is available only when the IP addresses of the device (192.168.1.108 by
default) and the PC stay in the same network segment.
Plan useable network segment properly to connect the device to the network.
The following figures and interfaces are for reference only, and the actual product shall prevail.
Initializing Device2.1
Double-click "ConfigTool.exe" to open the tool.Step 1
Click .Step 2
The Modify IP interface is displayed. See Figure 2-1.
Modify IPFigure 2-1
Click Search setting.Step 3
The Setting interface is displayed.
Enter the start IP address and end IP address of the network segment in which you want toStep 4
search devices, and then click OK.
All the devices found in the network segment are listed.
Select one or several devices whose Status shows Uninitialized, and then click Initialize.Step 5
The Device initialization interface is displayed.

Quick Start Guide
3
Select the devices that need initialization, and then click Initialize.Step 6
The password setting interface is displayed. See Figure 2-2.
Password settingFigure 2-2
Set and confirm the password of the devices, then enter a valid email address, and then clickStep 7
Next.
The final setting interface is displayed.
Password can be modified or reset in System Settings.
Select the options according to your needs, and then click OK.Step 8
The Initialization interface is displayed after initialization is completed. Click the success
icon ( ) or the failure icon ( ) for the details.
Click Finish.Step 9
The device status in the Modify IP interface (Figure 2-1) turns to Initialized.
Modifying Device IP Address2.2
You can modify IP address of one or multiple devices in one time. This section is based on
modifying IP addresses in batches.
Modifying IP addresses in batches is available only when the corresponding devices have the
same login password.
Do Step 1 to Step 4 in "2.1 Initializing Device" to search devices in your network segment.Step 1
After clicking Search setting, enter the username and password, and make sure that they
are the same as what you set during initialization, otherwise there will be wrong password
notice.
Select the devices whose IP addresses need to be modified, and then click Modify IP.Step 2

Quick Start Guide
4
The Modify IP Address interface is displayed. See Figure 2-3.
Modify IP AddressFigure 2-3
Select Static mode, and then enter start IP, subnet mask, and gateway.Step 3
IP addresses of multiple devices will be set to the same if you select the Same IP check
box.
If DHCP server is available in the network, devices will automatically obtain IP
addresses from DHCP server when you select DHCP.
Click OK.Step 4
Logging in to Web Interface2.3
Open IE browser, enter the IP address of the device in the address bar, and then press Enter.Step 1
If the setup wizard is displayed, finish the settings as instructed.
Enter the user name and password in the login box, and then click Login.Step 2
For the first login, click Click Here to Download Plugin, and then install the plugin asStep 3
instructed.
The main interface is displayed when the installation is finished. See Figure 2-4.

Quick Start Guide
5
Main interfaceFigure 2-4

Quick Start Guide
6
3Installation
Packing List3.1
The tool required for the installation such as electric drill is not provided in the package.
The operation manual and related tool are contained in the disk or the QR code, and the actual
package shall prevail.
Dimensions3.2
The following figures are for reference only, and the actual product shall prevail.
Unit: mm [inch]

Quick Start Guide
7
Installing Device3.3
3.3.1 Installation Method
3.3.2 Attaching Device
Make sure that the mounting surface is strong enough to hold at least three times of the weight of
the device and bracket.

Quick Start Guide
8
Cable going through the mounting surface

Quick Start Guide
9
Cable going through the side cable tray
3.3.3 Installing Waterproof Connector (Optional)
This part is needed only when there is a waterproof connector in the package and the device is used
outdoors.

Quick Start Guide
10
3.3.4 Adjusting Lens Angle

Quick Start Guide
