Dahua Technology DHI-ARD1233-W2(868) User manual

Wireless PIR Detector
User’s Manual
ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. V2.0.2

User’s Manual
I
Foreword
General
This manual introduces the installation, functions and operations of the Wireless PIR Detector
(hereinafter referred to as the "PIR"). Read carefully before using the device, and keep the manual
safe for future reference.
Model
DHI-ARD1233-W2(868); DHI-ARD1233-W2
Safety Instructions
The following signal words might appear in the manual.
Signal Words Meaning
Indicates a high potential hazard which, if not avoided, will result in
death or serious injury.
Indicates a medium or low potential hazard which, if not avoided,
could result in slight or moderate injury.
Indicates a potential risk which, if not avoided, could result in
property damage, data loss, lower performance, or unpredictable
result.
Provides methods to help you solve a problem or save you time.
Provides additional information as the emphasis and supplement to
the text.
Revision History
Version Revision Content Release Time
V2.0.2 Updated technical specifications. March 2023
V2.0.1 Updated the description for detector test. November 2022
V2.0.0 Updated the description for 24 h protection zone. August 2022
V1.1.0
●Added technical specifications and field of view.
●Updated descriptions of parameters.
●Updated images.
January 2022
V1.0.0 First release. October 2021
Privacy Protection Notice
As the device user or data controller, you might collect the personal data of others such as their face,
fingerprints, and license plate number. You need to be in compliance with your local privacy
protection laws and regulations to protect the legitimate rights and interests of other people by
implementing measures which include but are not limited: Providing clear and visible identification
to inform people of the existence of the surveillance area and provide required contact information.

User’s Manual
II
About the Manual
●The manual is for reference only. Slight differences might be found between the manual and the
product.
●We are not liable for losses incurred due to operating the product in ways that are not in
compliance with the manual.
●The manual will be updated according to the latest laws and regulations of related jurisdictions.
For detailed information, see the paper user’s manual, use our CD-ROM, scan the QR code or visit
our official website. The manual is for reference only. Slight differences might be found between
the electronic version and the paper version.
●All designs and software are subject to change without prior written notice. Product updates
might result in some differences appearing between the actual product and the manual. Please
contact customer service for the latest program and supplementary documentation.
●There might be errors in the print or deviations in the description of the functions, operations
and technical data. If there is any doubt or dispute, we reserve the right of final explanation.
●Upgrade the reader software or try other mainstream reader software if the manual (in PDF
format) cannot be opened.
●All trademarks, registered trademarks and company names in the manual are properties of their
respective owners.
●Please visit our website, contact the supplier or customer service if any problems occur while
using the device.
●If there is any uncertainty or controversy, we reserve the right of final explanation.

User’s Manual
III
Important Safeguards and Warnings
This section introduces content covering the proper handling of the PIR, hazard protection, and
protection of property damage. Read carefully before using the PIR, and comply with the guidelines
when using it.
Operation Requirements
●Make sure that the power supply of the PIR works properly before use.
●Do not pull out the power cable of the PIR while it is powered on.
●Only use the PIR within the rated power range.
●Transport, use and store the device under allowed humidity and temperature conditions.
●Prevent liquids from splashing or dripping on the device. Make sure that there are no objects
filled with liquid on top of the PIR to avoid liquids flowing into it.
●Do not disassemble the PIR.
Installation Requirements
●Connect the PIR to the adapter before power on.
●Strictly abide by local electrical safety standards, and make sure that the voltage in the area is
steady and conforms to the power requirements of the PIR.
●Do not connect the PIR to more than one power supply. Otherwise, the PIR might become
damaged.
●Observe all safety procedures and wear required protective equipment provided for your use
while working at heights.
●Do not expose the PIR to direct sunlight or heat sources.
●Do not install the PIR in humid, dusty or smoky places.
●Install the PIR in a well-ventilated place, and do not block the ventilator of the device.
●Use the power adapter or case power supply provided by the device manufacturer.
●The power supply must conform to the requirements of ES1 in IEC 62368-1 standard and be no
higher than PS2. Note that the power supply requirements are subject to the device label.
●Connect class I electrical appliances to a power socket with protective earthing.

User’s Manual
IV
Table of Contents
Foreword ........................................................................................................................................................................................................I
Important Safeguards and Warnings............................................................................................................................................III
1 Introduction ............................................................................................................................................................................................1
1.1 Overview ........................................................................................................................................................................................1
1.2 Technical Specifications.........................................................................................................................................................1
2 Checklist....................................................................................................................................................................................................4
3 Design.........................................................................................................................................................................................................5
3.1 Appearance...................................................................................................................................................................................5
3.2 Dimensions ...................................................................................................................................................................................6
4 Adding the PIR to the Hub ...............................................................................................................................................................7
5 Installation...............................................................................................................................................................................................8
5.1 Field of View.................................................................................................................................................................................8
5.2 Installing the PIR ........................................................................................................................................................................8
6 Configuration .......................................................................................................................................................................................11
6.1 Viewing Status ..........................................................................................................................................................................11
6.2 Configuring the PIR ................................................................................................................................................................12
Appendix 1 Cybersecurity Recommendations........................................................................................................................15

User’s Manual
1
1 Introduction
1.1 Overview
Wireless PIR detector is a wireless motion detector designed for indoor use. It can detect a human
moving within 12 m of the detector. It can be set up via the DMSS App for iOS and Android phones.
1.2 Technical Specifications
This section contains technical specifications of the PIR. Please refer to the ones that correspond with
your model.
Table 1-1 Technical specifications
Type Parameter Description
Port Indicator Light 1 × green alarm indicator
Button 1 × power button
Function
Tamper Alarm Yes
Remote Update Cloud update
Search Signal strength detection
Low Battery Alarm Yes
Wireless
Parameters
Carrier Frequency DHI-ARD1233-W2(868):
868.0 MHz–868.6 MHz
DHI-ARD1233-W2:
433.1 MHz–434.6
MHz
Transmission Power DHI-ARD1233-W2(868):
Limit 25 mW
DHI-ARD1233-W2:
Limit 10 mW
Communication
Distance
DHI-ARD1233-W2(868):
Up to 1,600 m (5,249.34 ft) in
an open space
DHI-ARD1233-W2:
Up to 1,200 m
(3,937.01 ft) in an
open space
Communication
Mechanism Two-way
Encryption Mode AES128
Frequency Hopping Yes
Temperature
Measuring Range -15 °C to +65 °C (+5 °F to +149 °F) (Indoor)
Measuring Precision ± 1 °C (± 1.8 °F)
Resolution 1 °C (33.8 °F)
Technical
Parameter
Detection Mode PIR
Sensor Dual-element low-noise PIR sensor
Test Mode Yes

User’s Manual
2
Type Parameter Description
Detection Range 12 m (39.37 ft) (90°) with installation height of 2.2 m
(7.21 ft)
Detection Speed 0.3 m/s–3 m/s (0.98 ft/s–9.84 ft/s)
Pet Immunity Level ≤ 18 kg (39.68 lb)
White Light
Resistance Level 2000 lx
Two-way Digital
Temperature
Compensation
Yes, no attenuation of detection distance in high
temperature
Sensitivity 3 levels adjustable
General
Power Supply CR123A battery
Battery Voltage 3 VDC
Min. Voltage 1.8 VDC
Battery Low
Threshold 2.7 VDC
Battery Restore
Threshold 2.75 VDC
Typical Voltage 3 VDC
Low Voltage Value 2.7 VDC
Consumption Quiescent current 9 uA
Max. current 60 mA
PS Type Type C
Battery Life 4 years
Power Consumption DHI-ARD1233-W2(868):
Max. 120 mW
DHI-ARD1233-W2:
Max. 75 mW
Operating
Environment
Indoor: -10 °C to +55 °C (+14 °F to +131 °F)
Certified temperature:-10°C to +40°C (+14°F to
+104 °F)
Operating Humidity 10%–90% (RH)
Product Dimensions 104.0 mm× 60.0 mm× 50.0 mm (4.09" × 2.36" × 1.97")
Packaging
Dimensions 135.0 mm× 98.5 mm× 56.8 mm (5.31" × 3.88" × 2.24")
Installation Wall mount
Net Weight 100 g (0.22 lb)
Gross Weight 170 g (0.37 lb)
Casing PC + ABS

User’s Manual
3
Type Parameter Description
Certifications
DHI-ARD1233-W2(868):
●EN 50131-1: 2006 + A2:2017 + A3:2020
●EN 50131-2-2: 2017
●EN 50131-5-3: 2017
●EN 50131-6:2017
●Security Grade (SG) 2
●Environmental Class (EC) II
●CE
DHI-ARD1233-W2:
●CE
●FCC

User’s Manual
4
2 Checklist
Figure 2-1 Checklist
Table 2-1 Checklist
No. Item Name Quantity No. Item Name Quantity
1 PIR 1 4 Quick start guide 1
2 Double-sided
adhesive tape 1 5 Legal and regulatory information 1
3 Screw package 1 — — —

User’s Manual
5
3 Design
3.1 Appearance
Figure 3-1 Appearance
Table 3-1 Structure
No. Name Description
1 Indicator
●Flashes green quickly: Pairing mode or reduced
sensitivity mode.
●Solid green: An alarm event was triggered.
●Solid green for 2 seconds: Pairing successful.
●Slowly flashes green for 3 seconds: Pairing failed.
●Flashes green quickly for 100 seconds, and then off:
sensitivity mode.
2 On/off switch Turn on or turn off the device.
3 Tamper switch When the tamper switch is released, the tamper alarm will be
triggered.
4 Back cover If the back cover is opened, the tamper alarm will be
triggered.
