Dahua 2M HD IP User manual

Fixed Mini Bullet Camera
2M HD IP
Ver. 1.1 / 2018.07
User’s Manual_Install Part
Before installing and using the camera, please read this manual carefully.
Be sure to keep it handy for future reference.

Contents
INSTALLATION
Disassemble the Camera
Installation
09
10
SPECIFICATION
Dimension11
INTRODUCTION
Important Safety Information
Product & Accessories
Part Name
03
07
08
Specication06

Safety Informaon
This symbol indicates that dangerous voltage
consisng a risk of electric shock is present within
this unit.
This exclamaon point symbol is intended to alert the
user to the presence of important operang and
maintenance (servicing) instrucons in the literature
accompanying the appliance.
WarningPrecauon
TO REDUCE THE RISK OFELECTRIC SHOCK, DONOT REMOVE COVER (OR BACK)NOUSER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION :
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
.
To prevent damage which may result in fire or electric shock
hazard, do not expose this appliance to rain or moisture.
WARNING
Be sure to use only the standard adapter that is specified in
the specificaon sheet. Using any other adapter could cause
fire, electrical shock, or damage to the product.
Incorrectly connecng the power supplyor replacing baery
may cause explosion, fire, electric shock, or damage to the
product.
Do not connect mulple cameras to a single adapter.
Exceeding the capacity may cause excessive heat generaon
or fire.
Securely plug the power cord into the power receptacle.
Insecure connecon may cause fire.
When installing the camera, fasten it securely and firmly.
A falling camera may cause personal injury.
Do not place conducve objects (e.g. screw drivers, coins,
metal items, etc.) or containers filled with water on top of
the camera. Doing so may cause personal injury due to fire,
electric shock, or falling objects.
Do not install the unit in humid, dusty, or sooty locaons.
Doing so may cause fire or electric shock.
If any unusual smells or smoke come from the unit, stop
using the product. Immediately disconnect the power sorce
and contact the service center. Connued use in such a
condion may cause fire or electric shock.
If this product fails to operate normally, contact the nearest
service center. Never disassemble or modify this product in
any way.
When cleaning, do not spray waterdirectly ontoparts of the
product. Doing so may cause fire or electric shock.
WARNING
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Precauon
Operang
•Before using, make sure power supplyand all other parts are
properly connected.
•While operang, if any abnormal condion or malfuncon
is observed, stop using the camera immediately and contact
your dealer.
Handling
•Do not disassemble or tamper with parts inside the camera.
•Do not drop the camera orsubject it to shock orvibraon as
this can damage the camera.
•Clean the clear dome cover with extra care. Scratches and
dust can ruin the quality of the camera image.
Installaon and Storage
•Do not install the camera in areas of extreme temperature,
exceeding the allowed range.
•Avoid installing in humid or dusty environments.
•Avoid installing in places where radiaon is present.
•Avoid installing in places where there are strong magnec
•Avoid installing in places where the camera would be subject
to strong vibraons.
fields and electric signals.
•Never expose the camera to rain or water.

Important Safety Instrucons
1. Read these instrucons. - All these safety and operang instrucons should be read before the product is
installed or operated.
2. Keep these instrucons. - The safety, operang and use instrucons should be retained for future reference.
3. Heed all warnings. - All warnings on the product and in the operang instrucons should be adhered to.
4. Follow all instrucons. - All operang and use instrucons should be followed.
5. Do not use this device near water. - For example: near a bath tub, wash bowl, kitchen sink, laundry tub, in a wet
basement; near a swimming pool; etc.
6. Clean only with dry cloth. - Unplug this product from the wall outletbefore cleaning. Do not use liquid cleaners.
7. Do not block any venlaon openings. Install in accordance with the manufacturer’s instrucons. - Slots and
openings in the cabinet are provided for venlaon, to ensure reliable operaon of the product, and to protect it
from over-heang. The openings should never be blocked by placing the product on bed, sofa, rug or other similar
surface. This product should not be placed in a built-in installaon such as abookcase or rack unless proper
venlaon is provided and the manufacturer’s unstrucons have been adhere to.
8.
that produce heat.
Do not install near any heat sources such as radiators, heat registers, or other apparatus (including amplifiers)
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plughas two blades with
one wider than the other. A grounding type plughas twoblades anda third groundingprong. The wide blade
or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched parcularly at plugs, convenience receptacles, and
the point where they exit from the apparatus.
Only use aachments/accessories specified by the manufacturer.
11.
12.
manufacturer, or sold with the apparatus. When a cart is used, use
Use only with cart, stand, tripod, bracket, or table specified by the
cauon when moving the cart/apparatus combinaon to avoid
injury from p-over.
13. Unplug this apparatus during lightening storms or when unused for long periods of me.
14.
in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the
Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged
apparatus,the apparatus has been exposed torain or moisture, does not operate normally, or has been
dropped.

Disposal of Old Appliances
1. When this crossed-out wheel bin symbol is aached to aproduct it means the product is covered by
the European Direcve 2002/96/EC.
2. All electrical and electronic products should be disposed of separately form the municipal waste
stream stream in accordance to laws designated by the government or the local authories.
3. The correct disposal of your old appliance will help prevent potenal negave consequences for
4. For more detailed informaon about disposal of your old appliance, please contact your city office,
the environment and human health.
waste disposal service or the shop where you purchased the product.
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protecon against harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instrucon manual, may cause
harmful interference to radio communicaons. Operaon of this equipment in a residenal area is likely to cause harmful interference in which case the user
will be required to correct the interferenece at his own expense.

Specificaon
FEATURES Opmized Mulple Profile Streaming
ROI(Region of Interest)
Various web plug-in
Smart AVC
Advanced built in ISP
SPECIFICATION
CAMERA
Image Sensor
Total Pixels
Focal Length
Angle
1/2.9” 2.2M CMOS
2001(H) X 1121(V)
3.6mm, F2.0
D : 109°, H : 94°, V : 50°
Shuer Speed
MIN. Illuminaon
IR
WDR
Day & Night
DNR
Privacy Zone
AGC
Other Image Processing
Auto / Manual (1/15 ~ 1/32000),
An-Flicker, Slow Shuer (off, 2X, 3X,
5X, 6X, 7.5X, 10X)
H2IR, 75
D-WDR
TDN (True day & Night)
3D-DNR
16 Programmable Zone
Auto
Exposure, White balance,
Sharpness, Brightness, Contrast,
Saturaon, Hue
GENERAL
Support Languages
Power
Temperature
Material
Dimensions(DXH)
Weight
(Adaptor is not Included)
DC12V : Max 4.5W
POE IEEE 802.3af Class2 : Max 6W
-20°C ~ 50°C
Aluminum Die-casng
161.7mm x 67.5mm
0.5kg
Cerficaon FCC, CE, ROHS, IP66
I/O & EVENT
Audio In/Out
Alarm In/Out
Video Output
(2nd Video Out)
Event Noficaon
N/A
N/A
N/A
FTP, E-mail
SECURITY & NETWORK
Network Protocol
Security
Programming I/F
IPv4 :
TCP/IP / UDP / AutoIP / RTP(UDP/TCP)
/ RTSP / NTP / HTTP / HTTPS / SSL
/ DNS / DDNS / DHCP / FTP / SMTP
/ ICMP / SNMPv1/v2/v3(MIB-2) /
ONVIF
HTTPS (SSL), IP filtering, 802.1x,
Digest Authencaon
CGI API, ONVIF
English, Japanese, Korean
0.25Lux, 0Lux with IR (F2.0)
ENCODER (VIDEO&AUDIO)
Video Compression
H.265 Profile
Mulple Profile
Streaming
Performance
Video Bitrate
Bitrate Control
Edge Storage
H.264, H.265, MJPEG
MP
1080p30 + CIF(352x288 or 352x240)
p30 with H.264, H.265 + MJPEG
100kbps~10Mbps,
Mul-rate for
Pre
view and Recording
Mul Streaming CBR/VBR at H.264,
H.265(Controllable frame rate and
Bandwidth)
H.264 Profile MP/HP
N/A

Product & Accessories
Introducon -
Camera
Cables
Screw & Plasc Anchor-4pcs Quick Manual Template Sheet
Please check if all the camera and accessories are included in the package.
Torx Wrench
Waterproof cap & Gasket Manual CD

Part Name
Introducon -
Bracket
Pan/Tilt Stoper Screw
DC Power Jack
Lens
RJ-45 Connector
Waterproof cap
Reset Buon

Installaon
Installaon -
1
Template Sheet
2
3
4
To pass cables through the wall/ceiling, drill holes on
the wall/ceiling.
Connect the network cable, power cable respecvely.
See the secon ‘Installaon - Cabling’ for details.
Fix the camera on the wall/ceiling by screw provided.
Aer adjusng the view angle, ghten the Pan/Tilt
stoperscrew.
Reset to the Factory Defaults
Press the reset buon for 5 seconds to return the setup
to the Factory Default.
Warning:
If you press the ‘Reset’ buon, you will lose all seng
data. If needed, please, make a note for further
installaon.
Before installing your camera, you have to read the following cauons.
2. Don’t let the cable to be caught in improper place or the electric line cover to be damaged. Otherwise
1. You have to check whether the locaon can bear five mes of the weight of your camera.
3. When installing your camera, don’t allow any person to approach the installaon site. If you have any
valuable things under the place, move them away.
it may cause a breakdown or fire.
ab
c
Put the Lan cable into (a), then (b) will be assembled to (a)
without making any space.
ghtly. As a final step, (c) need to be assembled to (b)
Loosen the Pan/Tilt stoper screw a lile before fixing the camera.
Reset Buon

Cabling
Installaon -
Power
Two Opons
Use a PoE-enabled switch to connect data and power through a single cable and begin viewing and recording images instantly.
A non-PoE switch will require an adaptor for power transmission.
Ethernet cableEthernet cable
2. Using a Non-PoE Switch
If a PoE-enabled switch is not used, use a power adaptor
for power transmission and non-PoE switch for data
transmission.
Follow the illustraons below to connect the camera
without a PoE-enabled Switch.
1. Using a PoE-Enabled Switch
The Camera is PoE-compliant, allowing transmission of
power and data via a single Ethernet cable.
PoE eliminates the need for the different cables used to
power, record, or control the camera. Follow the illustraon
below to connect the camera to a PoE-enabled switch using
an Ethernet cable.

Dimension
Specificaons -
Unit: mm
67.5
76 70.6
161.7
67.5
70
