Dahua IPC-HDW4431C-A User manual

HD IR Waterproof Network Camera Quick Start Guide
1
HD IR Waterproof Eyeball Network Camera
Quick Start Guide
DH-OEMFactory

HD IR Waterproof Network Camera Quick Start Guide
2
Important Notice
1. Please don’t update the firmware as it is updated from Chinese version and don’t
2. This user manual is taking IPC-HDW4431C-A as an example, but applies to other
models (IPC-HDBW4431R-S, IPC-HDBW4431R-AS, IPC-HDBW4431R-ZS, IPC-HFW4431R-
Z, IPC-HFW4431M-I2, IPC-HDW4433C-A, IPC-HDBW4433R-S(R-AS),(R-ZS)).
Table of Contents
1. Network Configuration..............................................................................................3
1.1 Modify IP Address .........................................................................................................3
1.2 Login WEB Interface.....................................................................................................5
2.Connect to NVR ...........................................................................................................12
2.1 NVR Configuration.....................................................................................................13
2.2 ONVIF NVR Configuration .....................................................................................14
3.Mobile Phone APP.......................................................................................................18
3.1 Downloading and Installation....................................................................................18
3.2 Add Device .....................................................................................................................19
DH-OEMFactory

HD IR Waterproof Network Camera Quick Start Guide
3
1. Network Configuration
Note: Camera power is DC 12V or POE 803.2a.f
In order to make the camera get access to the network smoothly, please plan the useable IP segment
reasonably according to the actual network environment.
1.1 Modify IP Address
IP address can be acquired and modified through quick configuration tool for the cameras which are
accessed via wired network. In this chapter, it will introduce the approach of modifying IP address via
“Quick Configuration Tool”; also you can modify the IP address in the network parameters of the WEB
interface.
Note: Currently the quick configuration tool only supports the cameras which apply to the same
network segment with computer IP address.
Step 1: Install ConfigTooL (download the ToolBox via official website, login the ToolBox, then
install the ConfigTool.)
DH-OEMFactory

HD IR Waterproof Network Camera Quick Start Guide
4
Open the ConfigTool. If the camera is connected correctly，it will show as Figure 1-1.
Figure 1-1
Step 2: Click the icon , input the IP address, which must be the same network segment with
your computer, to target IP as below. Input Subnet Mask and Gateway, and then click . Please
refer to Figure 1-2 for more details.
Figure 1-2
After entrying all information correctly, you will get the dialogue box as Figure 1-3:
DH-OEMFactory

HD IR Waterproof Network Camera Quick Start Guide
5
Figure 1-3
1.2 Login WEB Interface
Note: Different devices may have different WEB interfaces, the figures below just for reference.
Install WEB plug-in when you use WEB client for the first time, the exact operation steps are shown
as follows:
Step 1: Two ways can open web interface successfully
1): Based on above steps, click icon , then it will connect IE directly. Please refer to Figure1-4.
2): Open IE and input the modified camera IP address in the address bar.
Figure 1-4
DH-OEMFactory

HD IR Waterproof Network Camera Quick Start Guide
6
Step 2: Page turn to the login interface shown as below, input your user name and password. Default
factory user name and passwords is admin ,( new model camera is uninitialized, Need to set a new
password to initialize it) then click “login”. See Figure 1-5 for more details.
Figure 1-5
Note: The system will display “Update Password” prompt box for your first login, users need to
modify the password and save it properly. Write it down in case forget.. See Figure 1-6.
Figure 1-6
DH-OEMFactory

HD IR Waterproof Network Camera Quick Start Guide
7
Step 3: After logining successful , you may see the interface shown as in Figure 1-7.
Figure 1-7
Click on “Please click here to download and install the plug-in”. The system pops up a
warning information siad “do you want to run or save this file? ”. See Figure 1-8
Figure 1-8
DH-OEMFactory

HD IR Waterproof Network Camera Quick Start Guide
8
Click the “run” directly or save the file ,then install it. Follow the following steps,see Figure 1-
9 and Figure 1-10.
Figure 1-9
Figure 1-10
DH-OEMFactory

HD IR Waterproof Network Camera Quick Start Guide
9
When plug-in installation is completed, the page will close directly followed by the web-end
refreshment, then video captured will be shown.
Conditions
Conditions: Adjust image quality--see Figure 1-11.
Figure 1-11
Zoom and Focus --see Figure 1-12 (Note: Only motorized vari-focal devices support focus and
zoom function, like IPC-HDBW4431R-ZS, IPC-HFW4431R-Z)
Adjust focal length: after zoomed, set “Speed” and press “+”, “-“ or drag the sliding block directly.
Adjust definition: after focused, set “Speed” and press “+”, “-“ or drag the sliding block directly.
Note: SPEED is to set the length by pressing “+” and “-
When adjusting the focal length of the lens or click “Auto Focus”, the image definition will be
After try many times, the image may fails to be adjusted clearer, click “Restore All’ to reset the lens
DH-OEMFactory

HD IR Waterproof Network Camera Quick Start Guide
10
Click “Refresh” ,device will automatically synchronize the hardware to the location of sliding
block of lens zoom and focus.
Figure 1-12
Video
Set the Camera Parameters:
Select “Setup > Camera > Video > ” and the system will display the interface of “Video”. See
Figure 1-13
Figure 1-13
DH-OEMFactory

HD IR Waterproof Network Camera Quick Start Guide
11
SMTP (e-mail)
The SMTP interface --See Figure 1-14
Figure 1-14
Motion Detection
Select “Setup > Event > Video Detection > Motion Detection” and the system will display the
interface of “Motion Detection” -- see Figure 1-15 and Figure 1-16
Figure 1-15
Select “ Area setup” to set the motion detection area --see Figure 1-16
Figure 1-16
DH-OEMFactory

HD IR Waterproof Network Camera Quick Start Guide
12
IVS
IVS included some events. --see Figure 1-17
Figure 1-17
2. Connect to NVR
There are two ways that connect to NVR (two types of NVR), shown in Figure 2-1
Figure 2-1
NVR:
Connect camera to NVR, the NVR will auto adjust to camera IP, don’t need modify camera IP.
ONVIF NVR (Third-party brand)
1) Camera connect to NVR that have POE Ports, the camera IP Network Segment must be same as
the NVR Port’s. (e.g.: Hikvison NVR Port’s IP Network Segment is 192.168.254.XX, so the camera IP
must be 192.168.254.XX.)
DH-OEMFactory

HD IR Waterproof Network Camera Quick Start Guide
13
2) Camera connect to NVR via POE switch or router (NVR have not POE ports), the camera IP
Network Segment Should be same as the POE switch or router’s. (e.g.: router’s IP is 192.168.1.1, so the
camera IP must be 192.168.1.XX).
2.1 NVR Configuration
Search the IP by the Configtool. If your NVR is uninitialized, you need to initialize the device.
Login the NVR via browser, install the plugins.
2.1.1 Cameras that have default password “admin” ( Model as IPC-HDW4431C-A, 4431R-ZS,
4431R-Z)
Cameras can plug and play .
2.1.2.Uninitialized camera (Model as IPC-HDW4433C-A, IPC-HDBW4433R-AS).
Cameras can plug and play，and the uninitialized camera will initialized via NVR, and the password
is same as the NVR’s.
2.1.3.Camera password is not the “admin”
Cameras can’t plug and play, Need connect it to NVR by manual.
Select “Setting > Camera > Registration > modify , enter the camera password to add it, then Camera
connecte to NVR. --See Figure 2-2 and Figure 2-3, Figure 2-4.
Figure2-2
DH-OEMFactory

HD IR Waterproof Network Camera Quick Start Guide
14
Figure 2-3
Figure 2-4
2.2 ONVIF NVR Configuration (Hikvison NVR for example)
2.2.1 camera connect to Hikvison NVR POE Ports.(NVR have POE Ports)
Note: Check your NVR preview and playback max resolution supported before configuration.
Step1:Log in the camera via browser. Adjust camera resolution is higher than NVR max preview
resolution, and Synchronize Time in accordance with your local time. See Pics Figure 2-5, Figure 2-6
Figure 2-5
DH-OEMFactory

HD IR Waterproof Network Camera Quick Start Guide
15
Figure 2-6
Step2: Hikvison NVR POE Ports’s IP Segment is 192.168.254.XX, Change camera IP to
192.168.254.XX,
shown in Figure 2-7, then connect camera to NVR port.
Figure 2-7
Step3: Manual add camera to NVR
Log in the Hikvison NVR, Select “Configuration> Camera Management > Registration, See Figure 2-8
Figure 2-8
DH-OEMFactory

HD IR Waterproof Network Camera Quick Start Guide
16
Click camera channel , then click “modify”, adding method select “manual”, enter camera IP,
protocol select “ ONVIF”, Port “80”, enter the camera password, click “OK”. Shown in Figure 2-9
Figure 2-9
Refresh several times, status will be online, connected successful. Shown in Figure 2-10.
Figure 2-10
2.2.2 Camera connect to Hikvison NVR via Router or POE Switch (NVR havn’t POE Ports)
The camera , NVR and router IP must be in same Segment, such as the Router IP is 192.168.1.1,the
camera and NVR IP have to be 192.168.1.XX. Log in the NVR, Select “Configuration> Camera
Management > IP camera, See Figure 2-11
DH-OEMFactory

HD IR Waterproof Network Camera Quick Start Guide
17
Figure 2-11
Click the camera channel , then click “Quick Add”, select the camera, click “ok”, then click
“modify”, enter the camera IP, Protocol select “ ONVIF”, Port is “80”, enter the camera password, click
“OK”. Shown in Figure 2-12, Figure 2-13
Figure 2-12
Figure 2-13
Refresh several times, it will be online status, connected successful. Shown in Figure 2-14
DH-OEMFactory

HD IR Waterproof Network Camera Quick Start Guide
18
Figure 2-14
3. Mobile Phone APP
3.1 Downloading and Installation
The product has Android and iOS versions
Android:
Open Google Play app in your smart phone. In Google Play, search gDMSS Plus. The first app
searched out should be this software. See Figure 3- 1.
Figure 3- 1
iOS:
Open App Store APP in smart phone. search iDMSS Plus. The first app searched out should be this
software. See Figure 3- 2.
Figure 3- 2
