Dahua DHI-ARD1731-W2 User manual

Wireless PIR–Camera
User’s Manual
ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. V1.0.1

User’s Manual
I
Foreword
General
This manual introduces the installation, functions and operations of the Wireless PIR–Camera
(hereinafter referred to as the "PIR–Camera"). Read carefully before using the device, and keep the
manual safe for future reference.
Model
DHI-ARD1731-W2; DHI-ARD1731-W2 (868)
Safety Instructions
The following signal words might appear in the manual.
Signal Words
Meaning
DANGER
Indicates a high potential hazard which, if not avoided, will result in
death or serious injury.
WARNING
Indicates a medium or low potential hazard which, if not avoided,
could result in slight or moderate injury.
CAUTION
Indicates a potential risk which, if not avoided, could result in
property damage, data loss, reductions in performance, or
unpredictable results.
TIPS Provides methods to help you solve a problem or save time.
NOTE Provides additional information as a supplement to the text.
Revision History
Version Revision Content Release Time
V1.0.1
●Added information on the versions of the DMSS
app and the hub.
●Added a note that the PIR–Camera does not
support the function of the repeater (DHI-ARA43
series) to transmit images from the PIR–Camera to
the hub.
August 2022
V1.0.0 First release. June 2022
Privacy Protection Notice
As the device user or data controller, you might collect the personal data of others such as their face,
fingerprints, and license plate number. You need to be in compliance with your local privacy
protection laws and regulations to protect the legitimate rights and interests of other people by
implementing measures which include but are not limited: Providing clear and visible identification
to inform people of the existence of the surveillance area and provide required contact information.

User’s Manual
II
About the Manual
●The manual is for reference only. Slight differences might be found between the manual and the
product.
●We are not liable for losses incurred due to operating the product in ways that are not in
compliance with the manual.
●The manual will be updated according to the latest laws and regulations of related jurisdictions.
For detailed information, see the paper user’s manual, use our CD-ROM, scan the QR code or visit
our official website. The manual is for reference only. Slight differences might be found between
the electronic version and the paper version.
●All designs and software are subject to change without prior written notice. Product updates
might result in some differences appearing between the actual product and the manual. Please
contact customer service for the latest program and supplementary documentation.
●There might be errors in the print or deviations in the description of the functions, operations
and technical data. If there is any doubt or dispute, we reserve the right of final explanation.
●Upgrade the reader software or try other mainstream reader software if the manual (in PDF
format) cannot be opened.
●All trademarks, registered trademarks and company names in the manual are properties of their
respective owners.
●Please visit our website, contact the supplier or customer service if any problems occur while
using the device.
●If there is any uncertainty or controversy, we reserve the right of final explanation.

User’s Manual
III
Important Safeguards and Warnings
This section introduces content covering the proper handling of the PIR–Camera, hazard protection,
and protection of property damage. Read carefully before using the PIR–Camera, and comply with
the guidelines when using it.
Operation Requirements
●Make sure that the power supply of the PIR–Camera works properly before use.
●Do not pull out the power cable of the PIR–Camera while it is powered on.
●Only use the PIR–Camera within the rated power range.
●Transport, use and store the device under allowed humidity and temperature conditions.
●Prevent liquids from splashing or dripping on the device. Make sure that there are no objects
filled with liquid on top of the PIR–Camera to avoid liquids flowing into it.
●Do not disassemble the PIR–Camera.
Installation Requirements
●Connect the PIR–Camera to the adapter before power on.
●Strictly abide by local electrical safety standards, and make sure that the voltage in the area is
steady and conforms to the power requirements of the PIR–Camera.
●Do not connect the PIR–Camera to more than one power supply. Otherwise, the PIR–Camera
might become damaged.
●Observe all safety procedures and wear required protective equipment provided for your use
while working at heights.
●Do not expose the PIR–Camera to direct sunlight or heat sources.
●Do not install the PIR–Camera in humid, dusty or smoky places.
●Install the PIR–Camera in a well-ventilated place, and do not block the ventilator of the device.
●Use the power adapter or case power supply provided by the device manufacturer.
●The power supply must conform to the requirements of ES1 in IEC 62368-1 standard and be no
higher than PS2. Note that the power supply requirements are subject to the device label.
●Connect class I electrical appliances to a power socket with protective earthing.

User’s Manual
IV
Table of Contents
Foreword ........................................................................................................................................................................................................I
Important Safeguards and Warnings............................................................................................................................................ III
1 Introduction ............................................................................................................................................................................................ 1
1.1 Overview........................................................................................................................................................................................ 1
1.2 Technical Specifications......................................................................................................................................................... 1
2 Checklist.................................................................................................................................................................................................... 4
3 Design......................................................................................................................................................................................................... 5
3.1 Appearance................................................................................................................................................................................... 5
3.2 Dimensions ................................................................................................................................................................................... 6
4 Power On................................................................................................................................................................................................... 7
5 Adding the PIR–Camera to the Hub ............................................................................................................................................ 9
6 Installation.............................................................................................................................................................................................10
6.1 Field of View...............................................................................................................................................................................10
6.2 Installing the PIR–Camera...................................................................................................................................................10
7 Configuration .......................................................................................................................................................................................12
7.1 Viewing Status ..........................................................................................................................................................................12
7.2 Configuring the PIR–Camera .............................................................................................................................................13
Appendix 1 Cybersecurity Recommendations........................................................................................................................16

User’s Manual
1
1 Introduction
1.1 Overview
With its built-in 2-MP HD camera and CMOS image sensor, wireless PIR–Camera detects intrusions
and captures high-definition snapshots. It is a wireless passive infrared detector that sends
snapshots through the Wi-Fi and Ethernet connection to your phone and ARC (alarm center), for the
causes of intrusions to be effectively identified.
The camera is also uniquely designed to only take snapshots when an intrusion occurs, eliminating
the need to install cameras to constantly monitor scenes. Built to keep your family and business safe,
the entire data transmission process is encrypted and the camera does not actively obtain your
private information.
1.2 Technical Specifications
This section contains technical specifications of the PIR–Camera. Please refer to the ones that
correspond with your model.
Table 1-1 Technical specifications
Type Parameter Description
Video
Field of View 88° (H); 68° (V)
Image Type JPEG
Resolution 1600 × 1200; 1280 × 960; 640 × 480; 320 × 240
Detection Speed 0.3 m/s–3 m/s (0.98 ft/s–9.84 ft/s)
Frame Rate 2
Illumination Mode Infrared Light
Illumination
Range 12 m (39.37 ft)
Day/Night Switch Color/Black & White
Function
Indicator Light 1 × green alarm indicator
Button 1 × power switch
Remote Update Cloud update
Low Battery
Detection Yes
Battery Level
Display Yes
Tamper Tamper alarm
Signal Strength RF Signal test
RF-HD signal test

User’s Manual
2
Type Parameter Description
Carrier Frequency DHI-ARD1731-W2(868):
868.0 MHz–868.6 MHz
DHI-ARD1731-W2:
433.1 MHz–434.6 MHz
Communication
Distance
DHI-ARD1731-W2(868):
RF: Up to 1,600 m (5,249.34
ft) in an open space
RF-HD: Up to 300 m
(984.25 ft) in an open
space
DHI-ARD1731-W2:
RF: Up to 1,200 m
(3,937.01 ft) in an open
space
RF-HD: Up to 300 m
(984.25 ft) in an open
space
Communication
Mechanism Two-way
Frequency
Hopping Yes
Encryption Mode AES128
General
Power Supply CR123A × 3
Battery Life 4 years (if triggered twice a week with a battery
efficiency of 70%)
Operating
Temperature –10 °C to +55 °C (+14 °F to +131 °F) (indoor)
Operating
Humidity 10%–90% (RH)
Product
Dimensions 127.6 mm× 71.0 mm× 53.2 mm (5.02" × 2.80" × 2.09")
Packaging
Dimensions 121.0 mm× 65.0 mm× 170.0 mm (4.76" × 2.56" × 6.69")
Net Weight 202 g (0.45 lb)
Gross Weight 333 g (0.73 lb)
Installation Wall mount
Casing PC + ABS
Certifications CE CE; FCC
Technical
Detection Mode PIR
Sensitivity 3 levels adjustable
Detection Range 12 m (39.37 ft) (86°) with installation height of 2.2 m
(7.22 ft)
Detection Speed 0.3 m/s–3 m/s (0.98 ft/s–9.84 ft/s)
Pet Immunity
Level ≤18 kg (39.68 lb)
White Light
Resistance Level 2000 lux
Two-way Digital
Temperature
Compensation
Yes

User’s Manual
3
Type Parameter Description
Scenario Indoor
Operating Current 65 μA
Alarm Current Day: 170 mA (Avg); 800 mA (Max) Night: 230 mA (Avg);
2.8 A (Max)

User’s Manual
4
2 Checklist
Figure 2-1 Checklist
Table 2-1 Checklist
No. Item Name Quantity No. Item Name Quantity
1 PIR–Camera 1 5 Quick start guide 1
2 Double-sided adhesive
tape 1 6 Legal and regulatory
information 1
3 Screw package 2 7 Battery 3
4 QR code 1 - - -

User’s Manual
5
3 Design
3.1 Appearance
Figure 3-1 Appearance
Table 3-1 Structure
No. Name Description
1 IR light Provides IR light for dark environments.
2 Camera Captures images when an intrusion alarm is triggered.
3 Indicator
●Flashes green quickly: Pairing mode or reduced
sensitivity mode.
●Solid green: An alarm event was triggered.
●Solid green for 2 seconds: Pairing successful.
●Slowly flashes green for 3 seconds: Pairing failed.
4 Tamper switch When the tamper switch is released, the tamper alarm will be
triggered
5 Bracket tamper switch (Optional) If the bracket is removed, the tamper alarm will be
triggered.
6 Battery Insert batteries to power on the PIR–Camera.
7 On/off switch Turn on or turn off the PIR–Camera.
8 Back cover If the back cover is opened, the tamper alarm will be
triggered.

User’s Manual
6
3.2 Dimensions
Figure 3-2 Dimensions (mm [inch])

User’s Manual
7
4 Power On
Step 1 Loosen the screw to open the PIR–Camera.
Figure 4-1 Loosen the screw
Figure 4-2 Open the PIR–Camera
Step 2 Insert batteries into the PIR–Camera.
●When inserting the batteries, make sure that they are all charged to the same level.
●When inserting the batteries, align the "+" symbols on the battery to those on the PIR–
Camera.

User’s Manual
8
Figure 4-3 Insert batteries
Step 3 Turn on the PIR–Camera.
Figure 4-4 Turn on the PIR–Camera

User’s Manual
9
5 Adding the PIR–Camera to the Hub
Before you connect PIR–Camera to the hub, install the DMSS app to your phone. This manual uses
iOS as an example.
●Make sure that the version of the DMSS app is 1.99 or later, and the hub is V1.002.R.220625 or
later.
●Make sure that you have already created an account, and added the hub to DMSS.
●Make sure that the hub has a stable internet connection.
●Make sure that the hub is disarmed.
Step 1 Go to the hub screen, and then tap to add the PIR–Camera.
Step 2 Tap to scan the QR code at the bottom of the PIR–Camera, and then tap Next.
Step 3 Tap Next after the PIR–Camera has been found.
Step 4 Follow the on-screen instructions and switch the PIR–Camera to on, and then tap Next.
Step 5 Wait for the pairing.
Step 6 Customize the name of the PIR–Camera, and select the area, and then tap Completed.

User’s Manual
10
6 Installation
6.1 Field of View
Field of view of the PIR are shown below.
When installing and using the PIR–Camera, make sure there are no objects partially or fully
obscuring the detector's field of view.
Figure 6-1 Field of View
6.2 Installing the PIR–Camera
Prior to installation, add the PIR–Camera to the hub and test the signal strength and RF-HD. We
recommend installing the PIR–Camera in a place with a signal strength of at least 2 bars.
Step 1 Drill four holes into the wall according to the hole positions of the PIR–Camera, and then
put the expansion bolts into the holes.

User’s Manual
11
Figure 6-2 Drill holes
Step 2 Close the PIR–Camera.
Figure 6-3 Close the PIR–Camera
Step 3 Secure the PIR–Camera with a screw.
Figure 6-4 Secure the PIR–Camera

User’s Manual
12
7 Configuration
You can view and edit general information of the PIR–Camera.
7.1 Viewing Status
On the hub screen, select a PIR–Camera from the accessory list, and then you can view the status of
the PIR–Camera.
Table 7-1 Status
Parameter Value
Temporary Deactivate
The status for whether the functions of the PIR–Camera are enabled or
disabled.
●: Enable.
●: Only disable tamper alarm.
●: Disable.
Temperature The temperature of the environment.
Signal Strength
The signal strength between the hub and the PIR–Camera.
●: Low.
●: Weak.
●: Good.
●: Excellent.
●: No.
Battery Level
The battery level of the PIR–Camera.
●: Fully charged.
●: Sufficient.
●: Moderate.
●: Insufficient.
●: Low.
Anti-tampering Status The tamper status of the PIR–Camera, which reacts to the detachment
of the body.
Online Status
Online and offline status of the PIR–Camera.
●: Online.
●: Offline.
Entrance Delay Time Entrance delay time.
Exit Delay Time Exit delay time
24 H Protection Zone
Status
Active status of the 24 h protection zone.
●: Enable.
●: Disable.
Sensitivity Sensitivity level during a shock alarm.

User’s Manual
13
Parameter Value
Transmit through
Repeater
The status of whether the PIR–Camera forwards its messages to the
hub through the repeater.
The PIR–Camera does not support the function of the repeater (DHI-
ARA43 series) to transmit images from the PIR–Camera to the hub.
Program Version The program version of the PIR–Camera.
7.2 Configuring the PIR–Camera
On the hub screen, select a PIR–Camera from the accessory list, and then tap to configure the
parameters of the PIR–Camera.
Table 7-2 Parameter description
Parameter Description
Snapshot Test
Tap Snapshot Test on the PIR–Camera screen, and then the
PIR–Camera will take some snapshots. You can view a
notification message in the message list afterwards.
We recommend you to use snapshot test function when you
install the PIR–Camera for the first time. This will help you to
find the most suitable locations and angles.
Device Configuration
●View PIR–Camera name, type, SN and device model.
●Edit PIR–Camera name, and then tap Save to save
configuration.
Area Select the area to which the PIR–Camera is assigned.
Temporary Deactivate
Whether send commands to the alarm hub.
●Tap Enable, and then the PIR–Camera will send commands
to the hub. Enable is set by default.
●Tap Only Disable Tamper Alarm, and then the system will
only ignore tamper alarm messages.
●Tap Disable, and then the PIR–Camera will not send
commands to the hub.

User’s Manual
14
Parameter Description
Snapshot Config
Configure the number of snapshots that can be taken at a time,
the interval and the parameters of the image.
●Tap Times to Take Snapshots, and then select times from
1 to 10.
●Tap Trigger Interval, and then you can select 10, 30, 60, or
120 seconds.
●Tap Image resolution and Quantity, and then for the
image resolution, you can select 1600 × 1200, 1280 × 960,
640 × 480, or 320 × 240. For the image quantity, you can
select between 1 and 20.
For image resolution 1600 × 1200, you can only select
between 1 and 10 for the image quantity.
LED Indicator
LED Indicator is enabled by default. For details on indicator
behavior, see "3.1 Appearance".
If LED Indicator is disabled, the LED indicator will remain off
regardless of whether the PIR–Camera is functioning normally
or not.
Over-temperature Alarm
Enable the Over-temperature Alarm function, and then the
alarm will be triggered when the temperature of the area where
the PIR–Camera is installed is higher or lower than the defined
one.
24 H Protection Zone
Enable the 24 H Protection Zone function, and then the
accessory located in the 24 h protection zone is always active
whether the security system is configured in the armed mode
or not.
Home Mode Enable the Home Mode, and then the selected accessories
under the hub will be armed.
Delay Mode under Home
Mode
Enable the Delay Mode under Home Mode, the selected
accessory under the hub will be armed and the alarm will not
be triggered until the end of customized delay time.
Only enable Home Mode first can Delay Mode under Home
Mode take effect.

User’s Manual
15
Parameter Description
Delay Time
The system provides you with time to leave or enter the
protection zone without alarm.
●Delay Time for Entering Arming Mode: When you enter
the zone, if you do not disarm the system before the delay
ends, an alarm will be triggered.
Make sure that the delay time for entering arming mode is
no longer than 45 seconds in order to comply with
EN50131-1.
●Delay Time for Exiting Arming Mode: When you are in the
zone and arm the system, if you do not leave the zone
before the delay ends, an alarm will be triggered. You can
select from 0 s to 120 s.
The arming mode will be effective after the delay time.
Sensitivity
●Sensitivity level during a shock alarm.
●Select from low, medium and high.
Siren Linkage When an alarm is triggered, the accessories will report the alarm
events to the hub and alert with siren.
Signal Strength Detection Test the current signal strength.
Detector Test Tap Start Detection to test the status of the PIR–Camera.
RF-HD Test Tap Start Detection to test the signal strength for transmitting
images between the PIR–Camera and the hub.
Transmit Power
Select from high, low, and automatic.
The higher transmission power levels are, the further
transmissions can travel, but power consumption increases.
If you select Low, the PIR–Camera will enter into reduced
sensitivity mode.
Cloud Update Update online.
Delete
Delete the PIR–Camera.
Go to the hub screen, select the PIR–Camera from the
accessory list, and then swipe left to delete it.
