Dahua EVS50 Series User manual

I
Embedded Video Storage
(EVS50/EVS70)
Quick Start Guide
V2.1.2

I
Foreword
General
This User’s Manual (hereinafter referred to as "the Manual") introduces the functions and operations
of the EVS series (hereinafter referred to as "the Device").
Models
Series Model
Middle-class Middle-class 16-HDD single-controller, middle-class 24-HDD single-controller,
middle-class 36-HDD single-controller, middle-class 48-HDD single-controller
High-end High-end 24-HDD single-controller, high-end 48-HDD single-controller
Safety Instructions
The following signal words might appear in the manual.
Signal Words Meaning
DANGER
Indicates a high potential hazard which, if not avoided, will result in
death or serious injury.
WARNING
Indicates a medium or low potential hazard which, if not avoided,
could result in slight or moderate injury.
CAUTION
Indicates a potential risk which, if not avoided, could result in
property damage, data loss, reductions in performance, or
unpredictable results.
TIPS Provides methods to help you solve a problem or save time.
NOTE Provides additional information as a supplement to the text.
Revision History
Version Revision Content Release Time
V2.1.2 Updated the format according to the latest template. June 2021
V2.1.1 Update the manual according to the latest template. May 2019
V2.1.0
Update information about GDPR.
Add AI playback and routing functions.
Update user management and playback functions.
October 2018
V2.0.2 Add FCC information. September 2018

II
Version Revision Content Release Time
V2.0.1 Add privacy protection notice. May 2018
V2.0.0 Baseline switch. October 2017
V1.0.0 First release. January 2017
About the Manual
The manual is for reference only. Slight differences might be found between the manual and the
product.
We are not liable for losses incurred due to operating the product in ways that are not in
compliance with the manual.
The manual will be updated according to the latest laws and regulations of related jurisdictions.
For detailed information, see the paper user’s manual, use our CD-ROM, scan the QR code or visit
our official website. The manual is for reference only. Slight differences might be found between
the electronic version and the paper version.
All designs and software are subject to change without prior written notice. Product updates
might result in some differences appearing between the actual product and the manual. Please
contact customer service for the latest program and supplementary documentation.
There might be errors in the print or deviations in the description of the functions, operations and
technical data. If there is any doubt or dispute, we reserve the right of final explanation.
Upgrade the reader software or try other mainstream reader software if the manual (in PDF
format) cannot be opened.
All trademarks, registered trademarks and company names in the manual are properties of their
respective owners.
Please visit our website, contact the supplier or customer service if any problems occur while
using the device.
If there is any uncertainty or controversy, we reserve the right of final explanation.

III
Important Safeguards and Warnings
This section introduces content covering the proper handling of the Device, hazard prevention, and
prevention of property damage. Read carefully before using the Device, comply with the guidelines
when using it, and keep the manual safe for future reference.
Operation Requirement
Transport, use and store the Device under allowed humidity and temperature conditions.
Prevent liquids from splashing or dripping on the Device. Make sure that there are no objects
filled with liquids on top to avoid liquids flowing into the Device.
Do not disassemble the Device.
Only use the Device within the rated power range.
Make sure that the power supply of the Device works properly before use.
Do not pull out the power cable of the Device while it is powered on.
The appliance coupler is a disconnection device. Keep a convenient angle when using it.
Do not insert or take out the expansion drawer without power off first.
Installation Requirements
Keep the Device installed horizontally on the stable place to prevent it from falling.
Observe all safety procedures and wear required protective equipment provided for your use
while working at height.
Do not expose the Device to direct sunlight or heat source.
Do not install the Device in humid, dusty or smoky places.
Install the Device in a well-ventilated place, and do not block the ventilator of the Device.
Strictly abide by local electrical safety standards, and make sure that the voltage in the area is
steady and conforms to power requirements of the Device.
Use the recommended power cables in the region and conform to the rated power specification.
Use the power adapter or case power supply provided by the Device manufacturer.
Connect the Device with the adapter before power on.
Do not connect the Device to more than one power supply. Otherwise, the Device might be
damaged.
The power supply must conform to the requirements of ES1 in IEC 62368-1 standard and no
higher than PS2. Note that power supply requirements are subject to the Device label.
Connect the class I electrical appliance to a power socket with protective earthing.
Maintenance Requirements
Improper battery use might result in fire, explosion, or inflammation.
When replacing battery, make sure that the same model is used.

IV
Table of Contents
Foreword............................................................................................................................................................ I
Important Safeguards and Warnings............................................................................................................. III
1 Overview ........................................................................................................................................................ 1
Introduction .................................................................................................................................................................................1
Front Panel....................................................................................................................................................................................1
Rear Panel .....................................................................................................................................................................................2
2 Installation and Power Up............................................................................................................................. 4
Installing HDD .............................................................................................................................................................................4
2.1.1 Middle-class 16-HDD Single-controller Series...................................................................................................4
2.1.2 Other Series.....................................................................................................................................................................5
Powering Up ................................................................................................................................................................................6
2.2.1 Preparation......................................................................................................................................................................6
2.2.2 Powering Up the Device.............................................................................................................................................7
3 Web Basic Operations.................................................................................................................................... 8
Connecting the Network.........................................................................................................................................................8
Initializing the Device...............................................................................................................................................................8
Logging in Web.........................................................................................................................................................................10
Initial Configuration ................................................................................................................................................................12
3.4.1 Setting IP........................................................................................................................................................................12
3.4.2 Adding Remote Device.............................................................................................................................................16
3.4.3 Configuring Record Plan..........................................................................................................................................22
3.4.4 Enabling Record Function .......................................................................................................................................24
Video Direct Storage ...............................................................................................................................................................26
AI Playback .................................................................................................................................................................................27
IP SAN ...........................................................................................................................................................................................30
3.7.2 Creating Storage Pool ...............................................................................................................................................31
3.7.3 Managing Share Account ........................................................................................................................................32
3.7.4 Setting Share Folder ..................................................................................................................................................34
3.7.5 Setting FTP Parameters ............................................................................................................................................37
3.7.6 Opening Share Services ...........................................................................................................................................37
RAID Management ..................................................................................................................................................................38
3.8.1 Creating RAID ...............................................................................................................................................................38
3.8.2 Hotspare Management.............................................................................................................................................41
Cybersecurity Recommendations ............................................................................................. 43

1
1Overview
Introduction
The Device is designed for the management, storage and application of high-definition video data. It
uses Linux operation system and professional customized hardware platform, and it is configured with
multiple Hard Disk Drive (HDD) management system, front-end HD device management system, HD
video analysis system and large capacity video storage system.
It adopts high-traffic data network transmission & forward technology and multi-channel video
decoding & display technology, and realizes intelligent management, secure storage, fast forwarding
and HD decoding of large capacity and multi-channel HD video data.
The Device provides standard network file sharing service and offers integrated IP SAN/NAS solution.
It provides centralized storage solutions with large capacity, high scalability and high security for all
kinds of video monitoring systems.
The contents below are introduced in the example of middle-class 24-HDD single-controller.
Functions of other series are similar. Refer to the actual devices when necessary.
Front Panel
Front panel
Table 1-1 Front panel interfaces
No. Indicator/Button Description
1 Power button
Turns on or off the device. This button keeps blue light on when
the device is power on.
If the device is off, press this button to turn the device on.
To turn off the Device, press and hold this button for five
seconds.
2 HDD status
indicator
The light is out when the HDD is in normal operation.
The blue light keeps on if no HDD, HDD error or insufficient
HDD space.
3 Alarm status
indicator
The light is out when the device is in normal operation.
The red light keeps on when the power fails or the
temperature/fan is abnormal.

2
No. Indicator/Button Description
4 Network status
indicator
The blue light keeps on if there is network failure, IP conflict or MAC
conflict.
Rear Panel
Rear panel (5 Ethernet ports)
Rear panel (7 Ethernet ports)

3
Rear panel (9 Ethernet ports)
Table 1-2 Rear panel interfaces
No. Interface Description
1 Fan Used for case cooling.
2 Power
interface Connects AC power.
3 Main control
module See Table 1-3.
Table 1-3 Main control module interfaces
Interface/Indicator Description
1–4/5–8 Gigabit data port. Used for data transmission.
USB3.0 Connects the mouse and USB storage devices.
eSATA eSATA interface.
SAS1, SAS2 Connects the IN port of the expansion drawer.
Web Gigabit management port. Can be used as data port.
RS232 RS232 interface.
10G-1, 10G-2
10 gigabit port.
Devices of different models have different numbers of Ethernet ports and 10
gigabit ports. See the actual device.
Link/ACT Status indicator of the 10 gigabit port.

4
2Installation and Power Up
Installing HDD
The HDD is not installed by default on factory delivery. You need to install it by yourself.
WARNING
Some devices are heavy and should be carried jointly by several persons to avoid any personnel
injury.
2.1.1 Middle-class 16-HDD Single-controller Series
Press the red button on the HDD box in the front panel and unlock the handle. See Figure 2-
1.
Opening the handle
Pull out to take the empty HDD box. See Figure 2-2.
HDD box
Put the HDD into the disk box and fasten the screws on both sides of the box. See Figure 2-3.

5
Fastening the screws
To avoid any damage to the slot, do not close the handle if the HDD box has not been pushed
to the bottom.
Insert the HDD box into the HDD slot, push it to the bottom, and then lock the handle.
2.1.2 Other Series
Press the red button on the HDD box in the front panel and unlock the handle. See Figure 2-
4.
Opening the handle
Pull out to take the empty HDD box. See Figure 2-5.

6
HDD box
Put the HDD into the disk box and fasten the screws at the bottom of the box. See Figure 2-6.
Locking the screws
To avoid any damage to the slot, do not close the handle if the HDD box has not been pushed
to the bottom.
Insert the HDD box into the HDD slot, push it to the bottom and lock the handle.
Powering Up
2.2.1 Preparation
Properly connect the cables before powering up the Device and check against the following items:
Make sure that GND is connected correctly.

7
Different models of devices need different sources of power supplies. Make sure that all power
lines are connected correctly.
Check whether the supplied power voltage complies with the device requirement.
Check whether the network cables and SAS cables are connected correctly.
2.2.2 Powering Up the Device
This section takes middle-class 16-HDD single-controller series as the example.
Press the power button on the front panel. See Figure 2-7.
Front panel
See "1.2 Front panel" for the corresponding description table of front panel, and check whether the
indicators are normally displayed.
If the indicators are normal, the device is powered up successfully.
If the indicators are abnormal, remove the abnormalities according to the corresponding notes
and power up the Device again.

8
3Web Basic Operations
The system supports device access and management through web at personal computer (PC).
The web client system provides functions such as information viewing, storage management, system
configuration, and playback monitoring.
The following contents are only for your reference. Different models have different functions. See the
corresponding model.
Connecting the Network
Before logging in web, connect your PC and the Device to the same network, and make sure the
network between them is normal.
Connect the device to the network.
Set IP address, subnet mask and gateway IP for PC and the device respectively.
If there is no router in the network, assign IP address of the same network segment for
PC and the Device.
If there is router in the network, set the corresponding gateway IP and subnet mask for
PC and the Device respectively.
The Ethernet ports of the Device have different default IP.
Single-control device: Network interface card (NIC) 1 to NIC n corresponds to default IP
192.168.1.108 to 192.168.n.108.
Dual-control device: Different slots have different default IP.
Slot 1: NIC 1 to NIC n corresponds to default IP 192.168.1.108 to 192.168.n.108.
Slot 2: NIC 1 to NIC n corresponds to default IP 192.168.1.109 to 192.168.n.109.
The ports are for standard NIC, extension NIC, and web management card. You need to
confirm the default IP according to the actual device condition.
On PC, execute the command of Ping device IP address to check whether the network is
connected.
Initializing the Device
When you log in the device for the first time, you need to set the login password of the administrator
account (admin by default).
Open the browser and enter the IP address in the address bar.
The default IP address of single-control device is 192.168.1.108.
The default IP address of dual-control device is 192.168.0.108.
Press Enter.
The system prompts you to install plugins. See Figure 3-1.

9
Install plugins interface
Install plugins only when logging in to the web for the first time.
Click Install. Complete the installation as prompted.
Password setting
In the New Password box, enter the new password.
The password consists of 8 to 32 characters. It combines letter(s), number(s) and symbol(s) (at
least two of them). Set high security password based on the password strength tip.
Click Next.

10
Password protection
In the Assigned Email box, enter the assigned email.
After entering the assigned email, you can reset the admin password through the email.
If you do not need to set the password protection, you can clear the Assigned Email
check box.
If you have not entered the assigned email, you can enter Setup > Account > User to
set it after the initialization is completed.
Click Next.
Device initialization succeeded
Click Ok to complete the device initialization.
Logging in Web
You can access and manage the device remotely by logging in web through the browser.

11
Open the browser, enter the IP address in the address bar, and then press Enter.
Click Install.
The system downloads the control automatically. Click Run to install the control. The Web
login interface is displayed after successful installation. See Figure 3-5.
You need to install the control only when logging in for the first time.
If the system does not allow to download the control, check whether any other plugins
are installed which prohibit the download and reduce the security level of IE.
Web login interface
Enter the user name and password, and then select the network connection type.
The default user name of the administrator is admin, and the password is the one you set in
device initialization. To ensure security, it is recommended that you change the password
regularly and keep it properly.
Click Login.
The SYSTEM MANAGER interface is displayed. See Figure 3-6. For details, see Table 3-1.
System manager

12
Table 3-1 System manager
No. Name Description
1 Function
bar
You can view the basic system information, configure system parameters and
play monitoring images and videos.
2 User
name
Displays the current login user name.
Click at the right side of the user name and you can perform quickly set
configuration and user logout.
Quickly set: You can configure video, AI playback and IP SAN.
Exit: Log out the current user.
3 Alarm Click Alarm and you can search the alarm logs of the Device.
4 Version
Click Version and you can view the version information of the Device,
including video channel, S/N, web, system version, security baseline version,
Bios version and Onvif Client version.
5 Help Click Help and you can get the User's Manual for the Device.
Initial Configuration
3.4.1 Setting IP
Set the Device information such as the IP address and DNS server according to the network plan.
Select Setup > TCP/IP > TCP/IP.
The TCP/IP interface is displayed. See Figure 3-7 and Figure 3-8. For details, see Table 3-2.
Setting TCP/IP (single-control device)

13
Setting TCP/IP (dual-control device)
Table 3-2 TCP/IP setting parameters
Parameter Description
Enable Enter the virtual IP address of the dual-control device.
The main control board and sub control board of dual-control device have
their respective physical IP. After setting the virtual IP, in spite of switching
between the main and sub control boards, the user can always log in web
normally with the virtual IP.
IP Address
Subnet Mask
Default Gateway
Slot
Select the slot of the dual-control device. The corresponding NIC information
is displayed in the list.
Only dual-control device supports this function.
IP Version Select the IP version, including IPv4 and IPv6 formats.
Preferred DNS Enter the IP address of preferred DNS server.
Alternate DNS Enter the IP address of alternate DNS server.
Default NIC Select the default NIC of the Device.
LAN Download Select the check box. If network bandwidth allows, the LAN download speed
is 1.5–2 times of the normal download speed.
Click .

14
Editing
Configure the parameters. For details, see Table 3-3.
Table 3-3 NIC editing parameters
Parameter Description
Ethernet
Card Displays the current NIC name.

15
Parameter Description
Network
Mode
Displays the network mode of the Device.
Single NIC: The NIC is used alone. You can select one NIC to provide HTTP or RTSP
service. You need to set one default NIC (default is Network Card1) to request
the network service started by Email and File Transfer Protocol (FTP). Once the
card is offline, the system triggers a disconnection alarm.
Fault-tolerance: In this mode, the Device communicates with external devices
through NIC bonding. You can focus on one host IP address. At the same time,
you need to set one main card. Usually there is only one running card (main
card). The system will enable the alternate card when the main card
malfunctions. The system will not be offline only if all cards are offline. Notice
that all cards need to be in the same LAN.
Load balance: In this mode, the Device communicates with external devices
through NIC bonding. Workload is balanced among all cards. Their network
loads are generally the same. The system will not be offline only if all cards are
offline. Notice that all cards need to be in the same LAN.
Link aggregation: The system uses NIC bonding to realize communication
function. All bonded NICs are working together and bearing the network load.
The s
ystem allocates the corresponding ports to the specified switches
according to the port load setting. Once one port link malfunctions, the system
stops sending out data from current port. The system can calculate the new load
and specify the new port(s) to send out data. The system calculates again to
specify the port(s) once the malfunction port becomes available.
The Device only supports LACP link aggregation.
The Link Aggregation network mode is available when the switch supports link
aggregation and is configured with link aggregation.
NIC
When the Network Mode is set as Single NIC, you can bond the current NIC to any
other one.
Management NIC does not support this function.
IP Version You can select IPv4 or IPv6 Format. Currently both IP addresses are supported.
MAC
Address Displays the MAC address of the Device.
IP Address
Set the IP address, subnet mask and default gateway of the Device according to the
actual network planning.
Subnet
Mask
Default
Gateway
