Dahua EVS50 Series User manual

Embedded Video Storage Server
(EVS50, EVS70 Series)
Quick Start Guide
V2.1.1

Foreword II
Foreword
General
This Quick Start Guide (hereinafter referred to as "the Guide") introduces the functions and
operations of the EVS series devices (hereinafter referred to as "the Device").
Models
Series
Model
Middle-class
Middle-class 16-HDD single-controller, middle-class 24-HDD
single-controller, middle-class 36-HDD single-controller, middle-class
48-HDD single-controller
High-end
High-end 24-HDD single-controller, high-end 48-HDD single-controller
Safety Instructions
The following categorized signal words with defined meaning might appear in the Guide.
Signal Words
Meaning
Indicates a high potential hazard which, if not avoided, will
result in death or serious injury.
Indicates a medium or low potential hazard which, if not
avoided, could result in slight or moderate injury.
CAUTION
Indicates a potential risk which, if not avoided, may result in
property damage, data loss, lower performance, or
unpredictable result.
ELECTRICITY
Indicates dangerous high voltage.
Take care to avoid coming into contact with electricity.
LASER BEAM
Indicates a laser radiation hazard.
Take care to avoid exposure to a laser beam.
ESD
Electrostatic sensitive devices.
Indicates a device that is sensitive to electrostatic discharge.
TIPS
Provides methods to help you solve a problem or save you
time.
NOTE
Provides additional information as the emphasis and
supplement to the text.

Foreword III
Revision History
Version
Revision Content
Release Time
V2.1.1
Update the manual according to the latest template.
May 2019
V2.1.0
Update information about GDPR
Add AI playback and routing functions
Update user management and playback functions
October 2018
V2.0.2
Add FCC information
September 2018
V2.0.1
Add privacy protection notice
May 2018
V2.0.0
Baseline switch
October 2017
V1.0.0
First release
January 2017
Privacy Protection Notice
As the device user or data controller, you might collect personal data of others such as face,
fingerprints, car plate number, e-mail address, phone number, GPS, and so on. You need to
comply with local privacy protection laws and regulations to protect the legitimate rights and
interests of other people by implementing measures including but not limited to: providing clear
and visible identification to inform data subject the existence of surveillance area, and providing
related contact.
About the Guide
The Guide is for reference only. If there is inconsistency between the Guide and the actual
product, the actual product shall prevail.
We are not liable for any loss caused by the operations that do not comply with the Guide.
The Guide would be updated according to the latest laws and regulations of related
regions. For detailed information, see the paper manual, CD-ROM, QR code or our official
website. If there is inconsistency between paper manual and the electronic version, the
electronic version shall prevail.
All the designs and software are subject to change without prior written notice. The product
updates might cause some differences between the actual product and the Guide. Contact
the customer service for the latest program and supplementary documentation.
There still might be deviation in technical data, functions and operations description, or
errors in print. If there is any doubt or dispute, please refer to our final explanation.
Upgrade the reader software or try other mainstream reader software if the Guide (in PDF
format) cannot be opened.
All trademarks, registered trademarks and company names in the Guide are property of
their respective owners.
Go to our website, contact the supplier or customer service if there is any problem
occurred when using the Device.
If there is any uncertainty or controversy, please refer to our final explanation.

Important Safeguards and Warnings IV
Important Safeguards and Warnings
Operation Requirement
Do not place or install the Device in a place exposed to sunlight or near the heat source.
Keep the Device away from dampness, dust or soot.
Keep the Device installed horizontally on the stable place to prevent it from falling.
Do not drop or splash liquid onto the Device, and make sure there is no object filled with
liquid on the Device to prevent liquid from flowing into the Device.
Install the Device in a well-ventilated place, and do not block the ventilation of the Device.
Operate the Device within the rated range of power input and output.
Do not dissemble the Device.
Transport, use and store the Device under the allowed humidity and temperature
conditions.
Electrical Safety
Improper battery use might result in fire, explosion, or inflammation.
When replacing battery, make sure the same model is used.
Use the recommended power cables in the region and conform to the rated power
specification.
Use the power adapter provided with the Device; otherwise, it might result in people injury
and device damage.
The power source shall conform to the requirement of the Safety Extra Low Voltage (SELV)
standard, and supply power with rated voltage which conforms to Limited power Source
requirement according to IEC60950-1. Please note that the power supply requirement is
subject to the device label.
Connect the Device (I-type structure) to the power socket with protective earthing.
The appliance coupler is a disconnection device. When using the coupler, keep the angle
for easy operation.
