Daikin FWXT Series User manual

INSTALLATION
AND USER MANUAL
FWXT10AATV3(C)
FWXT15AATV3(C)
FWXT20AATV3(C)
Daikin Altherma
Heat pump convector
EKFA
INSTALLATION MANUAL
Daikin Altherma
Aesthetic feet kit
EN
Installation manual
Aesthetic feet kit
IT
Manuale d’installazione
Kit piedini estetici
ES
Manual de instalación
Kit de pies estéticos
DE
Installationshandbuch
Kit design-stützfüsse
FR
Manuel d’installation
Kit de pieds esthétiques
NL
Installatiehandleing
Kit esthetische pootjes
TR
Montaj kılavuzu
Estetik ayak kitini
PT
Manual de instalação
Kit de pés estéticos
EL
ΕΓΧΕΙΡΙΔΙΟ ΕΓΚΑΤΑΣΤΑΣΗΣ
Κιτ με βάσεις στήριξης

2
Compliance
We want to thank you for choosing one of our products.
We are confident that you will be happy with your selection because it represents the state of the art
in the technology of home climate control.
By following the suggestions contained in this manual, the product you have purchased will operate
without problems giving you optimum room temperatures with minimum energy costs.
This unit complies with the following European Directives:
• Low voltage 2014/35/UE;
• Electromagnetic compatibility 2014/30/UE ;
The pictograms in the next chapter provide the necessary
information for correct, safe use of the machine in a rapid,
unmistakable way.
Symbols
U
User
- Refers to pages containing instructions or information
for the user.
I
Installer
- Refers to pages containing instructions or information
for the installer.
S
Service
- Refers to pages containing instructions or information
for the installer TECHNICAL CUSTOMER SERVICE.
Safety pictograms
Generic danger
- Signals that the operation described could cause
physical injury if not performed according to the safety
rules.
Danger of high voltage
- Signals that the operation described could cause
electrocution if not performed according to the safety
rules.
Danger due to heat
- Signals that the operation described could cause
burns if not performed according to the safety rules.
Prohibition
- Refers to prohibited actions.
Editorial pictograms
Daikin Europe N.V.

3
General table of contents
1 GENERAL
1.1 General warnings .............................................................................................................................................................5
1.2 Essential safety rules ........................................................................................................................................................6
1.3 Product range ..................................................................................................................................................................7
1.4 Technical specifications ....................................................................................................................................................7
1.5 Filomuro overall dimensions ..............................................................................................................................................8
1.6 Dimensions and weight for transportation ..........................................................................................................................8
2 INSTALLATION 9
2.1 Unit placement.................................................................................................................................................................9
2.2 Installation procedure........................................................................................................................................................9
2.3 Installation space..............................................................................................................................................................9
2.4 Opening the unit ............................................................................................................................................................10
2.5 Wall installation...............................................................................................................................................................12
2.6 Installation template ........................................................................................................................................................14
2.7 Hydraulic connections ....................................................................................................................................................16
2.8 Condensate drain...........................................................................................................................................................18
2.9 Filling system .................................................................................................................................................................19
2.10 Evacuating the air when filling the system ........................................................................................................................19
2.11 Wiring ............................................................................................................................................................................20
3 CONTROL PANEL INSTALLATION AND CONNECTION 21
3.1 Board connections with TOUCHPAD AND REMOTE CONTROL.......................................................................................21
3.2 Connection for remote control panel ...............................................................................................................................22
4 INSTRUCTIONS FOR USE WITH TOUCH-SCREEN AND REMOTE CONTROL 26
4.1 Warnings .......................................................................................................................................................................26
4.2 Management of the unit with the touch-screen and remote control ...................................................................................26
4.3 Functional description.....................................................................................................................................................27
4.4 Troubleshooting..............................................................................................................................................................29
5 INSTRUCTIONS FOR USE WITH REMOTE PANEL EKWHCTRL1 30
5.1 Wall-mounted control panel with room probe...................................................................................................................30
5.2 Display ..........................................................................................................................................................................30
5.3 Keys function .................................................................................................................................................................31
5.4 General start-up .............................................................................................................................................................31
5.5 Activation.......................................................................................................................................................................31
5.6 Heating / cooling operating mode set-up.........................................................................................................................31
5.7 Stand By .......................................................................................................................................................................32
5.8 Temperature selection ....................................................................................................................................................32
5.9 Automatic operation .......................................................................................................................................................32
5.10 Silent operation ..............................................................................................................................................................32
5.11 Night function.................................................................................................................................................................32
5.12 Operation at maximum ventilation speed .........................................................................................................................33
5.13 Key locking ....................................................................................................................................................................33
5.14 Minimum brightness reduction ........................................................................................................................................33

4
5.15 Deactivation ...................................................................................................................................................................33
5.16 Room temperature probe offset adjustment.....................................................................................................................33
5.17 Long term shut-down .....................................................................................................................................................34
5.18 Error signals ...................................................................................................................................................................34
5.19 Electronic control board..................................................................................................................................................34
5.20 LED Signals (ref. A).........................................................................................................................................................34
6 ROUTINE MAINTENANCE 36
6.1 Maintenance ..................................................................................................................................................................36
6.2 External cleaning ............................................................................................................................................................36
6.3 Cleaning the air suction filter ...........................................................................................................................................37
6.4 Suggestions for power saving.........................................................................................................................................38
7 TROUBLESHOOTING 39
7.1 Troubleshooting table .....................................................................................................................................................39

5
1.1 General warnings
After unpacking, make sure that all the components
are present. If not, contact your installer of your DAIKIN
affiliate office.
DAIKIN appliances must be installed by an authorised
installer who, on completion of the work, will release a
declaration of conformity to the client in respect of the
laws in force and the indications given by DAIKIN in the
instructions leaflet supplied together with the appliance.
These appliances have been designed both for
conditioning and/or heating environments and must
be destined for this use only and compatibly with their
performance characteristics.
DAIKIN EUROPE N.V. accepts no responsibility, either
contractual or extra-contractual, for any damage caused
to persons, animals of property as a result of incorrect
installation, adjustment or maintenance or improper use.
In case of water leaks, turn the master switch of the
system to "OFF" and close the water taps.
As soon as possible, call the DAIKIN technical service
department or else professionally qualified personnel
and do not intervene personally on the appliance.
If the appliance is not used for a long period of time,
the following operations should be performed:
- Turn the master switch of the system to "OFF"
- Close the water taps
- If there is the risk of freezing, make sure that anti-freeze
has been added to the system otherwise empty the
system.
If the room temperature is too low or too high it is
damaging for the health and is also a useless waste of
energy.
Avoid prolonged contact with the direct air flow.
Do not leave the room closed for long periods.
Periodically open the windows to ensure a correct
change of air.
This instruction leaflet is an integral part of the
appliance and consequently must be kept carefully
and must ALWAYS accompany the appliance, even
when it is passed to a new owner or user or transferred
onto another system. If it is lost or damaged, please
contact the local DAIKIN technical service centre.
All repair or maintenance interventions must be
performed by the technical service department or by
professionally qualified personnel as foreseen in this
booklet. Do not modify or intervene on the appliance
as this could create dangerous situations and the
manufacturer will not be responsible for any damage
caused.
Danger from burns - take care when touching
GENERAL

6
1.2 Essential safety rules
Remember that some fundamental safety rules should
be followed when using a product that uses electricity
and water, such as:
The unit can be used by children over the age of
8, and by people with reduced physical, sensory or
mental capabilities, or with no experience or necessary
knowledge, as long as they are monitored or after they
have received instructions on the safe use of the unit
and have understood the dangers involved.
Children must not play with the appliance.
The cleaning and maintenance that must be
performed by the user should not be carried out by
children without supervision.
It is forbidden to touch the appliance with wet hands
or body when barefoot.
It is forbidden to carry out any cleaning before having
disconnected the appliance from the electricity mains
supply by turning the system master switch to "OFF".
It is forbidden to modify the safety or adjustment
devices or adjust without authorisation and indications
of the manufacturer.
It is forbidden to pull, cut or knot the electrical cables
coming out of the appliance, even if it is disconnected
from the mains supply.
IIt is forbidden to poke objects or anything else
through the inlet or outlet grills.
It is forbidden to open the doors which access the
internal parts of the appliance without first turning the
system master switch to "OFF".
It is forbidden to dispose of or leave in the reach of
children the packaging materials which could become
a source of danger.
It is forbidden to climb onto the appliance or rest any
object on it.
The external parts of the appliance can reach
temperatures of more than 70 °C.

7
1.3
1.4
Product range
Daikin wall mounted heat pump convectors (FWXT
series) are available in three different performance levels
and sizes, all with two-pipe configuration.
Technical specifications
TECHNICAL DATA
FWXT 10ATV3 15ATV3 20ATV3
Coil water content L 0.54 0.74 0.93
Maximum operating pressure bar 10 10 10
Maximum water inlet temperature °C 80 80 80
Minimum water inlet temperature °C 4 4 4
Hydraulic connections "
Eurokonus 3/4 Eurokonus 3/4 Eurokonus 3/4
Power supply voltage V/ph/Hz 230/1/50 230/1/50 230/1/50
Maximum power consumption at maximum speed W 17.6 19.8 26.5
Maximum power consumption at minimum speed W 4.8 5.1 5.8
Length mm 902 1,102 1,302
Height mm 318 318 318
Depth mm 128 128 128
Weight kg 14 16 19

8
1.5
FWXT
1.6
L
P
H
FWXT U.M. 10ATV3 15ATV3 20ATV3
L mm 927 1.127 1.327
M.E. 10ATV3 15ATV3 20ATV3
kg 15 17 20
L mm 1.035 1.235 1.435
H mm 490 490 490
P mm 213 213 213
Filomuro overall dimensions
Dimensions
Dimensions and weight for transportation
Package
Dimensions
Weight
LATERAL VIEW FRONT VIEW

9
2.1
2.2
20 20
120
2.3
INSTALLATION
Unit placement
Installation procedure
Daikin FWXT convectors have to be installed only in high
wall position, above 2 meters.
Avoid installing the unit near:
- areas exposed to direct sunlight;
- heat sources;
- in damp areas and areas in which the unit can come into
contact with water;
- in environments with oil mists;
- in environments subject to high frequencies.
Make sure that:
- the wall on which you intend to install the unit is strong
enough to support the weight;
- the wall surface is not crossed by pipelines or power lines;
- the wall is perfectly flat;
- there are no obstructions nearby that could compromise
the inlet and outlet airflow;
- the wall on which you are installing the unit is (if possible)
an external perimeter wall, in order to allow condensate
drain outside the premises;
- air flow is not directed towards by-standers.
The assembly steps described below and their drawings
refer to a version of the machine with connections on the
right side.
For ideal installation and performance levels, carefully
follow the instructions in the manual.
Failure to do so may cause system malfunctions and
automatically voids the warranty, and relieves the
manufacturer of any harm caused to persons, animals
or property.
Installation space
The figure shows the minimum distances required for the
convector from the walls and furniture on site.

10
2.4
A
B
A
B
B
A
Opening the unit
- Remove the side panels by pulling them upwards as
shown in the figure below;
- Remove the 6 hex screws present on the sides of the
front panel;
- Remove the aesthetic front panel as shown in the figure;
side panels
aesthetic front panel

11
A
B
C
B
A
B
C
C
- Remove the upper grille by pulling it in your direction
and lifting it upwards, as shown in the figure;
- remove the side panels by lifting them upwards;
upper filters
side plates
side screw

12
2.5
A
B
DC
Wall installation
• For smooth installation, especially if you want to
set-up the system before you install the device, we
recommend installing a wall recess, as shown in the
figure;
• If you do not complete installation of the device
when installing the wall recess, leave the water and
condensate drain pipes hanging loose, so that you
can later make the connections without joints;
• When you finally install the device, it will be possible
to connect the convector with a 90° fitting and socket
with eurokonus connection;
• another option if you can comfortably bend the
pipeline (which will depend on the depth of the
installed recess) is to install the eurokonus connection
inside the pipeline;
• pay attention to the tilt angle of the condensate drain
pipe, which must rest be laid on the lowermost part
of the recess so that the pipe’s height never exceeds
the height of the cooler-radiator drain connection;
• for the installation heights, refer to the installation
template supplied with the device and which is shown
in the following pages.
A
wall recess
B
connecting water pipelines
C
condensation drainage pipe
D
heat pump convector

13
A B
AA B
1.
3.
2.
5.
G
G
6. NO
1. Use the paper template shown in full scale on the next
page and trace the position of the two fixing brackets
on the wall.
2. Drill a hole using a proper tip and insert the plugs (2
per bracket) then attach the two brackets. Do not
over-tighten the screws so that you can adjust them
with a spirit level.
3. Firmly fasten the brackets by tightening the four
screws.
4. Check stability by moving the brackets to the right
and left, up and down.
5. Assemble the unit, making sure it fastens properly
onto the brackets and that it is stable.
6. Make sure the tilt angle of the cooler-radiator matches
the measure shown in the figure below.
plugs brackets
6. OK, max tilt 1°
toward hydraulic parts
Hydraulic
parts side

14
2.6
MINIMUM DISTANCE FROM THE CEILING
ø8 HOLES FOR DOWELS
Level for alignment check
HYDRAULIC CONNECTIONS ZONE
FOR LEFT INSTALLATION
EXTERNAL PERIMETER FOR RIGHT INSTALLATION EXTERNAL PERIMETER FOR LEFT INSTALLATION
ELECTRICAL CONNECTIONS
ZONE FOR RIGHT INSTALLATION
OUTLET FOR LEFT HYDRAULIC CONNECTIONS
TO INSTALL 900 MM MODEL,
FOLD AND JOINT THE
TWO DOTTED LINES
Installation template

15
ELECTRICAL CONNECTIONS
ZONE FOR LEFT INSTALLATION
OUTLET FOR RIGHT HYDRAULIC CONNECTIONS
LOWER PERIMETER OF THE MACHINE
UPPER PERIMETER OF THE MACHINE
HYDRAULIC CONNECTIONS ZONE FOR
RIGHT INSTALLATION
TO INSTALL 900 MM MODEL,
FOLD AND JOINT THE
TWO DOTTED LINES
TO INSTALL 1100 MM MODEL, FOLD AND JOINT THE
TWO DOTTED LINES
ø8 HOLES FOR DOWELS
EXTERNAL PERIMETER FOR RIGHT INSTALLATION EXTERNAL PERIMETER FOR LEFT INSTALLATION
Level for alignment check

16
2.7
FWXT U.M. 10ATV3 15ATV3 20ATV3
mm 14 16 18
Hydraulic connections
The engineer is responsible for choosing the right water
lines and their size, in accordance with good installation
practices and the applicable laws, keeping in mind that
under-sized pipelines lead to poor system operation.
To make the connections:
- position the water lines
- tighten the connections using the "wrench against
wrench" method
- check for any fluid loss
- apply a lining to the connections (use proper insulating
material)
The hydraulic lines and fittings must be thermally insulated.
Avoid partial insulation of the pipes.
Avoid over-tightening the pipes to avoid damage to the
insulation.
To ensure water tightness of the threaded connections,
use hemp and green paste; the use of teflon tape is
recommended if you have poured anti-freeze liquid in the
water circuit.
Carefully check that the insulation is tight, in order to
prevent the formation and dripping of condensate.
Note: Always provide an electrically controlled valve
on the machine or upstream that interrupts the water
flow when the setpoint is reached.
Pipeline diameter

17
OUT
A
IN
A
C
B
OUT
IN
C
B
Aconvector
Belectric cable entry hole
Cthermoelectric motor
IN water inlet pipe fitting
OUT water outlet pipe fitting
Connect the pipeline to the delivery and return lines as
shown in the figure, with the delivery line at the top;
Comply with the requirements for electrical connections,
as described in para. 2.11
Aconvector
Belectric cable entry hole
Cthermoelectric motor
IN water inlet pipe fitting
OUT water outlet pipe fitting
Connect the pipeline to the delivery and return lines as
shown in the figure, with the delivery line at the top;
Comply with the requirements for electrical connections,
as described in para. 2.11
Connection to the 3-way diverter valve unit with thermoelectric motor (EKT3VK0)
Connection to the 2-way valve unit with thermoelectric motor (EKT2VK0)

18
2.8
A
B
B
ø14mm
A
Condensate drain
The condensate drain network must be sized appropriately
(minimum inner pipe diameter: 14 mm) and the pipeline
positioned so that it maintains a consistent slope along the
line (never less than 1%). The drain pipe connects directly
to the drain pan installed at the bottom on the side panel
under the hydraulic connections.
- If possible, make the condensate liquid flow directly
onto a gutter or into a "clean water" drain.
- If the liquid is discharged into a sewer, we recommend
that you install a trap-vent to prevent bad odours from
rising back up into the building. The curve of the trap
must be lower than the condensate tray.
- If you need to drain the condensate into a container, it
must remain open and the pipe must not be immersed
in water to prevent adhesion and back-pressure that
would obstruct free flow.
- If the drain pipe has to overcome a gap in height
due to its particular installation which would obstruct
condensate flow, remember to install a pump:
These pumps are commonly available on the market.
However, it is advisable that after installing the pump you
check proper flow of the condensate liquid, pouring it in
very slowly (about 1/2 l of water in about 5-10 minutes)
into the drain pan.
Connect the drain connection of the drain pan that collects
the condensate fluid to a hose and tighten it properly.
Make sure the drip-guard extension is present and that it
has been properly installed.
drain connection
liquid drain pipe
Condensate drain pipe assembly

19
A
2.9
2.10
A
B
A
Coil vent
Evacuating the air when filling the system
When starting the system, make sure that the
lock-shield on the hydraulic unit is open. If there
is a power black-out and the thermal valve
is already running, use its cap to press the valve shutter
and open it.
- Open all the system’s shut-off valves (whether manual
or automatic);
- Start filling the system by slowly opening the water
tap;
- With the aid of a screwdriver, open the vent on the
uppermost coil connection (see figure below);
- When water begins to leak out of the breather valves,
close them and continue to fill the system (as per the
rated specifications).
Check the tightness of the gaskets.
We recommend that you repeat this operation when the
device has been running for a few hours and that you
regularly check the system’s pressure.
Pay attention to the tilt of the condensate drain pipe when
it channels condensate outside the premises as shown in
the figure.
A
B
convector
condensate drain pipe
Filling system

20
2.11 Wiring
• Access the electrical parts as described in paragraph
2.4.
• An on/off switch with delayed fuse or an automatic
circuit breaker (2A) must be installed to supply power
to the system.
• Because the wiring features a suppression filter, as
required by the applicable laws and standards, which
naturally induces leakage current to the ground, it
is best to install selective differential circuit breakers
upstream of the system.
• For safety reasons, the on/off switch referred to
above should be installed near the device or at any
rate in open view.
• The power cables must be equipped with copper
conductors having the following unitary sections (the
values indicated refer to a maximum line length of
15m). The cables must be appropriate for the type
of installation, in accordance with the applicable CEI
standards.
FWXT U.M. 10ATV3 15ATV3 20ATV3
Power conductor (phase + neutral) mm21.5 1.5 1.5
Protective conductor section G/V mm21.5 1.5 1.5
