Dalian DS-2BB6E10-AP User manual

Installing instruction
www.umdbetter.com
IP CAMERA
DS series
DS-2BB6E10-AP
DS-2BB6E14-APR

DS series IP Camera |zh 1
Copy right ©DALIAN YOUMEIDE TECHNOLOGY CO.,LTD
Thank you for purchasing our products, should you have anyquestion or inquiry, please kindly contact
us.
DS-2BB6E14-APR is dome camera with IR function, DS-2BB6E10-AP is Dome camera 。
Declaration
This document may contain several technical incorrect places or printing errors, and the content is
subject to change withoutnotice. The updates will be added to the new version of this document.
We will readilyimprove or update the products or procedures described in the document.
Preface
The guide is intended to ensure that users can use the products properly to avoid danger or property
loss. It includesquick instructions for using and managing the product on yournetwork. Before
operation, please read the document carefully advance and kept it for further reference.
Symbols
Description for the symbols appeared in this document:
Product Model
DS-2BB6E10-AP
DS-2BB6E14-APR
Remark

DS series IP Camera |zh
UMD Security Syetems Installation Manual
2
Safety Instructions
During the process of installation and operation, please make sure to conform to all the local
electrical codes.
Please adopt the appropriate power adapter, see datasheet for details.
To reduce the risk of fire or electrical shock, please do not expose the product to rain or moisture.
Please install blackouts equipment into the power supply circuit for convenient supply interruption.
If wall or ceiling mounted, please make sure the product is firmly fixed.
If the product does not work properly, please contact your dealer or the nearest service center. Do
not attempt to disassemble the product by yourself. (We won’t be responsible for any problem
caused by unauthorized repair or disassemble.)
Do not place the camera in the vibrated or impacted environment, and keep it away from
electromagnetic interference.
(it might cause damage to product if ignored)
Do not tough the cooling parts directly with hands to avoid scald.
Indoor products should be kept away from water or any liquid.
Do not place the camera in the extremely hot, cold temperatures, dusty or damp environment;
see datasheet for operating temperature and humidity.
Do not aim the camera at the strong light such as sunlight or incandescent lamp, or else the sensor
will be damaged.
Well ventilation is required to avoid accumulation of heat.
Do not tough the sensor modules with fingers. If cleaning is required, use a clean cloth with a bit of
ethanol and wipe it gently. If the camera won’t be used for an extended period of time, put on the
lens cap to protect it from dirt.
The original packing should be kept for maintenance in the future.

DS series IP Camera |zh
UMD Security Syetems Installation Manual
3
1.Requests for installation and maintenance personnel
Be qualified to do installation and maintenance of CCTV system, and
Know well about basic knowledge of CCTV system & parts and installation skills
With good command of basic knowledge of cabling and electrical connection in the low voltage
environment and operation skills
Be capable of reading this document
2.Requests for lifting equipment
Be appropriate for the installation places and ways
Be able to reach a certain heights
With highly secure

DS series IP Camera |zh
UMD Security Syetems Installation Manual
4
Table of Contents
1.Chapter 1 Introduction ............................................................................................................................................................
5
1.1 Description
.................................................................................................................................................................
5
1.2 Features
.....................................................................................................................................................................
5
1.3 Hardware Overview
.................................................................................................................................................
6
2.Chapter 2 Installation
..............................................................................................................................................................
9
2.1 Fix the camera:
.........................................................................................................................................................
9
2.3 Network connection:
.............................................................................................................................................
10
2.4 Power supply connection:
....................................................................................................................................
12
2.5 I/O connection:
....................................................................................................................................................... 13
2.6 Audio connection:
..................................................................................................................................................
14
2.7 CVBS output:
.......................................................................................................................................................... 15
2.8 Installation completes:
..........................................................................................................................................
15
3.Chapter 3 Quick Operation Guide
.....................................................................................................................................
16
3.1 Network connection
..............................................................................................................................................
16
3.2 Login In & Out
........................................................................................................................................................
16
3.3 Main Interface Introduction
..................................................................................................................................
21
3.4 Modifying the IP address
.....................................................................................................................................
21
4. Appendix 1 Network Interface of IP Camera
.................................................................................................................
23
5. Appendix 2 Default Network Parameters
....................................................................................................................... 23
6. Appendix 3 FAQs
.................................................................................................................................................................
24
7. Appendix 4 Technical parameters
.................................................................................................................................... 26
8. Product view
..........................................................................................................................................................................
27

DS series IP Camera |zh
UMD Security Syetems Installation Manual
5
1. Chapter 1 Introduction
1.1 Description
IP Camera is a kind of embedded digital surveillance product which combines the features of both
traditional analog camera and net digital video server. Due to the embedded Linux operating system
and high-efficient hardware platform, the system operates with high scheduling efficiency. Furthermore,
the firmware is burned in the flash, which makes the product small, reliable and highly stable.
1.2 Features
With high efficient processing chip and platform, it works fine and stable:
H.264 standard video compression, with higher compression ratio
Support SDHC storage, secure data storage and
Support motion detection, sensor alarm, network failure etc.
Support dual stream, mobile surveillance, corridor monitoring etc.
Support TCP/IP, HTTP, DDNS and other network protocols.
Support ONVIF and other standard network interface protocols.
Support remote upgrades and maintenance.
Ease of installation, ceiling mounted and wall mounted included.
Some features might be related to the specified models, please note that.

DS series IP Camera |zh
UMD Security Syetems Installation Manual
6
1.3 Hardware Overview
1.1.1 DS-2BB6E10-AP: Appearance of Fixed Dome IP Camera without IR, see Figure 1-1:
Figure 1-1 Appearance (without IR)
Interfaces of Fixed Dome IP Camera without IR, see Figure 1-2:
Figure 1-2 Interfaces (without IR)

DS series IP Camera |zh
UMD Security Syetems Installation Manual
7
1.1.2 DS-2BB6E14-APR: Appearance of Fixed Dome IP Camera with IR, see Figure 1-3:
Figure 1-3 Appearance (withIR)
Interfaces of Fixed Dome IP Camera with IR, see Figure 1-4:
Figure 1-4 Interfaces (with IR)
Description for interfaces of Fixed Dome IP Camera with or without IR:

DS series IP Camera |zh
UMD Security Syetems Installation Manual
8
Table 1-1 Description of interfaces:
-------------------------------------------------------------------------------------------------------------------------------------
If the camera is powered on, press Reset button for 10 seconds, all parameters will be reset to the
Factory Default Settings.
CVBS is intended for users to check whether the video is normal.
Audio input can be configured with Line In or MIC In.
-------------------------------------------------------------------------------------------------------------------------------------
No.
Description
1
CVBS, support analog video signal output
2
RJ45, 10M/100M Ethernet Port
3
Steady orange for no data transmission
4
Steady green for normal network connection
5
Alarm output
6
Alarm input
7
RS485
8
Power supply
9
Audio input
10
Audio output
11
Power supply indicator
12
Reset
13
SD card slot
14
Build-in MIC interface

DS series IP Camera |zh
UMD Security Syetems Installation Manual
9
2. Chapter 2 Installation
Before installation, please check whether the product is sound or not and all the items supplied with the
product are included. Commonly, the camera can be wall mounted and ceiling mounted.
This document is mainly focusing on the installation of ceiling mounted, for wall mounted; please refer
to this document as well.
If bracket installation, please pay attention to weight marked on the bracket that bracket could bear.
Take ceiling mounted as example, see procedures as below:
If wall is made of concrete, install the expansion screw first (the mounted holes should be same with
bracket)and then fix the bracket firmly
When wall is wood, use the self-tapping screws to install it directly.
2.1 Fix the camera:
Fix the ceiling plate to the wall surface, see Figure 2-1. If wall is made of concrete, install the expansion
screw first (the mounted holes should be same with bracket) and then fix the bracket firmly. If wall is
wood, use the self-tapping screws to install it directly.
Figure 2-1 Fix the ceiling plate

DS series IP Camera |zh
UMD Security Syetems Installation Manual
10
2.2 Plug in SD card:
The rear panel of the Fixed Dome IP Camera includes two SD card slots, plug in the SD card according
to direction of below picture to complete installation of SD card, if plug it out is required, press the SD
card and it will be ejected automatically. See Figure 2-2:
Figure 2-2 Plug in the SD Card
Plug in or out SD card should be operated when the product is powered off, which will avoid the
damage of SD card and prolong the life span of the product. Please note that only one SD card slot will
be available.
2.3 Network connection:
The product shall be connected using a unshielded twisted pair network cable (UTP Cat 5 or more).
Connect the product to the network, see Figure 2-3-1:

DS series IP Camera |zh
UMD Security Syetems Installation Manual
11
Figure 2-3-1 Network connection
Figure 2-3-2 Fix the Ethernet cable

DS series IP Camera |zh
UMD Security Syetems Installation Manual
12
2.4 Power supply connection:
Please adopt the appropriate power adapter, and make sure that the plug is firmly inserted into the
power socket. When the product is powered on, the power supply indicators will light up.
See Figure 2-4:
Figure 2-4 Power Supply connection
The date & time should be synchronized with the local time or computer for each boots, which is very
important to the correct date & time of recordings. Incorrect date & time may cause the failure of
recording.

DS series IP Camera |zh
UMD Security Syetems Installation Manual
13
2.5 I/O connection:
Alarm In/Out & RS485 included, see Figure 2-5:
Figure 2-5 I/O connection
I/O Pin
Features
Pin
I/O Socket
RS485
1
Positive (+2V ~ +6V)
2
Negative (-2V ~ -6V)
Alarm Input
3
Alarm Input Positive (Signal Input)
4
Alarm Input Negative (Connected to GND)
Alarm Output
5
Alarm Output to A
6
Alarm Output to B

DS series IP Camera |zh
UMD Security Syetems Installation Manual
14
2.6 Audio connection:
Connect the product to connectors of Line In & Out, see Figure 2-6:
Figure 2-6 Audio connection

DS series IP Camera |zh
UMD Security Syetems Installation Manual
15
2.7 CVBS output:
A cable with BNC connector will be supplied with the product, see Figure 2-7:
Figure 2-7 CVBS connection
2.8 Installation completes:
Cover the transparent casing and tighten the screws to complete installation. This series is also
available to be installed with shielded cover for outdoor environment. See Figure 2-8:
Figure 2-8 Installation with shielded cover

DS series IP Camera |zh
UMD Security Syetems Installation Manual
16
3. Chapter 3 Quick Operation Guide
3.1 Network connection
The related network parameters like IP address, subnet mask and port number of the IP Camera which
need to be configured after the hardware installation. But before configuration, please make sure that
the IP Camera is connected to the PC and accessible. Here two ways of connection between the PC
and IP Camera are introduced as below, see Figure 3-1:
The left side is direct line connection while the right is cross line connection
Figure 3-1 Network connection
3.2 Login In & Out
3.2.1 Login In
Run a browser (IE recommended) after connection between the PC and IP Camera is completed; input
the IP address of IP Camera in the browser’s address field to enter into the login page. If this is the first
time the product is accessed, please download the ActiveX control after it pops up automatically and
install it. See Figure 3-2-1 and 3-2-2.
The details of factory default settings as below:
IP address: 192.168.1.88
User name: admin
Password: admin

DS series IP Camera |zh
UMD Security Syetems Installation Manual
17
After Active X control is downloaded, double click Web Player.exe and pop up interface below, click
Install to complete the installation of Active X:
Figure 3-2-1
Figure 3-2-2
Note: Abnormal installation of ActiveX and its solutions:
1. When install ActiveX, it pops up the windows as Figure 3-3:

DS series IP Camera |zh
UMD Security Syetems Installation Manual
18
Figure 3-3
Please revise the security level of IE from Tools-> Internet options-> Security-> Custom level, see Figure
3-4, Figure 3-5:
Figure 3-4

DS series IP Camera |zh
UMD Security Syetems Installation Manual
19
Figure 3-5
2. During the process of installation of ActiveX, it may pop up the windows as Figure 3-6,
please shut down the IE browser and install it correctly:
Figure 3-6
