1 Introduction
1.1 Purpose of this Operating Guide
This Operating Guide provides information for safe installation and commissioning of the AC drive. It is intended for use by qualified
personnel.
Read and follow the instructions to use the drive safely and professionally.
Pay particular attention to the safety instructions and general warnings. Always keep this Operating Guide with the drive.
VLT®is a registered trademark for Danfoss A/S.
1.2 Additional Resources
1.2.1 Other Resources
Other resources are available to understand advanced drive functions and programming.
The VLT® HVAC Drive FC 131 Programming Guide provides information on how to program and includes complete parameter
descriptions.
The VLT® HVAC Drive FC 131 Design Guide provides all technical information about the drive. It also lists options and accesso-
ries.
The technical documentation is available in electronic form online at www.danfoss.com.
1.2.2 MCT 10 Setup Software Support
Download the software from the service and support section on www.danfoss.com.
During the installation process of the software, enter access code 81463800 to activate the VLT® HVAC Drive FC 131 functionality. A
license key is not required for using the VLT® HVAC Drive FC 131 functionality.
The latest software does not always contain the latest updates for drives. Contact the local sales office for the latest drive updates (in
the form of *.upd files), or download the drive updates from the service and support section on www.danfoss.com.
1.3 Document and Software Version
The Operating Guide is regularly reviewed and updated. All suggestions for improvement are welcome.
The original language of this manual is English.
Table 1: Document and Software Version
Edition
Remarks
Software version
AQ367426199594, version 0101
First edition.
4.6x
AQ367426199594en-000101 / 130R09886 | Danfoss A/S © 2021.06
Introduction
VLT® HVAC Drive FC 131
Operating Guide

1.4 Certificates and Approvals
Table 2: Certificates and Approvals
Certification
IP54
EC Declaration of Conformity
✓
RCM
✓
EAC
✓
UkrSEPRO
089
✓
1.5 Disposal
Do not dispose of equipment containing electrical components together with domestic waste.
Collect it separately in accordance with local and currently valid legislation.
AQ367426199594en-000101 / 130R0988 | 7Danfoss A/S © 2021.06
Introduction
VLT® HVAC Drive FC 131
Operating Guide

•
•
•
•
-
-
-
-
2 Safety
2.1 Safety Symbols
The following symbols are used in this manual:
DANGER
Indicates a hazardous situation which, if not avoided, will result in death or serious injury.
WARNING
Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION
Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
NOTICE
Indicates information considered important, but not hazard-related (for example, messages relating to property damage).
2.2 Qualified Personnel
To allow trouble-free and safe operation of the unit, only qualified personnel with proven skills are allowed to transport, store, as-
semble, install, program, commission, maintain, and decommission this equipment.
Persons with proven skills:
Are qualified electrical engineers, or persons who have received training from qualified electrical engineers and are suitably
experienced to operate devices, systems, plant, and machinery in accordance with pertinent laws and regulations.
Are familiar with the basic regulations concerning health and safety/accident prevention.
Have read and understood the safety guidelines given in all manuals provided with the unit, especially the instructions given in
the Operating Guide.
Have good knowledge of the generic and specialist standards applicable to the specific application.
2.3 Safety Precautions
WARNING
HIGH VOLTAGE
AC drives contain high voltage when connected to AC mains input, DC supply, or load sharing. Failure to perform installation,
start-up, and maintenance by qualified personnel can result in death or serious injury.
Only qualified personnel must perform installation, start-up, and maintenance.
WARNING
UNINTENDED START
When the drive is connected to AC mains, DC supply, or load sharing, the motor may start at any time. Unintended start during
programming, service, or repair work can result in death, serious injury, or property damage. Start the motor with an external
switch, a fieldbus command, an input reference signal from the local control panel (LCP), via remote operation using MCT 10
software, or after a cleared fault condition.
Disconnect the drive from the mains.
Press [Off/Reset] on the LCP before programming parameters.
Ensure that the drive is fully wired and assembled when it is connected to AC mains, DC supply, or load sharing.
AQ367426199594en-000101 / 130R09888 | Danfoss A/S © 2021.06
Safety
VLT® HVAC Drive FC 131
Operating Guide

1.
-
-
-
-
-
-
-
-
-
WARNING
DISCHARGE TIME
The drive contains DC-link capacitors, which can remain charged even when the drive is not powered. High voltage can be
present even when the warning indicator lights are off.
Failure to wait the specified time after power has been removed before performing service or repair work could result in death or
serious injury.
Stop the motor.
Disconnect AC mains, permanent magnet type motors, and remote DC-link supplies, including battery back-ups, UPS, and
DC-link connections to other drives.
Wait for the capacitors to discharge fully. The minimum waiting time is specified in the table Discharge time and is also visible
on the nameplate on top of the drive.
Before performing any service or repair work, use an appropriate voltage measuring device to make sure that the capacitors
are fully discharged.
Table 3: Discharge Time
Voltage [V]
Power range [kW (hp)]
Minimum waiting time (minutes)
3x400
0.75–7.5 (1.0–10)
4
3x400
11–90 (15–125)
15
WARNING
LEAKAGE CURRENT HAZARD
Leakage currents exceed 3.5 mA. Failure to ground the drive properly can result in death or serious injury.
Ensure the correct grounding of the equipment by a certified electrical installer.
WARNING
EQUIPMENT HAZARD
Contact with rotating shafts and electrical equipment can result in death or serious injury.
Ensure that only trained and qualified personnel perform installation, start-up, and maintenance.
Ensure that electrical work conforms to national and local electrical codes.
Follow the procedures in this manual.
CAUTION
INTERNAL FAILURE HAZARD
An internal failure in the drive can result in serious injury when the drive is not properly closed.
Ensure that all safety covers are in place and securely fastened before applying power.
2.4 Motor Thermal Protection
Procedure
Set parameter 1-90 Motor Thermal Protection to [4] ETR trip 1 to enable the motor thermal protection function.
AQ367426199594en-000101 / 130R0988 | 9Danfoss A/S © 2021.06
Safety
VLT® HVAC Drive FC 131
Operating Guide

3 Installation
3.1 Mechanical Installation
3.1.1 Side-by-side Installation
The drive can be mounted side by side but requires the clearance above and below for cooling.
Table 4: Clearance Required for Cooling
Size
IP class
Power [kW (hp)]
Clearance above/below [mm (in)]
I2
IP54
0.75–4.0 (1.0–5.0)
100 (4.0)
I3
IP54
5.5–7.5 (7.5–10)
100 (4.0)
I4
IP54
11–18.5 (15–25)
100 (4.0)
I6
IP54
22–37 (30–50)
200 (7.9)
I7
IP54
45–55 (60–70)
200 (7.9)
I8
IP54
75–90 (100–125)
225 (8.9)
NOTICE
The drives are not suitable for outdoor mounting.
3.1.2 Drive Dimensions
e
f
a
e
e
f
a
d
e
A
a
b
B
C
D
e30bf984.10
Illustration 1: Dimensions
Table 5: Dimensions, Enclosure Sizes I2–I8
Enclosure Size
I2
I3
I4
I6
I7
I8
IP class
IP54
IP54
IP54
IP54
IP54
IP54
Power [kW (hp)]
3x380–480 V
0.75–4.0
(1.0–5.0)
5.5–7.5
(7.5–10)
11–18.5
(15–25)
22–37
(30–50)
45–55
(60–70)
75–90
(100–125)
Height [mm (in)]
A
332 (13.1)
368 (14.5)
476 (18.7)
650 (25.6)
680 (26.8)
770 (30)
a
318.5 (12.53)
354 (13.9)
460 (18.1)
624 (24.6)
648 (25.5)
739 (29.1)
Width [mm (in)]
B
115 (4.5)
135 (5.3)
180 (7.0)
242 (9.5)
308 (12.1)
370 (14.6)
b
74 (2.9)
89 (3.5)
133 (5.2)
210 (8.3)
272 (10.7)
334 (13.2)
AQ367426199594en-000101 / 130R098810 | Danfoss A/S © 2021.06
Installation
VLT® HVAC Drive FC 131
Operating Guide

-
Enclosure Size
I2
I3
I4
I6
I7
I8
Depth [mm (in)]
C
225 (8.9)
237 (9.3)
290 (11.4)
260 (10.2)
310 (12.2)
335 (13.2)
Mounting hole [mm (in)]
d
11 (0.43)
12 (0.47)
12 (0.47)
19 (0.75)
19 (0.75)
19 (0.75)
e
5.5 (0.22)
6.5 (0.26)
6.5 (0.26)
9 (0.35)
9 (0.35)
9 (0.35)
f
9 (0.35)
9.5 (0.37)
9.5 (0.37)
9 (0.35)
9.8 (0.39)
9.8 (0.39)
Maximum weight kg (lb)
5.3 (11.7)
7.2 (15.9)
13.8 (30.42)
27 (59.5)
45 (99.2)
65 (143.3)
The dimensions are only for the physical units. When installing in an application, allow space above and below the units for cooling.
The amount of space for free air passage is listed in 3.1.1 Side-by-side Installation.
3.2 Electrical Installation
3.2.1 Electrical Installation in General
All cabling must comply with national and local regulations on cable cross-sections and ambient temperature. Copper conductors
are required. 75 °C (167 °F) is recommended.
Table 6: Tightening Torques for Enclosure Sizes I2–I8
Power [kW (hp)]
Torque [Nm (in-lb)]
Enclosure
size
IP class
3x380–480 V
Mains
Motor
DC connec-
tion
Control ter-
minals
Ground
Relay
I2
IP54
0.75–4.0 (1.0–5.0)
0.8 (7.0)
0.8 (7.0)
0.8 (7.0)
0.5 (4.0)
0.8 (7.0)
0.5 (4.0)
I3
IP54
5.5–7.5 (7.5–10)
0.8 (7.0)
0.8 (7.0)
0.8 (7.0)
0.5 (4.0)
0.8 (7.0)
0.5 (4.0)
I4
IP54
11–18.5 (15–25)
1.2 (11)
1.2 (11)
0.8 (7.0)
0.5 (4.0)
0.8 (7.0)
0.5 (4.0)
I6
IP54
22–37 (30–50)
4.5 (40)
4.5 (40)
–
0.5 (4.0)
3 (27)
0.6 (5.0)
I7
IP54
45–55 (60–70)
10 (89)
10 (89)
–
0.5 (4.0)
3 (27)
0.6 (5.0)
I8
IP54
75–90 (100–125)
14 (124)/24
(212)(1)
14 (124)/24
(212)(1)
–
0.5 (4.0)
3 (27)
0.6 (5.0)
1Cable dimensions ≤95 mm2.
3.2.2 IT Mains
CAUTION
IT MAINS
Installation on isolated mains source, that is, IT mains.
Ensure that the supply voltage does not exceed 440 V (3x380–480 V units) when connected to mains.
For IP54, 400 V, 0.75–18.5 kW (1.0–25 hp) units, open the RFI switch by removing the EMC screw inside the drive when at IT grid. The
EMC screw is shown in the the following illustration.
AQ367426199594en-000101 / 130R0988 | 11Danfoss A/S © 2021.06
Installation
VLT® HVAC Drive FC 131
Operating Guide

•
•
•
e30bc251.10
Illustration 2: IP54, 400 V, 0.75–18.5 kW (1–25 hp)
1
EMC screw
For IP54, 400 V, 22-90 kW (30–125 hp) units, the RFI switch can be opened in parameter 14-50 RFI Filter. Select [1] On to turn the RFI
filter on. The RFI filter ensures that the drive complies with EMC standards. Select [0] Off only when the drive is connected to IT
mains.
NOTICE
If reinserted, use only M3x12 screw.
3.2.3 Mains and Motor Connection
3.2.3.1 Introduction
The drive is designed to operate all standard 3-phase induction motors.
Use a shielded/armored motor cable to comply with EMC emission specifications and connect this cable to the motor.
Keep the motor cable as short as possible to reduce the noise level and leakage currents.
Also see EMC-Correct Installation in the 3.2.5 EMC-compliant Electrical Installation.
AQ367426199594en-000101 / 130R098812 | Danfoss A/S © 2021.06
Installation
VLT® HVAC Drive FC 131
Operating Guide

1.
2.
3.
3.2.3.2 Connecting to Mains and Motor
Mount the ground cables to the ground terminal.
Connect the motor to terminals U, V, and W, and then tighten the screws according to the torques.
Connect the mains supply to terminals L1, L2, and L3, and then tighten the screws according to the torques described in
3.2.1 Electrical Installation in General.
3.2.3.3 Enclosure Size I2
e30bc299.10
7
3
2
5
1
8
4
6
Illustration 3: Enclosure Size I2, IP54, 380–480 V, 0.75–4.0 kW (1.0–5.0 hp)
1
RS485
2
Mains
3
Ground
4
Cable clamps
5
Motor
6
UDC
7
Relays
8
I/O
AQ367426199594en-000101 / 130R0988 | 13Danfoss A/S © 2021.06
Installation
VLT® HVAC Drive FC 131
Operating Guide

3.2.3.4 Enclosure Size I3
e30bc201.10
Illustration 4: Enclosure Size I3, IP54, 380–480 V, 5.5–7.5 kW (7.5–10 hp)
1
RS485
2
Mains
3
Ground
4
Cable clamps
5
Motor
6
UDC
7
Relays
8
I/O
AQ367426199594en-000101 / 130R098814 | Danfoss A/S © 2021.06
Installation
VLT® HVAC Drive FC 131
Operating Guide

3.2.3.5 Enclosure Size I4
e30bd011.10
Illustration 5: Enclosure Size I4, IP54, 380–480 V, 11–18.5 kW (15–25 hp)
1
RS485
2
Mains
3
Ground
4
Cable clamps
5
Motor
6
UDC
7
Relays
8
I/O
AQ367426199594en-000101 / 130R0988 | 15Danfoss A/S © 2021.06
Installation
VLT® HVAC Drive FC 131
Operating Guide

3.2.3.6 IP54 Enclosure Sizes I2, I3, I4
e30bc203.10
Illustration 6: IP54 Enclosure Sizes I2, I3, I4
3.2.3.7 Enclosure size I6
e30bt326.10
Illustration 7: Connecting to Mains for Enclosure Size I6, IP54, 380–480 V, 22–37 kW (30–50 hp)
AQ367426199594en-000101 / 130R098816 | Danfoss A/S © 2021.06
Installation
VLT® HVAC Drive FC 131
Operating Guide

e30bt325.10
Illustration 8: Connecting to Motor for Enclosure Size I6, IP54, 380–480 V, 22–37 kW (30–50 hp)
311
e30ba215.10
RELA
Y 1
RELA
Y 2
03 02 01
90
05 04
Illustration 9: Relays on Enclosure Size I6, IP54, 380–480 V, 22–37 kW (30–50 hp)
AQ367426199594en-000101 / 130R0988 | 17Danfoss A/S © 2021.06
Installation
VLT® HVAC Drive FC 131
Operating Guide

3.2.3.8 Enclosure size I7, I8
91
L1
92
L2
93
L3
96
U
97
V98
W
88
DC-
99
95
e30bc248.10
Illustration 10: Enclosure Sizes I7, I8, IP54, 380–480 V, 45–55 kW (60–70 hp), IP54, 380–480 V, 75–90 kW (100–125 hp)
3.2.4 Fuses and Circuit Breakers
3.2.4.1 Branch Circuit Protection
To prevent fire hazards, protect the branch circuits in an installation - switch gear, machines, and so on - against short circuits and
overcurrent. Follow national and local regulations.
3.2.4.2 Short-circuit Protection
Danfoss recommends using the fuses and circuit breakers listed in this chapter to protect service personnel or other equipment in
case of an internal failure in the unit or a short circuit on the DC link. The drive provides full short-circuit protection in case of a short
circuit on the motor.
3.2.4.3 Overcurrent Protection
Provide overload protection to avoid overheating of the cables in the installation. Overcurrent protection must always be carried
out according to local and national regulations. Design circuit breakers and fuses for protection in a circuit capable of supplying a
maximum of 100000 Arms (symmetrical), 480 V maximum.
3.2.4.4 UL/Non-UL Compliance
To ensure compliance with UL or IEC 61800-5-1, use the circuit breakers or fuses listed in this chapter. Circuit breakers must be
designed for protection in a circuit capable of supplying a maximum of 10000 Arms (symmetrical), 480 V maximum.
3.2.4.5 Recommendation of Fuses and Circuit Breakers
NOTICE
If a malfunction occurs, failure to follow the protection recommendation may result in damage to the drive.
Table 7: Fuses and Circuit Breakers
Circuit breaker
Fuse
UL
Non-UL
UL
Non-UL
Bussmann
Bussmann
Bussmann
Bussmann
Maximum fuse
Power [kW (hp)]
Type RK5
Type RK1
Type J
Type T
Type G
AQ367426199594en-000101 / 130R098818 | Danfoss A/S © 2021.06
Installation
VLT® HVAC Drive FC 131
Operating Guide

•
•
•
•
•
3x380–480 V IP54
0.75 (1.0)
–
PKZM0-16
FRS-R-10
KTS-R-10
JKS-10
JJS-10
16
1.5 (2.0)
PKZM0-16
FRS-R-10
KTS-R-10
JKS-10
JJS-10
16
2.2 (3.0)
PKZM0-16
FRS-R-15
KTS-R-15
JKS-15
JJS-15
16
3.0 (4.0)
PKZM0-16
FRS-R-15
KTS-R-15
JKS-15
JJS-15
16
4.0 (5.0)
PKZM0-16
FRS-R-15
KTS-R-15
JKS-15
JJS-15
16
5.5 (7.5)
PKZM0-25
FRS-R-25
KTS-R-25
JKS-25
JJS-25
25
7.5 (10)
PKZM0-25
FRS-R-25
KTS-R-25
JKS-25
JJS-25
25
11 (15)
PKZM4-63
FRS-R-50
KTS-R-50
JKS-50
JJS-50
63
15 (20)
PKZM4-63
FRS-R-50
KTS-R-50
JKS-50
JJS-50
63
18.5 (25)
PKZM4-63
FRS-R-80
KTS-R-80
JKS-80
JJS-80
63
22 (30)
Moeller NZMB1-A125
–
FRS-R-80
KTS-R-80
JKS-80
JJS-80
125
30 (40)
FRS-R-125
KTS-R-125
JKS-125
JJS-125
125
37 (50)
FRS-R-125
KTS-R-125
JKS-125
JJS-125
125
45 (60)
Moeller NZMB2-A160
–
FRS-R-125
KTS-R-125
JKS-125
JJS-125
160
55 (70)
FRS-R-200
KTS-R-200
JKS-200
JJS-200
160
75 (100)
Moeller NZMB2-A250
–
FRS-R-200
KTS-R-200
JKS-200
JJS-200
200
90 (125)
FRS-R-250
KTS-R-250
JKS-200
JJS-200
200
3.2.5 EMC-compliant Electrical Installation
To ensure EMC-correct electrical installation, observe the following:
Use only shielded/armored motor cables and shielded/armored control cables.
Ground the shield at both ends.
Avoid installation with twisted shield ends (pigtails), because it reduces the shielding effect at high frequencies. Use the cable
clamps provided.
Ensure the same potential between the drive and the ground potential of PLC.
Use star washers and galvanically conductive installation plates.
AQ367426199594en-000101 / 130R0988 | 19Danfoss A/S © 2021.06
Installation
VLT® HVAC Drive FC 131
Operating Guide

B
a
c
k
OK
Com.
On
Warn.
Alarm
Hand
On Reset Auto
On
Menu
Status Quick
Menu Main
Menu
L1
L2
L3
PE
Minimum 16 mm2
equalizing cable
Control cables
All cable entries in
one side of the panel
Grounding rail
Cable insula-
tion stripped
Output con-
tactor
Motor cable
Motor, 3 phases and
PLC Panel
Mains-supply
Minimum 200 mm (7.87 in)
between control
cable, mains cable,
and between mains
motor cable
PLC
protective earth
Reinforced protective earth
e30bb761.13
(6 AWG)
Illustration 11: EMC-compliant Installation
3.2.6 Control Terminals
Remove the terminal cover to access the control terminals.
Use a flat-edged screwdriver to push down the lock lever of the terminal cover under the LCP, then remove the terminal cover as
shown in the following illustration.
For IP54 units, control terminals can be accessed after removing the front cover.
AQ367426199594en-000101 / 130R098820 | Danfoss A/S © 2021.06
Installation
VLT® HVAC Drive FC 131
Operating Guide
