Danfoss IP21/Type 1 Conversion Kit User manual

The instructions provide information about installing the IP21/
Type 1 conversion kit in VLT
®
AutomationDrive FC 360,
enclosure sizes J6 and J7.
Only Danfoss authorized, qualied personnel is allowed to
repair this equipment. The personnel must be familiar with the
instructions and safety measures described in the
VLT
®
AutomationDrive FC 360 Service Guide.
Items Supplied
•
IP21 top cover
•
NEMA conduit box
•
NEMA base cover
•
Screws and washers, M4x7 (8 pieces)
Description Ordering number
IP21/Type 1 Conversion Kit, J6 132B0376
IP21/Type 1 Conversion Kit, J7 132B0377
Table 1.1 Ordering Numbers
Tools Required
•
T20 screwdriver
Safety Instructions
WARNING
DISCHARGE TIME
The frequency converter contains DC-link capacitors, which
can remain charged even when the frequency converter is
not powered. High voltage can be present even when the
warning LED indicator lights are o. Failure to wait the
specied time after power has been removed before
performing service or repair work can result in death or
serious injury.
•
Stop the motor.
•
Disconnect AC mains and remote DC-link supplies,
including battery back-ups, UPS, and DC-link
connections to other frequency converters.
•
Disconnect or lock PM motor.
•
Wait for the capacitors to discharge fully. The
minimum waiting time is specied in Ta b le 1 . 2 .
•
Before performing any service or repair work, use
an appropriate voltage measuring device to make
sure that the capacitors are fully discharged.
Voltage [V] Power range [kW
(hp)]
Minimum waiting time
(minutes)
380–480 30–75 (45–100) 15
Table 1.2 Discharge Time
Installation Instructions
IP21/Type 1 Conversion Kit
Enclosure Sizes J6 & J7
VLT®AutomationDrive FC 360
Danfoss A/S © 12/2015 All rights reserved. MI06V102

Installation
1. Mount the top cover on the top of the frequency
converter.
2. Fasten with 4 screws, 2 screws on each side.
3. Tighten the screws to 1.5 Nm (13.3 in-lb).
1Topcover
Illustration 1.1 Mounting the Top Cover
4. Mount the conduit box on the bottom of the
frequency converter.
5. Fasten with 2 screws, 1 screw on each side.
6. Tighten the screws to 1.5 Nm (13.3 in-lb).
1Conduitbox
Illustration 1.2 Mounting the Conduit Box
7. Mount the conduit cover on the bottom of the
frequency converter.
8. Fasten with 2 screws, 1 screw on each side.
9. Tighten the screws to 1.5 Nm (13.3 in-lb).
1Conduitcover
Illustration 1.3 Mounting the Conduit Cover
