Danfoss EvaKool Travelmate User manual

Instruction Manual
1 | P a g e
Nexberg Pty Ltd T/a Evakool
16 Enterprise St CALOUNDRA
QLD 4551
Tel : [phone]
Fax : [phone]
Please read these instructions and the Safety section carefully before using
your refrigerator.
1．Safety Instructions Page 2
2．Notes on using the product Page 2
3．Operation Page 2-3
4．Cleaning and Maintenance Page 4
5．Troubleshooting Page 4
6．Error Codes Page 5
7．Warranty Statement Page 6

Instruction Manual
2 | P a g e
Features:
•Reliable cooling system – Danfoss compressor
•Efficient electronic technology, low energy consumption
•Multi-voltage system (DC 12-24 Volt) and (AC 100-120/220-240 Volt)
•Digital Battery Protection, protect your vehicle battery effectively
1. Safety Instructions
•Warning: Do not touch exposed cables.
•Warning: Do not use fridge if you suspect any connections could be wet.
•When using the fridge in the vehicle or boat, please make sure the circuit being used is fused.
•Any installation of DC power sources should be handled by a qualified professional.
•Make sure the source voltage is correct. The technical data label has the voltage data.
•Do not place any electrical devices inside the refrigerator as moisture could harm these
devices.
2. Notes on using the product
Your refrigerator requires good ventilation, especially around the vents of the refrigerator;
allow a gap of at least 200mm around the vents and 100mm around the rest of the unit.
Avoid humidity: Humidity inside the appliance can form frost and impair cooling.
Do not allow frost to build up. Never clean the appliance using a hose and never submerge the
unit in any liquid.
Avoid placing your refrigerator near a heat source. This helps the refrigerator to work more
efficiently and keep the contents cool.
Place the refrigerator on a flat surface and away from any edges. When using the fridge in a
vehicle, please use a fastening device to secure it.
3. Operation
Power ：
：：
： The electronic control module controls the compressor motor and has the function of
a three stage battery protection. When the input voltage drops below the minimum, the
compressor will cut out; when the voltage comes back up to the cut-in value, the compressor
will restart automatically.
Battery Protection: The Danfoss compressor requires over 10.4 Volts (12 Volt System) or
23.0 Volts (24V System) to operate. If the voltage drops below this the fridge will stop
running.
Cable Specification
The DC cables must have a suitable cross-section for their length, according to this table:
*Note: The length is from the battery to the refrigerator.
Cable Area 12V Max Cable
Length*
24V Max Cable
Length*
[mm2] AWG [m] [ft.] [m] [ft.]
2.5 12 2.5 8 5 16
4 12 4 13 8 26
6 10 6 20 12 39
10 8 10 33 20 66

Instruction Manual
3 | P a g e
Using the Fridge
•NOTE: IF THE UNIT IS POWERED OFF ONLY AN ORANGE LED WILL BE
ILLUMINATED. TO TURN ON YOUR UNIT PLEASE HOLD THE ON/OFF
SWITCH DOWN UNTIL THE RUN LIGHT CHANGES TO GREEN AND THE LED
DISPLAY IS ILLUMINATED.
•Temperature setting range ： -20ºC ～ 20ºC, -4ºF ～ 68ºF ；
•Plug in the DC or AC power cable. Use the ON/OFF switch to run the fridge. The LED
display on the control panel will light up and the interior temperature will be displayed.
•Press SET and then press the
△
UP and
▽
DOWN buttons to adjust the temperature. Press the
button
△
to increase while the button
▽
to decrease the temperature. To lock in the target
temperature press set three times or leave for 5 seconds. The display board will display the
current temperature inside the unit after the target temperature is set. After approximately 5
minutes the displayed temperature will start to decrease.
•If the power supply is cut off, the refrigerator will switch off automatically and then
automatically switch on again when the unit receives power.
•To change the fridge between ºC and ºF. Press SET twice and then
△
UP or
▽
DOWN to
change the setting.
•To change the battery voltage setting press the SET button three times and the use the
△
UP
and
▽
DOWN buttons to change between the settings. Leave the unit for 5 seconds to set this
setting. The three voltage settings are as follows :- (We advise to keep the setting on LOW)
oLOW – 10.4 Volts
oMED – 11.2 Volts
oHIGH – 12 Volts

Instruction Manual
4 | P a g e
4. Cleaning and maintenance
•Clean the appliance inside and out with a damp cloth every week. If it is dirty, use
sodium bicarbonate dissolved in lukewarm water to clean the unit.
•Never use abrasive products, detergents or soap. After washing, rinse with clean water
and dry carefully. Do not leave the refrigerator off with food inside or lid closed.
•Never clean the appliance under running water. Do not use abrasive cleaning agents or
hard objects during cleaning as these can damage the refrigerator.
5. Troubleshooting
The appliance is not turning on.
•Check the power supply
•Check whether the plug and the socket have a good connection.
•Check whether the fuse has been burned out
•Check whether the appliance has been turned on
The food inside is frozen.
•The setting temperature is too low
Bad performance in refrigeration
•Too much food been placed inside the refrigerator
•The lid is unlocked/or open
•The lid seal is broken
•Problems arising from poor ventilation
•There is too much warm product inside
•There is no room around the fridge and vents
•There is a heat source near the unit
•The temperature setting is inappropriate
Hear the sound of water from inside the unit
•This is normal, due to the flow of the refrigerant.
Unusual noise when refrigerator is working
•The refrigerator is not placed on a level surface
•Some part has come loose inside the refrigeration compartment (see a service agent)

Instruction Manual
5 | P a g e
6. Error Codes
The error codes are depicted by a number of flashes by the error light in a sequence every
four seconds.
Code Reason / Solution
1 Flash Low Voltage
-Please check the source voltage to ensure it is above
the cut out. Try lowering the voltage cut out setting to
LOW.
-The vehicle cabling may be inadequate/unsuitable,
please refer to cable specifications table for correct
cable thickness.
2 Flashes Fan or compressor running issue
-Fan is drawing too many Amps (Over 1 Amp) –
Replace Fan.
-The compressor is drawing too many amps (Over 12
Amps)
-Possible Electronic Box or compressor fault – contact
Evakool or Service Agent
3 Flashes The compressor speed is too low
-Reduce products / items inside unit
-Move unit to a lower ambient temperature
-Clean vents / ensure clear air flow over compressor
4 Flashes Ambient Temperature too high
-Clean vents / ensure clear air flow
-Fan Fault – Replace fan

Instruction Manual
6 | P a g e
EVAKOOL TRAVELMATE FRIDGE FREEZER RANGE
Warranty Statement
TERMS & CONDITIONS
Nexberg Pty. Ltd. trading as EvaK l undertakes t the riginal purchaser that this pr duct is s ld free f defect in materials
and/ r w rkmanship under n rmal use f r a peri d f 24 m nths. Subject t the f ll wing: -
•The warranty peri d c mmences fr m the date f
purchase by the riginal purchaser fr m an
auth rised EvaK l dealer.
•EvaK l will h n ur this warranty n presentati n f
pr f f purchase f the unit t EvaK l r its
appr ved service agent. The service agent may be
requested t pr vide EvaK l with a ph t c py f
the pr f f purchase t btain appr val t pr ceed
pri r t warranty being h n red.
•Evak l will n t be held resp nsible f r any c sts
incurred in making a warranty claim.
•Please teleph ne [phone] f r the name f an
auth rized service agent r refer t list pr vided. It is
the purchaser’s resp nsibility t freight the unit t
and fr m the service agent.
•EvaK l will n t be held resp nsible f r any damage
r l ss suffered r c st incurred whilst fridge is in
transit.
•Warranty repairs may nly be carried ut by an
auth rised service agent. EvaK l will n t reimburse
repair claims carried ut by unauth rized service
agents. Any unauth rized tampering with any part f
the unit will aut matically v id the warranty.
•Service agents may charge a fee f r viewing r
testing the unit. This is n t c vered by EvaK l r
this warranty and is payable at the service p int
unless auth rized by EvaK l.
•Any Evak l auth rized service centre in Australia
will be able t carry ut the service f y ur unit. If a
repair needs t be undertaken and is c vered in
terms f this warranty a warranty auth rizati n
number must be btained pri r t c mmencement f
any w rk.
•EvaKool will not accept a warranty claim if:
1. M dificati ns have been carried ut t the unit
with ut EvaK l’s written auth rity.
2. Damage t r failure f the unit has been
caused in EvaK l’s pini n by inc rrect,
extreme r unreas nable use.
3. Damage t r failure f the unit has been
caused in EvaK l’s pini n by misuse,
neglect, accident, impact r similar cause.
Refer the preventative maintenance guidelines.
•EvaK l has t tal discreti n n the variati n f the
warranty terms.
•Our g ds c me with guarantees that cann t be
excluded under the Australian C nsumer Law. Y u
are entitled t a replacement r refund f r maj r
failure and f r c mpensati n f r any ther
reas nably f reseeable l ss r damage. Y u are
als entitled t have the g ds repaired r replaced if
the g ds fail t be f acceptable quality and the
failure d es n t am unt t a maj r failure.
•The ab ve warranty c nditi ns are in additi n t any
ther rights and/ r remedies as per the applicable
law.
•Failure t f ll w the guidelines/rec mmendati ns in
this manual may v id the warranty.
•This warranty cann t be varied by thers.
COMPLETE THE ENCLOSED WARRANTY CARD AND
RETURN WITHIN THIRTY (30) DAYS OF PURCHASE
POST or Register your product warranty
ONLINE at www.evakool.com
