Wiring
CAUTION: Disconnect power supply before
wiring connections are made to avoid
possible electrical shock or damage to
equipment.
All wiring should conform to the National
Electrical Code and local regulations.
Terminal block
CAUTION: Use terminal screws furnished in
the contact block.
Use tightening torque 20 lb. in. (2.3 Nm).
Use copper wire only.
Contact load ratings
Load Option A
CUT-OUT on temperature drop
Wire terminals 1-4:
CUT-IN = High Set Point (HSP)
see “Setting”
CUT-OUT = Low Set Point (LSP)
see “Setting”
Terms 1-4 close on temperature rise
Terms 1-4 open on temperature drop
Example: CUT-IN = +50°F (+10°C)
CUT-OUT = +40°C (+4.5°C)
This means
CUT-IN = HSP = +50°F (+10°C)
and
CUT-OUT = LSP = +40°F (+4.5°C)
Note:
⇑ = Bellows movement on pressure rise
⇓ = Bellows movement on pressure drop
The free terminal can be used for signal
purpose.
Load Option B
CUT-OUT on temperature rise
Wire terminals 1-2:
CUT-IN = Low Set Point (LSP)
see “Setting”
CUT-OUT = High Set Point (HSP)
see “Setting”
Terms 1-2 close on temperature drop
Terms 1-2 open on temperature rise
Example: CUT-IN = +32°F (+0°C)
CUT-OUT = +50°F (+10°C)
This means
CUT-IN = LSP = +32°F (+0°C)
and
CUT-OUT = HSP = +50°F (+10°C)
Manual reset
To resume control operation after safety cut-
out, push reset knob as indicated.
Note:
Man. reset is possible only after a
temperature rise of xed dierential (example
5.4°F)
Note:
use FINGERS ONLY!
(Do NOT use
screwdriver)
KP w/ manual reset
Note:
Push manual reset knob during manual
tripping.
Manual tripping
(Electrical contacts/wiring test)
Note:
use FINGERS ONLY!
(Do NOT use screwdriver)
KP w/ auto reset
Main
lever
Contacts
position
Main
lever
Contacts
position
Contacts
position
Contacts
position
120 V a.c. 16 FLA, 96 LRA
240 V a.c. 8 FLA, 48 LRA
240 V .c. 12 W pilot duty
