Danfoss HC75-3 Operating manual

1
Electronic Programmable Room Thermostats
HC75-3 with integral sensor.
HC75A-3 with remote sensor.
SETTING INSTRUCTIONS
SETTING THE CLOCK
After the recessed RESET button
has been pressed the display appears
as shown, with the colon blinking,
and all the factory pre-set conditions
will be present.
To set the clock to the correct time,
press and release the button marked
PROG. The digits blink.
Press the DAY button (the digits stop
blinking) until the correct day number is shown. (1 Monday).
Press and release the + or - buttons to change the time by one minute,
or press and hold down to change the time in ten minute steps.
When the time is correct press PROG to start the clock and continue
setting sequence.
SETTING THE EVENT TIMES & TEMPERATURES
The first event (time and temperature)
is displayed, together with the day or
days when it is active. Note that the
day number(s) displayed will be that
of the current day. In 7 Day mode only
a single day number will be displayed,
in 5/2 Day mode either 12345 or 67
will be displayed.
To step through the six available
events press and release the NEXT
button.
Whilst each event is on display, it
may be altered as required.
Selecting an event time
Press and hold down the + o r - buttons
to change the event time in ten minute
steps. Press and release to change
by one minute.
Selecting a heating temperature
Press and release the s button to
raise the HEATING control
temperature by 0·5°C (1°F), or press and release the t button to lower
the HEATING control temperature by 0·5°C. Press and hold down
these buttons to make larger changes to the control temperature.
Selecting a cooling temperature
Press and release the button to raise the COOLING control
temperature by 0·5°C (1°F), or press and release the button to lower
the COOLING control temperature by 0·5°C. Press and hold down
these buttons to make larger changes to the control temperature.
Dead and
Whilst adjusting the HEATING and COOLING temperatures it will be
noted that the two temperatures never become closer together than
2°C(5°F). This designed-in dead band prevents the heating and
cooling equipment from switching simultaneously.
Event No.
Days
Time
AUTO
HEAT
COOL
OFF
AUTO
ON
Cooling
Control
temp.
Heating
Control
temp.
Event No.
Time
Day
AUTO
HEAT
COOL
OFF
AUTO
ON
Heating
Control
temp.
Cooling
Control
temp.
7 day mode
5/2 day mode
Selecting an 'OFF' event
If there is a demand to turn 'OFF' rather than turn down the heating or
turn up the cooling, for example during unoccupied periods, an 'OFF'
event can be selected.
Selecting a programmed 'OFF' event for heating: use the t button to
lower the heating set temperature to its minimum value which is 'OFF',
the characters 'OF' will replace the heating control temperature.
Selecting a programmed 'OFF' event for cooling: use the button to
raise the cooling set temperature to its maximum value which is 'OFF',
the characters 'OF' will replace the cooling control temperature.
When all events for the day(s) on
display are as required press DAY to
show the following day's events.
The display will appear similar to one
of the diagrams on the right,
depending on whether the HC75 has
been set up for 7 day or 5/2 day
mode.
Use the , +, -, s, t, , NEXT
buttons to alter the events as required,
OR
If the previous day's programme is to
be repeated, press COPY to repeat
those events with just one button
press.
(Pressing COPY when in 5/2 mode will repeat the events programmed
for days 1 to 5 at the weekend).
Use the DAY and NEXT buttons to check all the events programmed,
using the +,-, s, t, , buttons to make alterations to each event
as necessary.
When all the events for every day are
as required, press PROG to return to
RUN mode, with the colon blinking.
The heating/cooling system will now
be controlled to provide the
temperatures programmed.
Refer to the USER'S GUIDE for details of the manual over-rides
available during day to day operation.
7 day mode
AUTO
HEAT
COOL
OFF
AUTO
ON
AUTO
HEAT
COOL
OFF
AUTO
ON
5/2 day mode
AUTO
HEAT
COOL
OFF
AUTO
ON
2
32°C
31°C
30°C
29°C
28°C
27°C
26°C
25°C
24°C
23°C
22°C
21°C
20°C
19°C
18°C
17°C
16°C
15°C
14°C
13°C
MIDNIGHT 3:00 6:00 9:00 12:00 15:00 18:00 21:00 MIDNIGHT
COOLING
HEATING
EVENT 1
EVENTS
2, 3 & 4
EVENT 5
EVENT 6
EXAMPLE
USER SET
PROGRAMME
3°C
DEAD
BAND
MANUAL OVERRIDE
=
USED
AT 9 AM TO RAISE
TEMPERATURE BY 2°C.
PROGRAMMED 3°C DEAD
BAND MAINTAINED.
FACTORY PRE-SET PROGRAMME
The table should be used to record the users programme. If the HC75 has been configured for
5/2 day control only days 1 and 6 need be recorded.
DAYS
PROGRAMME
EVENTS
123456
FORMAT
CLGHTGCLGHTGCLGHTGCLGHTGCLGHTGCLGHTG
TIME TIME TIME TIME TIME TIME
1
(Monday)
Pre-set 25.0 20.0 27.0 15.0 25.0 20.0 27.0 15.0 25.0 21.0 27.0 15.0
6:30 8:30 11:30 13:30 16:30 22:30
USER’S
2
(Tuesday)
Pre-set 25.0 20.0 27.0 15.0 25.0 20.0 27.0 15.0 25.0 21.0 27.0 15.0
6:30 8:30 11:30 13:30 16:30 22:30
USER’S
3
(Wednesday)
Pre-set 25.0 20.0 27.0 15.0 25.0 20.0 27.0 15.0 25.0 21.0 27.0 15.0
6:30 8:30 11:30 13:30 16:30 22:30
USER’S
4
(Thursday)
Pre-set 25.0 20.0 27.0 15.0 25.0 20.0 27.0 15.0 25.0 21.0 27.0 15.0
6:30 8:30 11:30 13:30 16:30 22:30
USER’S
5
(Friday)
Pre-set 25.0 20.0 27.0 15.0 25.0 20.0 27.0 15.0 25.0 21.0 27.0 15.0
6:30 8:30 11:30 13:30 16:30 22:30
USER’S
6
(Saturday)
Pre-set 25.0 20.0 27.0 20.0 25.0 20.0 27.0 20.0 25.0 21.0 27.0 15.0
7:30 9:30 11:30 13:30 16:30 22:30
USER’S
7
(Sunday)
Pre-set 25.0 20.0 27.0 20.0 25.0 20.0 27.0 20.0 25.0 21.0 27.0 15.0
7:30 9:30 11:30 13:30 16:30 22:30
USER’S
If the unit is to operate in 5/2 day mode, then only days 1 and 6 need be completed.
32°C
31°C
30°C
29°C
28°C
27°C
26°C
25°C
24°C
23°C
22°C
21°C
20°C
19°C
18°C
17°C
16°C
15°C
14°C
13°C
MIDNIGHT 3:00 6:00 9:00 12:00 15:00 18:00 21:00 MIDNIGHT
COOLING
HEATING
EVENT 1
EVENT 4
EVENT 5
EVENT 6
FACTORY
PRE-SET
PROGRAMME
5°C
DEAD
BAND
EVENT 3
EVENT 2
In the above diagram, event 2 has been moved to 15:30. Note that events 3 & 4 have also
been moved to that time, and that the following control temperature will be that of event 4.
It is possible to move events past midnight into the following day, when the day number will
blink in the display, see the display diagram in the notes on setting event times.
NOTES ON SETTING EVENT
TIMES
If, during the event checking and setting
procedure, no buttons are pressed for more than
two minutes then the HC75 will return to RUN
mode automatically. If this appears to have
occured, it is advisable to re-check the
programme to ensure that it is as required.
When setting event times and temperatures it is
not possible to set event times out of
chronological order.
Event 1 may be set at any time from 0:00 to
23:59 (but would normally be in the morning).
Event 2 may be set at any time between event
1 and 23 hours, 59 minutes after event 1.
Event 3 may be set at any time between event
2 and 23 hours, 59 minutes after event 1.
Event 4 may be set at any time between event
3 and 23 hours, 59 minutes after event 1,.... and
so on.
If the event time being set is moved past midnight
into the following day then the number of the
following day will blink.
When using the + button to adjust events 1 to 5
and the event time being adjusted becomes the
same as the following event time, then both are
changed simultaneously. This applies to all
subsequent event times reached and is
demonstrated in the lower diagram on the left.
When using the - button to adjust events 2 to 6
and the previous event time is reached the -
button ceases to respond.
The factory pre-set programme may be reinstated
by pressing the recessed RESET button. This
will however reinstate all the factory pre-set
conditions, so that the clock type, temperature
scale and optimum start period (if enabled) may
also have to be re-set.
Event 6 on day 6
set after
midnight.
3
Electronic Programmable Room Thermostats
HC75-3 with integral sensor.
HC75A-3 with remote sensor.
USER'S GUIDE
How to:
Select a 12 hour or a 24 hour clock display.
Select a °C or a °F temperature display.
Change between Winter Time and Summer Time at the press of a
button.
Convert the HC75 to act as a thermostat, controlling at the selected
temperature continuously.
Use the HC75 as a frost thermostat.
Use the holiday function.
Override the programmed temperature.
Fig. 1. Display following a
RESET. - RUN mode.
(Colon blinking)
AUTO
HEAT
COOL
OFF
AUTO
ON
Fig. 2. Clock set to 12 hour
display.
AUTO
HEAT
COOL
OFF
AUTO
ON
DISPLAY ELEMENTS
(Those that will appear whilst following these user's instructions).
AUTO
HEAT
COOL
OFF
AUTO
ON
Holiday mode
selected
Temperature
override
indicators
Indicates
temperature
display
Boiler ON
indicator
Programmed HTG
temperature
indicator
Fan
running
indicator
Day of week
lock time,
digital
thermometer, or
number of
holiday days
Programme
override
indicators
Frost
protection
mode indicator
Programmed LG
temperature
indicator
SELECTING THE TEMPERATURE DISPLAY
(°C or °F)
The factory pre-set temperature display is °C. If a °F display is
preferred then press and hold down the DAY and COPY buttons until
the display changes. Repeat to return to a °C display.
SETTING THE CLOCK
Press PROG to display the time of day on its own (the display blinks).
Press DAY (the display stops blinking) to select today (1 Monday, 6
Saturday etc).Press and hold down the + or - button to change the
time quickly in ten minute steps, or press and release to change the
time by one minute.
When the day and time are correct, press and release PROG once to
start the clock and further press and release again until the colon starts
blinking, (RUN mode.) The intermediate stage is explained in the
Setting Instructions.
Heating/Cooling System Performance.
The HC75 includes one in-built and one optional comfort enhancement
feature that may have been enabled by your installer. Both will affect
the way in which the heating part of your system operates, and this will
be different from that provided by conventional time controls and room
thermostats.
The in-built feature is an intelligent electronic anticipator which measures
the rate of temperature rise then switches the heating plant off before
the set temperature is reached. However the required comfort
temperature will be reached due to the residual heat in the system after
the heating planthas shut down. This feature is only activated when the
space temperature is 2°C or more lower than the set temperature.
If the optional Chrono-proportional feature has been enabled, then the
heating plant will operate at regular intervals to prevent the large
swings in space temperature caused by heat emitters alternating
between very hot and cold. In mild weather and when the system is up
to temperature the heating plant may operate only in short bursts with
long periods of inactivity. This is not a fault, and will provide increased
comfort.
RUN MODE
Whilst the HC75 is in RUN mode, i.e. controlling the space temperature
in accordance with the programme, the colon between the hours and
minutes digits blinks. The colon does not blink whilst the time and
programme are being set.
SELECTING THE CLOCK TYPE (12hr or 24hr)
The factory pre-set clock has a 24 hour display. If a 12 hour display
with AM/PM indication is preferred then press and hold down the
NEXT and DAY buttons until the display changes. Repeat to return to
a 24 hour display.
Fig. 3. Temperature range
changed to Fahrenheit.
AUTO
HEAT
COOL
OFF
AUTO
ON
Fig. 4. Clock time ready for
changing.
(Colon steady, digits blinking).
AUTO
HEAT
COOL
OFF
AUTO
ON
4
WINTER TIME / SUMMER TIME CLOCK
When the clocks are changed from Summer Time to Winter Time (or
vica versa) there is no need to alter the clock by entering programming
mode (i.e. pressing the PROG button). Instead just press and hold
down the - button to change from Summer Time to Winter Time or the
+ button to change from Winter Time to Summer Time. The first time
this is done (after a RESET) the clock is set and can only be changed
by one hour as appropriate.
If a mistake is made, e.g. pressing the + button in the autumn when
the - button should have been pressed, rectify the problem by pressing
the correct button and then re-setting the clock by one hour as
appropriate. (Refer to SETTING THE CLOCK on the previous page).
TIME OR TEMPERATURE DISPLAY
The default display in RUN mode shows the time of day. This may be
changed to display the actual temperature being sensed by pressing
both COPY and NEXT buttons together. Return to time display by
pressing them together again.
THERMOSTAT MODE
The HC75 can be converted to control either heating or cooling, (not
both), at a constant user selected temperature by selecting "Thermostat
mode". To do this, press and hold down both s and t buttons until the
display changes to that shown in fig. 6. When entering thermostat
mode the default setting is heating only, with a default temperature of
8°C (46°F ), this can be changed as required by pressing either s or
t until the require temperature is displayed.
To control at a constant cooling temperature (heat off), press the 'SEL'
button to select 'COOL', the temperature will be shown as 28°C (82°F)
(fig. 6a) use the s and t buttons to select the required temperature.
When in thermostat mode if "OFF" is selected by means of the
button, both heating and cooling are turned off.
To return to normal programmed operation, press and hold both s and
t.
FROST THERMOSTAT MODE
While in thermostat mode the HC75 may be set to guard against
possible freeze damage in areas where the unit (or its remote sensor)
is installed. The heating control temperature may be set to a suitable
level using the s or t buttons.
HOLIDAY MODE - Heating or Cooling only
While in thermostat mode with either HEAT or COOL selected,
pressing the DAY button will activate the vacation mode. The display
will change to that shown in Fig. 7 or Fig. 7a with a number indicating
the default vacation period of 00 days. Use the + or - buttons to set
the number of days required, in the range 1-99 days. If the number of
days is left at 00 then the unit will return to normal at event 1 the
following day. When the selected number of days have elapsed the
unit will automatically return to normal, controlling temperatures to the
set program.
Control may also be restored to normal before all days have elapsed
by pressing the s and t buttons simultaneously.
USER OVERRIDES
Whilst the unit is operating normally in RUN mode the following
overrides are available:
TEMPERATURE SETTING OVERRIDE
Press s to increase or t to decrease the current set temperatures.
Each press will change the temperature settings by 0.5°C (or 1°F). To
make larger changes press the button and hold it down. The
temperatures can be raised until the cooling temperature reaches
32°C(90°F) or lowered until the heating temperature reaches 5°C(41°F).
Note that the programmed dead band between the heating and
cooling temperatures is maintained whilst the override is being used.
PROGRAMME OVERRIDE
Whilst running in AUTO mode both the heating plant and cooling plant
will be switched on and off to maintain the selected temperatures.
The SEL (select) button can be used to select one of three other
modes.
AUTO
HEAT
COOL
OFF
AUTO
ON
Fig. 5. Temperature Display.
(Space temperature is below
the set temperature, so the
heating plant and fan are
operating).
Fig. 6. Thermostat mode (Heating) Fig. 6a Thermostat mode (Cooling)
AUTO
HEAT
COOL
OFF
AUTO
ON
AUTO
HEAT
COOL
OFF
AUTO
ON
28.0°c
8.0°c
Fig. 7 - Heating Fig. 7A - Cooling
AUTO
HEAT
COOL
OFF
AUTO
ON
AUTO
HEAT
COOL
OFF
AUTO
ON
82.0°F
28.0°c
8.0°c
AUTO
HEAT
COOL
OFF
AUTO
ON
AUTO
HEAT
COOL
OFF
AUTO
ON
Fig. 8. Temperature raised -
heating plant & fan running.
Fig. 9. Temperature lowered -
cooling plant & fan running.
With HEAT selected only the heating
plant will be controlled, the cooling
plant being switched off.
With COOL selected only the cooling
plant will be controlled, the heating
plant being switched off.
With OFF selected both heating and
cooling will be switched off. In this
mode there is no frost protection.
FAN OVERRIDE
Pressing the button marked FAN
will switch the fan between AUTO,
ON and SMART.
AUTO: Thermostat starts fan when
there is a demand for either heating
or cooling.
ON: Fan runs continuously.
SMART: Fan runs continuously
during events 1-6 unless a
programmed 'OFF' is encountered, but reverts to Auto mode during
event 6-1. When in 'Smart' mode, the bar on the display adjacent to
FAN ON will flash.
FAN SPEED SELECTION
The slider switch under the flap can be used to select one of three fan
speeds. (A special fan motor is required).
BATTERY MAINTENANCE
Only good quality alkaline batteries should be used.
New batteries will provide the power for switching the outputs on and off for
approximately 2 years. When the batteries volts fall to the minimum level
needed to maintain operation a battery symbol will blink in the display. When
this symbol appears both batteries should be replaced with high quality
alkaline cells. Operation will continue normally until the 15th midnight after
the symbol started blinking and then the unit will switch off all outputs, and
shut down with just the time and the blinking battery displayed. Whilst the
battery symbol is still blinking, the old batteries may be removed and new
batteries placed in the sleeve provided and inserted within one minute.
Internal circuitry will maintain the user set programme memory during this
period.
AUTO
HEAT
COOL
OFF
AUTO
ON
AUTO
HEAT
COOL
OFF
AUTO
ON
AUTO
HEAT
COOL
OFF
AUTO
ON
Fig. 11.
Blinking battery symbol, change
batteries.
Part No: 8951 Iss 8 12/01
Danfoss Randall Ltd.
Ampthill Road,
Bedford, MK42 9ER
Tel: 01234 364621 Fax: 01234 219705
email: [email protected]
Website: www.danfoss-randall.co.uk
Danfoss Randall Ltd. continually strives to improve its products and
reserves the right to change designs and specifications without notice.
AUTO
HEAT
COOL
OFF
AUTO
ON
AUTO
HEAT
COOL
OFF
AUTO
ON

This manual suits for next models

1

Other Danfoss Thermostat manuals

Danfoss RET 230 HCW-1 User manual

Danfoss

Danfoss RET 230 HCW-1 User manual

Danfoss RET1001M User manual

Danfoss

Danfoss RET1001M User manual

Danfoss REP24CO User manual

Danfoss

Danfoss REP24CO User manual

Danfoss 3020P Assembly Instructions

Danfoss

Danfoss 3020P Assembly Instructions

Danfoss FHV-R User manual

Danfoss

Danfoss FHV-R User manual

Danfoss SET 3E User manual

Danfoss

Danfoss SET 3E User manual

Danfoss ECL Comfort 210 User manual

Danfoss

Danfoss ECL Comfort 210 User manual

Danfoss GET B-RF Guide

Danfoss

Danfoss GET B-RF Guide

Danfoss ECL Comfort 210 User manual

Danfoss

Danfoss ECL Comfort 210 User manual

Danfoss FH-CWT User manual

Danfoss

Danfoss FH-CWT User manual

Danfoss DEVIreg 316 User manual

Danfoss

Danfoss DEVIreg 316 User manual

Danfoss LX 420 User manual

Danfoss

Danfoss LX 420 User manual

Danfoss RT 14E User manual

Danfoss

Danfoss RT 14E User manual

Danfoss CET2000B-RF User manual

Danfoss

Danfoss CET2000B-RF User manual

Danfoss TP5000-RF Operating instructions

Danfoss

Danfoss TP5000-RF Operating instructions

Danfoss ECtemp 330 User manual

Danfoss

Danfoss ECtemp 330 User manual

Danfoss RAS-D2 Combi User manual

Danfoss

Danfoss RAS-D2 Combi User manual

Danfoss TP7000M User manual

Danfoss

Danfoss TP7000M User manual

Danfoss FP715Si User manual

Danfoss

Danfoss FP715Si User manual

Danfoss 088L5130 User manual

Danfoss

Danfoss 088L5130 User manual

Danfoss RT2-RF User manual

Danfoss

Danfoss RT2-RF User manual

Danfoss FP975 User manual

Danfoss

Danfoss FP975 User manual

Danfoss DEVIreg Multi User manual

Danfoss

Danfoss DEVIreg Multi User manual

Danfoss ECtemp 610 User manual

Danfoss

Danfoss ECtemp 610 User manual

Popular Thermostat manuals by other brands

Saswell SAS908XWHB-7-RF User manual and warranty card

Saswell

Saswell SAS908XWHB-7-RF User manual and warranty card

Worcester Greenstar Sense I Installation and operation manual

Worcester

Worcester Greenstar Sense I Installation and operation manual

White Rodgers 1A11-2 installation instructions

White Rodgers

White Rodgers 1A11-2 installation instructions

SPC Modulo Installation and operating instructions

SPC

SPC Modulo Installation and operating instructions

Warmup ELTPB installation guide

Warmup

Warmup ELTPB installation guide

DELTA DORE TYBOX installation guide

DELTA DORE

DELTA DORE TYBOX installation guide

AirTechnic TCA2 user manual

AirTechnic

AirTechnic TCA2 user manual

Adax WT user manual

Adax

Adax WT user manual

Siemens RAA20 user manual

Siemens

Siemens RAA20 user manual

OJ Electronics MWD5-1999-OJC3 user manual

OJ Electronics

OJ Electronics MWD5-1999-OJC3 user manual

ComfortNET CTK04 System installation guide

ComfortNET

ComfortNET CTK04 System installation guide

Aprilaire S84N 1H1C owner's manual

Aprilaire

Aprilaire S84N 1H1C owner's manual

AMX VST-TSTAT Dimensional drawing

AMX

AMX VST-TSTAT Dimensional drawing

Bosch TSTBM3H2CPH6W-A installation manual

Bosch

Bosch TSTBM3H2CPH6W-A installation manual

Home Automation Omnistat RC-80 owner's manual

Home Automation

Home Automation Omnistat RC-80 owner's manual

Salus S Series instruction manual

Salus

Salus S Series instruction manual

Carrier Debonair 2 owner's manual

Carrier

Carrier Debonair 2 owner's manual

Honeywell CM720 installation guide

Honeywell

Honeywell CM720 installation guide

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
