DANIU QY-EWQ-01 User manual

1/ 16
Infrared Forehead
Thermometer
Product Specification
Product model:QY-EWQ-01
Thank you for purchasing our infrared thermometer
Please read the instructions before use
After reading, please keep it properly for reference at any time.
For emergency use only at the epidemic situation.

2/ 16
Contents
1.Description‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧1
2.Safety manual‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧1
3.Feature‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧1
4.Other instructions‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧1
5.Precautions before use‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧2
6.Product structure‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧2
7.Description of LCD display ‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧2
8.Product adaptation range and contraindications‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧2
9.Technical index‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧3
10.Operating instructions‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧4
11.Reference temperature‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧6
12.Advice‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧7
13.Care and maintenance‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧7
14.Waste treatment instructions‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧8
15.Electromagnetic compatibility warning‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧8
16.Symbol Description‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧13
17.Product maintenance warranty card‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧14
18.Product accessories list‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧16
19.Statement‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧16

3/ 16
1.Description
This product is a professional infrared forehead thermometer to measure the temperature of the
human forehead. Different body parts were measured for different temperatures, because the more
exposed the body parts were, the more influenced by the ambient temperature.
2.Safety manual
Please read this manual carefully before use, users should use this product according to the
instructions.
The ambient temperature of this product is 16 ℃～35 ℃, the optimal temperature is 25 ℃.
Do not use this product in an environment above 50 ° C or below 0 ° C.
Do not place this product near live objects to avoid electric shock.
Do not use this product in an environment with a relative humidity greater than 93%.
Do not place this product too close to the electromagnetic range. (E.g. radio, mobile phone, etc.).
Please do not expose this product to the sun, or near the stove, and do not touch the water.
Do not bump or drop the product, and do not use it if it is damaged.
Sweat, hair, hat, or other foreign matter on the forehead can affect the accuracy of the measurement.
Please make sure the measurement distance is within 3-5 cm.
When forehead sweating or other reasons cause the forehead temperature does not reflect the body
temperature normally, please measure from the earlobe.
When cleaning is required, wipe the surface of the meter lightly with alcohol.
Contact the distributor if there is any problem with the product and do not repair the product by
yourself.
3.Feature
1）Measure body temperature with high accuracy.
2）Optional for ℃or ℉
3）Buzzer function
4）LCD display with backlight
5）Automatic range selection; resolution is 0.1 ° C (0.1 ° F)
6）The latest 20 measurement data can be memorized and stored (press the up and down arrow keys
to check that the latest 20 measurement data have been stored)
7）Automatic saving data and shutdown
4.Other instructions
1) This infrared forehead thermometer is a professional thermometer for measuring the forehead of a
human body. It is widely used for the householder, unable to replace a doctor's diagnosis.
2) This manual is applicable to QY-EWQ-01, QY-EWQ-02, QY-EWQ-03 models.
5. Precautions before use:
1) Make sure follow the below steps before using:
Step 1: Use a traditional thermometer to measure, assuming got the value is 7.5 ° C (99.5 ° F)
Step 2: Then, use our infrared forehead thermometer to measure the same person, the distance is 3-5
cm between the thermometer and the forehead (be careful to remove any obstacles that may affect the
measurement, such as hair, sweat, etc.), if you get the same temperature 37.5 ° C (99.5 ° F), the
infrared forehead thermometer is set up and ready for use. If you get a low reading, such as 36.4 ° C
(97.5 ° F, a difference of 1.1 ° C (2.0 ° F), you need to correct the infrared forehead thermometer, plus
the difference. Calibration steps "Note! Non-professional not operational!" After 5S, press and hold
the + key and the function key to power on. After hearing 2 beeps, press the-key to enter the
calibration mode. Take the 35-degree standard body and the 40-degree standard body in sequence. The
calibration is completed. Then switch to material temperature mode for temperature verification.
Step 3: Measure again to check.
2) Power on self test
△Aim at the target and press the measurement switch, the LCD will display all the numbers and
characters of the self-test.
And a self-test screen appears, as shown in Figure 1. This picture is displayed for about 1 second.

4/ 16
Picture 1:
△After the self-test is completed, a beep will be heard, indicating that the power-on self-test has
been completed, and the target temperature will be displayed on the LCD.
6.Product structure
The product mainly consists of an infrared sensor, a processor, a liquid crystal display (LCD),
buttons, a plastic case, a battery, and a circuit board.
①．Switch model
②．Liquid crystal (LCD) display
③．Infrared sensor
④．Handle
⑤．Up + button
⑥．Down-button
⑦．Set key
⑧．The battery cover
7.Description of LCD display Picture 2:
①Human body temperature mode
②.Switch ℃or ℉
③. Digital reading
④.Memory
⑤. Number of data logging / Standard model setting up
⑥. Battery indication Picture 3:
⑦. Prompt sound
⑧. Surface mode
8.Measure type and contraindications
8.1 Measure type
The heat radiation from the forehead can be well measured.
8.2 Contraindications
1) Conditions such as birth defects, congenital malformations, septic shock, and circulatory failure that
may seriously affect frontal temperature measurement;
2) suffering from mental disorders;
3) Suffering from serious heart, liver, kidney and other diseases;
4) Children have a defective immune system and severe fever who are from the 100 days newborn to
the age of three.
9.Technical Index
9.1Measuring range
Measured temperature range
33.0
℃～
43.0
℃
Proper measuring distance range
3 to 5 cm (1.18 to 1.97 inches) The best measurement is 3
cm
Automatic shut-down
13s
9.2 Measurement accuracy
33
～
43
℃（
91.4
～
109.4
℉）
±0.2
℃（
32.4
℉）
<33
℃（
91.4
℉）
±2.0
℃（
35.6
℉）
>43
℃（
109.4
℉）
±2.0
℃（
35.6
℉）

5/ 16
9.3 Basic parameters
The exact digits which displayed
0.1
℃（
0.1
℉）
Storage temperature
-20℃～55℃（-4℉～131℉）
Operation ambient temperature
16
℃～
35
℃（
60.8
℉～
95.0
℉）
The best
temperature is 25
℃
Relative humidity
≤85%RH
Power supply
DC 3V
（
2 AAA batteries
）
Dimensions
154*87.7*44MM
Net weight:
0.11kg
Anti-shock type
Internal power supply equipment
Protection against electric shock
BF type application part
Degree of protection against incoming fluid
Not applicable
Operating mode
Continue to operate
Production date
See product nameplate for details
Maximum permissible error
· ±0.2
℃
within the range of 33
℃
to 43
℃
· ±0.2℃outside the range of 33℃-43℃
Clinical accuracy
1
）
Clinical deviation: ≤ ± 0.3
℃
2）Clinical standard deviation: ≤ ± 0.3 ℃
Clinical repeatability
≤±0.3
℃
9.4 Product life
2 years (excluding battery)
9.5 Software release version No.: V1.1
9.6 Requirements for work environment, storage and transportation
1) Working environment:
■ Ambient temperature: 16 ℃～35 ℃(60.8℉～95.0℉) The best temperature is 25 ℃
■ Relative humidity: ≤85% RH
■ Atmospheric pressure: 70Kpa ～106Kpa
■ Power supply: DC3V (2 AAA batteries)
2) Storage and transportation environment:
■ Ambient temperature: -20° C-55 ° C (-4 ° F ~ 131 ° F);
■Relative humidity: <85% RH;
■No corrosive gas, well ventilated room.
■Transportation requirements are as stipulated in the order contract, but it must be prevented
from
severe impact, vibration and rain and snow splashing during transportation.
3) Outer packaging environment
■ Ambient temperature: -20 ℃-55 ℃
■ Relative humidity: <85% RH;
■ No corrosive gas, well ventilated room.
■ Transportation requirements are as stipulated in the order contract, but it must be prevented from
severe impact, vibration and rain and snow splashing during transportation.
10.Operating instructions
10.1 Battery instruction and key description
1. Battery usage instructions (refer to Figure 4):
There is a removable battery cover at the bottom of the handle. Please push here by hand in the
direction indicated

6/ 16
Picture 4:
■ Battery installation and replacement:
1) After the battery cover is opened, place the battery in the direction of the positive and negative
electrodes, and pay attention to the direction of the positive and negative electrodes.
2) Please replace the new battery while low battery alarm, press (Figure 4) to open the battery
compartment cover (see product structure ⑨), pay attention to the positive and negative polarity
when replacing the new battery. Noted that improper placement may damage the products or
batteries.
3) If you do not use it for a long time, better to remove the battery to extend the life to prevent
damage to the thermometer due to battery leakage.
2. Button description:
1): Calibration mode: After removing the battery, press and hold the + key and the function key to
power on lasting 5S. After hearing 2 beeps, press the-key to enter the calibration mode. Take the
numbers in sequence, complete the calibration, and then switch to the object temperature
measurement mode for temperature verification.
2): Power-on key: Press and hold the switch / function key for 3 seconds to power on / off,
3): Power on, enter the screen self-test, the end of the beep reminder, and enter the ambient
temperature display.
4): Temperature measurement key: short press, the collected temperature will be displayed on the
screen within 1 second, and the current test record will be kept before the next action.
5): Function key
● Short press the first time to switch between body temperature and surface temperature mode.
● Press and hold for 3 seconds to enter the setting mode:
a. F1 state, for F and ℃mode switching selection, press +,-to switch;
b. Short press again, F2 status is for adjusting the temperature of high temperature alarm, press +,-to
adjust the temperature to be alarmed;
c. Short press once again, F3 state, for the display data offset setting, press +,-to adjust the value to
be offset displayed;
d. Short press once again, F4 state, for the buzzer sound switch setting, press +,-to adjust the true
sound switch;
● In the power-on state, press the +/- key: In order to enter the temperature measurement view

7/ 16
viewing mode, press + to turn up,-to turn down, the latest 20 measurement data can be stored
3. Data storage
The body thermometer can automatically store the temperature of the human body measured nearly
20 times and display it on the screen. You can view the stored data by "+" or "-" when the power is
on.
10.2 Temperature measurement procedure
1.Aim the infrared forehead thermometer in the
middle of the forehead (Above the center of the
eyebrow, no hair covering)
And keep it vertical, 3 to 5 cm away,
press the measurement button,
the temperature is displayed immediately. Picture 5:
2. The measured temperature can be automatically stored when measurement. (see product structure
①) (press the "+,-" key to check that the latest stored 20 measurement data)
Note:
1) Before measuring, make sure there is no covering, like hair, sweat, cosmetics or hat and so on.
2) No temperature reflected when caused by the forehead’s sweats
or other reasons, please aim at the earlobe.still no covering by hair,
sweat, cosmetics or hats
Picture 6:
3) The boot time is extended by 1 to 2 seconds if the thermometer has not been used for a long time
that due to the thermometer will inspect the environment temp.
4) A person's body temperature changes at different times of the day, and is also affected by other
external conditions, such as age, gender, and skin color.
5) It is recommended to measure about three times at a time, whichever is the most displayed data.
11. Reference temperature
11.1 Normal body temperature range at different measurement parts
The human body is a very complex biological comprehensive system. Body temperature is an
important data to measure the normality of human life activities. Usually we measure our health by
measuring the temperature of the forehead, cochlea, anus, mouth and axillary. Different part would be
different value, the specific differences refer to the following table:
Measurement part Normal temperature (℃) Normal Fahrenheit (° F)
Anus 36.6～38 97.8～100.4
Oral cavity 35.5～37.5 95.9～99.5
Oxter 34.7～37.3 94.4～99.1
Ear 35.8～38 96.4～100.4

8/ 16
11.2 Normal body temperature range at different ages
A person's body temperature changes at different times of the day and is also affected by other
external conditions, such as age, gender, skin color, and thickness. For the normal temperature range
of different age groups, please refer to the table below:
Age Normal temperature (℃) Normal Fahrenheit (° F)
0 ～2 years old 36.4～38.0 97.5～100.4
3 to 10 years old 36.1～37.8 97.0～100.0
11 to 65 years old 35.9～37.6 96.6～99.7
> 65 years 35.8～37.5 96.4～99.5
Note:
Women's body temperature is different from men's, generally about 0.3 ℃higher than men's,
body temperature during ovulation will rise 0.3 ℃～0.5 ℃than usual.
12. Advice
·The protective sheet outside the LCD frame is very important, it is also the fragile part of the
meter, please use it carefully.
• Do not charge non-rechargeable batteries and do not throw them into fire.
· Please do not expose this product to the sun, and do not touch the water
13. Maintenance
13.1 Product care and cleaning
1) The sensor head is the most precise part of the product and must be carefully protected.
2) Do not use abrasive cleaners to clean this product.
3) Do not infiltrate the product into water or other liquids.
4) Keep the product in a dry place to avoid dust, pollution and direct sunlight.
5) Please clean the infrared forehead thermometer regularly, usually once a month. If necessary, you
can perform appropriate cleaning according to the actual soiling of the product; please use a dry soft
cloth to clean the infrared forehead thermometer. If the instrument is extremely dirty, use a cloth
moistened with water or a neutral detergent to fully dry it, wipe the body, and then wipe it with a dry
cloth.
13.2 Product Maintenance
If you encounter the following problems during use, please follow the instructions in the
maintenance instructions to find a solution. If the problem persists, please contact our customer
service.
1) LCD cannot display the value
If the temperature measurement mode is below 33 ° C or above 43 ° C, the LCD will not display
the data and will display "Lo" or "HI".
2) LCD display message "HI"
Using infrared forehead thermometer, LCD shows "HI", analysis shows that it has exceeded the
measurement range or measured temperature above 43 ℃in human body temperature measurement
mode.
3) LCD display message "Lo"
Using infrared forehead thermometer, the LCD displays the message "Lo", and the analysis shows
that the temperature is below the measurement range or the measurement temperature is lower than

9/ 16
33 ℃in the human body temperature measurement mode.
The information "Lo" or "HI" appears for reference:
Reason for the message "Lo" or "HI"
Temperature measurement result is out of
measurement range
Temperature value is affected by hair and
sweat
Ensure no obstructions during temperature
measurement
Temperature is affected by changes in
airflow
Ensure that the air remains stable during temperature
measurement
The measurement distance is too far Please note that the measurement distance should
not be greater than 5 cm
Enter indoors from outside low or high
temperature
Please wait 15 minutes until the subject's
temperature adapts to the measurement environment
before measuring
14.Waste treatment instructions
■Disposing electronic products and batteries directly in the trash can cause harm to the environment.
Please dispose of them in accordance with the laws of your area.
■Do not discard the trash can at the end of the use of the infrared forehead thermometer. Please
dispose of it according to the laws in your area, or contact the manufacturer for recycling.
15.Electromagnetic compatibility warning
Note:
·Comply with the relevant requirements of electromagnetic compatibility of YY0505—2012
standard.
· Users should install and use according to the electromagnetic compatibility information provided in
the accompanying documents.
·Portable and mobile RF communication equipment may affect the performance of infrared
thermometers, avoid strong electromagnetic interference when using, such as near mobile phones,
induction cookers, etc .;
·Guidelines and manufacturer's declarations are detailed in the annex.
Warning:
·The equipment or system should not be used close to or stacked with other equipment. If it must be
used close to or stacked, it should be observed to verify normal operation in the configuration in which
it is used.

10 / 16
Annex:
Guidance and manufacturer's declaration-electromagnetic emissions
The infrared thermometer is intended for use in the electromagnetic environment specified below. The purchaser or
user of the infrared thermometer should ensure that it is used in this electromagnetic environment:
Launch test Compliance Electromagnetic Environment-A Guide
GB4824 RF launch 1set
Infrared thermometers use RF energy only for their internal
functions. Therefore, its RF emissions are very low and may not
cause any interference to nearby electronic equipment.
GB4824 RF launch Class B Infrared forehead thermometers are suitable for use in all facilities,
including homes and public low-voltage power supply networks
directly connected to homes.
GB17625.1
Harmonic emission Not applicable
GB17625.12
Voltage fluctuation / flicker
emission
Not applicable
Guidelines and manufacturer's declaration-electromagnetic immunity
The infrared forehead thermometer is expected to be used in the electromagnetic environment specified below. The
purchaser or user of the infrared forehead thermometer should ensure that it is used in this electromagnetic
environment.
Immunity test IEC 60601 test level Coincidence
level
Electromagnetic Environment-A
Guide
Electrostatic Discharge
(ESD)
GB / T 17626.2
±6 KV contact discharge
± 8 KV air discharge
± 6 KV contact
discharge
± 8 KV air
discharge
The floor should be wood, concrete
or tile, and if the floor is covered
with synthetic material, the relative
humidity should be at least 30%.
Electrical fast transient
burst
GB / T 17626.4
± 2 KV to power cord
± 1KV to input / output line Not applicable Not applicable
Surge
GB / T 17626.5
± 1 KV differential
mode voltage
± 2 KV common mode
voltage
Not applicable Not applicable

11 / 16
Voltage on power input line
Sags, short interruptions
and
Voltage change
GB / T 17626.11
<5% UT for 0.5 weeks
(on UT,> 95% sag)
40% UT. 5 weeks
duration (60% sag on
UT)
70% UT for 25 weeks
(30% sag on UT)
<5% UT for 5S (> 95%
dip on UT)
Not
applicable
Not applicable
Power frequency magnetic
field
(50 / 60Hz)
GB / T17626.8
3A/m 3A/m/50H
z/60Hz
Power frequency magnetic fields should
have the power frequency magnetic field
level characteristics of a typical place in a
typical commercial or hospital environment.
Note: UT refers to theAC network voltage before the experimental voltage is applied
Guidance and manufacturer's declaration-electromagnetic immunity
The infrared forehead thermometer is intended to be used in the electromagnetic environment specified below. The
purchaser or user of the infrared forehead thermometer should ensure that it is used in this electromagnetic
environment:
Immunity test IEC 60601 test level Coincidenc
e level
Electromagnetic Environment-Guide
Note 1: Frequency of 80MHz and 800MH,using the high frequency channel.
Note 2 These guidelines may not be suitable for all situations. Electromagnetic propagation is affected by absorption
and reflection from buildings, objects and people.

12 / 16
RF conduction
GB / T
17625.6
RF radiation
GB / T
17626.3
3 Vrms
150 KHz to 80 MHz
3V/m
80 MHz to 2,5 GHz
Not
applicable
3V/m
Portable and mobile RF
communications equipment should not be
used closer to any part of the infrared
thermometer than the recommended
isolation distance, including cables. This
distance should be calculated by a formula
corresponding to the frequency of the
transmitter.
Recommended isolation distance
d =1.2
p
d =1.2
p
80 MHz to 800 MHz
d =2.3
p
800 MHz to 2,5 GHz
Among them, p is according to the
transmitter's maximum output rated power
provided by the transmitter manufacturer, in
watts (W), and d is the recommended
isolation distance in meters (m).
The field strength of the fixed RF transmitter
is determined by surveying the
electromagnetic field, and it should be lower
than the compliance level in each frequency
range.
a Fixed transmitter manufacturers, such as: base stations for wireless (cellular / cordless) phones and ground mobile
radios, amateur radio, AM (Amplitude Modulation) and FM (Frequency Modulation) radio broadcasts, and
television broadcasts. The field strength is theoretically It is impossible to predict accurately. In order to evaluate the
electromagnetic environment of fixed RF transmitters, the survey of electromagnetic sites should be considered. If
the measured field strength of the infrared forehead thermometer is higher than the RF compliance level of the above
application, the infrared forehead thermometer should be observed to verify its normal operation. If abnormal
performance is observed, supplementary measures may be necessary, such as reorienting or positioning the infrared
thermometer.
b In the entire frequency range of 150KHz-80MHz, the plant strength should be lower than 3V / m.

13 / 16
16.Symbol Description
Symbol graphics Meaning Symbol graphics Meaning
Note, refer to the attached file Reference instructions
Low voltage alert ( BF type application part
Trash
Recommended isolation distance between portable and mobile RF communication devices and
infrared forehead
thermometers
Infrared forehead thermometers are intended for use in electromagnetic environments where radiated RF
disturbances are controlled. According to the maximum output power of the communication equipment. Purchasers
or users of
infrared forehead thermometers can prevent electromagnetic interference by maintaining a minimum
distance between portable and mobile RF communication equipment (transmitters) and infrared forehead
thermometers as recommended below.
Transmitter's rated
maximum output power
/ w
Isolation distance for different frequencies of the transmitter / m
150kHz—80MHz
d=1.2
150kHz—80MHz
d=1.2
150kHz—80MHz
d=2.3
0.01 Not applicable 0.12 0.23
0.1 Not applicable 0.38 0.73
1 Not applicable 1.2 2.3
10 Not applicable 3.8 7.3
100 Not applicable 12 2.3
For the rated maximum output power of the transmitters not listed in the table above, the recommended isolation
distance d, in meters (m), can be determined using the formula in
the corresponding transmitter frequency column,
where p is the emission provided by the transmitter manufacturer Machine maximum output power in watts (w).
Note 1:At 80MHz and 800MHz frequencies, the higher frequency range formula is used.
NOTE 2
These guidelines may not be suitable for all situations. Electromagnetic propagation is affected by
absorption and reflection from buildings, objects and people.

14 / 16
Product Maintenance Card
(This link is reserved for the seller, using
this card as a voucher)
(This card is used for customer service
return, and must be completed)
Client's name:Phone:
Address:
Product name:Product model:
Purchase date:Purchase city:
Fault description:
Dear customer, please use the AAA battery
when replacing the battery
Product Maintenance Card
(This link is reserved for the seller, using
this card as a voucher)
(This card is used for customer service
return, and must be completed)
Client's name:Phone:
Address:
Product name:Product model:
Purchase date:Purchase city:
Fault description:
Dear customer, please use the AAA battery
when replacing the battery
17
、
Product Maintenance Card

15 / 16
Free Warranty Provisions
(I) Warranty period starts from the date of purchase. You can enjoy a two-year free
warranty and lifetime maintenance service taking a shopping invoice or warranty
card.
(2) The warranty provides free maintenance service if using according to the
instruction manual.
(3) Go to the service center or repair location if caused by the manufacturing
problems.
(4) The following conditions will not enjoy free repair:
(a) Disassemble and modify the products unauthorizedly
(b) Improper storage, such as breakdown and damage caused by transportation
damage, bumps, battery leakage, etc.
(c) Damage caused by force majeure (fire, earthquake, flood, lightning, etc.).
(d) Failure caused by the improper operations, not with the instructions.
(e) The warranty is invalid if altering the maintenance card or invoice without
authorization.
(5) Make sure ask the store staff to stamp the warranty card when purchasing this
product. Free service should hold the warranty card which was filled with purchase
date and the sealed (including the name and address of the store).
(6) Charged outside the warranty if need repair serive.
(7) This product maintenance card is only valid in China. One card per machine is
not reissued.
Free Warranty Provisions
(I) Warranty period starts from the date of purchase. You can enjoy a two-year
free warranty and lifetime maintenance service taking a shopping invoice or
warranty card.
(2) The warranty provides free maintenance service if using according to the
instruction manual.
(3) Go to the service center or repair location if caused by the manufacturing
problems.
(4) The following conditions will not enjoy free repair:
(a) Disassemble and modify the products unauthorizedly
(b) Improper storage, such as breakdown and damage caused by transportation
damage, bumps, battery leakage, etc.
(c) Damage caused by force majeure (fire, earthquake, flood, lightning, etc.).
(d) Failure caused by the improper operations, not with the instructions.
(e) The warranty is invalid if altering the maintenance card or invoice without
authorization.
(5) Make sure ask the store staff to stamp the warranty card when purchasing
this product. Free service should hold the warranty card which was filled with
purchase date and the sealed (including the name and address of the store).
(6) Charged outside the warranty if need repair serive.
(7) This product maintenance card is only valid in China. One card per machine is
not reissued.

16 / 16
18. Product accessories list
One QY-EWQ-01 infrared forehead thermometer, one manual, one certificate of conformity. Please in
kind prevail.
19.Statement
If necessary, the company can provide the specified circuit diagrams, component lists, legends,
calibration details for helping the users’ qualified technicians repair.
Certificate of Conformity
Product name: Infrared Forehead Thermometer
Product model: QY-EWQ-01
IQC:
Manufacturing Date:
Registrant/Manufacturer / After-sales service company: Hangzhou Qingyuan Medical
Equipment Technology Co.,Ltd.
Registrant/ Manufacturer residence: No.688 Dong'an 1st Road, Xintang Street, Xiaoshan
District, Hangzhou
Manufacturing Address / After-sales Service Address: No.688 Dong'an 1st Road, Xintang
Street, Xiaoshan District, Hangzhou
This product has been inspected by the company's quality control and assurance
department, and its quality meets technical standards.
