HW Group Poseidon 3262 How to use

Poseidon 3262 – starting guide HW group
Oficjalny dystrybutor:
www.atel.com.pl 45-231 Opole tel. [phone]
ATEL ELECTRONICS
e-mail: [email protected] ul. Oleska 121 fax. [phone]
Starting Guide – Poseidon 3262
First steps for remote monitoring with Poseidon & GSM
1) Connecting the Poseidon 3262


• Green POWER LED on the RJ45 socket lights up – power supply is OK
• Yellow LED on the RJ45 socket blinks – connection to 10 Mbit network is OK
Accessories
600 166 Poseidon 3262 Poseidon 3262 unit
600 257 Poseidon 3262 Tset Quick start set – contains a temperature sensor, AC adapter, etc.
600 242 Temp-1Wire 1m Temperature sensor, 1m cable
600 005 Temp-1Wire 3m Temperature sensor, 3m cable
600 056 Temp-1Wire 10m Temperature sensor, 10m cable
600 311 Temp-1Wire-Outdoor 3m Stainless steel outdoor temp sensor (–30°C to 120°C ), 3m cable
600 279 Humid-1Wire 3m Humidity sensor, 3m cable (1m= 600 278)
600 333 Humid-1Wire 10m Humidity sensor, 10m cable
600 330 HTemp-Rack19 Temp + humidity sensor, fits into a 1U rack slot
600 040 Poseidon T-Box Hub to connect 5 IT bus sensors to a Poseidon unit
600 280 Poseidon T-Box2 Hub to connect 2 IT bus sensors to a Poseidon unit
Poseidon 3262
1.
4
)
Connect temperature or humidity sensor to the
IT
bus (Temp-1Wire or Humid-1Wire – RJ12 jack). The
jack must click in.
1.3)
Connect the power adapter to a mains outlet (230 /
110V) and to the Poseidon power connector. The jack
must be plugged all the way in. The green LED lights up.
1.1)
Check the DIP switches. For installation, set them as shown
in the picture (DIP1=Off, DIP2=Off).
1.2)
RS-232 serial port for connecting a GSM modem or for
configuring the device.
1.5) Connect
Poseidon to the Ethernet (using a
patch cable to a switch, cross-over cable to a PC)
Temp
-
1Wire
-
Outdoor
3m
600 311
Poseidon T
-
Box
600 040
Poseidon T
-
Box
2
600 280
Temp
-
1Wire
1
m
600 242
HTemp
-
Rack19
600 330

Poseidon 3262 – starting guide
Oficjalny dystrybutor:
ATEL ELECTRONICS
2
) Configuring the IP address
UDP Config program –
in the root folder of the supplied CD (Windows and Linux version).
The program can be
downloaded from
www.HW-group.com
Software -> UDP Config.
.
• Click the icon to run
UDP Config – the
program
automatically
searches for
connected devices
• Click the Find
Devices button to
start searching for
devices.
The program looks for devices on your local
network. To identify a particular Poseidon unit, look
at its MAC address (printed on the label at the
bottom of the unit).
Double click a MAC address to open a dialog
window with basic device settings.
Set up network parameters
• IP address
• HTTP Port (default is 80)
• Mask
• Gateway IP address
• Name of your device –
optional
Click the Apply Changes button
to save th
settings.
Note:
Contact your network administrator if you
are unsure about these settings.
•
Reset to factory defaults
Toggle DIP1 several times within 5 seconds after powering up. Default settings
contains none passwords.
DIP1
•Disable
any configuration changes
While DIP2=On
any configuration change disabled.
Note: Set Dip2=Off to be able change IP address configuration
DIP2
Oficjalny dystrybutor:
www.atel.com.pl 45-231 Opole
e-mail: [e-mail] ul. Oleska 121
) Configuring the IP address
– UDP Config
in the root folder of the supplied CD (Windows and Linux version).
The program looks for devices on your local
network. To identify a particular Poseidon unit, look
at its MAC address (printed on the label at the
Double click a MAC address to open a dialog
optional
to save th
e
Contact your network administrator if you
Reset to factory defaults
Toggle DIP1 several times within 5 seconds after powering up. Default settings
contains none passwords.
any configuration changes
(online demo mode)
any configuration change disabled.
Note: Set Dip2=Off to be able change IP address configuration
HW group
tel. [phone]
fax. [phone]
in the root folder of the supplied CD (Windows and Linux version).
Toggle DIP1 several times within 5 seconds after powering up. Default settings
(online demo mode)
Note: Set Dip2=Off to be able change IP address configuration

Poseidon 3262 – starting guide HW group
Oficjalny dystrybutor:
www.atel.com.pl 45-231 Opole tel. [phone]
ATEL ELECTRONICS
e-mail: [email protected] ul. Oleska 121 fax. [phone]
3) Configuring the Poseidon with a web browser
3.1) Enter the IP address of the device to the address field in your web browser, or run
UDP Config and click the IP address.
3.2) Main WWW page of Poseidon 3262
•
Current Value – Current reading of the corresponding connected sensor. “–999.9” means
that the sensor is not available or was initialized only after the device was powered up.
• Alarm Alert – Alarm settings defined for the sensor: whether alarm is activate upon
exceeding the “Safe Range”, destination of alarm alerts.
• “For more information” – Contact information about the servicing organization. This text
can be changed in “Telnet setup”.
3.3) Retrieving current readings
• XML – via the values.xml file. Its format is defined in the XSD file downloadable from the
main page. Detailed explanation of the XML structure is in the manual.
• SNMP – the poseidon.mib description file can be downloaded from the main page. The
SNMP ports (defaults are 161 and 162) can be changed in Flash setup.
• Modbus/TCP – structure description is in the manual or in application examples. Standard
port 502 is open for reading.
Device IP address
Unique sensor ID
(serial number)
Sensor safe range Alert when a reading
is out of safe range
Device name
“
Flash setup
”
(detailed configuration)
Description of
SNMP
MIB and values.XML
structures
“Telnet setup”
(special configuration)

Poseidon 3262 – starting guide HW group
Oficjalny dystrybutor:
www.atel.com.pl 45-231 Opole tel. [phone]
ATEL ELECTRONICS
e-mail: [email protected] ul. Oleska 121 fax. [phone]
4) Flash Setup configuration
Click the “Flash Setup”link at the main page to open a graphic configuration interface. Adobe Flash
player must be installed in your web browser. You can find it on the supplied CD
(\Poseidon\install_flash_player_7.msi), or download the latest version from the Internet.
Flash Setup allows you to:
• Set up sensor names, “safe ranges” for alarms, and alarm alert
destinations
• Monitor current sensor readings, refreshed with specified
frequency
• Select temperature units (°C, °F, °K)
• Set current time and specify a NTP server for time
synchronization
• Set SNMP parameters (Community names & rights), define
targets for SNMP traps
• Set up alarm alerts via email and test them
• Set up security features: usernames and passwords, IP ranges
For more information, see the manual or visit www.HW-group.com.
