DAPAudio DS-220K User manual

DS-220K
ORDERCODE D1131

Congratulations!
You have bought a great, innovative product from DAP Audio.
The DAP Audio DS-220K brings excitement to any venue. Whether you want simple plug-&-play action or
a sophisticated show, this product provides the effect you need.
You can rely on DAP Audio, for more excellent audio products.
We design and manufacture professional audio equipment for the entertainment industry.
New products are being launched regularly. We work hard to keep you, our customer, satisfied.
For more information: [e-mail]
You can get some of the best quality, best priced products on the market from DAP Audio.
So next time, turn to DAP Audio for more great audio equipment.
Always get the best -- with DAP Audio !
Thank you!

1
3
3
3
5
5
6
7
7
8
8
9
10
10
10
11
11
11
11
11
11
11
11
11
11
12
12
12
12
12
12
12
12
12
12
12
12
13
13
13
14
14
17
18
18
18
Dap Audio
Dap Audio DS-220K™ Product Guide
Warning.........................................................................................................................................................................
Unpacking Instructions...........................................................................................................................................
Safety-instructions...................................................................................................................................................
Return Procedure...................................................................................................................................................
Claims......................................................................................................................................................................
Operating Determinations....................................................................................................................................
Description...................................................................................................................................................................
Overview.................................................................................................................................................................
Frontview.................................................................................................................................................................
Rearview.................................................................................................................................................................
Remote Control......................................................................................................................................................
Installation....................................................................................................................................................................
Set Up and Operation.................................................................................................................................................
Installing batteries..................................................................................................................................................
Operations...................................................................................................................................................................
Preparation.............................................................................................................................................................
Normal Playback...................................................................................................................................................
Pause.......................................................................................................................................................................
Stop.........................................................................................................................................................................
Previous and Next..................................................................................................................................................
Fast Forward/Reverse............................................................................................................................................
TFT- Mode................................................................................................................................................................
OSD.........................................................................................................................................................................
Subtitle....................................................................................................................................................................
Step...........................................................................................................................................................................
Time (Search)...........................................................................................................................................................
Repeat....................................................................................................................................................................
A-B Repeat.............................................................................................................................................................
Slow.........................................................................................................................................................................
Program..................................................................................................................................................................
Zoom.......................................................................................................................................................................
Volume and Mute.................................................................................................................................................
Menu.......................................................................................................................................................................
Title...........................................................................................................................................................................
Angle.......................................................................................................................................................................
Audio Channel Selection......................................................................................................................................
Before switching off the power..................................................................................................................................
CD’s.........................................................................................................................................................................
Precaution on storage..........................................................................................................................................
System Setup................................................................................................................................................................
General setup.........................................................................................................................................................
Audio setup.............................................................................................................................................................
Video setup.............................................................................................................................................................
Password setup.......................................................................................................................................................
Exit............................................................................................................................................................................

2
19
19
19
20
20
20
Dap Audio
Dap Audio DS-220K™ Product Guide
Connections................................................................................................................................................................
Connecting a television set..................................................................................................................................
Connecting a television set using an A/V cable...............................................................................................
Maintenance..............................................................................................................................................................
Troubleshooting..........................................................................................................................................................
Product Specifications...............................................................................................................................................

3
WARNING
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
• DAP DS-220K
• Remote control
• User manual
• 1x power cable –2m
• 1x RCA video cable - 2m
• 1x Stereo RCA audio cable –1,5m
• 2x AAA battery
SAFETY INSTRUCTIONS
Every person involved with the installation, operation and maintenance of this system has to:
-be qualified
-follow the instructions of this manual
Before you initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the system.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the system are not subject to
warranty.
This system contains no user-serviceable parts. Refer servicing to qualified technicians only.
CAUTION!
Keep this system away from rain and moisture!
CAUTION! Be careful with your operations.
With a dangerous voltage you can suffer
a dangerous electric shock when touching the wires!
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE YOUR INITIAL START-UP!

4
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-
observance of this manual or any unauthorized modification to the system.
Never let the power-cord come into contact with other cables! Handle the power-cord and all
connections with the mains with particular caution!
Never remove warning or informative labels from the unit.
Never use anything to cover the ground contact.
Never leave any cables lying around.
Do not insert objects into air vents.
Do not connect this system to a dimmerpack.
Do not switch the system on and off in short intervals, as this would reduce the system’s life.
Do not open the device and do not modify the device.
Do not drive the inputs with a signal level bigger, than required to drive the equipment to full
output.
Do not plug Mics into the console (or stagebox) while Phantom Power is on. Also mute the monitor
/ Pa system when turning Phantom Power on or off. Allow the system to adjust for a couple of
seconds, before setting the input gains.
Only use system indoor, avoid contact with water or other liquids.
Avoid flames and do not put close to flammable liquids or gases.
Always disconnect power from the mains, when system is not used. Only handle the power-cord
by the plug. Never pull out the plug by tugging the power-cord.
Always operate the unit with the AC ground wire connected to the electrical system ground.
Make sure you don’t use the wrong kind of cables or defective cables.
Make sure that the signals into the mixer are balanced, otherwise hum could be created.
Make sure you use DI boxes to balance unbalanced signals; All incoming signals should be clear.
Make sure that the available voltage is not higher than stated on the rear panel.
Make sure that the power-cord is never crimped or damaged. Check the system and the power-
cord from time to time.
Please turn off the power switch, when changing the power cord or signal cable, or select the
input mode switch.
Extreme frequency boosts in connection with a high input signal level may lead to overdriving
your equipment. Should this occur, it is necessary to reduce the input signal level by using the
INPUT control.
To emphasize a frequency range, you don’t necessarily have to move its respective control
upward; try lowering surrounding frequency ranges instead. This way, you avoid causing the next
piece of equipment in your sound path to overdrive. You also preserve valuable dynamic reserve
(“headroom”)
Avoid ground loops! Always be sure to connect the power amps and the mixing console to the
same electrical circuit to ensure the same phase!
If system is dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
If the system has been exposed to drastic temperature fluctuation (e.g. after transportation), do
not switch it on immediately. The arising condensation water might damage your system. Leave
the system switched off until it has reached room temperature.
If your Dap Audio device fails to work properly, discontinue use immediately. Pack the unit
securely (preferably in the original packing material), and return it to your Dap Audio dealer for
service.
Repairs, servicing and electric connection must be carried out by a qualified technician.
For replacement use fuses of same type and rating only.
WARRANTY: Till one year after date of purchase.

5
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
1) Your name
2) Your address
3) Your phone number
4) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
otherwise agreed in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.

6
OPERATING DETERMINATIONS
This system is not designed for permanent operation. Consistent operation breaks will ensure that the
system will serve you for a long time without defects.
If this system is operated in any other way, than the one described in this manual, the product may suffer
damages and the warranty becomes void.
Any other operation may lead to dangers like short-circuit, burns, electric shock, etc.
You endanger your own safety and the safety of others!
Improper installation can cause serious damage to people and property !
Connection with the mains
Connect the device to the mains with the power-plug.
Always pay attention, that the right color cable is connected to the right place.
International
EU (including UK)
From April 2004
North America
Pin
L
Brown
Black
Phase
N
Blue
White
Neutral
Green/Yellow
Green
Protective Earth
Make sure that the device is always connected properly to the earth!

7
Description of the device
Features
The DAP-audio DS-220K is a 1U Karaoke DVD player
LCD display with blue backlight
Preview monitor
Full control remote control unit
Reverb effect unit
2 Adjustable mic inputs
Overview
Fig. 1

8
Frontview
Fig. 2
1) Eject 14) Headphone Out
2) Power On/Off 15)Mic 1 Volume
3) Disc Slot 16) Mic 1 Input
4) Remote Sensor 17) Mic 2 Volume
5) LCD Display 18) Mic 2 Input
6) Play/Pause 19)Reverb Level
7) Mute 20)Remote Sensor
8) Repeat 21) Previous
9) Pgm (Program) 22) Up
10) OK Button 23)Down
11) Preview Monitor 24) Next
12) Power On/Off 25) Display
13)Headphone Volume
Rearview
Fig. 3
26)Optical Out 30)Video 1/ 2 Composite Out
27) Audio Left Unbalanced Out 31)Microphone 1 XLR Balanced Input
28) Audio Right Unbalanced Out 32) Microphone 2 XLR Balanced Input
29)S/PDIF Out 33) 230Vac Inlet

9
Remote Control
Fig. 4
34) Standby 53) Up (Pitch)
35)Program 54) Open/Close
36)Display 55) Title
37)Repeat 56) Menu
38)A-B 57) Setup
39)0-9 Keys 58) L/R
40)Audio 59) +10
41)Angle 60)Time
42)Slow 61)Zoom
43)Step 62) Subtitle
44)Stop 63) Vol +
45)Scroll up 64) Vol -
46)Scroll left 65) Mute
47)Enter 66) Scroll Right
48)Down (Pitch) 67) Scroll Down
49)Skip Reverse 68) Play/Pause
50)Normal (Pitch) 69) Skip Forward
51) Fast Reverse 70)DVD/USB/SD
52) Fast Forward 71)TFT On/Off

10
Installation
Remove all packing materials from the device. Check that all foam and plastic padding is removed..
Connect all cables.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. The power supply is printed on the back of the device.
Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connections
1. Turn off the Power switch.
2. Connect the DS-220K to your amplifier using the proper cables.
CAUTION: Be sure that the power is off, when connecting the cables.
Installing batteries
1. Remove the cover.
2. Insert batteries. Make sure that the terminals correspond to the symbols shown in the drawing below.
3. Replace the cover.
Note:
The batteries must be placed correctly.
Do not recharge, heat, open or short circuit the batteries. Do not throw the batteries into open
fire.
Do not mix different types or old and new batteries.
If the remote control does not work properly, or if the range is reduced, all batteries should be
replaced.

11
Operations
1. Preparation
• When you want to watch a DVD film, switch the TV-set on and select the video input connected to
the DVD player.
• If you want to listen to audio via your audio installation, switch the audiosystem on and select the
DVD player input.
2. Normal Playback
1. Press standby at the front panel to switch the DVD player on. The start logo appears on the TV
screen. If the disc drive already contains a disc, the playback will start as soon as the DVD player is
switched on.
2. Press the Eject (1) or the Open/Close (54) button to open the disc drive and insert a disc.
3. Press the Eject (1) or the Open/Close (54) button to close tye disc drive. Playback will start.
4. Press the Play/Pause (6, 68) button if the playback does not start automatically.
5. Some discs will start by presenting a menu. Use the Cursor (21, 22, 23, 24/ 45, 46, 66, 67) buttons to
choose between the different options, then press the OK (10)or Enter (47) button. Alternativly, you
can enter the number of the function in question using the 0-9 buttons (39).
3. Pause
1. Press Play/Pause (68) on the remote control or Play/Pause (6)on the frontpanel to stop playback
(still picture). The sound will be deactivated in still mode.
2. Press Play/Pause (68) on the remote control or Play/Pause (6)on the frontpanel to resume
playback.
4. Stop
1. Press the Stop (44) button on the remote control to stop playback. The start logo will appear on the
TV screen. Some discs offer the possibility of resuming from the same spot, e.g. DVD’s and music
CD’s.
2. Press Play/Pause (68) on the remote control or Play/Pause (6)on the frontpanel to resume playback
from where the playback was stopped or from the beginning depending on the DVD.
3. Press the Stop (44) button twice to stop the playback completely.
5. Previous and next
During playback, press Previous (21, 49)to return to the start of the track. Press Previous
(21/49) again to go back to the previous.
Each time you press the Next (24, 69)button you will skip to the next track.
6. Fast Forward/ reverse
1. Press Fast Forward (52)to go fast forward on the disc. The speed changes every time Fast
Forward (52) is pressed.
2. Press Play/Pause (6, 68) to return to normal playback.
3. Press Fast Reverse (51)to go fast forward on the disc. The speed changes every time Fast
Reverse (51) is pressed.
4. Press Play/Pause (6/ 68) to return to normal playback.
7. TFT-mode
Use the TFT On/Off (71)button to swich the TFT mode On or Off.
8. OSD (On Screen Display)
Press Display (36)to switch between TITLE PLAYE, TITLE LEFT, CHAPTER PLAYED, CHAPTER LEFT and
DISPLAY OFF.
9. Subtitle
When Title (55) is pressed, the display shows SUBTITLE 01/XX XXXXX. Where 01 is language number
one. XX is the total number of languages available on the disc. XXXXX is the language. (eg. Dutch,
German etc.) Use the Scroll (21, 22, 23, 24/ 45, 46, 66, 67) and Enter (47) or OK (10) buttons to select the
desired language.

12
10. Step
Press Step (43) to step a single frame/ picture forward during playback. Press Step (43) several times to
step several frames/ pictures forward. Press Play/Pause (6, 68) to resume playback.
11. Time (search)
Press Time (60)once, to view the search menu, press once more to cancel the function. In the search
menu, use the Scroll up (22, 45), Scroll down (23, 67) and the 0-9 (39) buttons to make the desired
choice. Press the Enter (10, 47) button to confirm.
12. Repeat
1. Press the Repeat (37)button once to choose on-screen which chapter to repeat.
2. Press the Repeat (37)button a second time to choose the title to be repeated.
3. Press the Repeat (37)button a third time to repeat all.
4. Press the Repeat (37)button a fourth time to exit the Repeat Mode.
13. A-B Repeat
Press A-B (38) to set up the starting point and again to set the stop point to complete the setup.
The section between A and B will be repeated. Press the button a third time to cancel.
14. Slow
Press Slow (42)to play a disc slowly forwards or backwards. The speed chanches everytime you press
the Slow button. Press the Enter (10, 47) or Play/Pause (6, 68) button to return to normal playback.
15. Program
Press Prog (35) to enter program mode. Enter the desired number at the desired program on track or
title and chapter. Move the cursor to START to start the program. If you wish to cancel the function,
press stop an then the Enter (10, 47) or Play (6, 68) button
16. Zoom
Press the Zoom (61)button to enlarge the picture. The size of the picture changes everytime the
button is pressed.
17. Volume and Mute
Press the Vol + (63) button to increase the volume level and the Vol –(64) button to decrease the
volume level.
Pressing the Mute (65) button will mute the audiosignal. Press again to cancel the mute function.
18. Menu
Press this button to see the DVD’s main menu and make the desired choice using the Scroll (21, 22,
23, 24/ 45, 46, 66, 67) and OK (10) or Enter (45) buttons.
19. Title
On some DVD’s the title menu will apear when pressing the Title (55) button. Choose the desired
tracks using the Scroll (21, 22, 23, 24/ 45, 46, 66, 67) or the 0-9 (39) buttons and OK (10) or Enter (45)
buttons.
20. Angle
Pressing the Angle (41) button allows you to choose between different camera’s. This function only
applies to DVD’s which are recorded this way.
21. Audio Channel Selection
Pressing Audio (40) button allows you between different types of sound reproduction such as:
Audio: 1/2: AC3 2 CH English
Audio: 2/2: AC3 5.1 CH English

13
Before switching off the power
When you have finished using the CD player. Press the Eject (1) or Open/Close (54) button. When the
disc is completely ejected, take out the disc without using force. Now you can safely switch off the power.
CAUTION:
• Do not try to insert the disc when the power is off.
• Do not switch off the power, while the disc is ejecting.
• Switch off the power after the disc has been completely ejected.
DVD’s
1. Precautions on handling DVD’s
• Do not allow fingerprints, oil or dust to get on the surface of the disc. If the disc is dirty, wipe it off with a
soft dry cloth.
• Do not use thinner, water, record spray, electrostatic-proof chemicals, or silicone-treated cloths
to clean discs.
• Always handle discs carefully to prevent damaging the surface; in particular when removing a disc
from its case or returning it.
• Do not bend the disc.
• Do not put the DVD near heating sources.
• Do not enlarge the hole in the center of the disc.
• Do not write on the label (printed side) with a hard-tipped implement such as a pencil or ball point pen.
• Condensation will form if a disc is brought into a warm area from a colder one, such as outdoors in
winter. Do not attempt to dry the disc with a hair dryer, etc.
2. Precaution on storage
• After playing a disc, always unload it from the player.
• Always store the disc in the jewel case to protect from dirt or damage.
• Do not place discs in the following areas:
1. Areas exposed to face sunlight for a considerable time.
2. Areas subject to accumulation of dust or high humidity.
3. Areas that are affected by heat from indoor heaters, etc.

14
System Setup
DVD Setup Menu
When youpress the Setup (57) button, the setup menu will be displayed. You can select four tabs:
A. General
B. Audio
C. Video
D. Password
E. Exit
When you have entered the setup menu you can use the Scroll (21, 22, 23, 24/ 45, 46, 66, 67) buttons te
navigate and select the desired item. When you have selected an item, press Enter (47) or OK (10) to
confirm the entry and go to the submenu.
A. General Setup
This menu is used for setting up the TV screen format, video functions and DVD functions and includes:
1. TV Display
2. Angle Mark
3. OSD Language
4. Captions
5. Screensaver
6. HDCD
7. Last Memory
1. TV Display
In this submenu you can select the format of the TV to which the DVD is connected you can choose
between:
Normal/ PS: 4:3 Pan & Scan for a normal TV.
Normal/LB: 4:3 Letterbox for a normal TV.
Wide: 16:9 Wide screen for a widescreen TV.
Note: Available aspect ratio’s will be printed on the back of the DVD packaging. Some DVD’s are
recorded in the cinema widescreen format (16:9) and others in the standard format (4:3). Some DVD’s
are recorded in both formats and may thus feature the Pan Scan function. If available, the Pan Scan
function will allow the 4:3 format to fill out the entire screen. However a part of the picture will be cut off
on both sides.

15
2. Angle Mark
When a DVD enabling multiple camera angles is used, the user can select a certain camera angle using
the Angle (41) button on the remote control. However, the function must be activated first. The ANGLE
MARK setting must be set to “ON” if you want the device to support multiple camera angles.
3. OSD Language
This function allows you to allow you to select a language for the setup menu and for the screen display.
4. Captions
Closed Captions (CC) is a standardized method used to code text into a NTSC TV signal. A DVD may
include Closed Captions. If a DVD title has a (CC) mark on the back of the packaging, you can set
captions to ON and read the written headlines on the TV screen. The function is factory set to ON.
5. Screen Saver
If the unit is not used for more then 2 minutes, the screen saver will be activated. This will prolong the
service life of the connected TV set. The screen server is factory set to ON.

16
6. Last Memory
If last memory is activated, the DS-220K will remember the last track before switching off. As the unit is
switched on again, it will resume playback at the last track played before switching off.
B. Audio Setup
Includes:
1. SPDIF Setup
2. Equalizer
3. 3d Processing
1. SPDIF Setup
In the SPDIF Setup menu you can set up the digital sound format that comes from the coaxial or optical
output on the rear panel. This signal is used when the unit is connected to a digital surround receiver.
OFF: Closes the digital outputs.
RAW: Opens for the pure, non modulated digital signal.
PCM: Stands for Pulse Code Modulation. It may be necessary to activate this function if the digital
surround receiver can’t recognize the sound format.
2. Equalizer

17
In the Equalizer Setup menu you can select between Preset settings for Rock, Pop, Live, Dance, Techno,
Classic, Soft or off.
3. 3d Processing
The 3d Processing submenu allows you to select a Reverb effect. You can choose between 5 reverb
modes or switch the reverb function off.
C. Video Setup
Includes:
1. Quality
2. Panel Quality
1. Quality
Allows you to adjust the sharpness, Brightness and contrast of the video outputs.

18
2. Panel Quality
Allows you to adjust the sharpness, brightness, contrast and hue of the built in preview monitor.
D. Password Setup
Allows you to protect your system with a password.
E. Exit
Allows you to exit the setup menu.
