DartZone Dartstorm User manual

Ages 8+
Item No. 6270
WITH
Breech
Release
Switch
Trigger Nozzle
Breech
Cover
Gear Drive
Handle
Right Drum Left Drum
40 - Round Ammo Belt
40 Darts - Fly up to 90 Feet
WANT MORE DARTS?
Visit www.dartzonecovertops.com for details.
1. Loading Darts
(a) Your Ammo Belt comes in a loop and has 40 empty Cartridges.
(b) Insert a dart into each empty Cartridge. Ensure that each dart
has been pushed in all the way.
* Note:- Dartstorm®‘s Ammo Belt is not universal with other DartZone®blasters.
2. Loading Batteries
(a) Move the power switch to the “OFF” position.
(b)
Loosen the Battery Cover screws with a Phillips/cross-head screwdriver.
(c) Lift the Battery Cover; and insert 6 x 1.5V AA Alkaline batteries (not
included). Follow the polarity directions (See diagram 2).
(d) Close the Battery Cover and replace the screws.
1. 2.

4.
3. Installing the Drums
(a) The front of each Drum should be facing the front of the blaster.
(b) With the nozzle pointing away from you, insert the Left and Right Drums
into their respective slots (See diagram 3-b).
(c) The Drums are designed to disengage if the blaster is dropped to the
oor. Just reattach; as above.
4. Loading the Ammo Belt
(a) Push the Breech Release Switch forward, and lift the Breech Cover.
(b) Lift the Ammo Belt by the end with the Dummy Cartridge (with the
directional arrow), and drop the other end into the “Left Drum”
(See diagram).
(c) Position the Dummy Cartridge into the middle of the drive gear.
Make sure that the directional arrow is pointing towards the front
of the blaster (See diagram).
3(a). 3(b).
5. Power On
(a) Push the Power Switch to the “ON” position.
(b) Press trigger to launch the darts. The Ammo Belt will advance automatically and drop into the Right Drum.
• Replace the batteries.
• Rapid depressing and releasing of the trigger does not give sufcient time for the motors
to spin. Hold down the trigger for a longer period.
Trouble Shooting:
Problem Suggestion
Pressed Trigger: No Response
• Check that batteries have been inserted in the correct polarity.
Pressed Trigger; Motor moves;
but does not fire
• Check that the Darts have been inserted all the way to the rear of the Cartridges.
Ammo Belt does not rotate
•Check that Ammo Belt has been positioned correctly in the drive gear.
Darts travel only a short distance
Dartstorm®jams during firing
• Ammo Belt not placed behind the Raised Ring.
• Turn the Power Switch to the “OFF” position.
• Lift Breech Cover.
• Remove Ammo Belt by lifting the rear end upwards. Retrieve jammed Dart.
(Jerking the Ammo Belt sideways will damage the Darts.)
• Reload and replace Ammo Belt.
Battery Safety Information:
• Batteries are to be inserted with the correct polarity and always follow the product and
battery manufacturers’ instructions.
• Never mix old and new batteries (replace all batteries at the same time).
• Never mix Alkaline, standard (Carbon-Zinc) or rechargeable (Nickel-Cadmium) batteries.
• Only batteries of the same equivalent type as recommended are to be used.
• Do not use RECHARGEABLE batteries, unless specied.
• Non-rechargeable batteries are not to be recharged.
• Rechargeable batteries are to be removed from the product before being charged (if removable).
• Rechargeable batteries are only to be charged under adult supervision (if removable).
• Always remove exhausted or dead batteries from the product.
• Remove batteries from product before storage.
• The supply terminals are not to be short-circuited.
• Batteries may explode or leak if misused.
• Battery /Batteries should be installed by an adult only.
• AA/LR6 or AAA/LR03 Batteries may present a choking hazard.
• Keep away from young children.
