DAS INTEGRAL-MC01 User manual

INTEGRAL-MC01
User manual
www.dasaudio.com

2INTEGRAL-MC01 Manual
INTEGRAL
Overview
DAS Audio is a unique brand. We
create sound solutions for businesses,
always adapted to the different needs
of our clients.
The Integral Series is the heart and brain of our installation
solutions. It comprises of a series of devices that in addition
to feeding and processing the signal of our speakers,
allow an absolute control to our users, guaranteeing the
protection and quality of the equipment.
You are about to discover what it means to work with our
brand, and this is just the beginning. You will have access
to quality training materials on our website, where you will
discover specific business solutions and learn how to use
them: dasaudio.com/en/training/
This user manual is designed to guide you, swiftly and
smoothly, during the installation of our equipment, but
in case you have any questions or doubts, do not hesitate
to contact our technical support team by writing directly
to [email protected]om or, if you prefer, through our
website, contacting your nearest office at dasaudio.com/
contact

3INTEGRAL-MC01 Manual
INTEGRAL
Description and features
INTEGRAL-MC01 is a desktop electret condenser goose-
neck microphone. Desktop base allows microphones
to be used in multi-purpose or conference rooms, retail
stores, etc. where quick setup or permanent installation
is required.
The desktop base features two 3-pin XLR type input and
output connectors enabling direct connection to the
audio receivers and microphone. The user button with
integrated red indicator permits advanced local control.
The desktop base includes a built-in preamplifier which
works with two AAA batteries (3 Vdc) in case of not hav-
ing the possibility of connecting it to a source providing
phantom power.
• Wide dynamic range and frequency response for
accurate sound reproduction
• 12-48Vdc Phantom Power required (or 3Vdc Batteries)
• Electret condenser microphone
• Cardioid pattern

4INTEGRAL-MC01 Manual
INTEGRAL
Top panel
1Base Desktop
2Neck and Microphone´s cartridge
3Windscreen
4LEDs
5 On/Off button
6XLR type input connector
2
3
4
5
6
1

5INTEGRAL-MC01 Manual
INTEGRAL
Bottom panel
1 Battery Holder: 2 x AAA 1.5Vdc batteries
2Rubber feet (x4)
3Output XLR type connector
2
3
1

6INTEGRAL-MC01 Manual
INTEGRAL
Connections
The INTEGRAL-MC01 transmits analog balanced audio
signal by the use of standard microphone cabling.
Connect the desktop base to any audio receiver such
mixing console, audio matrix or Matrix amplifier (MA
models) providing phantom power; for permanent
installation is highly recommendable to use this option.
A preamplifier is also included in the microphone
stand and powered with two AAA batteries (3 Vdc) in
case no Phantom source is connected. In this case the
microphone can be connected directly to any amplifier
(A models).
Shown in the image below an INTEGRAL-MC01 connected to an INTEGRAL-WPM1:
Shown in the image below an INTEGRAL-MC01 connected to an INTEGRAL-MA1004/1604 unit:
Connecting the microphone to a receiver
providing phantom power:
ON
SIGNAL/LIMIT
PROTECT
COMMS
ENTER
BACK
UP
DOWN
INTEGRAL MA1004
DAS AUDIO

7INTEGRAL-MC01 Manual
INTEGRAL
Connections
Shown in the image below an INTEGRAL-MC01 is directly connected to whatever the INTEGRAL-
Axxxx amplifier models. It is necessary to use the preamplifier of the microphone with the
batteries. This solution is not recommended for permanent use as the batteries will need to be
replaced.
INTEGRAL A402
DAS AUDIO
LE VE L BLE VE L A
SIGNAL / CLI P
ON SIGNAL / CLIP
Connecting the microphone without Phantom
power and using the internal desktop base
preamplifier (with batteries):

8INTEGRAL-MC01 Manual
INTEGRAL
Microphone placement
Place the microphone within 15 to 30cm (6 to 12 in.) of the desired audio
source.
Aim the microphone towards the desired source, such as the talker. Aim it
away from any unwanted source, such as a loudspeaker. The loudspeakers
should always avoid facing the microphone, in order to prevent feedback.
The speaker system should be in a location that will not be in the walking
path of the presenter or easily walked in front of.
When using more than one microphone in order to avoid feedback and
phasing problems follow the rule 3:1, the distance from any audio source
to the closest microphone has to be at least 3 times less than the distance
from the audio source to the other microphones.
d d3d

9INTEGRAL-MC01 Manual
INTEGRAL
Specifications
Microphone type
Frequency Response
Polar Pattern
Output Impedance
Power Requirements
Power Consumption
Dimensions (H x W x D)
Weight
H*: Height with microphone´s neck at 40º
Electret Condenser
40Hz – 16kHz
Cardioid
75Ohm
12-48Vdc Phantom or 3Vdc Batteries
25mA
360* x 115 x 142mm
(14 x 4.5 x 5.6 in)
615g (0.28 lb)
W D
H
