DAS DR-508 User manual

DR 500 series
User´s Guide
Antes de utilizar el equipo, lea la sección
“Precauciones de seguridad” de este
manual. Conserve este manual para
futuras consultas.
Before operating the device, please read
the “Safety precautions” section of this
manual. Retain this manual for future
reference.

CONTENTS
INTRODUCTION
RIGGING SYSTEM
6
7 a 10
3
4
5
11 a 13
14
15
LINE DRAWINGS
SPECIFICATIONS
CONFIGURATIONS
2 x DR-515 (o DR-512)
2 x DR-515 / DR-508 / DR-512 + action18
2 x DR-515 (o DR-512) + 2 x action18
2 x DR-515 (o DR-512) + 2 x action218
SAFETY PRECAUTIONS
WARRANTY
DECLARATION OF CONFORMITY
Manual del Usuario / DR 500 passive series / User’s Manual

3
Manual del Usuario / DR 500 passive series / User’s Manual
DR-500 series Precauciones de Seguridad
Safety Precautions
Cajas acústicas pasivas / Passive loudspeaker enclosures
Conserve y lea todas estas instrucciones.
Siga todas las advertencias.
El signo de exclamación dentro de un triángulo indica la
existencia de componentes internos cuyo reemplazo puede
afectar a la seguridad.
Keep these instructions.
Heed all warnings. Follow all instructions.
The exclamation point inside an equilateral triangle indicates the
existence of internal components whose substitution may affect
safety.
El doble cuadrado indica equipo de Clase II. The double square indicates Class II device.
Limpie con un paño seco. No use limpiadores con disolventes.
Las especificaciones se encuentran en la etiqueta de la parte
posterior del producto. The specifications can be found on the rear label of the product.
Clean only with a dry cloth. Do not use any solvent based
cleaners.
No existen partes ajustables por el usuario en el interior de este
equipo. Cualquier operación de mantenimiento o reparación
debe ser realizada por personal cualificado. Es necesario el
servicio técnico cuando el aparato se haya dañado de alguna
forma, tal como que haya caído líquido o algún objeto en el
interior del aparato, haya sido expuesto a lluvia o humedad, no
funcione correctamente o haya recibido un golpe.
No user serviceable parts inside. Refer all servicing to qualified
service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture,
does not operate normally or has been dropped.
DR-508------------->150 cm
DR-512------------->140 cm
DR-515------------->130 cm
DR-508------------->150 cm
DR-512------------->140 cm
DR-515------------->130 cm
Equipo diseñado para funcionar entre 15ºC y 42ºC con una
humedad relativa máxima del 95%. Working temperature ranges from 15ºC to 42ºC with a relative humidity of 95%.
No exponga este equipo a la lluvia o humedad. No exponga el
equipo a salpicaduras ni coloque sobre él objetos que
contengan líquidos, tales como vasos y botellas. Equipo IP-20.
Do not expose this device to rain or moisture. Do not place any
objects containing liquids, such as bottles or glasses, on the top
of the unit. Do not splash liquids on the unit. IP-20 equipment.
No emplace altavoces en proximidad a equipos sensibles a
campos magnéticos, tales como monitores de televisión o
material magnético de almacenamiento de datos.
Do not place loudspeakers in proximity to devices sensitive to
magnetic fields such as television monitors or data storage
magnetic material.
Este símbolo indica que el presente producto no puede ser
tratado como residuo doméstico normal, sino que debe
entregarse en el correspondiente punto de recogida de equipos
eléctricos y electrónicos.
This symbol on the product indicates that this product should
not be treated as household waste. Instead it shall be handed
over to the appicable collection point for the recycling of
electrical and electronic equipment.
El cableado exterior conectado al equipo requiere de su
instalación por una persona instruida o el uso de cables flexibles
ya preparados.
The outer wiring connected to the device requires installation by
an instructed person or the use of a flexible cable already
prepared.
El equipo cuenta con dos conectores de entrada en paralelo
para facilitar la conexión de varias cajas en paralelo. Note that the two Speakon input connectors are wired in parallel to provide easy parallel connection of several enclosures.
El colgado del equipo sólo debe realizarse utilizando los herrajes
de colgado recomendados y por personal cualificado. No
cuelgue la caja de las asas.
The appliance should be flown only from the rigging points and
by qualified personnel. Do not suspend the box from the
handles.
Para las cajas con vaso para trípode, la altura máxima de
seguridad desde el suelo a la base de la caja montada sobre
trípode modelo TRD-2, con pies a 55 cm del eje del trípode, es:
For enclosures with tripod socket, the maximum safety height
from floor to bottom of enclosure when mounting on a TRD-2
tripod, with legs spread 55cm from the central pole, is:
55 cm

GARANTÍA
WARRANTY
Todos nuestros productos están garantizados por un periodo de 24
meses desde la fecha de compra.
Las garantías sólo serán válidas si son por un defecto de
fabricación y en ningún caso por un uso incorrecto del producto.
Las reparaciones en garantía pueden ser realizadas,
exclusivamente, por el fabricante o el servicio de asistencia técnica
autorizado.
Otros cargos como portes y seguros, son a cargo del comprador
en todos los casos.
Para solicitar reparación en garantía es imprescindible que el
producto no haya sido previamente manipulado e incluir una
fotocopia de la factura de compra.
All D.A.S. products are warrantied against any manufacturing defect
for a period of 2 years from date of purchase.
The warranty excludes damage from incorrect use of the product.
All warranty repairs must be exclusively undertaken by the factory
or any of its authorised service centers.
To claim a warranty repair, do not open or intend to repair the
product.
Return the damaged unit, at shippers risk and freight prepaid, to
the nearest service center with a copy of the purchase invoice.
4Manual del Usuario / DR 500 passive series / User’s Manual

DECLARACIÓN DE CONFORMIDAD
DECLARATION OF CONFORMITY
D.A.S. Audio, S.A.
C/ Islas Baleares, 24 - 46988 - Pol. Fuente del Jarro - Valencia. España
(Spain).
Declara que la serie DR-500:
Declares that DR-500 series:
Cumple con los objetivos esenciales de las Directivas:
Abide by essential objectives relating Directives:
lDirectiva de Baja Tensión (Low Voltage Directive) 2006/95/CE
lDirectiva de Compatibilidad Electromagnética (EMC) 2004/108/CE
lDirectiva RoHS 2011/65/CE
lDirectiva RAEE (WEEE) 2002/96/CE
Y es conforme a las siguientes Normas Armonizadas Europeas:
In accordance with Harmonized European Norms:
lEN 60065:2002 / A11:2008
Audio, video and similar electronic apparatus. Safety requirements.
lEN 55103-1:2009
Electromagnetic compatibility. Product family standard for audio, video,
audio-visual and entertainment lighting control apparatus for
professional use. Part 1:Emission.
lEN 55103-2:2009
Electromagnetic compatibility. Product family standard for audio, video,
audio-visual and entertainment lighting control apparatus for
professional use. Part 2:Immunity.
5
Manual del Usuario / DR-500 passive / User’s Manual

INTRODUCTION
DR-508
- Compact 2-way, full-range system
- 8” bass loudspeaker
- Compression driver with titanium diaphragm
- Multiple mounting options
- Stand mountable
The DR-508 is an ultracompact full-range system that
uses a new 8” low frequency transducer. The M-34
compression driver handles high frequency reproduction.
The polypropilene enclosures is light-weight and rugged.
DR-515
- 2-way, full range system
- 15” bass loudspeaker
- Compression driver with titanium diaphragm
- Stand mountable
- Monitor position
The DR-515 exemplifier the achievements of D.A.S.
engineers in high pressure injection molding technology.
The DR-515 mounts a propietary 15” low frequency
transducer and the high efficiency M-34 compression
driver and CD horn assembly.
DR-512
- Compact 2-way, full-range system
- 12” bass loudspeaker
- Compression driver with titanium diaphragm
- Multiple mounting options
- Stand mountable
The DR-512 combines design with function in a
medium size enclosure. It´s unique enclosure offers an
oversized handle for easy carrying, will accept a standard
35 mm mounting stand and includes a floor monitor
position for added flexibility. Built-in rigging points and an
optional mounting bracket facilitates use in permanent
installations. The 2-way passive design incorporates 12”
low frequency transducer and the M-34 compression
driver.
Características
The DR 500 series combines design with function, achieving a product that redefines the meaning of reliability,
sound quality and efficiency in compact sound reinforcement enclossures. The use of the lastest high-
pressure injection molding techniques provides the DR 500 series with structural polypropylene enclosures that
are both attractive and durable. They are specially appropiate in any sound reinforcement application
requiring a lightweight compact solution.
6Manual del Usuario / DR 500 passive series / User’s Manual

CONFIGURATIONS
TRD-2
Dr-515 ( or DR-512)
Manual del Usuario / DR 500 passive series / User’s Manual
DR 500 series
DR-515
D.A.S. Audio, s.a. (Valencia) MADE IN SPAIN
PROGRAM POWER
RMS POWER
IMPEDANCE
FREQUENCY RANGE
700 W
350 W
8 W
47 Hz - 20 kHz
22000001
LINKED
INPUT
(+1 -1)
EUROPEAN
PRODUCT
N1918
DR-512
PROGRAM POWER
RMS POWER
IMPEDANCE
FREQUENCY RANGE
600 W
300 W
8 W
50 Hz - 20 kHz
DR 500 series
D.A.S. Audio, s.a. (Valencia) MADE IN SPAIN
22000001
LINKED
INPUT
(+1 -1)
EUROPEAN
PRODUCT
N1918
7
CH BCH A
BRIDGE
CH A
CH B
BRIDGE
1+
2+
1+
1-
2-
2+
SPEAKER OUTPUT
WARNING:TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK
DONOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE
VER MANUAL DE INSTRUCCIONES PARALA CONEXIÓN
REFE
R TO IN STR UCTIONS MANUA L FOR CO NNECTION
ANSCH LUS
SWEISE BITTE D
ER ANLE
ITUNG ENTNEHMEN
VOIR MANUEL D'IN
STRUC
TION
S POUR LA
CONNEXION
CH A INPUT
CH B INPUT
D.A.S. AUDIO S.A. (VALENCIA) SPAIN
MADE IN CHINA
1.0V
STEREO
SENSITIVITY
MODE
GROUND
0.775V
BRIDGE
OFF
1.44V
PARALLEL
ON
S.N.
F 10A L 250V FUSE
MODEL: PS-800
230V 10A 50Hz/60Hz
OUTPUT PWR PER CH: 390W@4
FOR CONTINUED PROTECTION AGAINST RISK
OF FIRE REPLACE ONLY WITH THE SAME TYPE
CH B 1+ 1-
CAUTION ATTENTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN DANGER D’ELECTROCUTION NE PAS OUVRIR
GND
COLDHOT
GND
COLD
HOT 2
31
N1918
PS-800
Output B Output A
Mixer
Input B
LR
Input A
DSP-26
INPUTS
AB
TRD-2
Dr-515 ( or DR-512)

LINKED
INPUT
(+1 -1)
EUROPEAN
PRODUCT
DR-508
DR 500 series
D.A.S. Audio, s.a. (Valencia) MADE IN SPAIN
22000001
N1918
PROGRAM POWER
RMS POWER
IMPEDANCE
FREQUENCY RANGE
400 W
200 W
8 W
60 Hz - 20 kHz
8Manual del Usuario / DR 500 passive series / User’s Manual
LINKED
INPUT
(+1 -1)
EUROPEAN
PRODUCT
N1918
PROGRAM POWER
RMS POWER
IMPEDANCE
FREQUENCY RANGE
1200 W
600 W
8 W
33 Hz - 160 Hz
D.A.S. Audio, s.a. (Valencia), MADE IN SPAIN
action 18
22000001
CH BCH A
BRIDGE
CH A
CH B
BRIDGE
1+
2+
1+
1-
2-
2+
SPEAKER OUTPUT
WARNING:TOREDUCE RISKOF FIREOR ELECTRICSHOCK
DONOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE
VER MANUAL DE INSTRUCCIONES PARA LA CONEXIÓN
REFE
R TO IN STR UCTIONSMANUA L FOR CO NNECTION
ANSCH LUS
SWEISE BITTE D
ER ANLE
ITUNG ENTNEHMEN
VOIR MANUEL D'IN
STRUC TION S POUR LA CONNEXION
CH A INPUT
CH B INPUT
D.A.S. AUDIO S.A. (VALENCIA) SPAIN
MADE IN CHINA
1.0V
STEREO
SENSITIVITY
MODE
GROUND
0.775V
BRIDGE
OFF
1.44V
PARALLEL
ON
S.N.
F 10A L 250V FUSE
MODEL: PS-800
230V 10A 50Hz/60Hz
OUTPUT PWR PER CH: 390W@4
FOR CONTINUED PROTECTION AGAINST RISK
OF FIRE REPLACE ONLY WITH THE SAME TYPE
CH B 1+ 1-
CAUTION ATTENTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN DANGER D’ELECTROCUTION NE PAS OUVRIR
GND
COLDHOT
GND
COLD
HOT 2
31
N1918
CH BCH A
BRIDGE
CH A
CH B
BRIDGE
1+
2+
1+
1-
2-
2+
SPEAKER OUTPUT
WARNING:TOREDUCE RISKOF FIREOR ELECTRICSHOCK
DONOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE
VER MANUAL DE INSTRUCCIONES PARA LA CONEXIÓN
REFE
R TO IN STR UCTIONSMANUA L FOR CO NNECTION
ANSCH LUS SWEISE BITTE D
ER ANLE ITUNG ENTNEHMEN
VOIR MANUEL D'IN
STRUC TION S POUR LA CONNEXION
CH A INPUT
CH B INPUT
D.A.S. AUDIO S.A. (VALENCIA) SPAIN
MADE IN CHINA
1.0V
STEREO
SENSITIVITY
MODE
GROUND
0.775V
BRIDGE
OFF
1.44V
PARALLEL
ON
S.N.
F 10A L 250V FUSE
MODEL: PS-800
230V 10A 50Hz/60Hz
OUTPUT PWR PER CH: 390W@4
FOR CONTINUED PROTECTION AGAINST RISK
OF FIRE REPLACE ONLY WITH THE SAME TYPE
CH B 1+ 1-
CAUTION ATTENTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN DANGER D’ELECTROCUTION NE PAS OUVRIR
GND
COLDHOT
GND
COLD
HOT 2
31
N1918
PS-800
PS-800
Mixer
Output B
Output Bridge
Input B Input A
Input A
Output A
action 18
TRD-2
TRD-2
DSP-26
INPUTS
AB
DR-508 / DR-512 / DR-515
CONFIGURATIONS (cont´d)
LR
DR 500 series
DR-515
D.A.S. Audio, s.a. (Valencia) MADE IN SPAIN
PROGRAM POWER
RMS POWER
IMPEDANCE
FREQUENCY RANGE
700 W
350 W
8 W
47 Hz - 20 kHz
22000001
LINKED
INPUT
(+1 -1)
EUROPEAN
PRODUCT
N1918
DR-512
PROGRAM POWER
RMS POWER
IMPEDANCE
FREQUENCY RANGE
600 W
300 W
8 W
50 Hz - 20 kHz
DR 500 series
D.A.S. Audio, s.a. (Valencia) MADE IN SPAIN
22000001
LINKED
INPUT
(+1 -1)
EUROPEAN
PRODUCT
N1918
DR-508 / DR-512 / DR-515

CONFIGURATIONS (cont´d)
9
Manual del Usuario / DR 500 passive series / User’s Manual
LINKED
INPUT
(+1 -1)
EUROPEAN
PRODUCT
N1918
PROGRAM POWER
RMS POWER
IMPEDANCE
FREQUENCY RANGE
1200 W
600 W
8 W
33 Hz - 160 Hz
D.A.S. Audio, s.a. (Valencia), MADE IN SPAIN
action 18
22000001
Output B
Output B
Output A
Output A
TRD-6
action 18
TRD-6
action 18
DR-512 (or DR-515)
CH BCH A
BRIDGE
CH A
CH B
BRIDGE
1+
2+
1+
1-
2-
2+
SPEAKER OUTPUT
WARNING:TOREDUCE RISKOF FIRE ORELECTRIC SHOCK
DONOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE
VER MANUAL DE INSTRUCCIONES PARA LA CONEXIÓN
REFE
R TO IN
STR UCTIONSMANUA
L FOR
CO
NNECTION
ANSCH LUS SWEISE BITTE D
ER ANLE
ITUNG ENTNEHMEN
VOIR MANUEL D'IN
STRUC
TION
S POUR LA
CONNEXION
CH A INPUT
CH B INPUT
D.A.S. AUDIO S.A. (VALENCIA) SPAIN
MADE IN CHINA
1.0V
STEREO
SENSITIVITY
MODE
GROUND
0.775V
BRIDGE
OFF
1.44V
PARALLEL
ON
S.N.
F 10A L 250V FUSE
MODEL: PS-800
230V 10A 50Hz/60Hz
OUTPUT PWR PER CH: 390W@4
FOR CONTINUED PROTECTION AGAINST RISK
OF FIRE REPLACE ONLY WITH THE SAME TYPE
CH B 1+ 1-
CAUTION ATTENTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN DANGER D’ELECTROCUTION NE PAS OUVRIR
GND
COLDHOT
GND
COLD
HOT 2
31
N1918
PS-800
Mixer
Input B
Input B
Input A
Input A
DSP-26
INPUTS
AB
FORCONTINUED PROTECTION AGAINST RISK
OFFIRE REPLACE ONLYWITH THE SAME TYPE
PS-2400
CHBCH A
BRIDGE
CHA
CHB
BRIDGE
1+
2+
1+
1-
2-
2+
SPEAKEROUTPUT
CHA INPUT
CHB INPUT
D.A.S.AUDIO S.A. (VALENCIA)SPAIN
MADEIN CHINA
1.0V
STEREO
SENSITIVITY
MODE
GROUND
0.775V
BRIDGE
OFF
1.44V
PARALLEL
ON
S.N.
CHB 1+ 1-
GND
COLDHOT
GND
COLD
HOT 2
31
N1918
LR
LINKED
INPUT
(+1 -1)
EUROPEAN
PRODUCT
DR-508
DR 500 series
D.A.S. Audio, s.a. (Valencia) MADE IN SPAIN
22000001
N1918
PROGRAM POWER
RMS POWER
IMPEDANCE
FREQUENCY RANGE
400 W
200 W
8 W
60 Hz - 20 kHz
DR 500 series
DR-515
D.A.S. Audio, s.a. (Valencia) MADE IN SPAIN
PROGRAM POWER
RMS POWER
IMPEDANCE
FREQUENCY RANGE
700 W
350 W
8 W
47 Hz - 20 kHz
22000001
LINKED
INPUT
(+1 -1)
EUROPEAN
PRODUCT
N1918
DR-512
PROGRAM POWER
RMS POWER
IMPEDANCE
FREQUENCY RANGE
600 W
300 W
8 W
50 Hz - 20 kHz
DR 500 series
D.A.S. Audio, s.a. (Valencia) MADE IN SPAIN
22000001
LINKED
INPUT
(+1 -1)
EUROPEAN
PRODUCT
N1918
DR-512 (or DR-515)

CH BCH A
BRIDGE
CH A
CH B
BRIDGE
1+
2+
1+
1-
2-
2+
SPEAKER OUTPUT
WARNING:TOREDUCE RISKOF FIREOR ELECTRIC SHOCK
DONOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE
VER MANUAL DE INSTRUCCIONES PARA LA CONEXIÓN
REFE
R TO IN
STR UCTIONSMANUA
L FOR
CO
NNECTION
ANSCH LUS SWEISE BITTE D
ER ANLE ITUNG ENTNEHMEN
VOIR MANUEL D'IN
STRUC
TION
S POUR LA
CONNEXION
CH A INPUT
CH B INPUT
D.A.S. AUDIO S.A. (VALENCIA) SPAIN
MADE IN CHINA
1.0V
STEREO
SENSITIVITY
MODE
GROUND
0.775V
BRIDGE
OFF
1.44V
PARALLEL
ON
S.N.
F 10A L 250V FUSE
MODEL: PS-800
230V 10A 50Hz/60Hz
OUTPUT PWR PER CH: 390W@4
FOR CONTINUED PROTECTION AGAINST RISK
OF FIRE REPLACE ONLY WITH THE SAME TYPE
CH B 1+ 1-
CAUTION ATTENTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN DANGER D’ELECTROCUTION NE PAS OUVRIR
GND
COLDHOT
GND
COLD
HOT 2
31
N1918
PS-800
Mixer
Output B
Output B
Input B
Input B
Input A
Input A
Output A
Output A
DSP-26
INPUTS
AB
FORCONTINUED PROTECTION AGAINST RISK
OFFIRE REPLACE ONLYWITH THE SAME TYPE
PS-2400
CHBCH A
BRIDGE
CHA
CHB
BRIDGE
1+
2+
1+
1-
2-
2+
SPEAKEROUTPUT
CHA INPUT
CHB INPUT
D.A.S.AUDIO S.A. (VALENCIA)SPAIN
MADEIN CHINA
1.0V
STEREO
SENSITIVITY
MODE
GROUND
0.775V
BRIDGE
OFF
1.44V
PARALLEL
ON
S.N.
CHB 1+ 1-
GND
COLDHOT
GND
COLD
HOT 2
31
N1918
TRD-6
action 218
TRD-6
action 218
DR-515 (or DR-512)
LINKED
INPUT
(+1 -1)
EUROPEAN
PRODUCT
N1918
PROGRAM POWER
RMS POWER
IMPEDANCE
FREQUENCY RANGE
2400 W
1200 W
4 W
29 Hz - 160 Hz
D.A.S. Audio, s.a. (Valencia), MADE IN SPAIN
action 218
22000001
10 Manual del Usuario / DR 500 passive series / User’s Manual
CONFIGURATIONS (cont´d)
LR
DR 500 series
DR-515
D.A.S. Audio, s.a. (Valencia) MADE IN SPAIN
PROGRAM POWER
RMS POWER
IMPEDANCE
FREQUENCY RANGE
700 W
350 W
8 W
47 Hz - 20 kHz
22000001
LINKED
INPUT
(+1 -1)
EUROPEAN
PRODUCT
N1918
DR-512
PROGRAM POWER
RMS POWER
IMPEDANCE
FREQUENCY RANGE
600 W
300 W
8 W
50 Hz - 20 kHz
DR 500 series
D.A.S. Audio, s.a. (Valencia) MADE IN SPAIN
22000001
LINKED
INPUT
(+1 -1)
EUROPEAN
PRODUCT
N1918 DR-515 (or DR-512)

11
Manual del Usuario / DR 500 passive series / User’s Manual
RIGGING SYSTEM
This manual contains needed information for
flying D.A.S. Audio line array systems, description
of the elements and safety precautions. To perform
any operations related to flying the system, read
the present document first, and act on the
warnings and advice given. The goal is to allow the
user to become familiar with the mechanical
elements required to fly the acoustic system, as
well as the safety measures to be taken during
set-up and teardown.
Only experienced installers with adequate
knowledge of the equipment and local safety
regulations should fly speaker boxes. It is the
user's responsibility to ensure that the systems to
be flown (including flying accessories) comply with
state and local regulations.
The working load limits in this manual are the
results of tests by independent laboratories. It is
the user's responsibility to stay within safe limits. It
is the user's responsibility to follow and comply
with safety factors, resistance values, periodical
supervisions and warnings given in this manual.
Product improvement by means of research and
development is on going at D.A.S. Specifications
are subject to change without notice.
To this date, there is no international standard
regarding the flying of acoustic systems. However,
it is common practice to apply 5:1 safety factors
for enclosures and static elements. For slings and
elements exposed to material fatigue due to
friction and load variation the following ratios must
be met; 5:1 for steel cable slings, 4:1 for steel
chain slings and 7:1 polyester slings. Thus, an
element with a breaking load limit of 1000 kg may
be statically loaded with 200 kg (5:1 safety factor)
and dynamically loaded with 142 kg (7:1 safety
factor).
When flying a system, the working load must
be lower than the resistance of each individual
flying point in the enclosure, as well as each box.
Hanging hardware should be regularly inspected
and suspect units replaced if in doubt. This is
important to avoid injury and absolutely no risks
should be taken in this respect. It is highly
recommended that you implement an inspection
and maintenance program on flying elements,
including reports to be filled out by the personnel
that will carry out the inspections. Local
regulations may exist that, in case of accident,
may require you to present evidence of inspection
reports and corrective actions after defects were
found.
Warnings
Absolutely no risks should be taken with
regards to public safety. When flying enclosures
from ceiling support structures, extreme care
should be taken to assure the load bearing
capabilities of the structures so that the installation
is absolutely safe. Do not fly enclosures from
unsafe structures. Consult a certified professional if
needed. All flying accessories that are not supplied
by D.A.S. Audio are the user's responsibility. Use
at your own risk.
Flyable DR 500 series models feature 6 internal
steel angles, with 2 mounting threads each, so
that 12 flying points are available (2 on each side,
3 on the top panel and 3 on the bottom panel and
2 on the rear panel). Eyebolt flying points are
factory sealed with M10 screws, which are
replaced with eyebolts on the flying points as
required. Flying with eyebolts is very economical
and safe, and is specially recommended for fixed
installations where the boxes are permanently
fixed.
The illustration shows the internal metal
hardware of an enclosure with eyebolt flying.
Introduction

ANL-2
12 Manual del Usuario / DR 500 passive series / User’s Manual
The Allen-head screws must be removed and
replaced by M10 eyebolts on one side of the
enclosure. Each rigging point has 200 kg (440 lb)
working load limit. Then choose the slings or
chains of required load resistance and length,
bearing in mind that the length difference between
the front and back slings or chains will determine
the vertical orientation. Alternatively, the back
bottom eyebolt points can be used to provide
vertical orientation.
The ANL-2 set is an optional set of three
eyebolts and three carabiners. (Dimensions are in
milimetres).
Flying with eyebolts
Each ANL-2 eyebolt has a rated working load
of 200 kg. (440 lb). Each ANL-2 carabiner has a
working load of 330 kg (726 lb). If using other
hardware, make sure it is rated to handle the
required load.
When using eyebolts it is important to bear in
mind that the rated working load is only true for a
load applied in the plane of the eye, and is
significantly reduced for other angles. The drawing
illustrates the concept. The table shows the
variation of the working load as a function of the
load angle. In the case of the ANL-2 eyebolt, this
means that the 200 kg working load becomes 60
kg at 45 degrees. Do not use eyebolt flying if the
load angle is higher than 45 degrees.
The following illustrations show different views
on eyebolt flying for a single box. The length of the
back cables or chains determines the vertical
angle of the box.
100% 65% 30% 25%
0 Degrees
% Working
load
30 Degrees 45 Degrees More than 45
Degrees

AX Mounting
AXM Mounting
TRD-2 Mounting
13
Manual del Usuario / DR 500 passive series / User’s Manual
Introduction
AX accesories are specially designed for
enclosures DR-508, DR-512, DR-515 and different versions.
Mounting instructions
You can consult the mounting instructions of AX
for DR 500 series on the web: www.dasaudio.com
Mounting instructions
You can consult the mounting instructions of AXM
for DR 500 series on the web: www.dasaudio.com
Mounting instructions
You can consult the mounting instructions of AXM
for DR 500 series on the web: www.dasaudio.com
Introduction
AXM accesories are specially designed for
enclosures DR 508, DR 512 y DR 515 and different versions.
Introduction
TRD-2 accesory allows a stand mounting for
enclosures DR-508, DR-512, DR-515 and different versions.

LINE DRAWINGS
ALL DIMENSIONS IN MILIMETERS
14 Manual del Usuario / DR 500 passive series / User’s Manual
DR 508DR 515 DR 512
Bottom View Right View
Left View
Front View Rear View
Bottom View Front View Rear View
Bottom View Right View
Front View Rear View
409
694
400
610
361
300
453
304

SPECIFICATIONS
15
DR-508 DR-512 DR-515
Peak Power Handling 800 W 1200 W 1400 W
1
RMS (Average) Power Handling 200 W 300 W 350 W
Frequency Range (-10 dB) 60 Hz – 20 kHz 50 Hz – 20 kHz 47 Hz – 20 kHz
Nominal Impedance 8 ohms 8 ohms 8 ohms
On-axis Sensitivity 1 W/ 1 m 93 dB SPL 96 dB SPL 96 dB SPL
Maximum Peak SPL at 1 m 122 dB 131 dB 131 dB
HF Horn Coverage Angles (-6dB) 90º x 45º 90º x 45º 90º x 45º
Enclosure Material Polypropylene Polypropylene Polypropylene
Color/Finish Black Black Black
Transducers/Replacement Parts LF: 8C / GM 8C
HF: M-34 / GM M-34
LF: 12Mi / GM 12Mi
HF: M-34 / GM M-34
LF: 15Mi / GM 15Mi
HF: M-34 / GM M-34
Connectors 2 x NL4 Speakon 2 x NL4 Speakon 2 x NL4 Speakon
Dimensions (H x W x D) 45 x 30 x 30 cm
18 x 12 x 12 in 62 x 40 x 37 cm 24 x 16 x 14.5 in 71 x 46 x 42 cm 28 x 18 x 16.5 in
Weight 9.9 kg (21.8 lb) 16.6 kg (36.5 lb) 18.6 kg (41 lb)
Accessories ANL-1
AX-108
AX-M
FUN-DS-108
TRD-2
TRD-6
ANL-1
AX-115
FUN-DS-112
TRD-2
TRD-6
ANL-1
AX-115
FUN-DS-115
TRD-2
TRD-6
1 Based on a 2 hour test continuously applying 6 dB crest factor pink noise (IEC shaped).
Manual del Usuario / DR 500 passive series / User’s Manual

UM_DR500_01_EN
www.dasaudio.com
D.A.S. AUDIO OF AMERICA, INC.
Sunset Palmetto Park
6816 NW 77th Court.
Miami, FL. 33166 - U.S.A.
TOLL FREE: 1-888DAS4USA
Tel. [phone]
Fax [phone]
D.A.S. AUDIO ASIA PTE. LTD.
25 Kaki Bukit Crescent #01-00/02-00
Kaki Bukit Techpark 1
Singapore 416256
Tel. [phone]
Fax [phone]
D.A.S. AUDIO, S.A.
C/. Islas Baleares, 24
46988 Fuente del Jarro
Valencia, SPAIN
Tel. [phone]
Tel. Intl. [phone]
Fax [phone]
Fax Intl. [phone]
