7
ChloroMatic®MODEL ESR, ESC and ESCpH SERIES FEATURES:
STAND- BY:
The Stand - By indicator will be On when the Unit is preparing to produce sanitiser. This will be either during the
systemsinitialstartuporwhentheCellhasbeenturnedOffduringtheltrationcycle.
FLOW:
IfthereisaproblemwithwateroworgasisdetectedintheCellHousingthefIowindicatorwillbeOn.Whenthis
occurs the pump or pipes should be inspected for damage and the Flow Sensor connection checked.
SANITISER OUTPUT CONTROL:
The Sanitiser Output Control varies the amount of time the Cell operates during the ltration cycle.
The Sanitiser Output Control will not vary the electrical current supplied to the Cell. (As shown on the Display).
Asanexample,ifoneltrationcycleissetat5hours,andtheSanitiser Output Control is set to 80%, then the
totalamountoftimetheCellwilloperateduringthe5-hourcyclewillbe4hours.IftheSanitiser Output Control is
setto60%,theCellwilloperatefor3hourstotaloverthe5-hourltrationcycle.
When the Sanitiser Output ControlissettoMIN,theCellwillbeOFFforthedurationoftheltrationcycle.When
the Sanitiser Output ControlissettoMAX,theCellwillbeONforthedurationoftheltrationcycle.
The Sanitiser Output Control is graduated in steps of 10% from MIN (OFF) to MAX (ON).
Duringtheltrationcycle,theCellwillbeturnedONandOFFanumberoftimeseachhour,unlesstheSanitiser
Output Control is set at MIN or MAX. Using the previous example (of 60%), the Cell will operate for about 36
minuteseachhour.This36-minuteoperatingtimewillbemadeupofanumberofsmalleroperatingperiods.As
an example, the Cell may turn ON 12 times (for a period of 3 minutes each time) over the hour to make up the 36
minutes.
Thisenablestheelectroniccircuitrytore-adjusttoanychangesinthepoolwatercondition.Forexample,dilution
from winter rains, the addition of salt etc.
If the Cell is OFF and you wish to check its operation, simply turn the Sanitiser Output Control to MAX and the
CellwillturnON.Oncechecked,adjusttheSanitiser Output Control back to the desired position and after a few
minutes the Cell will turn OFF again.
To turn the Cell OFF, simply turn the Sanitiser Output Control to MIN. This will be convenient for backwashing.
LOW SALINITY INDICATOR
Your ChloroMatic®isttedwithanumberofprotectivesystemsincludingtheLow Salinity Indicator (operation
LED’s). As the salt level in the pool decreases, the wear on the Cell increases. Although salt is not consumed in
the ChloroMatic®process,itislostthroughsplashing,back-washingandonbathersastheyleavethepool.The
salt level is also reduced by rain, which causes dilution. Salt is not lost to evaporation.
As the salt level in the pool falls toward the minimum Operation LED2 will turn RED. At this point the salt level
should be increased by adding 25kg of salt per 25,000 litres of pool water. The addition of salt should not affect the
ChloroMatic®as it is protected against overloads. If no action is taken and the salt level continues to fall damage to
the system may result.
OPERATION OF ChloroMatic®ESC SYSTEM:
The ChloroMatic®ESC system has the following additional features:
1. POLARITY INDICATOR ON OUTPUT Display-The±Symbol appears before the cell output display to
indicate which polarity the system is in, i.e. positive or negative. This symbol will alternate and is factory pre set.
2. SANITISER OUTPUT-WhenadjustingtheSanitiser Output (refer following section) the ESC system’s
CellOutputDisplayashesthecontrolsetting(i.e.percentageoftimethattheCelloperatesduringtheltration
cycle) for a few seconds then resumes displaying Cell Output, or standby light (if in waiting).
3. CLEANING OF CELL – The ESC System uses a patented Electronic reverse polarity system to clean your Cell,
providing the convenience of lower maintenance.
4. PUMP CUT-OUT – The ESC System features a protective interlock system which cuts off power to the pool
pumpifthereisnowaterowingthroughthecellhousing.Thisisespeciallyhelpfulifthepump‘runsdry’and
hence may stop the pump motor from burning out.
