DAX BSN-CL12243 User manual

BSN-CL12243
TOILETS SERIES

FEATURES
BSN-CL12243
• Ceramic material
• White gloss finish
• Chrome flush buttons
• Soft close seat included
• Dual flush
• 1.06 - 1.6 GPF
• One piece construction
• Floor mount
18-1/2”
28-3/4”
11-13/16”
15-15/16”
16-1/8”
29-3/4”
6-7/8”
12-5/8”
16-1/8”
5-1/2”

ww w. daxib.c om
MODEL
BOWL HEIGHT
BOWL SHAPE
HEIGHT
LENGTH
WIDTH
FLUSH TYPE
FLUSH VALVE SIZE
GALLONS PER FLUSH
INSTALLATION TYPE
MATERIAL (IN)
COLOR
SEAT INCLUDED
TRIP LEVER PLACEMENT
WATER AREA
WATERSENSE CERTIFIED
PRODUCT WEIGHT
UPC APPROVED
BSN-CL12243
15-3/4”
OVAL
29-3/4”
28-3/4”
16-1/8”
DUAL FLUSH
260MM
1.06 - 1.6 GPF
FLOOR MOUNT
CERAMIC
WHITE
INCLUDE
NO
5-1/2”X7-1/2”
NO
114.9997 LB
NO
TECHNICAL SPECIFICATION BSN-CL12243
TOILET BSN-CL12243
[email protected]

ww w. daxib.c om
INSTALLATION GUIDE BSN-CL12243
01
03
Thoroughly clean the oor area where the toilet will be
installed. Align the ange ring at the pit pipe and mark
the place where the bolts should be xed, take it away,
drill the holes at the marks with a suitable bit and x
the expansion pipe. Screw the ange ring and x the
whole ange ring on the oor with the bolts.
Unplug the waste opening. Gently place the toilet
right side up in position with the toilet mounting bolts
going through the holes in the porcelain base. Press
down on the toilet until it is leveled, if necessary use
wedges to make it leveled.
The toilet should be placed on the oor upside
down, on a soft piece of cloth to prevent
scratching. Place the wax ring in the circular
recess in the base of the bowl.
Connect the water inlet to the tank. Make sure
water pressure is suffcient to l the tank.
Check the replenishing pipe and see if the
water overfow pipe is inserted. Warning: if the
overfow pipe is not inserted, the fushing may
be affected.
Slowly open the water inlet and check the
water tightness of each connection joint.
Install the toilet seat in accordance with the
instructions.
Apply a mould-proof silicon between the foor
and the toilet base.
02
04
05 06
07
08
[email protected]
