Kohler ODEON K-6286T User manual

-1-
ODEON
IN-WALL TANK
INSTALLATION INSTRUCTIONS
K-6283T/K-6286T
·
·
·
·
Read installation guide in illustration and word file
carefully, and install the tank according to instructions in
the guide to avoid product damage and installation
inconvenience caused by inappropriate operation.
All data contained is based upon the last product
information available at the time of publication. Kohler
Company reserves the right to implement changes of
product characteristics, packaging and availability at any
time without further notice.
Do not apply erosive cleanser and solvent in the tank,
which will damage tank spares and result in leakage in the
tank. Kohler will not be responsible for any damage
related to above mentioned cleanser or solvent.
Do not apply spares that are not provided by Kohler, and
please note that glass adhesive tape shall not be applied
to the installation of Kohler spares. Kohler will not be
responsible for any damage related to installation with
spares not provided by Kohler.
·Water temperature must not exceed 27 C.
o
·
·
·
·
·27oC
.......................................................K-6283T
( )........................K-6286T
K-8854T
Ordering Information
RATIO In-Wall Tank Faceplate...................................K-6283T
ODEON In-Wall Tank(Without Iron Rack) ..................K-6286T
Can match with K-8854T faceplate.
·
·
·
·
(K-6286T) 3/6L
Function Explanation
·
·
·
·
Anti flow-backwards
Adjustment of inlet water level
Adjustment of flushing volume
Single/double gear flushing
Water usage (K-6286T): 3/6L
·
·
·
·
Installation of in-wall tank is much easier and nice-looking
comparative to that of traditional tank. Meanwhile, the
space layout will be more reasonable due to the
application of in-wall tank pipes and connectors.
The most remarkable advantage of in-wall tank is that the
installation will never be limited to certain area, and can
be installed wherever as you wish, which will make the
bathroom layout more reasonable and nice-looking, and
make good use of every inch of the bathroom space.
Design And Installation Concept Of In-wall Tank
, 2012
Copyright Kohler China Ltd., 2012
1206284-T01-A

-2-
05/7/13
ROUGHING-IN
Adhesive
Agglutination
UNIT: mm
Adhesive
438
753~833
348
310~390
196
75~235
Cutting Range
1105-1185
Recommended
Installation Height
Finished Floor
15-55
·
·
·
·
·
·
·
·
400
Advantages Of In-wall Tank
·
·
·
·
·
·
·
·
Sustainable to pressure of 400 kg.
Will not affect the structure of the wall and provides
excellent sound insulation.
Easy installation and time efficient.
.
.
Clean, garbage free, and space .
Made of macromolecular materials that prevents corrison
and leaking.
Adjustable dual flush design which conserves water.
Do not need to prepare any other spare parts
Easy maintenance and servicing
saving
Kohler reserves the right to change marked dimensions without prior notice.
Reference Value
1206284-T01-A

-3-
1. Mark on the wall for appropriate position for fixing bracket,
and drill four holes with diameter of 12mm and depth of
70-76mm with churn drilling as shown in illustration, and fill
in the holes with bulge screw and tighten the screw to set
the fixing bracket.
Note: Ensure the fixing bracket to remain level.
1.
12mm 70-76mm
Screw
O
Fixing Bracket
Bulge Screw
Gasket
Spring
Nut
Put the tank onto the fixing bracket as shown in the right
figure and adjust the tank to level . Then tighten screws with
hex-head key. Note: it is a must to keep the tank level.
Connect the inlet hose with tank inlet pipe. (Note: it is
necessary to keep the inlet valve closed at this step.) ()
Level
Tank
Tighten
Loosen
Medium Allen Key
Connecting Pipe
Water Pipe
INSTALLATION
1206284-T01-A

3. Install the rectangular shield in the block screen of the tank,
and tighten the screw to fix the rectangular shield to the
tank.
3.
4. Fix the leak-proof gasket to syphon as shown in illustration,
and adjust the syphon to appropriate position to be fixed to
the infall of bowl.
4.
5. When finishing the brickwork, eliminate unwanted part of
the rectangular shield.
5.
Rectangular Shield
Leak-proof Gasket
Syphon
Screw
-4-
Block Shield
Sharp Knife
Rectangular Shield
1206284-T01-A

7. Fix the adjustable board on the wall by tightening the
locknut as shown in the illustration. And the locknut should
be directly put on the position of the sign of LOCK . (Signs
are marked on the adjustable board, please refer to the
indications in installation)
""
7.
LOCK (
)
6. When fixing the adjustable board to block shield, the
locknut should be put directly on positong of the sign of
OPEN .
Remark: Stir pole shall remain level.
""
6. OPEN
Lock
Adjustable Board
Reversed Lock
Cover
Adjustable Board
Locknut
Stir Pole
Block
Shield
Locknut
Adjustable Board
8. Install the cover as shown in the illustration. Put the lock on
the cover directly on the reversed lock on adjustable board,
then push the cover and lock it. The installation shall begin
from bottom to top.
8.
-5-
1206284-T01-A

9. In-wall tank toilet is ready to be put into use.
A. Hold the cover with both hands and push upward to take
down the cover.
A.
9.
Long
Flush Button
Short Flush Button
MAINTENANCE AND CONTROL PROCEDURESMAINTENANCE AND CONTROL PROCEDURES
Finished Installation Illustration
Cover
Cover
-6-
1206284-T01-A

B. Tighten the locknut to the marked position of OPEN to
take out the adjustable board.
""
B. OPEN
Locknut
C. Pin the indentation on block screen with screwdriver to
take out the block screen.
C.
Block
Screen
D. Wash Filtration Net
Close corner valve first, then loosen and take out the
tighten nut, and wash the waste on filtration net with clean
water. Then reset the tighten nut to the original position.
D.
Open
Close Corner Valve
Tighten Nut
Filtration Net
Loosen Nut
-7-
1206284-T01-A

E.
E. Adjust The Control Pole Of Drainage Valve
Pin the pole first to take out the control button as shown in
the illustration. Then take out the fixing frame with both
hands.
Pole
Control Button
Fixing Frame
F. Pull out reversed lock on the fixing frame as shown in the
illustration, and adjust the height of the control poles to
ensure the leak-proof of drainage valve.
F.
-8-
Fixing Frame
Fixing Frame
Control Button
Pole
1206284-T01-A

H. Adjust Inlet Valve
Hoist and reduce the water level in the tank by adjusting
the control pole. Turn the control pole counterclockwise to
lower down the floating box and reduce the water level of
the tank. Turn the control pole clockwise to hoist the
floating box and increase the water level in the tank
H.
G. Adjust Drainage Valve
Drainage volume and overflow level of the tank can be
adjusted by drainage valve: 1) Heavy drainage adjustment:
Open adjustment switch to open the small hole. 2) Slight
drainage adjustment: adjust the height of floating box and
the water level of slight drainage will be at the bottom of
the floating box.
G.
(1)
(2)
Control Pole
Drainage Valve
Adjustment Switch
Floating Box
-9-
Floating Box
Adjustment Switch
1206284-T01-A

TROUBLE SHOOTING PROCEDURESTROUBLE SHOOTING PROCEDURES
No water fills in via inlet
valve
The inlet valve is closed Open inlet valve (refer to page 7)
Floating box of inlet valve is blocked by tank wall Adjust floating box to appropriate position
Floating box of inlet valve is block by waste Wash the floating box with clean water
Wrong installation of adjustable board Reset (refer to page 7)
Control pole is too long Adjust the control pole to appropriate
position
Water level of the inlet valve is not appropriate
No drainage when
pressing the heavy and
slight drainage button
Too high or too low water
level
Leak of the toilet and
squat
Symptoms Probable Causes Recommended Action
Control pole is too short
Inappropriate adjustment of the overflow pipe
(7)
(7)
(8)
Readjust water level (refer to page 8)
Adjust the control pole to appropriate
position
Adjust the overflow pipe to appropriate
position
-10-
1206284-T01-A
