DAYLIFF DG3600D Installation instructions

Installation &
Operating Manual
DG
Portable Diesel Generators
DG 12000DS
DG 6000DS/DG8000DSM
DG3600D/DG6000D/
DG8000D/DG8000DT
DGW200D

GENERATOR SPECIFICATIONS
1.
1
2.
SAFETY WARNINGS 3
CONTROLS
3.
3
ELETRICAL CONNECTIONS
4.
3
GENERATOR OPERATION
5.
4
INDEX
© Davis & Shirtliff Ltd 2020
Contents herein are not warranted
ROUTINE MAINTENANCE
6.
4
TROUBLE SHOOTING
7.
5
WARRANTY
8.
6

1
1. GENERATOR SPECIFICATIONS
The Dayliff Range of portable diesel generators are dependable, quality products
specially designed for mains standby and remote site power supply applications.
Particular features include:
l Reliable and economical air cooled diesel engines equipped with large size
exhausts for low noise levels available in both open and canopied configurations.
l High efficiency square core alternators providing reliable power output.
l DC output for charging.
l Integrated control panel with voltmeter for operational convenience.
l Fuseless type over current protection.
l Oil alert system to stop engine in the event of low oil level.
l High capacity fuel tank for extended operation.
l Fitted with AMF auto start facility which when combined with an optional ATS
power change over panel enables fully automatic power failure operation (not
open sets).
lStrong tubular frame for protection and ease of handling(open sets)
lAcoustic models further strengthened canopy on castors limits noise to min 70dBA
@ 7m
For DGW200D
• AC auxiliary current and DC welding current can be used simultaneously.
• Supplied complete with electrode holder and 4m cable, welding clamp and 4m
cable, output plugs and separate castor wheels for movable applications.
Dayliff generators are of compact design and their advanced features make them
suitable for all small scale power supply applications.
Congratulations on selecting a Dayliff DG Diesel Generator. They are
manufactured to the highest standards and if installed and operated
correctly will give many years of efcient and trouble free service. Careful
reading of this Installation Manual is therefore important, though should
there be any queries they should be referred to the equipment supplier.
DG 6000DS/
DG8000DSM
DG 12000DS
DG3600D/DG6000D
DG8000D/DG8000DT
DGW200D

2
*Acoustic Set with AMF noise level: 70dBA@7m
NOTE: Given outputs are sea level ratings. Sets should be rated at 1% for every 100m
0 0
higher than 100m above sea level, and 2% for every 5 C temperature above 20 C.
Welding Data
Specications
Electrical Data
Alternator: Brushless, self exciting, 2 pole Pole Output: 50Hz, 240V single phase
Voltage Regulator: AVR Power Factor: 1ph - 1,3ph - 0.8
Direct Current: DG-D -12V/6A Speed: 3000rpm
DGW-D -12V/8.3A
Dimensions & Weights
Welding Performance
No Load
Voltage
(V)
Operation
Voltage
(V)
Operating
Current (A)
Welding Rod Currents (A)
2.5mmØ 3.2mmØ 4mmØ
Max. Arching
Current (A)
Model
1x240 Electric 418 7.7 6
12.5
4.6
4.2 LA186
DGW200D
65 28-35 50-120 50-100 100-160
DGW200D 160-180
180
Model L
(mm)
W
(mm)
H
(mm)
Weight
(kg)
740 475 590 125
DGW200D
L
W
H
Fuel
Tank
Capacity
(litres)
Model Rated
(KVA)
Max
(KVA)
Start
Type
Output
Model
Engine
Capacity
(cc)
Max
Power
(HP)
Opera-
ting
Period
(Hrs)
LA186FAFG 418 8.5 4
12.55.0
1x240 4.5
DG6000D
Voltage
(V)
3x415 Electric
954 20 12
50
13.7
12.5 LA290
1x240 Electric
954 20 12
50
11
10 LA290
DG12000DSM*
DG12000DST*
1x240
1x240
1x240
3x415
Recoil/Electric
Electric
Recoil/Electric
418
499
499
499
8.5
10
10
10
5
16
12.5
25
12.5
5.0
6.5
6.5
8.1
4.5
6.0
6.0
7.5
DG6000DS* LA186FAFG
LA192F
LA192FAG
LA192F
Recoil
LA178FG 306 5.5 18
12.53.0
1x240 2.7
DG3600D
DG8000D 5
8
8
Recoil/Electric
Recoil/Electric
DG8000DSM
DG8000DT
740 475 590 95
1150 670 940 295
900
740
960
520
475
560
700
600
710
150
120
164
680 455 545 80
DG6000D
DG12000DSM
DG12000DST
DG6000DS
DG3600D
DG8000D/
DG8000DT
DG8000DS

3
2. SAFETY WARNINGS
Instruction
Manual
!
Gasoline
Read and carefully understand the Instruction Manual
before use.
Avoid proximity to fire when refueling highly
inflammable!
Ensure good ventilation around the generator and do
not operate indoors.
Exhaust gases are very poisonous
Do not use generator on a slope.
Fuel spillage may occur and cause a fire.
Do not restrict the exhaust silencer.
There is a danger of overheating and fire.
Do not connect generators together.
Generator damage will occur.
Ensure a competent trained person is used in case of
overhaul.
3. CONTROLS
All generators are fitted with the following:-
Ÿ2no. 3 pin AC outlets, +ve and -ve DC connections.
ŸEngine on/off switch.
ŸMagnetic circuit breaker electric cutout.
ŸVoltmeter
4. ELECTRICAL CONECTIONS
WARNING
If the generator is to be connected for standby power use
ensure a qualified electrician is employed. The generator must
be isolated from the utility power when connected or serious
damage will result to the generator and house power circuits.
ŸEnsure total load does not exceed the generator rating. Maximum power output must
only be used briefly or generator damage will occur.

4
6. ROUTINE MAINTENANCE
For comprehensive diesel engine operation, see separate engine manual.
ENGINE OIL: Check engine oil every time you use the generator. If low refill it. Change
engine oil after first month or after 20hrs operation and thereafter every 3 months or 100
hours of operation, in both cases whichever is sooner.
FUEL FILTER: Every 3 months check the fuel filter under the fuel cock for debris and
clean. Use a spanner to remove.
AIR CLEANER: Check the air cleaner every time you use it and clean it every 3 months or
after 100 hours operations, whichever is sooner. Clean by blowing away accumulated
dust and soaking in kerosene.
ŸDC output to be used for charging automotive and solar 12V batteries only. Ensure
correct polarity when connecting cables, i.e +ve to +ve and -ve to -ve generator to
battery terminals.
ŸEnsure the generator is properly earthed. Consult a qualified electrician if in doubt.
5. GENERATOR OPERATION
ŸCHECK ENGINE OIL. Operating without oil will cause severe engine damage and
invalidate the warranty.
ŸTo start ensure ignition ‘ON’, fuel valve ‘ON’ and choke ‘ON’. Then either pull starter
cord (manual start) or turn key (electric start). For electric start do not turn the engine
on for more than 5 seconds. If it fails to start release the switch and wait 15 seconds
before re-trying. Switch off choke when engine has started.
ŸCheck output voltage is 240V on the voltmeter. If not adjust engine speed. If the speed
setting is correct and the voltage is low then the generator is overloaded and load must
be reduced.
ŸIf more than an appliance is connected apply load progressively with greatest load
first.
Ÿ Close fuel valve whenever generator is not operating.
WARNING
Always start generator before applying load by switching the
circuit breaker and stop the generator after disconnecting
load. Starting and stopping under load will damage the
generator and powered accessories.

5
No Electrical
output Circuit breaker tripped
Reduce generator load
Check for short circuit in load
Loose connection in output cable
Right engine oil to drain
Oil leakage
from muffler or
air cleaner Engine has tipped over
Check engine speed
Reduce generator load
Low Electrical
output
Low output voltage
Excessive electrical load
Engine does
not start
Clean carburettorCarburettor is blocked
Clean and adjust plugSpark plug is wet / dirty
Clean air cleaner
Air cleaner dirty
Reduce oil to suitable level
Too much engine oil
Oil sensor is activated. Add oil
(Oil sensor prevents engine
from running if oil level is low)
Insufficient engine oil
No fuel
Check fuel cock open
Clean if fuel filter blocked
Battery flat (Electric start) Charge/replace battery
7. TROUBLE SHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION

8. TERMS OF WARRANTY
6
If equipment failure occurs in the normal course of service having been competently
installed and when operating within its specified duty limits warranty will be provided as
follows:-
ŸUp to three months - The item will be replaced or repaired at no charge.
ŸOver three months, less than six months - The item will be replaced or
repaired at a cost to the customer of 50% of the Davis & Shirtliff market
price.
The warranty on equipment supplied or installed by others is conditional upon the
defective unit being promptly returned free to a Davis & Shirtliff ofce and collected
thereafter when repaired. No element of site repair is included in the warranty and any site
attendance costs will be payable in full at standard charegeout rates. Also proof of
purchase including the purchase invoice must be provided for a warranty claim to be
i) General Liability
ii) Standard Warranty
• In lieu of any warranty, condition or liability implied by law, the liability of Dayliff
(hereafter called the Distributor) in respect of any defect or failure of equipment
supplied is limited to making good by replacement or repair (at the Distributor’s
discretion) defects which under proper use appear therein and arise solely from faulty
design, materials or workmanship within a specified period. This period commences
immediately after the equipment has been delivered to the customer and at its
termination all liability ceases. Also the warranty period will be assessed on the basis
of the date that the Distributor is informed of the failure.
ŸThis warranty applies solely to equipment supplied and no claim for consequential
damages, however arising, will be entertained. Also the warranty specifically excludes
defects caused by fair wear and tear, the effects of careless handling, lack of
maintenance, faulty installation, incompetence on the part of the equipment user, Acts
of God or any other cause beyond the Distributors's reasonable control. Also, any
repair or attempt at repair carried out by any other party invalidates all warranties.

INS182G-03/20
