DAYLIFF DG 6000D Installation instructions

DG
Portable Diesel Generators
Installation &
Operating Manual
DG 6000DS
DG 6000D

GENERATOR SPECIFICATIONS
1.
1
2.
CONTROLS 2
ELECTRICAL CONNECTIONS
3.
2
GENERATOR OPERATION
4.
3
ROUTINE MAINTENANCE
5.
3
INDEX
© Davis & Shirtliff Ltd 2014
Contents herein are not warranted
SAFETY WARNINGS
6.
4
TROUBLE SHOOTING
7.
5
WARRANTY
8.
6

1
1. GENERATOR SPECIFICATIONS
Thank you for choosing Dayliff DG diesel generators. It has been
manufactured to the highest standards and if operated correctly should give
many years of efficient and trouble free service. Careful reading of this
instruction manual is therefore extremely important and if you have any
queries
please refer
them
to your
retailer.
The Dayliff Range of portable diesel generators are dependable, quality products
specially designed for mains standby and remote site power supply applications.
Particular features include:
l Reliable and economical air cooled diesel engines equipped with large size
exhausts for low noise levels available in both open and canopied
configurations.
l High efficiency square core alternators providing increased power output
and enabling operation of sensitive electronic equipment.
l AC auxillary current and DC welding current can be used simultaneously
(DGW)
l DC output for charging.
l Integrated control panel with voltmeter for operational convenience.
l Fuseless type over current protection.
l Oil alert system to stop engine in the event of low oil level.
l High capacity fuel tank for extended operation.
l Fitted with AMF auto start facility which when combined with an optional ATS
power change over panel enables fully automatic power failure operation
(not DG6000D).
l Strong tubular frame for protection and ease of handling(DG6000D)
l Silent models (not DG6000D) feature strengthened canopy on castors and
limits noise to 70dBA @ 7m.
DG 6000DS
DG 6000D

2
Specifications
Dimensions & Weights
Dayliff generators are of compact design and their advanced features make them
suitable for all small scale power supply applications.
740
900
1160
Model
DG6000D
L (mm) W (mm) H (mm) Weight
(kg)
DG6000DS
DG12000DSM
DG12000DST
475
520
675
590
700
945
95
150
300
Fuel
tank
capacity
(litres)
Model Rated
(KVA)
Max
(KVA)
Starter
Output
Model
Engine
Capacity
(cc)
Max
Power
(HP)
Opera-
ting
Period
(Hrs)
Electric
LA186FAFG 418 10 6
12.55.0
1x240
1x240
1x240
3x415
4.5
Electric
Electric
Electric
418
954
954
10
20
20
5
14
14
16
53
53
5.0
11
13.7
4.5
10
12.5
LA186FAFG
LA290
LA290
DG6000D
DG6000DS
DG12000DSM
DG12000DST
Voltage
(V)
DGW 200D Electric
418 7.7 6
12.5
4.6
4.2 LA186
Welding Data
Welding Performance
No Load
Voltage (V)
Operation
Voltage (V)
Operating
Current (A)
65 28-35 50-120
Welding Rod Currents (A)
2.5mmØ
50-100
3.2mmØ
100-160
DGW200D
4mmØ
160-180
Max. Arching
Current (A)
180
Model
DERATING: Given outputs are sea level rating. Sets should be derated at 1% for
0
every 100m higher than 100m above sea level, and 2% for every 5 C temperature
0
above 20 C
ELECTRICAL DATA
Alternator: Brushless, self exciting, 2 pole
single phase
Power Factor: 1 Voltage Regulator: AVR
Direct Current:12V/8.3A Speed: 3000rpm
Power Output: 50Hz, 240V,
685
DGW200D 520 625 107

3
5. ROUTINE MAINTENANCE
ENGINE OIL: Check engine oil every time you use the generator. If low refill it.
Change engine oil after first month or after 20hrs operation and thereafter
every 3 months or 100 hours of operation, in both cases whichever is
sooner.
FUEL FILTER: Every 3 months check the fuel filter under the fuel cock for
debris and clean. Use a spanner to remove.
! CHECK ENGINE OIL. Operating without oil will cause severe engine damage
and invalidate the warranty.
4. GENERATOR OPERATION
WARNING
Always start generator before applying load by switching the
circuit breaker and stop the generator after disconnecting
load. Starting and stopping under load will damage the
generator and powered accessories.
!
output must only be used briefly or generator damage will occur.
! DC output to be used for charging automotive and solar 12V batteries only.
Ensure correct polarity when connecting cables, i.e. +ve to +ve and-ve to -
ve generator to battery terminals.
! Ensure the generator is properly earthed. Consult a qualified electrician if in
doubt.
Ensure the total load does not exceed the generator rating. Maximum power
3. ELECTRICAL CONECTIONS
WARNING
If the generator is to be connected for standby power use
ensure a qualified electrician is employed. The generator must
be isolated from the utility power when connected or serious
damage will result to the generator and house power circuits.
2. CONTROLS
All generators are fitted with the following:-
! 2 no 3 pin AC outlets, +ve and -ve DC connections.
! Engine on/off switch.
! Magnetic circuit breaker electric cutout.
! Voltmeter

4
6. SAFETY WARNINGS
Do not restrict the exhaust silencer.
There is a danger of overheating and fire.
Read and carefully understand the Instruction
Manual before before use.
Instruction
Manual
Ensure a competent trained person is used in case
of overhaul.
Do not use generator on a slope.
Fuel spillage may occur and cause a fire.
Do not connect generators together
Generator damage will occur.
Avoid proximity to fire when refueling.
Highly inflammable!
!
Gasoline
Ensure good ventilation around the generator and
do not operate indoors.
Exhaust gases are very poisonous.
AIR CLEANER: Check the air cleaner every time you use it and clean it every 3
months or after 100 hours operations, whichever is sooner. Clean by blowing
away accumulated dust and soaking in kerosene.

5
Right engine oil to drain
No Electrical
output Circuit breaker tripped
Reduce generator load
Check for short circuit in load
Loose connection in output
cable
Engine does
not start
Clean air cleaner
Air cleaner dirty
Reduce oil to suitable level
Too much engine oil
Oil sensor is activated. Add oil
(Oil sensor prevents engine
from running if oil level is low)
Insufficient engine oil
Check fuel cock open
No fuel
Clean if fuel filter blocked
Battery flat (Electric start) Charge/replace battery
Check engine speed
Reduce generator load
Oil leakage
from muffler or
air cleaner Engine has tipped over
Low Electrical
output
Low output voltage
Excessive electrical load
7. TROUBLE SHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION

6
8. TERMS OF WARRANTY
i) General Liability
! In lieu of any warranty, condition or liability implied by law, the liability of
Davis & Shirtliff (hereafter called the Company) in respect of any defect or
failure of equipment supplied is limited to making good by replacement
or repair (at the Company's discretion) defects which under proper use
appear therein and arise solely from faulty design, materials or workmanship
within a specified period. This period commences immediately after the
equipment has been delivered to the customer and at its termination all
liability ceases. Also the warranty period will be assessed on the basis of the
date that the Company is informed of the failure.
! This warranty applies solely to equipment supplied and no claim for
consequential damages, however arising, will be entertained. Also the
warranty specifically excludes defects caused by fair wear and tear, the
effects of careless handling, lack of maintenance, faulty installation,
incompetence on the part of the equipment user, Acts of God or any other
cause beyond the Company's reasonable control. Also, any repair or
attempt at repair carried out by any other party invalidates all warranties.
ii) Standard Warranty
If equipment failure occurs in the normal course of service having been
competently installed and when operating within its specified duty limits
warranty will be provided as follows:-
 Up to six months - The item will be replaced or repaired at no
charge.
 Over 6 month, less than a year - The item will be replaced or
repaired at a cost to the customer of 50% of the Davis & Shirtliff
market price.
The warranty on equipment supplied or installed by others is conditional
upon the defective unit being promptly returned free to a Davis &
Shirtliff office and collected thereafter when repaired. No element of site
repair is included in the warranty and any site attendance costs will be
payable in full at standard chargeout rates. Also proof of purchase including
the purchase invoice must be provided for a warranty claim to be considered.
Also proof of purchase including the purchase invoice must be provided for a
warranty claim to be considered.

INS182F-07/15
