DAYLIFF DSmart300 Installation instructions

DSmart
Smart Water Boosting System
Installation &
Operating Manual
DSmart300/500 DSmart750
DSmart1500

PUMP SPECIFICATIONS
1.
1
2.
SYMBOLS & WARNINGS 3
INSTALLATION
3.
4
OPERATION
4.
10
MAINTENANCE
5.
12
INDEX
© Davis & Shirtliff Ltd 2023
Contents herein are not warranted
TROUBLE SHOOTING
6.
14
WARRANTY
7.
17

1
1. PUMP SPECIFICATIONS
Congratulations on selecting a Dayliff DSmart Pump. They are
manufactured to the highest standards and if installed and operated
correctly will give many years of efcient and trouble free service.
Careful reading of this Installation Manual is therefore important and
any queries should be referred to the equipment supplier.
35
3
FLOW RATE (m /hr)
10
20
30
04816 20
12
10
20
30
40
60
012345
50
6
5
15
25
35
45
55
3
FLOW RATE (m /hr)
10
20
30
5
15
25
PUMP HEAD (m)
50
10
20
30
40
5
15
25
35
45
3
FLOW RATE (m /hr)
012 3 4 4.5
40
60
50
12 3 4
3
FLOW RATE (m /hr)
DSmart300
00.5 1.5 2.5 3.5
DSmart500
DSmart750
30%
50%
60%
80%
100% DSmart1500
100%
80%
60%
50%
30%
30%
50%
60%
80%
100%
30%
50%
60%
80%
100%
DSmart300/500 DSmart750 DSmart1500
PUMP HEAD (m)
PUMP HEAD (m) PUMP HEAD (m)

2
PUMPS
DAYLIFF DSmart Pumps are innovative centrifugal self-priming variable speed automatic water
boosting systems for pressurised water supply, variable speed technology providing constant
pressure at varying water demand levels. Pump construction is engineering plastic throughout
except DSmart750 which has stainless steel pump body with external casings made from UV
proof components suitable for indoor and outdoor installations. Particular features include:-
ŸInnovative inverter controlled variable speed technology that minimises energy
consumption.
ŸQuiet operation with max noise levels of 50dB.
ŸFully automatic operationwith adjustable constant pressure settings that matches flow with
demand.
ŸEasy to use LED control panelwith display for operating mode, operating pressure and
various fault indicators.
ŸConvenience featuresincluding standard inlet and outlet connectors and inbuilt non-
return valve.
ŸHigh/Low temperature protection and leakage warning.
ŸIntegrated pressure tank for dry running and anti-cycling protection.
ŸParallel connection for 2 pump operation available for Dsmart1500
DSmart are exceptionally advanced pumps that use state-of-the-art inverter technology to
provide the perfect solution for a complete water supply system in domestic, residential and
small commercial water supply applications.
MOTORS
Pumps are fitted with high efficiency IE5 Permanent Magnet variable frequency motor that
incorporates thermal protection against motor overload and dry run protection with auto-
restart. The motor can be directly connected to the mains power supply through an
appropriately sized 13A fuse or MCB.
Enclosure Class: IPX5
Insulation Class: F
Max Speed: 5200rpm
Power Input:165 - 260V / 1PH / 50 - 60Hz
OPERATING CONDITIONS
Pumped Liquid: Thin, clean, chemically non-aggressive liquids without fibres
0
Max. Ambient Temperature: +40 C
0 0
Water Temperature: +4 C - +75 C

3
Model Motor
(kW)
Dimensions (mm) Weight
(kg)
L W
0.5
0.3
4.5
3
4
3
1330
285
205
183
280
253
7
6
P2
Current
(A)
Inlet/
Outlet
(”) H
DSmart500
DSmart300
DSmart750 0.75 5.5
5.2 390 195 290 9
DSmart1500 1.5 713.1 511 215 382 24
2
Max
Inlet/Outlet
Pressure (Bar)
Inlet
W
L
H
Outlet
DSmart300/500 Dsmart750
Outlet
Inlet
H
L
Outlet
Inlet
H
DSmart1500
W
PUMP DATA
2. SYMBOLS AND WARNINGS
WARNING
WARNING
The power supply cable should never be used to carry or shift the
pump. If damaged, it must be replaced with a cable of similar
specication.
Before commencing installation ensure equipment is well
protected and the power supply has been switched off.
WARNING
The power cable should be provided with short circuit protection
(MCB) to guard against high frequency currents faults. Ensure
that the earthing complies with the required local standards.
WARNING
The pump is supplied with grounding wire. To reduce the risk of
electric shock, ensure that the pump is properly grounded.
WARNING
It is not recommended to use RCD (Residual Current Device) with
variable speed drives/motors. However, if mandatory, use Type B
because of the nature of the constant DC leakage current.
The electrical connections should be carried out in accordance
with local regulations. Ensure that the values indicated on the
nameplate match with the supply voltage and frequency.
WARNING

4
3. INSTALLATION
Inspecting the product
ŸCheck pump’s voltage and frequency of the product match the voltage and frequency of
the installation site.
No Part Name Material Part Name Material
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Waterproof Screw
Screw
Check Valve
Pump Body
Prop
Water Inlet Guide Glade
Impeller
Guide Glade
Impeller
Seal Holder
Waterproof Gland
Pump Support
Rotor
Bearing
Motor
Aluminium
Nylon 66
304
Nylon
Nylon 66
PPO
PPO
PPO
PPO
PPO
Aluminium
EPDM
304
CR15
-
No
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
Fan
Fan Cover
Hull
Crash Pad
Hull
Controller
Overhead Tank
Screw
Pressure Sensor
Sensor Bracket
Temperature Sensor
5-Way Valve
Water Injection Screw
Strainer
Check Valve
Nylon 66
PPO
PP
Plastic
Rubber
Plastic
-
Carbon Stall
304
-
PPO
-
Nylon 66
Nylon 66
-
DSmart 300/500

35
No Part Name Material Part Name Material
1
2
3
4
5
6
7
8
9
10
11
12
13
Hull
Guide Glade
Impeller
Prop
Radiation Fin
Seal Holder
Pump Support
Motherboard
Water Proof Gland
Rotor
Bearing
Spring Washer
PC+PBT
PPO-GF30
No
14
15
16
17
18
19
20
21
22
23
24
25
26
Fan Cover
Fan
Capacitor Box
Gland
Controller
Stator
Overhead Tank
Transducer
Sensor Bracket
Bottom Bracket
Check Valve
Pump Body
Check Valve
PP-GF10
ABS (VO)
NBR
P.C Board
Copper Coil
-
-
06Cr19Ni10
PC+PBT
-
Water Inlet Guide Glade
PPO-GF30
PPO-GF30
PA6-GF30
ABS
PPO-GF30
Zl102
PC+PBT
NBR
304+45#SI
Steel
RS Bearing
65Mn Steel
PP-GF10
HPb59-1
-
DSmart 750

3336
No Part Name
DSmart 1500
Material Part Name Material
1
2
3
4
5
6
7
8
9
10
11
12
13
Bolt
Check Valve
Drain Plug
Pump Body
Gland
Return Valve
Water Inlet Guide Glade
Guide Glade
Impeller
Gearing
Hull
Seal Holder
Pump Support
45#Nickel
plating
HPb59-1
06Cr19Ni10
NBR
No
14
15
16
17
18
19
20
21
22
23
24
25
26
Rotor
Motor
Fan
Fan Cover
Bearing
Controller
Panel
Gland
Hull
Overhead Tank
Mechanical Seal
Check Valve
Bottom Bracket
50WW600
PP
PP
/
/
/
Silica
ABS
Q235/IIR
HPb59-1
HPb59-1
HPb59-1
06Cr19Ni10
06Cr19Ni10
06Cr19Ni10+45#
06Cr19Ni10
/
ABS
06Cr19Ni10
ZL102
06Cr19Ni10/EPDM
HPb59-1

3337
WARNING
During both the rst installation and maintenance the POWER
in the supply line should be switched off.
ŸEnsure that the pump is mounted in a level position on the base plate, with an
inclination angle not exceeding ± 5°.
ŸAttach the pump securely to a stable, level base by utilizing screws inserted through
the openings in the base plate.
Fig 3
Fig 2Fig 1
WARNING
For emergencies and maintenance, the pump must be easily
accessible.
WARNING
The pumps must be installed in a dry position and protected
from the elements by means of a suitable cover.
NOTE
As advised on dimensions table, enough space for service and
maintenance access should be considered.
WARNING
The pump can be installed indoors or outdoors.

8
ŸTo prime pump, add water to the priming plug until it overflows.
ŸWhen installing the water pump, avoid use of soft rubber pipe, due to risk of
collapsing.
ŸThe foot valve shall be vertical and installed 30cm away from the bottom of the water
to avoid drawing in of sediments.
ŸAll connections of the inlet pipeline must be sealed to minimize elbows, otherwise
suction may not be effected.
ŸThe diameter of the water inlet pipe shall be at least the same as that of the pump inlet
to prevent hydraulic loss from affecting the water outlet performance.
ŸWhen using the pump pay attention to the water level drop and ensure the foot valve is
not exposed above the water surface.
ŸWhen the length of the water inlet pipe is more than 10m or the lifting height of the
water is more than 4m, the diameter of the water inlet pipe must be greater than the
diameter of the pump inlet.
ŸWhen installing the pipeline, make sure that the pump is not under pipeline pressure.
ŸIt is advisable to install a strainer when source water is suspected to be dirty.
ŸThe outlet pipe diameter shall be at least the same as the outlet diameter to minimize
the pressure drop, high flow rate and noise.
ŸWhen the water pump is installed in a place that may be flooded ensure to install a
raised platform to prevent the ventilation holes from being flooded.
ŸWhen installing the pump, ensure to eliminate any air locked within the pipeline.
Pipe Connection

9
Installation Examples
Higher Floor
Tank
Tank
Tank
Roof
Higher Floor
Higher Floor
Foot Valve Well
Ground
Tap Water
Roof
Lower Floor
Ground
Higher Floor
Lower Floor

10
4. OPERATION
Priming the pump
To start the pump, it is necessary to prime it by filling with water. Do not start the
pump until it has been filled with water.
ŸUnscrew the priming plug and allow an even flow of water.
ŸScrew the plug on again. The pump is now ready to start.
Starting the pump with control panel
ŸTo prepare the pump for venting, open a tap.
ŸInsert the power plug into the socket and turn on the power supply. The pump will
power after 3 seconds after main power is introduced.
ŸClose the tap once water flows.
ŸOpen the highest tap point in the installation, such as a shower.
ŸUse the buttons to adjust the pressure set point to the required pressure.
ŸOnce done, close the tap.
To set pressure
ŸThe pump's water pressure can be adjusted to any value between 1.5 to 6.0 bar
and 7 bar for DSmart 1500.
ŸThe default pressure, as indicated is 2 bar which for most applications is sufficient.
The difference between inlet pressure and outlet pressure must not exceed 3.5
bar. For example, if the inlet pressure is 0.5 bar, the maximum outlet pressure
should be 4 bar.
Outlet
Priming Plug
Inlet
Drain Plug

Control Panel
Troubleshooting Error
Code “E”
1. In pressure mode, this indicator displays the pump’s operating pressure. In speed mode,
this indicator displays digits of thousands and hundreds for the current running speed.
2. In pressure mode, this indicator displays the pump’s set pressure. In speed mode, this
indicator displays digits of tens and ones for the current running speed.
Operation
ŸPress power button to start the pump (may take 3 seconds), switch light on.
Press the power button to stop the pump, switch light off.
ŸPress and hold power button for 10 seconds to switch between pressure mode and speed
mode.
12
3
4
5
6
Troubleshooting Error
Code “1~12”
11
Notes:
Pressure mode:
The indicator displays the operating pressure and set pressure. To adjust the pump's pressure,
press the button. The pressure can be set within a range of 1.5 to 7.0 bar.
Speed mode:
The indicator displays the running speed (r.p.m). In this mode, the pump does not stop
automatically. To adjust the pump's speed, press the or button. The speed can be set within
a range of 2,500 to 5,200 r.p.m.

Indicator buttons:
ŸPump is ‘ON’.
ŸLeakage detected in pipeline: Check where the leakage could occur or contact nearest
Dayliff retailer.
ŸVoltage protection: Input voltage has fallen out of specification for pump. Contact nearest
Dayliff retailer.
ŸDry run detected: Refer to section 6: common fault codes and troubleshooting list “error
codes E10.
Dry Run Protection
This pump is provided with dry run protection, which includes a safety control circuit that can
detect when the pump experiences water storage. If the pump runs out of water, it will stop as
part of a protective logic sequence. Before restarting the pump, ensure there is enough water
supply and all terminal fitting outlets are closed.
In case of water shortage and uninterrupted power supply, the pump controller will initiate a
protective logic sequence.
WARNING
The pump will stop operation when it detects water shortage and
will remain off for 5 minutes. The pump will then run two times the
same sequence. If the water shortage still remains, it will stop
operation for 6 hours before attempting to start again.
Maintenance in Operation
ŸThe inlet pipe must be full of water. The pump should not be operated without water.
ŸRegularly check the motor current, which shall not exceed the rated current of the motor.
ŸAfter long term operation of the pump, due to mechanical wear, the noise and vibration of
the unit may increase, leakage may also occur and the performance compromised. At this
point, the pump should be shut down for inspection.
5. MAINTENANCE
12
Note
ŸPressure mode is set as default.
ŸSpeed mode be activated only when pressure sensor fails. Speed mode ensures that the
pump operates temporarily for water usage
WARNING
The fewer the lights are on, the more energy is saved.
ŸPress reset button for 3 seconds to reset all parameters back to the default.
ŸIncrease set pressure or running speed by pressing .
Decrease set pressure or running speed by pressing .
WARNING
In speed mode, the water pump does not stop automatically.

Mechanical Seal Maintenance
ŸThe mechanical seal lubrication shall be clean and free of particles.
ŸBefore starting, turn the motor severally to prevent the graphite ring from breaking and
damage due to sudden starting.
ŸThe seal leakage tolerance is 3 drops/min, otherwise, it should be repaired.
ŸWhen repairing and assembling the mechanical seal, avoid contact with oily substances
and use soapy water instead to lubricate and reduce resistance.
13

6. TROUBLE SHOOTING
Before troubleshooting it is necessary to switch off the power supply and ensure it cannot
be accidentally switched on
ERROR
CODE CORRESPONDING FAULT TROUBLE SHOOTING
E1
Pa n e l a n d m o t h e r b o a r d
communication failure
Check whether the panel cable is well connected, and try
plugging and unplugging again. If it cannot be resolved. The
panel or motherboard has failed and will need replacement.
E2 Stall Try to turn the fan blade to see if the impeller is stuck.
E3 Voltage failure,  icon lights up Check voltage.
E4 Outlet pressure sensor failure
Check whether the lower pressure sensor interface is in poor
contact and re-plug. If still unresolved, replace the pressure
sensor.
E5 Controller failure
• Power off, wait for the panel light to go out, then power on
again.
• If still unrecovered, the motor or driver board is damaged
and may need to be replaced.
E6 Loss of phase
Check whether the motor cable is connected measure the
resistance of the motor wire and check if there is any
discontinuity.
E7 Overcurrent
• Check if there is a short circuit in the motor.
• Check the voltage resistance of the motor to see if the
voltage resistance is enough.
• Re-power and test if the motor is ok, the starter may be
damaged due to accidental impact.
E9 Water temperature protection Check whether the water temperature is abnormal.
E10 Lack of water,  icon lights up
Check whether the water is available.Enter the factory menu to
adjust the water shortage pressure and adjust it to the current
pressure.
E11 Leakage,  icon lights up
Check whether the pipeline is leaking, or whether the check
valve is leaking, it does not affect the water use, it only serves as
a reminder.
E12 Driver board overheating fault
Wait for the temperature of the pump to drop, and
automatically resume operation, or move the pump to a cool
and ventilated place.
14

15
PROBLEM POSSIBLE CAUSE SOLUTION
No electric power
The pump
does not start
Check power supply
Check wiring connections
Check power supply within the
voltage range prescribed on the
pump nameplate
Pump is blocked
Rotate the rotor shaft at the blade
end or dismantle the pump and
remove particles from pump cover
Static inlet/outlet pressure exceeded Reposition pump
Controller damaged Replace the controller
Suction is blocked
Pump runs with
no water being
discharged
Clear blockage
Pump is not primed Remove the drain plug and ensure
pump is filled with water
Pump drawing in air Check inlet pipes if there is a
leakage
Pump inlet pressure is too low
Insufficient
water pressure
Check the inlet pressure or inlet
pipe diameter
Blockage in inlet pipe Clean the inlet pipe or the pump
Leakage in inlet pipe Repair the inlet pipe
The outlet pressure is too low Increase the pressure setting
Pump does not
stop
Leak in the pipe line Check the pipe line and eliminate
the leak
Impeller blocked Dismantle the pump and remove
the particles
Faulty pressure sensor Replace the sensor

16
PROBLEM POSSIBLE CAUSE SOLUTION
Pump is noisy
Bearing damaged Repair or replace else contact
Dayliff retailer
Impeller damaged
Inlet pipe is too small Check inlet pipe size
Pump leaks
Mechanical seal worn out Replace mechanical seal
Pipes fitted correctly Check and repair pipes

7. TERMS OF WARRANTY
i) General Liability
ii) Standard Warranty
17
• In lieu of any warranty, condition or liability implied by law, the liability of
Dayliff (hereafter called the Distributor) in respect of any defect or failure
of equipment supplied is limited to making good by replacement or
repair (at the Distributor discretion) defects which under proper use
appear therein and arise solely from faulty design, materials or
workmanship within a specified period. This period commences
immediately after the equipment has been delivered to the
customer and at its termination all liability ceases. Also the warranty
period will be assessed on the basis of the date that the Distributor is
informed of the failure.
• This warranty applies solely to equipment supplied and no claim for
consequential damages, however arising, will be entertained. Also
the warranty specifically excludes defects caused by fair wear and tear,
the effects of careless handling, lack of maintenance, faulty installation,
incompetence on the part of the equipment user, Acts of God or any
other cause beyond the Distributors reasonable control. Also, any repair
or attempt at repair carried out by any other party invalidates all
warranties.
General Terms
If equipment failure occurs in the normal course of service having been
competently installed and when operating within its specified duty limits
warranty will be provided as follows:-
ŸUp to one year - The item will be replaced or repaired at no
charge.
ŸOver one year, less than two years - The item will be replaced or
repaired at a cost to the customer of 50% of the Davis & Shirtliff
market price.
The warranty on equipment supplied or installed by others is conditional
upon the defective unit being promptly returned free to a Davis &
Shirtliff ofce and collected thereafter when repaired. No element of site
repair is included in the warranty and any site attendance costs will be
payable in full at standard chargeout rates.
Also proof of purchase including the purchase invoice must be provided for
a warranty claim to be considered

INS539A-11/23
