DaySequerra M3 User manual

M3
Multi-Tuner
Monitor
User Manual


2"
M3#User#Manual#
Welcome"
Thanks for purchasing the DaySequerra M3 HD RadioTM Multi-Tuner. We design and build all of our
DaySequerra products to be completely reliable and easy to use, so you can concentrate on producing
great sounding broadcasts, not struggling with complicated equipment or difficult to use product
manuals.
While the M3 has been designed to be straightforward to use, we do suggest that you spend a few
minutes familiarizing yourself with the features and operational functions that are contained in this
manual.
DaySequerra has been building broadcast quality products since 1989. The technology developed for
the M3, and all of our products, has evolved through a process of user feedback, extensive listening,
field-testing and careful refinement.
In the event that you encounter any technical or operational difficulties with this or any DaySequerra
product, please feel free to contact us at 856-719-9900. Our office hours are from 9 to 5 ET, Monday
through Friday. Or you can email your questions to: [email protected].
Also, please remember to visit our website www.daysequerra.com for warranty registration and the
latest DaySequerra product information.
We have worked hard to ensure that your DaySequerra M3 will reliably serve as a useful link between
your source material and your broadcasts.
We sincerely hope our products help you achieve a new level of excellence in your work!
"
"
"
David"V."Day"
and#the"DaySequerra"Team
Day Sequerra 154 Cooper Rd. #902 W. Berlin, NJ 08091 Voice 856-719-9900 [e-mail] www.daysequerra.com
| |
|
|
|

M3#User#Manual#
3"
Table"of"Contents"
Important Safety Information 4
Service Information 4
Introduction 4
M3 Key Features 5
M3 Technical Specifications 5
Unpacking and Installing 6
Front Panel Controls and Indicators 6
Rear Panel Controls and Connectors 9
M3 Operating Description 10
Sample VFD Displays 12
Performance Loss Monitor 18
User Settings 23
One Year Warranty 24
"
"
"
All rights reserved DaySequerra Corp, Copyright 2011.
All logos and trademark used herein are the property of their respective owners.
Specifications subject to change.
M3.0 Revision B.

4"
M3#User#Manual#
Important"Safety"Information"
•Indoor use only. Not for use in wet or damp environments.
•Maximum Relative Humidity: <80%
•Class I Equipment (grounded type)
•Electrical rating: 100-120/220-240V~50-60Hz 18W
•Fuse Rating: 2A 250V 20MM
•AC Mains supply voltage fluctuations are not to exceed +10% of the nominal voltage
•Operations temperature range -40°C to 70°C
•Maximum altitude: 3000m (9843ft)
•Equipment suitable for continuous operation
•Weight: 8.2kg (18lbs) equipment only; 10.9kg (24lbs) shipping
Important Note: Please connect your M3 to an uninterruptible power supply (UPS) to provide
other protection against power surges and brownouts.
Service"Information
The DaySequerra M3 contains no user serviceable components inside the unit. Please contact
DaySequerra for repair and upgrade information. In the event that your unit needs to be returned to the
factory, contact us for a return authorization number. The tuner ID and firmware version is momentarily
displayed at tuner start-up for your convenience. Please visit www.daysequerra.com and register
your new M3 so we can keep you informed of the latest hardware and software updates.
Introduction
The DaySequerra M3 HD RadioTM Multi-Tuner is the first broadcast quality monitor available with three
AM/FM tuners each complete with multicast capability. The M3 has been designed as the benchmark
in sensitivity (< 15.0dBf in FM) and reliability, and at the same time delivers the highest quality,
accurate monitoring of existing analog and HD RadioTM AM and FM broadcast signals (THD+N <.005%
with stereo separation >90dB for HD RadioTM FM signals).
Each of the three independent tuners in the DaySequerra M3 features an ultra low noise RF front-end
with built-in preselector and double-balanced mixer, low-jitter DAC and Class-A biased audio outputs
provide the highest fidelity reception and demodulation of HD RadioTM programs, including display of
program applicable data (PAD) for MPS and multicast signals, including Apple “Buy Button” UFID.
Its robust, modular architecture ensures that the M3 will never become obsolete. The rugged M3
chassis houses dedicated hardware RF, audio and power supply modules that, along with firmware
updates via flash programmable memory, completely anticipates the growth of new HD RadioTM
services and programming. This design approach along with our product update program ensures that
a broadcaster’s investment in a DaySequerra product will continue to pay off well into the future.
Please read this manual thoroughly before operating your M3.

M3#User#Manual#
5"
M3"Key"Features
THREE SEPARATE AM, FM AND HD RADIO™ TUNERS - dedicated vacuum florescent displays
SEPARATE AM AND FM ANTENNA INPUTS – Industry standard 75-ohm “F” connectors
DEDICATED HD LOCKED, MULTICAST AVAILABLE, DELAY SET AND TUNER ALARM
STEREO ANALOG OUTPUTS – Balanced (+4dBm) for 100% analog modulation
AES3 DIGITAL AUDIO OUTPUTS– full-time for all broadcast audio; 110-ohm transformer isolated
IEC320 POWER INLET – 120/240VAC via internal solder jumpers; integrated fuse holder
SYNTHESIZED, PUSHBUTTON TUNING – AM and FM bands including multicast channels
PRESETS – 40 preset stations per tuner
HD LOCKED –HD RadioTM audio present, indicates digital carrier SN > 58dB/Hz
DELAY BIT – Indicates active analog diversity delay for HD RadioTM broadcasts
HEADPHONE OUTPUT –high output, Class A with system processor controlled gain
DATA DISPLAY –RDS/RBDS, SIS and PSD data including Apple “Buy Button” UFID data
ALARM OUTPUTS –Six rear panel mounted assignable alarm relay contact closures for each tuner
POWER LOSS - unit returns to its previous state after momentary power loss
M3"Technical"Specifications
RF TUNING RANGE AM – 520kHz to 1720kHz in 10kHz increments
FM – 87.9MHz to 108.1MHz in 200kHz increments!
RF USEABLE SENSITIVITY AM – 30dBf for –20dB SNR @ 30% modulation
FM – 15dBf for –30dB SNR @ 100% modulation
IF REJECTION AM – greater than 100dB for –20dB SNR
FM – greater than 100dB for –30dB SNR !
AF BANDWIDTH AM – + 1dB 40Hz to 15kHz
FM – + 1dB 20Hz to 20kHz !
AF THD+N < 0.005% (digital audio)
!
STEREO CHANNEL SEPARATION > 90dB (digital audio)
!
HD RadioTM HYBRID ACQUISITION < 4.5 seconds
HD RadioTM BLEND LEVEL ACCURACY < 0.5dB!
!
HD RadioTM PAD DATA DISPLAY Station long and short name, program type, song title,
artist, album, genre and comment fields limited to a total of
1018 bytes per message per iBiquity specifications; Apple
“Buy Button” UFID

6"
M3#User#Manual#
Unpacking"and"Installing"the"M3
Immediately upon receiving your M3, please make a careful inspection for any shipping damage. If
damage is found or suspected, please notify the carrier at once and then contact your dealer.! ! The
DaySequerra M3 is shipped in one carton, which contains: the M3 unit, an AC power cable and this
User Manual.
We strongly encourage you to save the shipping carton and shipping materials supplied with your M3.
They are specially designed to properly protect your M3, and in the event that you need to return it for
service, only these OEM shipping materials can ensure its safe return to our factory.
We provide a limited 1-year warranty on all of our products, but if you don’t register your unit, it’s hard
for us to help you if and when help becomes necessary. So please take a few minutes to complete
the warranty registration form on our web site, www.daysequerra.com. Thank you!
Rack Mount Installation. The M3 chassis has four rack mounting holes in its chassis and has been
designed to fit in a 19” standard 2RU space. Plastic ‘finishing’ washers are recommended to protect
the painted finish around the mounting holes.
Power Connection. The AC power cable supplied with M3 must be connected from the M3’s IEC320
power entry module to an AC mains outlet with a functional earth ground connection. The M3 has been
set at the factory to operate at 120VAC unless otherwise specified on the shipping carton. Please
connect your M3 to an uninterruptible power supply (UPS) to protect against power surges and
brownouts.
Audio Output Connections. Balanced analog audio outputs are on male XLR connectors on the M3
rear panel with pin 1 GND, pin 2 HIGH (non-inverting) and pin 3 LOW (inverting).
The M3 digital audio output is transformer isolated in AES consumer format on a male XLR connector
on the rear panel with pin 1 XFMR, pin 2 XFMR and pin 3 GND.
Front"Panel"Controls"and"Indicators
The M3 front panel consists of three independent HD RadioTM tuner areas, with each area containing
the following ‘dedicated’ controls and displays: VFD, 4 indicator LED’s and 3 control pushbuttons. The
front panel also contains two ‘shared’ switch panels, each consisting of 5 indicator LED’s and 5 control
pushbuttons for directing commands to one of the M3’s three individual tuners based on the Tuner 1, 2,
3 switch selection. The functions of ‘dedicated’ and ‘shared’ controls and displays are described below.
Dedicated Controls and Displays
The following controls and displays are ‘dedicated’ to their respective tuner as defined on the M3 front
panel.
Vacuum florescent display (VFD) – Multi-function display that indicates current tuner band,
frequency, mode, HD RadioTM SIS and PAD data, and RDS/RBDS data from analog FM broadcasts.
Also used to display Mode Service, Forcing and Data Display menus.

M3#User#Manual#
7"
UP and DN –For manual AM and FM tuning in TUNER BAND mode and scrolling through PRESETS
in PRESETS mode. Also used to navigate Mode Service, Forcing and Data Display menus, as
described below.
SELECT – Multi-function switch for selecting multicast tuning, storing PRESETS and controlling other
tuner functions, as described herein.
HD LOCKED – Blue LED indicator illuminates when tuner has acquired OFDM portion of an HD
RadioTM signal and digital carrier SN is > 58dB/Hz, thereby permitting HD RadioTM digital audio to be
valid.
MULTICAST – Blue LED indicator illuminates when tuner has acquired OFDM of an HD RadioTM signal
and there is at least one multicast signal present, i.e., HD-2 through HD-8.
DELAY SET – Blue LED indicator illuminates when tuner has acquired OFDM of an HD RadioTM MPS
signal and the analog diversity delay is active. The LED is off when there is no delay bit set, i.e. “ball
game mode” meaning that the analog program has not been delayed to be coincident with the HD
RadioTM MPS signal.
TUNER ALARM – Red LED indicator identifies a detected alarm condition in any tuner module.
It is solid when any alarm on the selected tuner has been enabled. When an alarm condition occurs,
the tuner module’s LED flashes, the beeper beeps and the appropriate rear panel contact closes.
M3 Front Panel Layout
""
HEADPHONES. Headphone stereo output is via a recessed front panel mounted mini-TRS jack.
Pressing and holding the MODE – SERVICE button will allow you to access the headphone output
adjustment screen. The up and down buttons will adjust your headphone output accordingly. When
desirable level is set, press SELECT to save your settings and exit the menu. Default set at the factory
is 50mV.

8"
M3#User#Manual#
Shared Controls and Displays
The following controls and displays are ‘shared’ among the three tuner module based on the Tuner 1,
2, 3 switch selection.
TUNER 1, 2, 3 – Selects the tuner module to receive front panel switch activity via the system
processor and bus.
ALARM SETUP - A momentary push of this switch enables the alarm setup menu in the selected tuner
module’s VFD. Hold this switch for 5 seconds to arm the alarms as configured in the alarm setup
menu.
CLEAR ALARMS -A momentary push of this switch clears all active alarms for the selected tuner
module. The Alarm LED then goes back to solid, the beeper stops and the rear panel contact opens.
Hold this switch for 5 seconds to disarm the alarms as configured in the alarm setup menu.
TUNER BAND – Selects manual AM and FM tuning for the selected tuner module; tune using the
dedicated UP and DN controls. Blue arrow LED illuminates when mode is active.
PRESETS – Each tuner module has capability to recall 20 stored AM stations and 20 stored FM
stations – for a total of 120 stations. PRESETS control selects PRESETS mode for the selected tuner
module; scroll through stored stations using the dedicated UP and DN controls. Blue arrow LED
illuminates when tuner is in PRESETS mode. When in PRESETS mode, second momentary push of
PRESETS switch toggles between AM and FM stored presets.
MODE - SERVICE – Momentary push activates MODE – SERVICE menu. Blue arrow LED illuminates
only when switch is being pushed, or when MODE – SERVICE menu is active. In any active mode,
second momentary push of MODE – SERVICE at any time clears mode. The MODE – SERVICE menu
options are MODE, SERVICE and DIAGNOSTICS.
FORCING – The FORCING control is used to setup the forcing state of the selected tuner module.
Blue arrow LED illuminates only when switch is being pushed, or when FORCING menu is active. The
FORCING menu contains three options: Forced Analog, Forced Digital and A-D Split; options are
dependent on the type of broadcast being received, i.e., HD-1, multicast HD-2 through HD-8, or analog,
as described below. In any active mode, second momentary push of FORCING control at any time
clears mode.
DATA - DISPLAY and DATA - DISPLAY Menu – Selects decoded RDS/RBDS from an analog FM
broadcast and PSD messages from an HD RadioTM broadcast for display on the second line of the
VFD. Momentary push DATA - DISPLAY switch scrolls display through each RDS/RBDS and HD
RadioTM PSD message data field, as described below.

M3#User#Manual#
9"
Press and hold DATA - DISPLAY switch for 5 seconds to activate DATA - DISPLAY menu. The
firmware version, e.g., “v4.0.9 A3.2.1” is displayed for 5 seconds before displaying the first menu
option. The menu’s first selection enables or disables “Scrolling Data” mode where tuner displays each
RDS/RBDS and HD RadioTM PSD message data field for approximately 5 seconds before scrolling to
the next field. UP or DN switches toggle the setting; pressing “SELECT” saves the setting and
increments the menu to the next field. The second menu field enables or disables “Audio Muting.” Next
press of “SELECT” saves the setting and exits the menu. Blue arrow LED illuminates only when switch
is being pushed, or when DATA - DISPLAY menu is active. Default is AUTO mode with station short
name to be displayed in second line of VFD when tuned to an HD RadioTM station.
Rear Panel Controls and Connectors
The rear panel consists of three HD RadioTM tuner module areas, with each area containing the
following for each HD Radio™ tuner module: separate AM and FM antenna inputs, balanced analog
stereo audio outputs at +4dBV on XLR connectors, transformer-isolated digital audio output on XLR
connector—44.1kHz, 16-bit that provides full-time digital audio output for all broadcasts (5.1 surround
sound capable), and a DB15 connector with access to six assignable alarm relay contact closures.
The rear panel also contains a master AC power switch, an IEC320 power inlet with integrated fuse
holder, and an RJ-45 connector or ‘network port’ that will initially be used for re-programming the
system processor. A 120/240VAC input voltage selector is located on the bottom of the unit directly
underneath the power inlet.
M3 Rear Panel Layout

10"
M3#User#Manual#
M3 Operating Description
Power-up and Standby. The power switch is located on the rear panel of the M3; when switched on,
the tuner displays the hardware and software version of the M3 to be displayed for 3 seconds on Tuner
1’s VFD.
If rear panel AC switch is turned off or if the power is momentarily interrupted, all tuner modules and M3
control/status returns to its previous state.
Front Panel Locked. With any of the tuner modules in any mode, if the Tuner 1 switch is depressed
for 5 seconds, entire M3 goes into Front Panel Locked mode, i.e., all front panel controls are inhibited
except for Tuner 1 switch; all VFD indications, analog and digital audio outputs and PLM alarm
monitoring continue. Blue arrow LED adjacent to Tuner 1 switch flashes indicating Front Panel Locked
mode.
Momentary push of any front panel control causes Tuner 1 VFD to display FRONT PANEL LOCKED for
10 seconds then returning to its normal display for tuned station. Depressing the Tuner 1 switch for 5
seconds while M3 is in Front Panel Locked mode re-enbles all front panel controls and indicators, and
returns M3 and all tuner modules to normal operation. Tuner 1 VFD displays “Exiting Front Panel
Locked Mode” message during M3 state transition.
TUNER BAND Control. TUNER BAND control toggles between manual AM and FM tuning for the
selected tuner module based on the Tuner 1, 2, 3 switch selection. TUNER BAND arrow LED
illuminates when mode is active.
HD RadioTM AM – VFD Sample Display for WATT-AM in TUNER BAND mode
A
M
5
3
0
H
D
-
1
A
U
T
O
W
A
T
T
-
A
M
HD RadioTM FM – VFD Sample Display for WATT-FM in TUNER BAND mode
F
M
1
0
8
.
3
H
D
-
1
A
U
T
O
W
A
T
T
-
F
M
UP. Momentary push of UP control on each tuner module tunes frequency up one increment in TUNER
BAND mode, when held for three seconds, it tunes faster. UP selects next higher stored preset station
in PRESETS mode (no faster mode, one push per preset). Inter-station audio muting is active while
tuning. Selects next item in other menus and is used for other functions as described herein.
DN. Momentary push of DN control on each tuner module tunes frequency down one increment in
TUNER BAND mode, when held for three seconds, it tunes faster. DN selects next lower stored preset
station in PRESETS mode (no faster mode, one push per preset). Inter-station audio muting is active
while tuning. Selects next item in other menus and is used for other functions as described herein.

M3#User#Manual#
11"
SELECT Control.When tuned to an HD RadioTM HD-1 signal and at least one multicast broadcast is
present, i.e., HD-2 through HD-8, momentarily depressing the SELECT switch puts tuner into multicast
tuning mode, and automatically tunes the tuner module to the first multicast broadcast available. Use
the UP control to scroll through all of the multicast stations available. Use the DN control to exit
multicast tuning mode and re-tune to the HD-1 signal.
When selected tuner module has acquired any station in TUNER BAND mode and SELECT switch is
held for three seconds, tuner goes into PRESETS store mode; PRESETS arrow LED flashes. UP and
DN controls then allow user to scroll through the previously stored stations in positions A1 through A20
or F1 through F20, dependant on band. Inter-station audio muting is active while tuning between
preset stations. Next momentary push of SELECT switch stores selected station in that PRESETS
position.
PRESETS Control. In PRESETS tuning mode, the tuner has the capability to store 20 AM stations
and 20 FM stations per tuner module – for a total of 120 stations.
Preset stations are stored for recall in positions A1 through A20 and F1 through F20 respectively for
AM and FM bands. When selected tuner module is in TUNER BAND mode and PRESETS switch is
momentarily depressed, tuner goes into PRESETS mode; PRESETS Arrow LED will illuminate when
the tuner is in PRESETS tuning mode. UP and DN scroll through the preset stations stored for the
band selected. Second momentary push of PRESETS switch toggles between AM and FM tuner
bands. To switch out of PRESETS mode and select manual tuning, momentarily depress TUNER
BAND switch.
HD RadioTM AM - VFD Sample Display for WATT-AM stored in preset position A9
A
9
5
3
0
H
D
-
1
A
U
T
O
W
A
T
T
-
A
M
HD RadioTM FM - VFD Sample Display for WATT-FM stored in preset position F2
F
2
1
0
8
.
3
H
D
-
1
A
U
T
O
W
A
T
T
-
F
M
MODE - SERVICE – Momentary push activates MODE – SERVICE menu. Blue arrow LED illuminates
only when switch is being pushed, or when MODE – SERVICE menu is active. In any active mode,
second push of MODE – SERVICE at any time clears mode. Use the UP or DOWN switches to change
the selection and press SELECT to enable the selection.

12"
M3#User#Manual#
The MODE – SERVICE menu options are MODE, SERVICE and DIAGNOSTICS outlined as follows:
M
O
D
E
-
S
E
R
V
I
C
E
<
M
O
D
E
>
•Selecting MODE activates the MODE option to display the HD RadioTM broadcast’s Service
Mode and MPA Codec Mode.
Service Mode - Displays the current Service Mode being broadcast. Valid Service Modes are
MP1 or MP5 or MP6 for FM and MA1 or MA3 for AM.
MPA Codec Mode - Displays the MPA Codec mode if digital audio was acquired. Valid MPA
Codec Mode values are 0-3.
Sample Broadcast MODE VFD Display
S
E
R
V
I
C
E
M
O
D
E
M
P
1
M
P
A
C
O
D
E
C
M
O
D
E
2
•Use UP, DOWN or SELECT to exit MODE display and return to MODE – SERVICE menu;
second push of MODE – SERVICE at any time clears mode.
M
O
D
E
-
S
E
R
V
I
C
E
<
S
E
R
V
I
C
E
>
•Selecting SERVICE activates the SERVICE option to display the HD RadioTM broadcaster’s
Country Code and FCC Facility ID Code.
Country Code - The broadcaster’s Country Code is displayed. Valid Country Codes are 2-digit
numerical values.
FCC Facility ID Code - The broadcaster’s FCC Facility ID Code is displayed. Valid FCC Facility
ID Codes are 2-digit numerical values.
Sample Broadcast SERVICE VFD Display
C
O
U
N
T
R
Y
C
O
D
E
1
0
F
C
C
I
D
C
O
D
E
2
2
•Use UP, DOWN or SELECT to exit SERVICE display and return to MODE – SERVICE menu;
second push of MODE – SERVICE at any time clears mode.
M
O
D
E
-
S
E
R
V
I
C
E
D
I
A
G
N
O
S
T
I
C
S
>
N
E
X
T

M3#User#Manual#
13"
•Selecting DIAGNOSTICS activates the DIAGNOSTICS option to display the HD RadioTM
broadcast parameters described below as well as initiate collection of bit-error rate and block-
error rate when a BER-BLER test vector is being broadcast.
M
O
D
E
-
S
E
R
V
I
C
E
<
D
I
A
G
N
O
S
T
I
C
S
>
•Carrier-to-noise ratio and signal-to-interference ratio values are displayed on first
DIAGNOSTICS screen.
Sample First DIAGNOSTICS Option VFD Display
C
A
R
R
-
N
O
I
S
E
8
9
D
B
S
I
G
N
A
L
-
I
N
T
7
6
D
B
Carrier-to-Noise Ratio (Cd/N0) - Displays the carrier-to-noise ratio, where Cd refers to the total
power in both digital sidebands, and N0 refers to the noise spectral density. This measurement
is calculated in a 1 Hz bandwidth.
Signal-to-Interference Ratio - Displays the signal-to-interference ratio in dB.
•Momentary push of UP scrolls to next DIAGNOSTICS screen that displays audio signal-to-noise
and QI values.
Sample Second DIAGNOSTICS Option VFD Display
S
I
G
-
N
O
I
S
E
7
6
D
B
Q
I
V
A
L
U
E
1
5
Signal-to-Noise Ratio - Displays the audio signal-to-noise ratio in dB.
QI Value - Displays the quality of the HD RadioTM digital audio signal in a range from 0-15. A
value of 15 represents the highest audio quality.
•Momentary push of UP scrolls to next DIAGNOSTICS screen that can initiate Bit Error Rate
Mode. Push SELECT to enter Bit Error Rate Mode.
B
E
R
-
B
L
E
R
T
E
S
T
S
<
E
N
T
E
R
>

14"
M3#User#Manual#
•When the HD RadioTM broadcast exciter is put into Bit Error Rate Mode and a special test vector
is being broadcast, the Channel Error window displays bit error rate information for P1, P2, P3
logical channels and block error rate information on the PIDS logical channel.
Sample BER-BLER VFD Display
B
I
T
E
R
R
O
R
3
E
-
5
B
L
O
C
K
E
R
R
O
R
7
E
-
8
•When HD RadioTM digital audio is being broadcast and BER-BLER TESTS have been selected,
the Channel Error will display NA (Not Available) as shown below.
B
I
T
E
R
R
O
R
N
A
B
L
O
C
K
E
R
R
O
R
N
A
•Next momentary push of UP, DN or SELECT scrolls to root MODE – SERVICE menu.
M
O
D
E
-
S
E
R
V
I
C
E
<
M
O
D
E
>
M
O
D
E
-
S
E
R
V
I
C
E
<
S
E
R
V
I
C
E
>
M
O
D
E
-
S
E
R
V
I
C
E
<
D
I
A
G
N
O
S
T
I
C
S
>
•Momentary push of MODE – SERVICE at any time clears mode.
Forcing Control. The FORCING control is used to setup the forcing state of the Selected Tuner
Module. Blue arrow LED illuminates only when switch is being pushed, or when FORCING menu is
active. The forcing options are dependent on the current tuner setting HD-1, Multicast or Analog
station. If tuned to an analog station, first press of the FORCING switch displays the IBOC FILTER
menu.
I
B
O
C
F
I
L
T
E
R
O
N
<
O
F
F
•Use the UP or DOWN switches to change the selection and then press SELECT to set 5kHz
IBOC filter ON or OFF permitting full 10kHz AM audio bandwidth.
Exit the FORCING mode or FORCING menu at any time by pressing FORCING switch.

M3#User#Manual#
15"
The first press of the FORCING switch when tuned to an HD-1 displays the A-D SPLIT Forcing menu.
Exit the FORCING mode or FORCING menu at any time by pressing FORCING switch.
F
O
R
C
I
N
G
M
E
N
U
<
A
D
S
P
L
I
T
>
Use the UP or DOWN switches to change the selection and press SELECT to set the Forcing mode. If
SELECT is pressed when AD SPLIT is selected, the A-D Split mode is enabled and the display
changes to the following:
Sample A-D Split VFD Display
F
M
1
0
8
.
3
H
D
-
1
A
D
S
P
L
I
T
W
A
T
T
-
F
M
•To exit AD SPLIT press FORCING menu. Press FORCING menu again to reenter menu. To
change the selections use the UP or DN scrolls.
•If SELECT is pressed when ANALOG is selected, the Forced Analog mode is entered and the
display changes to the following:
Sample Forced Analog Display
F
M
1
0
8
.
3
S
T
A
N
A
L
O
G
W
A
T
T
-
F
M
•To exit AD SPLIT press FORCING menu to return to menu.
•Use the UP and DN scrolls to change the selection.
Sample Forced Digital Display
F
M
1
0
8
.
3
H
D
-
1
D
I
G
I
T
A
L
W
A
T
T
-
F
M
•In A-D SPLIT mode, the analog audio outputs have an analog audio signal in the left channel
and a digital audio signal in the right channel.
Subsequent momentary push of FORCING switch turns FORCING mode and FORCING LED off.
Default mode is off.

16"
M3#User#Manual#
DATA - DISPLAY Menu – Press the DATA - DISPLAY switch in for 5 seconds to activate the DATA -
DISPLAY menu. The firmware version, e.g., “V3.2.0 A3.5.0” is displayed for 5 seconds before
displaying the first menu option. Blue arrow LED illuminates only when switch is being pushed, or when
DATA - DISPLAY menu is active. Exit the DATA - DISPLAY menu at any time by pressing DATA -
DISPLAY switch. If SELECT is momentarily pressed during the firmware version display menu scrolls
to DATA - DISPLAY menu’s first selection.
Sample Firmware Version Display
D
A
Y
S
E
Q
U
E
R
R
A
V
3
.
2
.
0
A
3
.
5
.
0
The DATA - DISPLAY menu’s first selection enables or disables “Scroll All Data” mode when tuner
displays each RBDS or HD RadioTM PAD message data field for approximately 5 seconds before
scrolling to the next field. UP or DN switches toggle the setting; pressing “SELECT” saves the setting
and increments the menu to the next field.
S
C
R
O
L
L
A
L
L
D
A
T
A
<
O
N
>
The M3’s audio output can be set to automatically mute for received signals with RF signal strength
less than 45dBf. The second DATA - DISPLAY menu field enables or disables this “Audio Muting”
feature. UP or DN switches toggle the setting; pressing “SELECT” saves the setting and increments the
menu to the next field.
A
U
D
I
O
M
U
T
I
N
G
<
O
N
>
Subsequent momentary push of DATA - DISPLAY switch turns DATA - DISPLAY menu and DATA -
DISPLAY LED off. Default mode is off.
DATA – DISPLAY.DATA - DISPLAY control selects how decoded RDS/RBDS from an analog FM
broadcast and PAD messages from an HD RadioTM broadcast will be displayed on the second line of
the VFD. Blue arrow LED illuminates only when switch is being pushed, when DATA - DISPLAY menu
is active, or when DATA - DISPLAY mode is active. Exit the DATA - DISPLAY mode at any time by
pressing DATA - DISPLAY switch.
When tuned to an HD RadioTM station, default DATA - DISPLAY setting is off with station short name to
be displayed in second line of VFD. Each subsequent momentary push of SELECT switch scrolls
through each PAD field in the following sequence:
•Station long name
•Station program type
•Song title
•Artist

M3#User#Manual#
17"
•Album
•Genre
•URL
•ID
•Comment
•Commercial
Sample PAD Song Title Field Display
F
M
9
5
.
7
H
D
-
1
W
H
Y
C
A
N
‘
T
T
H
I
S
B
Subsequent momentary push of DATA - DISPLAY switch turns DATA - DISPLAY mode and DATA -
DISPLAY LED off. VFD display second line scrolls if PAD field is longer than 16 characters. If there is
no data for the selected field, VFD displays “NO” plus the data category, e.g., “NO ALBUM DATA.”
If “Scroll All Data” mode is enabled in DATA - DISPLAY menu, as described above, tuner displays each
HD RadioTM PAD message data field for approximately 5 seconds before scrolling to the next PAD data
field.
The PAD UFID (unique file identifier) contains a hierarchal encoding of “Buy Button” or song purchase
information. Each UFID frame consists of two components: an owner identifier in the form of a URL
(uniform resources locator) and an ID (purchase identifier). The URL will be displayed as an internet
URL, e.g., www.itunes.com. The ID component contains the purchase identifier according to the
specific encoding format defined for that owner.
Station long name, station short name and program type are processed as an ID3 tag. HD RadioTM
PSD message, i.e., song title, artist, album, genre, comment, commercial and UFID “Buy Button” fields
are limited to 127 bytes each for a total of 1018 bytes per message per iBiquity specifications. For
more information on ID3 tags and PSD messages, please visit www.ibiquity.com and www.id3.org.
When an HD RadioTM FM broadcast is forced to analog using the Forced Analog option in the
FORCING menu, the default DATA - DISPLAY setting is off with the RBDS program information field,
most often the station short name, to be displayed in second line of VFD. Each subsequent momentary
push of SELECT switch scrolls through each RBDS field in the following sequence:
•Program Type (PT)
•Program Identification (PI)
•Radio Text (RT)
Subsequent momentary push of DATA - DISPLAY switch turns DATA - DISPLAY mode and DATA -
DISPLAY LED off. VFD display second line scrolls if RBDS field is longer than 16 characters. If there
is no data for the selected field, VFD displays “NO” plus the data category, e.g., “NO RT DATA.”
If “Scroll All Data” mode is enabled in DATA - DISPLAY menu, as described above, tuner displays each
RBDS data field for approximately 5 seconds before scrolling to the next RBDS data field.

18"
M3#User#Manual#
Performance Loss Monitor
Performance Loss Monitor (PLM) Connections – The PLM provides Normally Open opto-isolated
alarm outputs on a rear panel mounted DB15 connector to report selected alarm conditions, including
loss of RF carrier, program audio, OFDM lock and PAD data on each Tuner Module. The following lists
the DB15 pin-outs. Relay contacts are rated at 10mA @ 24VDC.
Alarm on Loss of
+ Contact
- Contact
RF Carrier
1
2
Audio
3
4
OFDM Lock
5
6
RBDS
7
8
PAD Data
9
10
MC-Avail or Delay
11
12
Alarm Configuration Menu – After selecting the desired tuner, press the ALARM SETUP switch to
activate the Alarm Configuration Menu. VFD displays ALARM CONFIG with “ENABLE” and “SETUP”
options. Select desired option using UP and DN switches to toggle the setting. Select “ENABLE” to arm
all alarms as previously configured and exit Alarm Configuration Menu; select “SETUP” to continue with
alarm configuration menu. Press “SELECT” to increment the menu to the next alarm function. Exit the
Alarm Configuration Menu at any time by pressing ALARM SETUP switch.
A
L
A
R
M
C
O
N
F
I
G
E
N
A
B
L
E
<
>
S
E
T
U
P
All Alarms
•Select “ON” to activate all alarms at the minimum threshold with the minimum alarm delay.
Select “OFF” to set all alarms to off; select “SETUP” option to continue with alarm configuration
menu. Use UP and DN switches to toggle the setting.
•Push “SELECT” switch to increment the menu to the next alarm function.
A
L
L
A
L
A
R
M
S
O
N
O
F
F
>
S
E
T
U
P
<

M3#User#Manual#
19"
Alarm Output 1 – RF Carrier Loss (alarm based on analog RF signal strength)
•Highlight desired “SET” or “OFF” option using UP and DN switches to toggle the
setting. Select “SET” to set this tuner alarm and continue with alarm configuration
menu; select “OFF” to set this tuner alarm function to off. Push “SELECT” to
continue.
R
F
C
A
R
R
I
E
R
L
O
S
S
>
S
E
T
<
O
F
F
•If “SET” is selected, submenu for “Level” threshold with “LOW”, “MED” and “HIGH”
options is displayed next. “LOW” option sets RF carrier loss threshold for
approximately 10µV (25dBf); “MED” option sets RF carrier loss threshold for
approximately 100µV (45dBf); and “HIGH” option sets RF carrier loss threshold for
approximately 3KµV (75dBf). Use UP and DN switches to toggle the setting and
highlight the desired option.
R
F
C
A
R
R
I
E
R
L
E
V
E
L
L
O
W
>
M
E
D
<
H
I
G
H
Push “SELECT” switch to increment the menu to the next alarm function.
•Submenu for “Alarm Delay” with “30”, “60”, “120” and “240” second options is
displayed next. Use UP and DN switches to toggle the setting and highlight the
desired option.
A
L
A
R
M
D
E
L
A
Y
3
0
>
6
0
<
1
2
0
2
4
0
S
Push “SELECT” switch to increment the menu to the next alarm function.
Alarm Output 2 – Audio Loss (Silence Detect)
•Highlight desired “SET” or “OFF” option using UP and DN switches to toggle the
setting. Select “SET” to set this tuner alarm and continue with alarm configuration
menu; select “OFF” to set this tuner alarm function to off.
Push “SELECT” to continue.
A
U
D
I
O
L
O
S
S
>
S
E
T
<
O
F
F

20"
M3#User#Manual#
•If “SET” is selected, submenu for “Level” threshold with “LOW”, “MED” and “HIGH”
options is displayed next. “LOW” option sets audio loss threshold for approximately
-60dB; “MED” option sets audio loss threshold for approximately -40dB; and “HIGH”
option sets audio loss threshold for approximately -20dB. Use UP and DN switches
to toggle the setting and highlight the desired option. Push “SELECT” switch to
continue.
A
U
D
I
O
L
E
V
E
L
L
O
W
>
M
E
D
<
H
I
G
H
•Submenu for “Alarm Delay” with “30”, “60”, “120” and “240” second options is
displayed next. Use UP and DN switches to toggle the setting and highlight the
desired option.
A
L
A
R
M
D
E
L
A
Y
3
0
>
6
0
<
1
2
0
2
4
0
S
Push “SELECT” switch to save and increment the menu to the next alarm function.
Alarm Output 3 – OFDM Lock Loss (HD RadioTM modem lock)
•Highlight desired “SET” or “OFF” option using UP and DN switches to toggle the
setting. Select “SET” to set this tuner alarm and continue with alarm configuration
menu; select “OFF” to set this tuner alarm function to off. Push “SELECT” to
continue.
O
F
D
M
L
O
C
K
L
O
S
S
>
S
E
T
<
O
F
F
•If “SET” is selected, submenu for “Alarm Delay” with “30”, “60”, “120” and “240”
second options is displayed next. Use UP and DN switches to toggle the setting and
highlight the desired option.
A
L
A
R
M
D
E
L
A
Y
3
0
>
6
0
<
1
2
0
2
4
0
S
Push “SELECT” switch to save and increment the menu to the next alarm function.
