DAYTEK HOMEBUILDER User manual

v1.0
CAUTION! –INFLATE TYRE WITH CARE. DO NOT EXCEED RECOMMENDED
PRESSURE. ENSURE SQUARE NECK OF BOLTS ARE LOCATED IN BOWL
DURING ASSEMBLY.
TIP –PLACE STRONG TAPE OVER THE HEAD OF THE BOLTS TO HOLD THEM
IN POSITION DURING ASSEMBLY. USE A MALLET TO KNOCK COMPONENTS
INTO POSITION IF NEEDED.
1. PLACE WHEELBARROW BOWL UPSIDE DOWN OVER A BENCH OR TABLE EDGE.
2. ASSEMBLE HANDLES “A” INTO FRONT FRAME “B” AS PER DIAGRAM. LOCATE ASSEMBLY OVER THE HOLES IN THE
BOWL. INSERT 2 x LONG BOLTS FROM INSIDE THE BOWL AT POSITION 1 AND FINGER TIGHTEN WITH WASHERS & NUTS.
3. ASSEMBLE LEGS “C” TOGETHER IN A CROSS-PATTERN AT POSITION 2 WITH 1 x SHORT BOLT AND FINGER TIGHTEN
WITH WASHER & NUT.
4. LOCATE THE LEGS OVER THE BOWL AS SHOWN AND FIX WITH 4 x LONG BOLTS AT POSITION 3 & 4. FINGER TIGHTEN
WITH WASHERS & NUTS.
5. ASSEMBLE THE 2 STRUTS “D” TO THE FRONT OF THE BOWL AND FINGER TIGHTEN ONLY.
B
BOWL
WHEEL
Cx2
Ax2
Dx2
AXLE x1
AXLE SPACER
x2
AXLE
BRACKET
x2
x8
x3
X11
X11

v1.0
FITTING THE WHEEL
6. INSERT AXLE THROUGH THE WHEEL HUB.
7. SLIDE AXLE SPACER OVER EACH END OF AXLE. ENSURE AXLE AND SPACER ARE POSITIONED CENTRAL IN THE HUB.
8. LOCATE ONE AXLE BRACKET AT POSITION 5 ON FRONT FRAME “B”. INSERT 1 x LONG BOLT THROUGH STRUT, AXLE
BRACKET AND FRAME. TIGHTEN WITH WASHER & NUT AS SHOWN IN DIAGRAM BELOW.
9. INSERT ONE END OF AXLE AND WHEEL ASSEMBLY INTO THE AXLE BRACKET. ENSURE THE FLAT EDGE ALIGNS WITH
THE FORM OF THE AXLE BRACKET.
10.SLIDE THE SECOND AXLE BRACKET INTO POSITION ON THE OTHER SIDE OF THE FRAME. ALIGN THE AXLE TO ENSURE
IT SLOTS INTO POSITION AT THE SAME TIME.
11. SECURE STRUT, AXLE BRACKET AND FRAME WITH 1 x LONG BOLT AND TIGHTEN WITH WASHER & NUT.
12. CHECK OVER ENTIRE ASSEMBLY, FULLY TIGHTEN ALL BOLTS AND ENSURE THAT THE WHEEL IS FREE TO SPIN.
