Caddytek Explorer V2 User manual

The Explorer V2
User’s Manual

CaddyTek Inc.
20175 S. Atlantic Blvd., # C
Monterey Park, CA 9175 , USA
www.caddytek.net

WARNING:
FOR YOUR OWN SAFETY, PLEASE REVIEW THESE WARNINGS AND
KEEP THIS USER GUIDE FOR FUTURE REFERENCE.
●Before using this golf cart, please read and understand the important
instructions and warnings in this user guide.
●AVOID INJURY by always following the instructions carefully.
●AVOID INJURY by keeping clear of moving parts while adjusting, folding
or unfolding this cart.
●ALWAYS make sure the cart is fully extended and locked before use.
●ALWAYS make sure the cart is folded and locked properly before lifting or
transporting.
●ALWAYS use the brake when parking the cart.
●DO NOT run while using this cart.
●DO NOT use accessories other than those designed specifically for this
cart.
●Keep hands and fingers away from moving parts or sliding sections of the
cart.

Package contents:
1. The main frame with two front wheels (9.5 ‘’)
2. Two rear wheels (10.5 ‘’)
3. Umbrella holder
. Drink holder
5. This user’s manual
6. Tools for adjustment
In case any of the above items are missing or damaged, please call 800-906-6918 or email
service [email protected] to report.
Part Identification:
A: TPE handle
B: Handle frame
C. Scorecard holder assembly
D: Umbrella holder base
E: Upper bag holder bracket assembly
F: Handle frame locking assembly
G: Main frame
H: Leg frame bracket
I: Sub-connecting rods
J: holes leg frame
K: 2 holes leg frame
L: Front wheel frame locking assembly
M: Right stabilization bar
M1: Left stabilization bar
N: Supporting cable
O: Right rear wheel axel holder
O1: Left rear wheel axel holder
P: Foot brake assembly
Q: Front wheel frame
R: Rear wheel assembly
S: Lower bag holder bracket assembly
T: Front wheel
U: Umbrella holder
V: Handle mesh net
W: Drink holder
X: Elastic strap assembly

Asse ble and Extend the cart
+
Extend the upper bag holder
bracket as shown in Fig. 1
Hold the upper bag holder and the
handle frame with hands as
shown in Fig. 3
Fig. 1 Fig. 2
Frame locking
buckles
Release handle and front wheel
frame locking buckles as shown
above Fig.2.
Pull the handle frame upward to fully extend the handle frame as in Fig. and Fig. 5, and lock the locking
buckle as in Fig. 6.
Extend the lower bag holder
assembly as shown in Fig 9.
Fig. 5 Fig. 6
buckle
Fig. 3
Fig.
Fig. 7
buckle
Fig. 8
buckle
Fig. 9
Fully extend front wheel frame and lock the buckle as in Fig. 7. Hold the
handle while releasing the locking buckle to adjust the handle height and
lock the buckle again as Fig. 8 shows.

Folding the cart
+
Press the button and insert the rear wheel into the wheel axel holder as shown in Fig. 10 and
Fig. 11. The cart now is ready for use as shown in Fig. 12.
Release the handle and front wheel
frame locking buckles as Fig.1 .
CAUSION: Please hold on to
the handle when releasing
the handle frame locking
buckle to avoid the frame
dropping abruptly and
causing injury.
Fig. 13 Fig. 15
Fig. 17
Holding the handle frame and
the upper bag holder bracket,
move the handle downward to
fold the cart as shown in Fig. 15.
Fold the upper bag holder as
Fig.17 shown above.
The cart now is folded completely
as Fig.18.
Fig. 1
Fold the lower bag holder
as shown above .
buckle
buckle
Handle frame locking buckle
Front wheel frame locking buckle
Button
Fig. 10
Fig. 18
Fig. 11
Fig. 12
Fig. 16
After the cart is fully folded, lock both
locking buckles as show in Fig. 16.
.

Install U brella Holder
Hole 1
To put in use:
Simply attach the umbrella holder onto the cart as
in Fig. 22 & 23.
Press the foot brake to brake,
Lift it up to release as Fig.2
Fig. 2
Fig. 22 Fig. 23
Install the drink holder
Adjust the width between front wheels
Press the button and slide the front wheel
out/in ward to adjust the width between
front wheels as Fig. 26, so that different
sizes of golf bag can be fitted on the cart.
Button
Fig. 26
Adjusting & tightening the handle
buckle
Fig. 25
Time to time, please tight the upper
connection nut with provided tool, as above
Fig. 25, to prevent lose handle and prolong the
life of the cart.
nut
Use the brake
Fixed block on base
Slot
on
Hole 2
Hole 2
When installing the drink holder as Fig.19, align the smallest part of the slot on the holder
with the fixed blocks. Then pull horizontally to fit the holder on the base as Fig.20 & 21.
Fig. 19
Fig.
20
Fig. 21

Front Wheel Align ent
Fig. 27
Left Right
Fig. 29
Hex. wrench
Alignment adjusting screws A/B
If the cart veers to the left, please use the hex wrench to turn screw A counterclockwise and
Screw B clockwise to adjust the alignment.
If the cart veers to the right, please use the hex wrench to turn screw A clockwise and
screw B counterclockwise to adjust the alignment.
Fig. 28
A
B
Right
Left
T
o
open the
scorecard holder cover
Press the button to open the scorecard holder cover as Fig. 30
Fig. 30
button

WARRANTY
CaddyTek Inc. warrants its products to be free of defects and workmanship for one year
from the date of purchase. We will either repair or replace defective products at our option.
Normal wear and fading of products is not considered a manufacturer's defect. This
warranty does not apply to claim of damage to items used in connection with CaddyTek Inc.
products. In the case of deterioration due to normal use we will repair the item for a
nominal charge. CaddyTek Inc. is the sole judge of any claim or warranty.
For customers in the North American, please contact CaddyTek Inc. for the service. For
customers outside of North American, please either contact with your dealer for the
warranty service or you are welcome to contact CaddyTek Inc. directly.

6
PRODUCT REGISTRATION
I have read and understand this product's operation and warranty, and wish to record
my purchase:
Model:______________________________
Name(Mr./Mrs./Ms):________________________________
Address:______________________________________________
City:______________ Province:____________ Postal Code:______________
Tel:____________ Email____________________
Date of Purchase :______________Name of Store/Dealer:__________________
Round of Golf per Month:_______________ H'CAP_______________________
Signed:________________________ Date:________________________
Failure to return this card may result in delayed response to you warranty claim

Caddytek Inc.
20175 S. Atlantic Blvd., # C
Monterey Park, CA 91754
USA
You can also register your golf cart on www.caddytek.net
Stamp
