dB Technologies a2ti Manual

a2ti
420120318Q REV.1.4
QUICKSTART USER MANUAL
Section 1
PROFESSIONAL
2CH POWER
AMPLIFIER
ON
SIGNAL
LIMITER
PROTECT
-20dB
-10dB
-5dB
CH1
CH2
0dB 0dB
0
0
0
0
--
The warnings in this manual must be observed together with the "USER MANUAL - Section 2".
Le avvertenze nel presente manuale devono essere osservate congiuntamente al “MANUALE D’USO – Sezione 2”.
Die Warnungen in diesem Handbuch müssen in Verbindung mit der "BEDIENUNGSANLEITUNG - Abschnitt 2"
beobachtet werden”.
Les avertissements speciés dans ce manuel doivent être respectés ainsi que les "CARACTERISTIQUES TECH-
NIQUES -Section 2"
Las advertencias del presente manual se deben tener en cuenta conjuntamente con las del “MANUAL DEL USU-
ARIO” - Sección 2”.
A.E.B. Industriale Srl Via Brodolini, 8 Località Crespellano 40053 VALSAMOGGIA BOLOGNA (ITALIA)
Tel [phone] Fax [phone] www.dbtechnologies.com [email protected]

420120318Q REV.1.4
a2ti
REAR PANEL
FRONT PANEL
Thank you for choosing a dBTechnologies Product!
A2TI is a powerful 2 channel class D amplier (PFC and SMPS power supply) with 4- poles speakON outputs.
The user can choose between BRIDGE, PARALLEL, or STEREO MODE.
The balanced inputs, with sensitivity selector, can be linked to create a more complex ampliers network.
It can cover a wide range of applications, expecially in xed installations.
PACKING CONTENT
• A2TI amplier
• mains cable (VDE connector)
• this quickstart and warranty documentation
1. VDE connector with fuse
2. Balanced CH1 input (XLR connector) with Link output
3. Balanced CH2 input (XLR connector) with Link output
4. Sensitivity selector
5. MODE selector
6. CH1 4-poles speakON output
7. CH2 4-poles speakON output
8. CH1 level knob
9. CH2 level knob
10. CH1-CH2 meters
11. Power switch
- Lights at the action of all the protection circuits
- Lights when compression/limiter is protecting the amplier
- Lights when the output signal is around -5 dB than full power.
- Lights when the output signal is around -10 dB than full power.
- Lights when the output signal is around -20 dB than full power.
- Lights at the presence of input audio signal
- Lights when the amplier turn on
ON
SIGNAL
LIMITER
PROTECT
-20dB
-10dB
-5dB
CH1 CH2
P R O F E S S I O N A L
2 C H P O W E R
A M P L I F I E R
0dB
0
0
-0dB
0
0
-
Attention!
Touching uninsulated OUTPUT CHANNELS or bare wiring may result in an unpleasant sensation.
Don’t touch uninsulated OUTPUT CHANNELS or bare wiring when power on.

a2ti
420120318Q REV.1.4
FIRST TURN ON
• Connect the passive loudspeakers, using cables with speakON connectors (4-5 outputs), depending on
impedance, max rated power, and amplier mode. Select the amplier MODE (5).
• Connect the inputs, using balanced cables with XLR connectors (6-7 input). Select the inputs
sensitivity (4).
• If needed, link the input LINK connectors, to relaunch the signal to a second amplier.
• Set the level knobs (8, 9) to the minimum level.
• Connect the mains cable (socket 1), turn on the amplier (11).
• Adjust the level knobs (8, 9), while the audio signal comes from your source.
INPUT SENSITIVITY / OUTPUT MODE
The user can select the input sensitivity and the output mode of the amplier.
The input sensitivity can be selected from (0.775 V, 1 V, 32 dB), depending on the charaterisctics of the
source.
The amplier can operate in three different modes:
- brigde (combines two input signal into one output signal to reach a higher power rating)
- parallel (route one input signal two both the outputs)
- stereo (the default mode, CH1 input is routed in CH1 output, CH2 input is routed in CH2 output)
See the upper table and the main tech specs for a further explanation.

420120318Q REV.1.4
a2ti
MAIN TECH SPECS
Type: Class D amplier
Output Power:
8 Ω stereo* 1000 W x 2
4 Ω stereo** 1750 W x 2
8 Ω bridge** 3500 W
Frequency response: 20 Hz - 20 kHz (+0/-1dB)
Input sensitivity: 0.775 V / 1 V / 32 dB
Product dimensions (mm): 483(w) x 306.5(d) x 89(h)
Weight: 7.9 kg
Features, specication and appearance of products are subject to change without notice. dBTechnologies
reserves the right to make changes or improvements in design or manufacturing without assuming any obligation
to change or improve products previously manufactured.
Check the complete user manual on www.dbtechnologies.com for further information about the system and available
accessories.
Scan with your QR reader App to
download the complete user manual.
* The power is tested under the condition of 40ms burst,1kHz sine wave and 1% THD.
** The power is tested under the condition of 20ms burst,1kHz sine wave and 1% THD.
This product is suitable for usage up to an altitude of 2000 m.
