THE DCS REFRIGERATOR
MODEL:
RF48SS
Use and Care Manual

Its TDM cycle makes it possible to extend storage of food for longer periods.
Nano Silver Health System for antibiosis and bacteriostasis
Fresh Island:Cutting Edge Customized Temp Control System
TWIN Cooling TDM
By monitoring the states of the freezer and the fridge
compartments on a real time basis, it runs both of the
evaporators in optimal conditions and makes it
possible to maintain world best 71% of humidity in the
fridge compartment and extend storage life of food.
By nano-coating the liner surfaces (compartments and
doors) with silver, it prevents the propagation of bacteria
inside of the refrigerator making it possible to store foods
safely much longer.
■Advantages of Silver Nano-Coating
- It does not harm the human body, is nonpoisonous and
prevents the propagation of more than 650 kinds of
bacteria, viruses and fungi.
- Most of bacteria, viruses and fungi will be destroyed or
impossible to propagate by the electric force of Ag+ions.
- It is made of silver particles which are effective without the
deterioration of its antibiosis and bacteriostasis functions
for its life time.
By optimizing storage temperatures and realizing 71%
of humidity with TWIN Cooling TDM, it is
now possible to customize its storage temperatures for
various types of foods and different
purposes.
Condenser
TDM
Valve
Compr
essor
Freezer Evaporator
Fridge Evaporator
GOURMET refrigerators feature the following functions.
Elimination Rate
BRANDSOURCE IB 2007.1.19 939 AM 페이지 3 in

SAFETY PRECAUTIONS 4
NAME OF EACH COMPONENT 6
PRECAUTIONS BEFORE INSTALLATION 8
CHECKPOINTS BEFORE USE 10
CHECK THE FOLLOWING BEFORE USE.
BUTTON & DISPLAY PANEL 11
FUNCTION OF EACH BUTTON
HOW TO STORE FOOD 12
HOW TO CONTROL TEMP 14
TO ADJUST TEMPERATURES
HOW TO USE DISPENSER 16
HOW TO REPLACE WATER-PURIFYING FILTER 18
FRESH ISLAND 19
WISDOM FOR LIFE 21
HOW TO CLEAN AND TAKE CARE OF THE PRODUCT 24
CHECKPOINTS BEFORE SERVICE CALLS 27
PRODUCT SPEC 30
CONTENTS
3
PREPARATION
USAGE
OTHERS
ds.
BRANDSOURCE IB 2007.1.19 939 AM 페이지 4 in

This product operates on rated 115V.
115V
It indicates that there is possibility of
death or serious injury if the
instruction is not complied with.
It indicates that there is possibility of
personal injuries or property damage
if the instruction is not complied with.
Make sure to follow the
instructions for your safety.
The following instructions are to prevent personal injuries and property damage.
Please read all the instructions to use the product properly.
4
SAFETY PRECAUTIONS
PREPARATION
■SAFETY WARNIINGS
• Before operating the appliance, please read this manual thoroughly and retain it for your reference.
• Because these following operating instructions cover various models, the characteris of your
refrigerator may differ slightly from those described in this manual.
• The appliance is not intended for use by children or infirm persons without adult supervision.
• Children should be supervised to ensure that they do not play with the appliance.
• HFC- R134a is used as a refrigerant.
• The refrigerator only uses ice makers which are made by brandsource Electronics for the
refrigerator.
• The incorporated ice-makers are to be installed only by the manufacturer or its service agent.
CAUTION/WARNING SYMBOLS USED OTHER SYMBOLS USED
WARNINGS
Do not plug several appliances into the same multiple
power board.
• This could cause overheating and the risk of fire.
Make sure that the power plug is not squashed or dam-
aged by the back of the refrigerator .
• A damaged power plug may overheat and cause fire.
Do not bend the power cord excessively or place heavy
articles on it .
• This constitutes a fire hazard. If the power cord is
damaged, have it replaced immediately by the
manufacturer or its service agent.
Do not directly spray water inside or outside the refrigerator.
• There is a risk of fire or electric shock.
Do not spray inflamable gas near the refrigerator.
• There is a risk of explosion or fire.
Do not insert the power plug with wet hands.
• You may receive an electric shock.
Do not put a container filled with water on the
refrigerator.
• If spilled, there is a risk of fire or electric shock.
Do not install the refrigerator in a damp place or a
place where it may come in contact with water.
• Deteriorated insulation of electrical parts may cause an
electric shock or fire.
Do not store volatile or flammable substances in the
refrigerator.
• The storage of benzene, thinner, alcohol, ether, LP gas and
other such products may cause explosion.
Do not disassemble or repair the refrigerator by yourself.
• You run the risk of causing a fire, malfunctions and/or
personal injury.
Do not change the interior halogen lamp by yourself but
call to service center.
• Otherwise, there is a risk of electric shock.
When disposing of a refrigerator, remove the door/door
seals/door latch so that children or small animals cannot
become trapped inside.
The refrigerator must be earthed.
• You must earth the refrigerator to prevent any power
leakage or electric shocks caused by current leakage from
the refrigerator.
Never use gas pipes, telephone lines or other potential
lightening rods as earth.
• Improper use of the earthed plug can result in electric
shock.
• Keep ventilation openings in the appliance enclosure or
mounting structure clear of obstruction.
• Do not use mechanical devices or any other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
• Do not damage the refrigerant circuit.
• Do not use electrical appliances inside the
refrigerator/freezer, unless they are of a type recommended
by the manufacturer.
It explains terms to help users
to understand how to use the
product properly.
It is a mark indicating that the
power plug should be removed
from the wall outlet.
It is a mark indicating that
earthing is required to prevent
electric shock.
It helps users to use the
product more efficiently.
It is a mark indicating that it is
prohibited to disassemble.
It is a mark for a reference
page.
WARNINGS
BRANDSOURCE IB 2007.1.19 939 AM 페이지 5 in

SAFETY PRECAUTIONS
PREPARATION
5
.
CAUTIONS
Do not overfill the refrigerator with food.
• When you open the door, an item may fall out and
cause personal injury or material damage.
Do not put bottles or glass containers in the freezer.
• When the contents freeze, the glass may break and
cause personal injury.
If the wall socket is loose, do not insert the power
plug.
• There is a risk of electric shock or fire.
Do not disconnect the power cord by pulling on it.
• Damage to the cord may cause a short-circuit, fire
and/or electric shock.
• If the power cord is damaged, it must be replaced by
the manufacturer, a certified service agent or qualified
service person in order to avoid a hazard.
Do not store articles on the top of the appliance.
• When you open or close the door, the articles may fall
and cause personal injury and/or material damage.
Do not store pharmaceutical products, scientific
materials or temperature-sensitive products in the
refrigerator.
• Products that require strict temperature controls must
not be stored in the refrigerator.
Do not let children hang on the door.
a serious injury may occur.
If you smell pharmaceutical or smoke, pull out the power
plug immediately and contact your GOURMET service
center.
Do not touch the inside walls of the freezer or products
stored in the freezer with wet hands.
• This may cause frostbite.
Do not insert your hands into the bottom area
under the appliance.
• Any sharp edges may cause personal injury.
Never put fingers or other objects into the dispenser hole
and ice chute. It may cause personal injury or material
damage.
HFC-R134a is used as a refrigerant.
The refrigerant used in the refrigerator/freezer and the
gases in the insulation material require special disposal
procedures. Ensure that none of the pipes on the back of
the appliance are damaged prior to disposal.
Do not use a wet or damp cloth when cleaning the plug.
Remove any foreign matter or dust from the power plug
pins.
• Otherwise there is a risk of fire.
• If the refrigerator is disconnected from the power supply, you
should wait for at least five minutes before plugging it back.
When there is thunder or lightening or when the product
is not used for a long time, flip up the grill panel and set
the power switch to the O (OFF).
• Possibility of electric shock or fire.
The appliance is not intended for use by young children
or infirm persons without supervision.
Young children should be supervised to ensure that they
do not play with the appliance.
Do not store items in the ventilation space.
• It will cause a decrease in cooling capacity.
Do not place the fridge directly under the sunlight.
The power plug must be connected before the appliance
is positioned.
If the power cord is damaged, it must be replaced by
manufacturer, a certified service agent or qualified
service personnel.
• Never start up an appliance showing any signs of damage.
If in doubt, consult your dealer.
Please dispose of the packaging material for this product
in an environmentally friendly manner.
Please contact your local authorities in regard to the
enviromentally safe disposal of this product.
This product is intended only for the storage of food in a
domestic environment.
This product has 360。rotating casters.
So, if you take your hands off the product on a slant, it
will skid on the slant and fall over. To prevent lt, make
sure to hold the product firmly.
• If the product topples over, it cause severe injuries or death.
This product is too heavy. So, there is the possibility of
tipping forward when it is not installed properly. When
moving the product, make sure not to tip it over.
• If the product topples over, it cause severe injuries or death.
WARNINGS
CAUTIONS
BRANDSOURCE IB 2007.1.19 939 AM 페이지 6 in

6
Button & Display Panel
Show the set functions.
Grill Panel
Dispenser
supplies drink water via a water filter
and ice cubes made with the ice maker.
Freezer Door
Remember each part name.
NAME OF EACH COMPONENT
PREPARATION
BRANDSOURCE IB 2007.1.19 939 AM 페이지 7 in

Door Handle Fridge Door
Remember each part name.
7
NAME OF EACH COMPONENT
PREPARATION
Filter
BRANDSOURCE IB 2007.1.19 939 AM 페이지 8 in

PRECAUTIONS BEFORE INSTALLATION
PREPARATION
8
■Select an installation place
Make sure to check before
installation.
Model
GSE4820SS
A
48"
B
27.8"
C
84"
D
96.8"
E
88.5"
Model A B C
AB
CDE
Location of
Electrical
Receptacle
Water
Supply
Opening
1"×1"
A
B
C
Please check the followings before installing the product.
Check if the product can clear the doors on its way to the installation position.
▶If the product is not able to clear the doors, it is not possible to install.
Please check if there is enough space to install the product.
▶If there is not enough space, it is not possible to install.
GSE4820SS 47.5" 83.5"(min)
84.3"(max)
over than 24"
BRANDSOURCE IB 2007.1.19 939 AM 페이지 9 in

PRECAUTIONS BEFORE INSTALLATION
9
Check if the floor can support the weight of the refrigerator and the
food inside (1102lb or 500kg total).
▶It could damage the refrigerator.
Check if the product is placed within the reach of a wall outlet.
When the product is a dispenser model, check if it is within easy access
of water supply and the humidity is low.
▶Please select a place with easy access to water supply for the the water &
ice dispenser.
Avoid a place with high heat or extremely cold.
▶Install the product with an ambient temperature between 46℉(8℃) and
109℉(43℃).
▶When it is installed in a place with an extremely cold or hot ambient
temperature, the product could mal-function and its cooling capacity will
decrease resulting in an increase in power consumption.
■Select an installation place
Do not earth it to a gas
pipe or a telephone cord.
Possibility of explosion,
electric shock or fire.
■Earth the product
●Maker sure your house power supply has
an earth circuit always use a 3 pin plus
with an earth wire.
Check if the floor is flat.
▶If the refrigerator is installed on an uneven floor, it will cause vibration and
noise.
Make sure to earth the product to prevent electric leakage or an
electric shock.
▶When the product fails to operate : Make sure it is earthed to prevent
electric leakage or an electric shock.
▶When there is no earth with normal products:When touching the
handle or surface of the product, a minute amount of electric leakage
can be felt. (It can be felt on all products made of electricity conducting
materials (metal plate).It is obliged to use a right angle power
plug.Also, make sure to earth the product.)
<When the wall outlet has a earth terminal>
▶It doesn't need earthing. (But, when
the wall outlet has no earth terminal,
make sure to earth the product.)
<When the wall outlet has no earth terminal>
▶When plugging the product into a wall outlet having no earth, connect
the earth wire to the earth screw on the back of the product and then
connect the other end to a metallic water pipe or earth guide.
▶Never use a wall outlet or an extension cord having no earth wire.
(Without earth, minute electric leakage can be generated.)
▶Please refer to the installation manual for installation details.
earth
Terminal
PREPARATION
BRANDSOURCE IB 2007.1.19 939 AM 페이지 10 in

CHECKPOINTS BEFORE USE
USAGE
10
When plastic smells are coming from the refrigerator
▶Open the refrigerator doors and air the inside.
- With a new product, there could be plastic smells inside the refrigerator.
▶Before using the product, please remove all the adhesive tapes eliminating
chemical smells.
When storing food for the first time
▶Place food in the refrigerator when it cools down in 2~3 hours after the
product is plugged in.
- When you place food in the refrigerator before it cools enough, food smells
permeate the inner liners.
When the start-up sound is loud
▶When starting up a new refrigerator, the compressor and the motor operate
at high rpm to cool down the freezer and the fridge compartments quickly,
generating a slight noise.
- When it gets to set temperature and reaches a stable state, the noise decrease.
When an alarm goes off during operation
▶If any one of the doors remains open at a more than 15 degree angle for
more than 2minutes, it sends off an alarming sound every minute
indicating that a door is open.
When the power goes off
▶Please maintain the doors closed.
- When the power does not come back on for 2~3 hours in summer, the cool
temperature inside will be maintained.
Before using the refrigerator, make sure to check the followings.
It will show ways to use the product safely and efficiently.
Check the following before use.
BRANDSOURCE IB 2007.1.19 939 AM 페이지 11 in

QUICK ICE
BUTTON & DISPLAY PANEL
USAGE
11
QUICK ICE
WATER
CUBED ICE
CRUSHED ICE
g
e
SOUND
You can select or cancel it.
POWER REF.
You can use this function to cool down the
compartment faster.
REF. TEMP
The fridge compartment temperature
can be set at between 34℉(1℃) and
46℉(8℃)by pressing this button.
POWER FRE.
You can use this function to freeze food quickly or
to make ice cubes much faster.
FRE. TEMP
The freezer compartment temperature
can be set at between -6℉(-21℃)
and 8℉(-13℃)by pressing this button.
■Dispenser Function Select Button ■Fresh Island Function Display
QUICK ICE
▶ Select it when you need ice in a hurry.
WATER
▶Select it for water.
CUBED ICE
▶Select it for cubed ice.
CRUSHED ICE
▶Select it for crushed ice.
Soft Freezing
▶It shows that Fresh Island is operating in
soft freezing conditions.
Quick Cool
▶It shows that Fresh Island is operating in
quick cooling conditions.
Chill
▶It shows that Fresh Island is operating in
optimized refrigeration conditions.
Cool
▶It shows that Fresh Island is operating in
cool freezing conditions.
Soft Freezing
Quick Cool
Chill
Cool
■Water Filter Indicator Function Display
Water Filter Indicator
▶ When the green light changes to yellow, it is time to replace the water filter. If indicator is red, quick replacement is strongly recommended.
▶When the water filter is replaced, reset the indicator by pressing the FILTER CHANGE button for 3 seconds.
Basic functions of each button and the display.
Function of Each Button
Button &
Display Panel
LOCK
You can lock all the buttons
with this function.
※The above functions are available only with Fresh Island.
BRANDSOURCE IB 2007.1.19 939 AM 페이지 12 in

HOW TO STORE FOOD
USAGE
12
Store fruits after washing in water.
Divide storing food into small sizes and
store them.
▶Power can be saved because food can
be cooled-down quickly.
Put food with higher water contents on the
front part of the fridge shelf.
▶When you put it on the inner part of the
fridge shelf directly exposed to the cold
air, it could become frozen.
Do not store hot foods cooling it down.
▶If you cool it down before putting it in the
refrigerator, the product can perform
efficiently and power can be saved.
▶
When hot food is put in the refrigerator, it could
cause water condensation or frost inside.
Make sure to store food containers with
lids or plastic wrap on them.
■Tips on food storage
Each storage space provides its own storage conditions for different kinds of food.
You can enjoy the optimum taste of food by storing it in a selected place.
Let's figure out the correct
use of each storage space.
Please store foods with enough space among items.
▶When excessive amount of food is stored, it
could interrupt air circulation resulting in a
decrease cooling capability.
Winter Closet
You can store frozen pizzas
and ice cream etc.
Freezer Compartment Shelf
You can store various kinds of frozen food
such as meat, fish, and ice creams.
Freezer Door Bin
You can store small packaged frozen food
such as beans. But, do not store ice
creams or food for long time storage
Ice Bin
Store ice cubes made by the ice maker.
Do not store other food except ice cubes.
Dried Food & Meat Keeper.
For the purpose of storing for a long time
and store meat and chicken after wrapping
with aluminum foil or plastic wrap.
BRANDSOURCE IB 2007.1.19 939 AM 페이지 13 in

HOW TO STORE FOOD
USAGE
13
●Do not touch on containers or food in the freezer compartment with wet hands.Possibility of frostbite.
●Do not put food or containers in a place directly exposed to the cold air discharging port. It could be colder than
the set temperature resulting in food damage.
●Do not keep medical products or lab materials in the refrigerator. This product is only for food storage.
●Do not put any glass bottles in the freezer compartment. When the content freze, it can burst and causing
severe injury.
Dairy Bin
You can store dairy products such as
butter and cheese.
Fridge Door Bin
You can store small packaged
refrigerated food and beverages such
as milk, fruit juice and beer.
Fridge Compartment Shelf
Please put dishes or refrigerated foods
with enough space between items.
Veggie/Fruit Drawer
You can store vegetables and fruits in
fresh conditions.
Fresh Island
You can store meat, raw fish and food which
needs to be stored at lower temperature
than that in the fridge compartment to be
used within a week.( Refer to P.19~20)
BRANDSOURCE IB 2007.1.19 939 AM 페이지 14 in

Press the [ FRE. TEMP] button.
▶Freezer temperatures can be adjusted between -6℉and 8℉with an interval
of 2℉. At this time, the temperature indication bars will be illuminating, showing
the temperature range (MAX, MID or MIN).
When the freezer temperature is set, it will display the set temperature for
the first 5 seconds. And then, it will display its current temperature.
▶When the set temperature and the displayed temperature are different from
each other, it will be automatically adjusted to the set temperature.
▶The numbers on the display represent the inside temperature of the freezer
compartment.
■How to control freezer temperature
HOW TO CONTROL TEMP
USAGE
14
FRE. TEMP MAX
MID
MIN
Press the [POWER FRE.] button.
▶POWER FRE will illuminate in the display and it will start operating.
Press the [POWER FRE.]button one more time to cancel the POWER
FRE function.
● The POWER FRE function will be automatically turned off after a
certain period of time and the freezer temperature will return to the
temperature set right before the POWER FRE function is selected.
●When you press the [POWER FRE.] button, the refrigerator will
continuously operate for a certain period of time.
To control the freezer temperature, follow the procedures below.
●The freezer temperature could change depends on the number of door
opening times, the quantity of stored food and the ambient temperature.
●Each storage section in the freezer compartment may have a different
temperature.
●When the temperature in the freezer compartment has increased due to
frequent use or the storage of hot food, the temperature display will
blink.(In this case, when the temperature reaches the set temperature, it
will stop blinking. if when it keeps on blinking, please contact our service
center.)
POWER FRE.
■To speed up ice production
Learn how to control the fridge & the freezer temperatures.
Power can be saved by keeping food in appropriate temperatures.
To adjust temperature
QUICK ICE
BRANDSOURCE IB 2007.1.19 939 AM 페이지 15 in

HOW TO CONTROL TEMP
USAGE
15
Press the [REF. TEMP] button.
▶Fridge temperatures can be adjusted between 34℉and 46℉with an
interval of 2℉.
At this time, the temperature indication bars will be illuminating, showing
the temperature range (MAX, MID or MIN).
When the fridge temperature is set, it will display the set temperature
for the first 5seconds. And then, it will display its current
temperature.
▶When the set temperature and the displayed temperature are different
from each other, it will be automatically adjusted to the set temperature.
▶The numbers on the display represent the inside temperature of the
fridge compartment.
To control the fridge temperature, follow the procedures below.
●The fridge temperature could change depends on the number of door
opening times, the quantity of stored food and the ambient temperature.
●Each storage section in the fridge compartment may have a different
temperature.
●When the temperature in the fridge compartment has increased due to
frequent use or the storage of hot food, the temperature display will blink.
(In this case, when the temperature reaches the set temperature, it will stop
blinking. But, if it keeps on blinking, please contact our service center.)
REF. TEMP
MAX
MID
MIN
●The POWER REF function will be automatically turned off after a certain
period of time and the fresh food temperature will return to the
temperature set right before the POWER REF function is selected.
●When you press the [POWER REF.] button, the refrigerator will
continuously operate for a certain period of time.
POWER REF.
■How to control fridge temperature
■ To cool down the fridge compartment faster
Press the [POWER REF.] button.
▶POWER REF will illuminate in the display and it will start operating.
Press the [POWER REF.] button one more time to cancel the
POWER REF function.
BRANDSOURCE IB 2007.1.19 939 AM 페이지 16 in

16
■ Keep in mind the followings when using the ice maker!
■ Check if the ice maker works with following methods.
ON
OFF
ON
OFF
󳫹
If you need more storage space, remove ice bucket and you can use that
space as a storage space.
Take out the ice bin in the upper part of the freezer compartment.
▶Put your hand on the bottom of the ice bin and lift it up.And then,hold the upper
part of it and pull it forward.
If you drop it down, it could hurt your feet or damage the floor.
1
To test a ice maker, lift up the feeler arm three successive times when the
power switch is on ( LED lamp is red )
▶After ice maker heater is energized, harvesting motor will work.
It's normal if water is supplied.
Feeler arm
Power switch
Lamp
2
Enjoy high quality ice cubes and drinking water with the
dispenser of the GOURMET refrigerator.
Let's figure out how to
use the dispenser.
HOW TO USE DISPENSER
USAGE
①
②
▶It takes 12 hours to get down to temperatures cold enough to make ice
cubes when the refrigerator is initially plugged in.
▶In order to operate the ice maker properly, water pressure of
0.14Mpa ~1.0Mpa(1.4~10kgf/cm2 , 1.4 ~10bar), is required. And it have to
be connected to portable water supply only.
▶If common water pressure is higher than required pressure you had better
use a decompression device to prevent from breakage
▶The ice production speed depends on the number of door openings during
its operationand using conditions such as the ambient temperature.
▶When ice dispenser is not used frequently, ice cubes will melt and get
joined together affecting the operation of the dispenser. At this time, take
out the ice maker and throw away the ice lump.
When you do not use water and ice for a long time such as during winter
or vacation season, shut off the water valve to cut the water supply.
- If the water pipe or the water purifier ruptures or water leaks out of it, it could get flooded.
When ice melts due to a power failure, wipe-dry the freezer compartment
after taking out the ice
maker and throwing away the ice lump
- Melted ice could escape the refrigerator making the floor slippery and damaging the floor.
QUICK ICE
■HOW TO USE DISPENSER
Brandsource refrigerators have embeded water filters.'
So, please use a supplied water filter when using it.
Ice cubes and water first made or supplied after the installation could send
out plastic smells.
▶Throw away the first full bucket of ice.
▶Throw away the first six glassfuls of water.
BRANDSOURCE IB 2007.1.19 939 AM 페이지 17 in

HOW TO USE DISPENSER
USAGE
17
■To get ice
Press the WATER button and press the glass against the dispenser pad.
▶Throw away the first six glassful of water after the installation.
When you take out water after the installation, it could have plastic smell.
▶Even though the refrigerator is in operation, the first glass of water could be
warm. So, get several cubes of ice first and then take out water to drink cool
water.
You can take out up to six glasses of water continuously and water will be
cooled down in 2~3 hours.
You can take out up to six glasses of water continuously and water will be
cooled down in 2~3 hours.
●If you get ice with a thin glass cup or ceramic ware, it could get
broken.
●When you get ice stale in color, stop using it and contact our
service center.
●Do not put your hands into the ice crusher discharge
opening.You can get hurt.
Press the CUBED ICE/CRUSHED ICE button and select the
shape of ice.
Press the glass gently against the middle of the dispenser pad.
▶Take the glass closer to the chute to prevent ice from bouncing out of the cup.
1
2
■To get water
QUICK ICE
QUICK ICE WATER CUBED ICE CRUSHED ICE
BRANDSOURCE IB 2007.1.19 939 AM 페이지 18 in

So
Free
It is a parts filtering impurities that are bad for human being such as chlorine
and its smell and offensive taste contained in tap water.
Filtrate of water-purifying filter is made from vegetable active carbon.
Purifying Effect
▶ It is NSF (National Science Foundation) certified, and meets a standard
requirement for food safety of NSF 42,53. It also passed the following standard test.
When to Replace
▶ When the green lamp on icon in the display part of refrigerator
turns orange, it is recommended to replace a filter. If the color of lamp turns red
from orange, replace the filter immediately.
▶ Purchase a water-purifying filter from a near service center for replacement.
Separate a water-purifying filter
▶Open the unit grill in the upper part of refrigerator, rotate the filter by 90°to
the left (unlock), and pull it down.
Put an installing date sticker on a new filter.
▶ Unpack the filter box, and peel off the red protective cap.
▶ Put an installing date sticker on the new filter.
Example) If installing it in October, put on 'OCT 10' sticker.
Fit a new filter in.
▶ Fit the filter in a fixing part, rotate it by 90°to the right(lock), and
match an indicating line ( ) with Lock ( ) sign.
▶ Close an unit grill, and press ice-maker test button to check if water flows out.
▶ It is recommended to run off water for about 2 minutes (or 2 liter)
when you install or replace a filter for the first time.
▶ After replacing a filter, press button for 3 seconds until the
color of lamp turns green from red.
1
2
3
■ What is Water-Purifying Filter?
■ Filtrate and Purifying Effect
■ How To Replace Water-Purifying Filter
Certification Standard
Remove Capacity
NSF 42
NSF 53
Smell, Chloride
Pathogene, insecticide, asbestos, slime,
benzol,organic compound, mercury
Place a bucket little bit bigger than the filter to catch the
dropping water when separating the filter.
Unlock
Lock
18
Have a knowledge of
water-purifying filter.
How To Replace Water-Purifying Filter
USAGE
BRANDSOURCE IB 2007.1.19 939 AM 페이지 19 in

Fresh Island
USAGE
19
■Function selection
1
When Quick Cool is selected
▶With this Quick Cool function, you can cool down up to three bottles of room
temperature beer enough to drink within an hour.
▶You can put food in the Fresh Island and press the Quick Cool button, the
refrigerator will operate for an hour continuously.
▶If you use Quick Cool, take out the food from the Fresh Island and put it in
the fridge compartment during its operation. The food could become frozen
with the strong flow air.
▶To cancel the Quick Cool function, press the Quick Cool button once more.
When the Quick Cool function is completed, it goes back to the previous
refrigeration setting.
Soft
Freezing Quick
Cool
Chill Cool
LOCK
Soft
Freezing Quick
Cool
Chill Cool
LOCK
Soft
Freezing Quick
Cool
Chill Cool
LOCK
2
When Soft Freezing is selected
▶When Soft Freezing is selected, the temperature of the Fresh Island will be
set to 23℉and the temperature will be maintained at 23℉regardless of
fridge temperature setting.
▶The temperature ( 23℉) of Soft Freezing falls into the Soft Freezing
temperature range. Water in meat or fish will not freeze hard it will freeze soft
enough that it can be cut easily.
You can speed up cooling or make frozen food soft enough to cut easily with this
function. Also, by adjusting the temperature of each compartment, you can store
customize the storage of different kinds of food.
Let's figure out the
Fresh Island function.
BRANDSOURCE IB 2007.1.19 940 AM 페이지 20 in

Fresh Island
USAGE
20
When Cool is selected
▶ When Cool is selected, the Fresh Island panel will display 38℉ set at
the Fresh Island temperature control and the Fresh Island will be
controlled based on
38℉ .
▶ When Cool is selected, it will be set to 38℉ .
So, you can have more refrigeration space by using it as the fridge
compartment.
When LOCK is selected
▶ The system will be locked with its current setting and all the
function buttons can not be changed
▶ To cancel the LOCK function, press the LOCK button once more.
When Chill is selected
▶ When Chill is selected, the temperature of the Fresh Island will be
set to
31℉ and the temperature of the fridge compartment will be
maintained at
31℉ regardless of its temperature setting.
▶31℉ is a temperature at which water in food is on the verge of
freezing. With this temperature, you can freshly keep meat or fish
that you are about to cook.
■Function selection
4
5
3
- Do not put food, vegetables or fruits with high water content in
the Fresh Island.
●It can freeze them.
●Water contained in food begins to freeze at
31℉
or
23℉
.
So, beverages such as fruit punch and juice, vegetables and fruits
could become frozen.
- Different types of beverages and foods may have different cooling
times.
Soft
Freezing Quick
Cool
Chill Cool
LOCK
Soft
Freezing Quick
Cool
Chill Cool
LOCK
Soft
Freezing Quick
Cool
Chill Cool
LOCK
BRANDSOURCE IB 2007.1.19 940 AM 페이지 21 in
