FibreMATRIX™
Fibre Channel Switch
Manual
© 2005, 2010 Data Device Corporation. All trademarks are the property of their respective owners.
Model: FC-76000
For more information: www.ddc-web.com/FC-76000
Applications
• Military Programs
• Aerospace Programs
• Sensor Interfaces
• High Speed Networking
• Storage Networks
• Test Labs
The FC-76000 FibreMATRIX™ series are 16-port VME Fibre Channel fabric switches optimized to meet the
performance, reliability, and demanding environmental requirements of embedded, real time, military and
aerospace applications. FibreMATRIX fibre Channel VME switches operate at either 1 Gb/s or 2 Gb/s data rates,
provide cut-through and store-and-forward routing with 127 priority levels, multicast, and broadcast. The switches
provide optical media interfaces on a conduction- or air-cooled VME64x form factor.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

DDC's Data Networking Solutions
MIL-STD-1553 | ARINC 429 | Fibre Channel
As the leading global supplier of data bus components, cards, and software solutions for the military, commercial,
and aerospace markets, DDC’s data bus networking solutions encompass the full range of data interface
protocols from MIL-STD-1553 and ARINC 429 to USB, and Fibre Channel, for applications utilizing a spectrum of
form-factors including PMC, PCI, Compact PCI, PC/104, ISA, and VME/VXI.
DDC has developed its line of high-speed Fibre Channel and Extended 1553 products to support the real-time
processing of field-critical data networking netween sensors, compute notes, data storage displays, and weapons
for air, sea, and ground military vehicles.
Whether employed in increased bandwidth, high-speed serial communications, or traditional avionics and ground
support applications, DDC's data solutions fufill the expanse of military requirements including reliability,
determinism, low CPU utilization, real-time performance, and ruggedness within harsh environments. Out use of
in-house intellectual property ensures superior mutli-generational support, independent of the life cycles of
commercial devices. Moreover, we maintain software compatibility between product generations to protect our
customers' investments in software development, system testing, and end-product qualification.
DDC provides an assortment of quality MIL-STD-1553 commercial, military, and COTS grade cards and
components to meet your data conversion and data interface needs. DDC supplies MIL-STD-1553 board level
products in a variety of form factors including AMC, USB, PCI, cPCI, PCI-104, PCMCIA, PMC, PC/104, PC/104-
Plus, VME/VXI, and ISAbus cards. Our 1553 data bus board solutions are integral elements of military, aerospace,
and industrial applications. Our extensive line of military and space grade components provide MIL-STD-1553
interface solutions for microprocessors, PCI buses, and simple systems. Our 1553 data bus solutions are
designed into a global network of aircraft, helicopter, and missle programs.
DDC also has a wide assortment of quality ARINC-429 commercial, military, and COTS grade cards and
components, which will meet your data conversion and data interface needs. DDC supplies ARINC-429 board
level products in a variety of form factors including AMC, USB, PCI, PMC, PCI-104, PC/104 Plus, and PCMCIA
boards. DDC's ARINC 429 components ensure the accurate and reliable transfer of flight-critical data. Our 429
interfaces support data bus development, validation, and the transfer of flight-critical data aboard commercial
aerospace platforms.
MIL-STD-1553
ARINC 429
DDC has developed its line of high-speed Fibre Channel network access controllers and switches to support the
real-time processing demands of field-critical data networking between sensors, computer nodes, data storage,
displays, and weapons, for air, sea, and ground military vehicles. Fibre Channel's architecture is optimized to
meet the performance,reliability, and demanding environmental requirements of embedded, real time, military
applications, and designed to endure the multi-decade life cycle demands of military/aerospace programs.
Fibre Channel
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

D A T A D E V I C E C O R P O R A T ION
Data Device Corporation FC-76000 Manual
www.ddc-web.com Rev A-01/10-0
i
FC-76000 FIBREMATRIX
FIBRE CHANNEL SWITCH
HARDWARE MANUAL
MN-76000XX-001
The information provided in this Manual is belived to be accurate; however, no
responsibility is assumed by Data Device Corporation for its use, and no license or rights
are granted by implication or otherwise connection therewith.
Specifications are subject to change without notice.
Please visit our Web site at http://www.ddc-web.com/ for the latest information.
All rights reserved. No part of this Manual may be reproduced or transmitted in any form
or by any mean, electronic, mechanical photocopying recording, or otherwise, without
the prior written permission of Data Device Corporation.
105 Wilbur Place
Bohemia, New York 11716-2426
Tel: [phone], Fax: [phone]
World Wide Web - http://www.ddc-web.com
For Technical Support - 1-800-DDC-5757 ext. 7771
United Kingdom - Tel: [phone], Fax: [phone]
France - Tel: [phone], Fax: [phone]
Germany Tel: [phone], Fax: [phone]
Japan - Tel: [phone], Fax: [phone]
© 2009 Data Device Corp.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

R E C O R D O F C H A N G E
Data Device Corporation FC-76000 Manual
www.ddc-web.com Rev A-01/10-0
ii
Revision
Date
Pages
Description
Rev A
Jan., 2010
All
Initial Release
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

T A B L E O F C O N T E N T S
Data Device Corporation FC-76000 Manual
www.ddc-web.com Rev A-01/10-0
iii
1PREFACE ............................................................................................................. 1
1.1Text Usage .................................................................................................................. 1
1.2 Special Handling and Cautions ................................................................................... 1
1.3 Trademarks ................................................................................................................. 1
1.4 What is included in this manual? ................................................................................. 1
1.5 Technical Support ....................................................................................................... 2
2OVERVIEW .......................................................................................................... 3
2.1Features ...................................................................................................................... 3
2.2 System Requirements ................................................................................................. 4
2.3 Tested Inoperable Products ........................................................................................ 4
2.4 What is Included .......................................................................................................... 4
3HARDWARE INSTALLATION ............................................................................. 9
3.1 VME 64X Interface ...................................................................................................... 9
3.2 Electrical and Mechanical Information ......................................................................... 9
3.2.1 Front Panel ..................................................................................................... 10
3.2.2 Serial Port ....................................................................................................... 10
3.2.3 Switch Serial Port to PC Connection ............................................................... 10
3.2.4 Ethernet Port ................................................................................................... 11
3.2.5 LC Fibre Optic Connectors .............................................................................. 12
3.2.6 Rear-Panel Pinout ........................................................................................... 12
3.2.7 Mating Cables ................................................................................................. 13
3.2.8 Jumpers .......................................................................................................... 13
4MANAGEMENT CONSOLE ............................................................................... 15
4.1 Terminal Emulator Configuration ............................................................................... 15
4.1.1 ASCII Setup .................................................................................................... 15
4.1.2 Serial Port Connection Configuration .............................................................. 15
4.1.3 Ethernet Setup ................................................................................................ 15
4.2 Configuration Options ................................................................................................ 15
4.2.1 Overview of Menu Tree ................................................................................... 16
4.2.2 FC-76000 User Interface Menu Quick Guide ................................................... 16
4.2.3 User Interface Log-in ....................................................................................... 17
4.2.4 Main Menu ...................................................................................................... 17
4.2.5 Configuration Menu ......................................................................................... 18
#RTxxx .......................................................................................................................... 29
TYPE x .......................................................................................................................... 29
WKA x ........................................................................................................................... 29
PTE xxxx ....................................................................................................................... 30
PTM xxxx ...................................................................................................................... 30
END\r\n ......................................................................................................................... 30
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

T A B L E O F C O N T E N T S
Data Device Corporation FC-76000 Manual
www.ddc-web.com Rev A-01/10-0
iv
#GC .............................................................................................................................. 30
S07 x............................................................................................................................. 31
S8F x ............................................................................................................................ 31
AM0 x............................................................................................................................ 31
LUM x ........................................................................................................................... 31
EDT x ............................................................................................................................ 31
END\r\n ......................................................................................................................... 31
#PCx ............................................................................................................................. 32
PWR “xx” ...................................................................................................................... 32
BBC x............................................................................................................................ 32
RTT “xx” ........................................................................................................................ 32
END\r\n ......................................................................................................................... 32
4.2.6 Status Main Menu ........................................................................................... 33
4.2.7 Statistics Main Menu ....................................................................................... 35
4.2.8 Flash Programming Main Menu ...................................................................... 38
4.2.9 Diagnostic Test menu ...................................................................................... 42
5ORDERING INFORMATION .............................................................................. 46
6INDEX ................................................................................................................. 47
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

L I S T O F F I G U R E S
Data Device Corporation FC-76000 Manual
www.ddc-web.com Rev A-01/10-0
v
Figure 1. FC-76000 FibreMatrix Switch .............................................................................5
Figure 2. FC-76000 FibreMatrix Switch Block Diagram .....................................................5
Figure 3. FC-76000 Outline Drawing .................................................................................9
Figure 4. LC Connector (front view) ................................................................................. 12
Figure 5. Jumper Locations ............................................................................................. 14
Figure 6. Menu Quick Guide ............................................................................................ 16
Figure 7. Login Screen..................................................................................................... 17
Figure 8. Main Menu ........................................................................................................ 18
Figure 9. Configuration Menu .......................................................................................... 19
Figure 10. Domain ID ....................................................................................................... 19
Figure 11. Master Switch Selection ................................................................................. 19
Figure 12. WKA Server Configuration .............................................................................. 20
Figure 13. Global Settings ............................................................................................... 20
Figure 14. E_D_TOV Selection ........................................................................................ 22
Figure 15. Implicit Login Table ......................................................................................... 22
Figure 16. Ethernet Sub-menu ......................................................................................... 23
Figure 17. Port Sub-menu ................................................................................................ 24
Figure 18. Set Port Dialog Screen ................................................................................... 24
Figure 19. Routing Table ................................................................................................. 25
Figure 20. Routing Table Index Entry Screen .................................................................. 25
Figure 21. Routing Table Mask Entry Screen .................................................................. 26
Figure 22. Routing Table Index Entry Screen .................................................................. 26
Figure 23. Routing Table Write Route Screen ................................................................. 26
Figure 24. Download File Screen ..................................................................................... 28
Figure 25. Status Menu .................................................................................................... 33
Figure 26. Port Summary (switch status) ......................................................................... 33
Figure 27. Name Server Login Table ............................................................................... 34
Figure 28. Extended Name Server Login Table ............................................................... 34
Figure 29. Statistics Menu ............................................................................................... 35
Figure 30. FC Services Statistics Screen ......................................................................... 35
Figure 31. Port Statistics Screen ..................................................................................... 37
Figure 32. Ethernet Screen .............................................................................................. 37
Figure 33. Temperature ................................................................................................... 38
Figure 34. Flash Programming Main Menu ...................................................................... 39
Figure 35. Fabric Chip Erase Prompt............................................................................... 39
Figure 36. Fabric Chip Flash Programming Screen ......................................................... 40
Figure 37. Port Chip Erase Prompt .................................................................................. 40
Figure 38. Port Chip Flash Programming Screen ............................................................ 41
Figure 39. Store Current Config Screen ........................................................................... 41
Figure 40. Store Current Configuration Screen ................................................................ 42
Figure 41. Reboot Switch ................................................................................................. 42
Figure 42. Diagnostic Test Main Menu ............................................................................ 42
Figure 43. Routing Table Test ......................................................................................... 43
Figure 44. Register Test .................................................................................................. 43
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

L I S T O F F I G U R E S
Data Device Corporation FC-76000 Manual
www.ddc-web.com Rev A-01/10-0
vi
Figure 45. Loopback Test ................................................................................................ 43
Figure 46. Flash Interface Test ........................................................................................ 44
Figure 47. DMA Test ........................................................................................................ 44
Figure 48. Clock Sync Test .............................................................................................. 44
Figure 49. Run All Test .................................................................................................... 45
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

L I S T O F T A B L E S
Data Device Corporation FC-76000 Manual
www.ddc-web.com Rev A-01/10-0
vii
Table 1. System Requirements ............................................................................................4
Table 2. FC-76000 Specification Table ................................................................................6
Table 3. Serial Port pinout ................................................................................................. 10
Table 4. Wiring diagram for switch serial port to female DB9 ............................................ 11
Table 5. Ethernet port pinout ............................................................................................. 11
Table 6. VME64X P1/P2 pinout ......................................................................................... 12
Table 7. TB5 Jumpers........................................................................................................ 13
Table 8. TB10 Jumpers ...................................................................................................... 14
Table 9. Look Up Mask/DID fields ..................................................................................... 21
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Data Device Corporation FC-76000 Manual
www.ddc-web.com Rev A-01/10-0
1
1 PREFACE
This manual uses typographical conventions to assist the reader in understanding the
content. This section will define the text formatting used in the rest of the manual
1.1 Text Usage
BOLD–indicates important information and table, figure, and chapter
references.
BOLD ITALIC–designates DDC Part Numbers.
Courier New–indicates code examples.
<…> - indicates user-entered text or commands.
1.2 Special Handling and Cautions
The FC-76000 uses state-of-the-art components, and proper care should be used to
ensure that the device will not be damaged by Electrical Static Discharge (ESD),
physical shock, or improper power surges and that precautions are taken to avoid
electrocution.
Warnings: Turn off power to the computer hardware and unplug from wall.
NEVER insert or remove card with power turned on.
Ensure that standard ESD precautions are followed. As a minimum, one
hand should be grounded to the power supply in order to equalize the
static potential.
Do not store disks in environments exposed to excessive heat, magnetic
fields or radiation.
1.3 Trademarks
All trademarks are the property of their respective owners.
1.4 What is included in this manual?
This manual contains a complete description of hardware installation and use.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

P R E F A C E
Data Device Corporation FC-76000 Manual
www.ddc-web.com Rev A-01/10-0
2
1.5 Technical Support
In the event that problems arise beyond the scope of this manual, you can contact
DDC by the following:
US Toll Free Technical Support:
1-800-DDC-5757, ext. 7771
Outside of the US Technical Support:
1-631-567-5600, ext. 7771
Fax:
1-631-567-5758 to the attention of DATA BUS Applications
DDC Website:
www.ddc-web.com/ContactUs/TechSupport.aspx
Please note that the latest revisions of Software and Documentation are available for
download at DDC‟s Web Site, www.ddc-web.com.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Data Device Corporation FC-76000 Manual
www.ddc-web.com Rev A-01/10-0
3
2 OVERVIEW
The FC-76000 FibreMatrix series cards are VME64X form factor Fibre channel
switches optimized for use in military/aerospace applications. The FibreMatrix
switches operate at either 1 Gb/s or 2 Gb/s data rates in switched fabric topologies.
There are versions of the switch that have either 8 or 16 ports, and are either
conduction or fan-forced (convection) cooled.
The FibreMatrix switch is based on DDC‟s own Fibre Channel technology.
FibreMatrix‟s base architecture is optimized to meet the highly deterministic
performance, high reliability, and demanding environmental requirements of
embedded, real time military applications. Its flexible FPGA-based architecture can
be tailored to meet a wide range of specific system requirements. Moreover,
FibreMatrix is not subject to rapidly changing commercial market forces that can
result in shortened life cycles. Instead, DDC's FibreMatrix technology has been
designed to meet the multi-decade life cycle demands of military/aerospace
programs, continuing DDC‟s demonstrated commitment as a long-term military COTS
supplier of digital interface devices.
The FibreMatrix switch supports Class 2 acknowledged and Class 3 unacknowledged
Fibre Channel service.
To support the unique requirements of military aerospace applications, the
FibreMatrix includes a number of advanced architectural features. Features include
implicit Fibre Channel login, Fibre Channel priority and ELS clock synchronization.
The FibreMatrix is designed to operate in harsh environments at temperatures from
-40 C to +70 C, and withstand mechanical shock and vibration typically found in
military/aerospace environments.
The FibreMatrix switch is suitable for a wide variety of applications for embedded
avionics and vetronics systems. These include sensor interfacing, multi-processor
and DSP arrays, radar systems, display systems, serial backplanes, and storage.
2.1 Features
Up to 8 ports in one 6U VME64X slot
Up to 16 ports in two 6U VME64X slot
1.0625 or 2.125 Gbps operation in banks of 8 ports
850 nm Optical media, LC connectors
Management through Ethernet or serial port
Non-blocking Crosspoint Architecture
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

O V E R V I E W
Data Device Corporation FC-76000 Manual
www.ddc-web.com Rev A-01/10-0
4
Conduction OR convection cooled
Commercial or extended temperature range
1024-Entry Routing Table
Fibre Channel Features
- Class 2 or Class 3 service
- Explicit or implicit log-in
- ELS clock sync, 56 bit resolution of a 64 bit counter
- ELS client and server
- 8 receive buffers
- 127 priority levels
2.2 System Requirements
Table 1. System Requirements
System Parameter
Minimum Requirement
VME 64X Requirements
+3.3 volt and +5 volt power supplies
One slot for 8 port, 2 slots for 16 port
Rack thermal requirements
See Table X for details
Power requirements
5.0 V and 3.3 V. See Table X for details
2.3 Tested Inoperable Products
DDC FC-750XX Fibre Channel NAC cards
Qlogic ISP231X based HBAs
Various FC analyzers such as AAI, Ixia, etc.
2.4 What is Included
The FC-76000 FibreMatrix® switch ships with the following items:
FC-76000 series Fibre Channel Switch
CD containing manual
6-conductor modular jack cable, crossover
6-pin modular jack-to-female DB9 adapter
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

O V E R V I E W
Data Device Corporation FC-76000 Manual
www.ddc-web.com Rev A-01/10-0
5
Figure 1. FC-76000 FibreMatrix Switch
Figure 2. FC-76000 FibreMatrix Switch Block Diagram
Note that the 16 port switch is a two board implementation. The implementation
consists of a base card, which contains 8 fiber optic ports, and a mezzanine card,
which contains another 8 fiber optic ports. When a unit is shipped as a 16 port, it is
recommended that the mezzanine card never be separated from the base card.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

O V E R V I E W
Data Device Corporation FC-76000 Manual
www.ddc-web.com Rev A-01/10-0
6
Table 2. FC-76000 Specification Table
PARAMETER
MIN
TYP
MAX
UNITS
ABSOLUTE MAXIMUM RATING
+3.3 V Supply Voltage
+5V Supply Voltage
-0.3
-0.3
3.6
5.5
V
V
POWER SUPPLY REQUIREMENTS (Note 1)
Voltages/Tolerances
+3.3 V
+5 V
Current Drain (Note 2)
+3.3 V
+5 V
3.25
4.875
3.3
5.0
1.1
7.8
3.45
5.25
2.85
8.60
V
V
A
A
FIBRE CHANNEL PHYSICAL INTERFACE
Optical Interface
1 Gb/s (FC-PI 100-M6-SN-I)
Maximum Link Distance
0.5
300
M
2 Gb/s (FC-PI 100-M6-SN-I)
Maximum Link Distance
0.5
150
M
PERFORMANCE CHARACTERISTICS
Port-to-Port Latency
1 Gb/s
2 Gb/s
1.6
1.1
2
2
µS
µS
THERMAL
Power Dissipation
Operating Temperature
(measured at thermal interface)
-C00
-300
Storage Temperature
-40
0
-55
12
+71
+55
+85
W
°C
°C
°C
ENVIRONMENTAL CHARACTERISTICS
(as per ANSI/VITA 47-2005)
C-76161V2-300 (Forced Air Cooling)
VITA 47 Environmental Class EAC1
Operating Temp (inlet air): AC1
0 - +55
°C
Minimum Required Air Volume Flow Rate (sea
level) at maximum inlet temperature
25
CFM
Non-Operating Temp: C1
-40 - +85
°C
Temperature Cycling: C1
-40 - +85, 500 cycles
°C
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

O V E R V I E W
Data Device Corporation FC-76000 Manual
www.ddc-web.com Rev A-01/10-0
7
Table 2. FC-76000 Specification Table
PARAMETER
MIN
TYP
MAX
UNITS
ENVIRONMENTAL CHARACTERISTICS
(as per ANSI/VITA 47-2005) (cont’d.)
C-76161V2-300 (Forced Air Cooling) (cont‟d.)
Vibration Class: V1
5 Hz to 100 Hz (PSD) = 0.04 g²/Hz, 1 hr
per axis
Hz
Humidity
95% relative humidity for five 48 hr cycles
C-76161V2-200 (Forced Air Cooling)
VITA 47 Environmental Class EAC6
Operating Temp (inlet air): AC3
-40 - +70
°C
Minimum Required Air Volume Flow Rate (sea
level) at maximum inlet temperature
25
CFM
Non-Operating Temp: C3
-50 - +100
°C
Temperature Cycling: C3
-50 - +100, 500 cycles
°C
Vibration Class: V2
5 Hz to 100 Hz PSD increasing at 3
dB/octave, 1 hr per axis
100 Hz to 1000 Hz PSD = 0.04 g2/Hz, 1 hr
per axis
1000 Hz to 2000 Hz PSD decreasing at 6
dB/octave, 1 hr per axis
Hz
Hz
Hz
Humidity
95% relative humidity for five 48 hour
cycles
Shock Class
20g, 11 millisecond, half-sine shock
pulses in all three axes
g/ms
C-76161V2-C00 (Conduction Cooling)
VITA 47 Environmental Class ECC3
Operating Temp (alloable edge temp): CC3
-40 - +70
°C
Non-Operating Temp: C3
-50 - +100
°C
Temperature Cycling: C3
-50 - +100, 500 cycles
°C
Vibration Class: V3
5 Hz to 100 Hz PSD increasing at 3
dB/octave, 1 hr per axis
100 Hz to 1000 Hz PSD = 0.1 g2/Hz, 1 hr
per axis
1000 Hz to 2000 Hz PSD decreasing at 6
dB/octave, 1 hr per axis
Hz
Hz
Hz
Humidity
95% relative humidity for five 48 hour
cycles
Shock Class
40g, 11 millisecond, half-sine shock
pulses, all three axes
g/ms
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

O V E R V I E W
Data Device Corporation FC-76000 Manual
www.ddc-web.com Rev A-01/10-0
8
Table 2. FC-76000 Specification Table
PARAMETER
MIN
TYP
MAX
UNITS
PHYSICAL CHARACTERISTICS
Form Factor
VME Double Height Board per ANSI/VITA 1.1-1997 (R2003)
Single-board construction for 8 ports
Two-board construction for 16 ports
16 port version has VME connectors on base card only
Conduction-cooled version IAW IEEE 1101.2 (front panel
I/O)
PHYSICAL CHARACTERISTICS (cont’d)
Size
160 x 233.35
mm
(6.299 x 9.181)
(in)
Weight (convection cooled)
28.8
oz
(816.0)
(g)
Table 2 Notes:
1. VME 64 spec defines +5V as +4.875 to + 5.25 V. VME 64X spec defines +3.3V as +3.25 to +3.45V.
2. Power consumption numbers are preliminary, based upon a small sampling of switch cards.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Data Device Corporation FC-76000 Manual
www.ddc-web.com Rev A-01/10-0
9
3 HARDWARE INSTALLATION
3.1 VME 64X Interface
Requires 3.3 volt and 5V power supplies
Does not connect to any VME signals other than 5V, 3.3V and ground
Does not have a P0 connector
The fan-forced convection cooled version of the switch requires airflow. Please
see thermal specs. The conduction cooled version of the switch requires it‟s
thermal rail be held between –40 deg C and +70 deg C.
3.2 Electrical and Mechanical Information
Figure 3. FC-76000 Outline Drawing
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

H A R D W A R E I N S T A L L A T I O N
Data Device Corporation FC-76000 Manual
www.ddc-web.com Rev A-01/10-0
10
3.2.1 Front Panel
All customer I/O is done via the front panel. The front panel contains, starting from
the top:
Power LED (green)
Heartbeat LED (orange)
Serial port, RS-232 levels: 6 pin modular jack
Either 8 or 16 FC ports, which are LC fiber optic connectors
10/100 Ethernet connector: 8 pin modular jack w/ 2 embedded LEDs
Recessed Reset pushbutton switch
3.2.2 Serial Port
The management serial port is a front panel mounted 6-pin modular jack connector.
See Table 3 for the serial port pinouts.
Table 3. Serial Port pinout
Serial port pin
Signal Name
1
-
2
Rx_Data (into switch)
3
GROUND
4
-
5
Tx_Data (out of switch)
6
-
3.2.3 Switch Serial Port to PC Connection
A 6-conductor modular jack cable and modular jack-to-female DB9 adapter is
shipped with each switch. The modular jack cable that ships with the switch is a
crossover cable. The table below shows how the modular jack-to-DB9 adapter must
be wired to allow communication with a standard DB9 serial port on a PC. Note that
only the 3 pins shown should be populated in the adapter.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
