De Dietrich Thermique VIVADENS MCR 24 User manual

After Sales Service Guide
300013727 15/05/2007 JgK
VIVADENS wall-hung gas condensation boilers
MCR 24, 24/28 MI, 30/35 MI, 34/39 MI
MCR 24 BS/80, MCR 24 BS/130

2
Use of this guide is reserved for qualified professionals
Symbols used

Any intervention on the appliance and heating
equipment must be carried out by a qualified
technician.
Abide by prevailing local regulations.
For Belgium: Any work on the gas block must
be carried out by a factory technician.
Caution danger Risk of injury and damage to equipment. Attention must be paid to the
warnings on safety of persons and equipment
Specific information Information must be kept in mind to maintain comfort
ZReference Reference to other paragraphs in the guide

3
1
2
3
4
5
6
1. PRESENTATION - SPECIFICATIONS
Contents: page 6
2. OPERATING PRINCIPLE
Contents: page 14
3. PRODUCT DEVELOPMENT
Contents: page 22
4. TROUBLESHOOTING DIAGRAMS
Contents: page 30
5. CONTROLS AND SETTINGS
Contents: page 50
6. ELECTRICAL DIAGRAMS
Contents: page 102

4

5
1
PRESENTATION
SPECIFICATIONS

6
1
CONTENTS
1. PRESENTATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.1 The various models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.2 Performances in line with RT 2000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.3 Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.3.1 Description and options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.4 Options for the control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2. SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.1 Technical characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.2 Location of the rating plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.3 Characteristics of DHW tanks for MCR 24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.4 Hydraulic specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.4.1 Boiler pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.4.2 Expansion chamber . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

7
1
1. PRESENTATION
The boilers in the VIVADENS range are wall-hung gas condensation boilers, developed and sized for all types of installation. They are
innovative in their modern design and meticulous finish and particularly in their use of state of the art technologies which offer exceptional
performance combining comfort, energy savings and environmental friendliness.
MCR 24, MCR 24/28 MI, MCR 30/35 MI, and MCR 34/39 MI boilers are delivered fully assembled, fully equipped and ready for connection.
Preset to operate on natural gas H, the boilers can also operate on natural gas L and on propane after conversion (and assembly of a
conversion kit package HG31 for the MCR 34/39 MI model).
1.1 The various models
1.2 Performances in line with RT 2000
Boiler Model Power ranges (kW)
Heating only MCR 24 6,3 - 25,3 kW
Heating + instant DHW
MCR 24/28 MI 6,3 - 25,3 kW
MCR 30/35 MI 6,6 - 31,6 kW
MCR 34/39 MI 6,8 - 35,9 kW
Heating + DHW BMR 80 MCR 24/BS 80 6,3 - 25,3 kW
Heating + DHW SR 130 MCR 24/BS 130 6,3 - 25,3 kW
Generator type:
- MCR 24 : Heating only
- MCR 24/28 - 30/35 MI- 34/39 MI: Heating and domestic hot water
Boiler type: Condensation
Burner: Modulating with premixing
Energy used: Natural gas or Propane
Combustion evacuation: Chimney or Forced flue
Min. return temperature: None
Min flow temperature: 20 °C
"EC certificate" reference: PIN 0063BQ3009
C000667
MCR_Q0002MCR_Q0008

8
1
1.3 Control panel
1.3.1 Description and options
MCR boilers are fitted with a simple, user-friendly control panel.
The control panel is used for the ongoing adaptation of "heating" and "DHW" output to need.
The control panel includes the functions:
- antifreeze protection ;
- deblocking of the circulating pump every 25 hours ;
- a troubleshooting system with alarm code display.
The addition of optional equipment optimises the management of your heating installation:
- Room temperature thermostat option ;
- Wire-controlled or wireless programmable room temperature thermostat options ;
- Easymatic wire-controlled or Easyradio wireless remote control options with connection interface for controlling 1 direct circuit or 1
direct circuit with 1 mixing valve circuit ;
- Outside sensor option ;
- Domestic hot water sensor option for optimal management of DHW production.
Heating temperature adjustment key or - Heating temperature setting key or +
Space key or reset Maintenance key or validation key
Pressure
Main ON/OFF switch
Sweep key
Menu key

9
1
1.4 Options for the control panel
Settable ambient thermostat (Package AD 137)
Wireless settable ambient thermostat (Package AD 200)
Non settable ambient thermostat (Package AD 140)
The programmable thermostats handle the regulation and weekly programming of heating by activating the
burner according to various operating modes: "Automatic" depending on programming, "Permanent" at a set
temperatureor"Holidays".The"wireless"versionisdeliveredwithareceiverboxtobeaffixedtothewallclose
to the boiler.
The non-programmable thermostat is used to regulate the room temperature depending on the instruction
given.
Easymatic communicating wire-controlled remote control (Package FM 50)
Easyradio communicating wireless remote control (Package AD 201)
To operate, these remote controls must be complemented by a boiler/remote control "interface" PCB
and an outside sensor.
Easymatic/Easyradio interface for connecting 1 direct circuit Package AD 221 + outside temperature
sensor Package AD 225.
Easymatic/Easyradio interface for connecting 1 direct circuit + 1 mixing valve circuit Package AD 222
+ outside temperature sensor Package AD 225.
Theseremotecontrolshandletheregulationandweeklyprogrammingofyourheatingneedsbyactivatingthe
burnerandthecirculatingpumponthedirectcircuitoronthevalvecircuit(ifconnected)dependingonseveral
operating modes: "Automatic" depending on programming, "Permanent comfort", "Permanent reduced",
"Holidays", or "Summer". Likewise, they handle the regulation and programming of domestic hot water.
Exterior sensor 12 kΩ(Package AD 225)
The outside sensor can be used alone or in combination with room temperature thermostats or
communicatingremotecontrolsforheating regulation depending on theoutsidetemperature.Itis essential in
the case of an installation with circuit with mixing valve.
12 kΩdomestic hot water sensor (Package AD 226)
Thedomestic hotwatersensorisused forthepriorityregulationofDHWproductionusing anindependenthot
water tank. It is required particularly if connecting a BMR 80 or SR 130 tank available as optional equipment
for these boilers.
AD 200
MCR_G003
AD 140
MCR_G006
AD 201
MCR_G007
AD 221
MCR_G008
AD 222
MCR_G009
AD 225
MCR_G010
AD 226
MCR_G011

10
1
2. SPECIFICATIONS
2.1 Technical characteristics
1 mbar = 100 Pa (1 daPa ~ 1 mm H2O)
*Not sold in Italy
Boilers MCR 24 MCR 24/28MI MCR 30/35MI MCR 34/39MI*
Nominal useful output 40/30 °C (Heating mode) (min./max) kW 6.3/25.3 6.3/25.3 6.6/31.6 6.8/35.9
Nominal useful output 80/60 °C (min./max) kW 5.5/23.6 5.5/23.6 5.7/29.5 5.9/33.3
Nominal useful output (DHW mode) (max) kW - 27.4 34.3 38.2
Nominal input power (heating and DHW modes) kW 24/24 24/28 30/35 34/39
Minimum useful output 40/30 °C (Heating mode) kW 6.3 6.3 6.6 6.8
Minimum input power (heating and DHW modes) kW 5.8 5.8 6.1 6.3
Gas flow rate on Pn (at
15°C - 1013 mbar):
Natural gas H m3/h 2.5 2.5 3.2 3.6
Natural gas L m3/h 333.74.2
Propane Kg/h 1.9 1.9 2.3 2.6
PCI efficiency, Load and
water temperature
efficiency:
100% Nominal power, Average temperature:
70 °C
% 98.3 98.3 98.2 98
100% Nominal power, Return temperature: 30 °C % 104.4 104.4 104.4 104.4
30% Nominal power, Return temperature: 30 °C % 108.7 108.7 109.7 110.5
Maximum temperature (Safety thermostat cut-off) °C 110 110 110 110
Stand-by losses (∆T = 30 °C) W30302928
Water content l 1.7 1.8 2 2.2
Weight without water, without mounting frame, without casing kg 29 30.5 32 31.5
Specifications of the heating circuit
Nominal water flow (∆T = 20 K) m3/h 1.03 1.03 1.29 1.47
Rated net head (∆T = 20 K) mbar >250 >250 >200 >200
Flow temperature °C 75 75 75 75
Maximum pressure bar3333
Expansion chamber l888-
Initial pressure of the expansion tank bar111-
Minimum operating pressure bar 0.8 0.8 0.8 0.8
Domestic hot water specifications
Instruction set outlet temperature °C 55 55 55 55
Specific hot water flow (∆T = 30 K) (in accordance with EN 625) l/min - 13.4 15.5 18.2
Nominal max cold water pressure bar8888
Minimum pressure (11 l/min) bar - 0.4 0.4 0.4
Combustion products circuit
Connecting diameter
(mm)
60/100 60/100 60/100 60/100
Mass flue gas flow rate (min./max) Kg/h 10/37 10/47 10/59 10/62
Flue gas temperature 80/60 °C °C 78 78 74 71.5
Pressure available at the flue gas nozzle Pa 50 100 100 140
Condensation water pH 50/30 °C - 1-7 1-7 1-7 1-7
Electrical specifications
Power supply voltage (50 Hz) V 230 230 230 230
Power consumption W 115 115 150 180
Electrical power circulating pump W 90 90 125 135
Auxiliary electrical power (Nominal power, ex circulating pump) W25252545
Insulation class IPX4D IPX4D IPX4D IPX4D

11
1
2.2 Location of the rating plate
Affixed to thelowercover, the ratingplate indicates themaincharac-
teristics of the boiler.
Codes dF and dU on the rating plate should be input in parameters
PdF and PdU to restore the factory settings or if replacing the main
PCB. (See section 5, parameters).
Table of dF and dU codes
2.3 Characteristics of DHW tanks for MCR 24
C000655
De Dietrich Thermique SA. F-67580 MERTZWILLER
0063-06
MCR24
ser. no.:
0608701126100
Pn (80/60°C): 16.7 - 23.6 kW
Pn (50/30°C): 18.0 - 25.0 kW
Qn (Hi): 17.0 - 24.0 kW
PMS 3 bar
PIN: 0063BQ3009
NOx: class 5
230V ~ 50Hz (IPX4D) 115W
B23P, B33, C13, C33, C43,
C53, C63, C83
Gaz naturel - 20 mbar
I2EESI3P
dF:005 dU:004
regulado por:
Preddisposta per:
Ref : 250897411657418
010871380911082402106087011261
MCR_G044
dF code Boiler
dF004 MCR24
dF006 MCR24/28MI
dF007 MCR30/35MI
dF008 MCR34/39MI
dU code Country
dU04 FR
dU05 IT.ES.REST
dU06 BE
dU08 P
DHW tank BMR 80 DHW tank SRL 130
Tank capacity (Domestic hot water) l 80 130
Power exchanged kW 22.6 22.6
Specific flow at ∆T =30 K l/min 16.5 20.0
Flow per hour at ∆T =35 K l/h 555 555
Flow in 10 min. at ∆T =30 K l/10 mm 165 200

12
1
2.4 Hydraulic specifications
2.4.1 Boiler pump
The boiler is fitted with a 2-speed pump, type Grundfos UPS 15-60 (MCR 24, MCR 24/28 MI)or UPS 15-70 (MCR 30/35 MI, MCR 34/39 MI).
The boiler can handle pump operation at full output in domestic hot water mode. For central heating mode, the pump is set to minimum output
by default. Pump output can be increased by setting parameter P21 to 1.
X: Rated net head
Y: Flow rate
: high speed
: Low speed
• MCR 24, MCR 24/28 MI
• MCR 34/39 MI, MCR 34/39 MI
2.4.2 Expansion chamber
Theboilerisfittedasstandardwithan8-litreexpansiontank(Initialpressureoftheexpansiontank1bar).Thetotal water volumeisdetermined
according to the static height of the installation and for an average water temperature of 80°C (Outlet : 80°C; Return : 60°C).
If the water volume is greater than 100 litres or the static height of the system exceeds 5 metres, an additional expansion tank must be fitted.
Pressure: Safety valve 3
Initial pressure of the expansion tank (bar) 0.5 11.5
Total water volume (litres) Volume of the expansion vessel (litres)
100 4.8 8 13.3
125 6 10 16.6
150 7.2 12 20
175 8.4 14 23.3
200 9.6 16 26.6
250 12 20 33.3
300 14.4 24 39.9
To obtain other volumes, multiply the volume of the system by one of the factors: 0.048 0.080 0.133

13
2
OPERATING PRINCIPLE

14
2
CONTENTS
1. MAIN PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.1 Pump logic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1.2 DHW reheating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1.3 Heating slope boiler only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
1.4 Heating slope boiler with regulator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
1.5 Examples of correspondence of the setting heating curve/temperatures . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2. TYPICAL SYSTEMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3. OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.1 Boiler start-up cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

15
2
1. MAIN PARTS
1. Automatic air vent
2. Smoke nozzle
3. Outlet for measuring combustion hygiene
4. Heat exchanger
4bis. Stainless steel burner
5. Air/gaz canal
6. Fan air inlet
7. Gas block
8. Display
9. Control panel
10. Pressure gauge
11. Circulating pump
12. Expansion chamber
(only for MCR 24, MCR 24/28 MI, MCR 30/35 MI)
13. Ignition/ionisation electrode
14. Heating outlet
15. DHW flow
16. Gas connection
17. Drinking water connection
18. Heating return
19. Disconnector
20. Safety valve
21. Plate exchanger
4
4 bis
3
-#2?'
1
5
20
2
12
13
6
7
21
11
9
19
18
17
16
15
14
8
10
9

16
2
1.1 Pump logic
In summer mode
-Inmode(domestichotwater)orwithEasymatic in #mode (Summer), the pump operatesduring the production of domestic hot water.
WithanEasymatic,thepumpshutsdownafterthepumpflowswitch-offdelay (Parameter14).Theheating/domestichotwaterreversalvalve
remains in the DHW position.
In winter mode
With room temperature thermostat
- The pump switches off 2 minutes after the contact of the room temperature thermostat is opened. After the production of domestic hot
water, if the room temperature thermostat is open, the pump switches off after 5 seconds and the heating/domestic hot water reversal
valve remains in the DHW position.
With Easymatic or Easyradio
- When the desired room temperature is not reached, the pump operates continually. When the room temperature is too high, the pump is
shut down after the pump switch-off delay (Parameter 14). If the room temperature is too high after domestic hot water production, the pump
shuts down after the pump switch-off delay; the heating/DHW reversal valve remains in the DHW position.
Boiler antifreeze protection
Antifreeze protection is always guaranteed, whatever the boiler operating mode.
If the temperature of the flow water is less than 7°C, the pump is activated.
If the temperature of the flow water is less than 3°C, the boiler is activated.
If the temperature of the flow water exceeds 10°C, the boiler is shut down and the circulating pump runs for a further 15 minutes.
1.2 DHW reheating
If a room thermostat, connected via connectors 7 and 8, is activated, the boiler will
operate permanently until it reaches the flow setting point.
This function is a protection device for the boiler only, not for the system or buiding
fabric.
ECO Parameter 4 MCR with domestic hot water tank MCR ... MI
Comfort mode OFF 0 Maintains set DHW temperature after a
DHW request, after an ECO on period
and every 70 minutes
Maintains the primary water in the DHW
exchanger at the set DHW temperature
after a DHW request, after an ECO on
period and every 70 minutes
Eco mode ON 1 No reheating No reheating
With control unit AUTO 2 Dependingontheregulatorprogramme,
but without exceeding the DHW setting
in the boiler
Dependingontheregulatorprogramme,
maintains the primary water in the DHW
exchanger at the set DHW temperature
but without exceeding the DHW setting
in the boiler

17
2
1.3 Heating slope boiler only
P1 can be accessed by the user
The connection of an outside sensor is used to regulate the boiler according to the outside temperature.
4 parameters are used to set the heating curve:
- P1 sets the maximum flow temperature (adjustable from 20°C to 85°C). In example above: 75 °C.
- P27 sets the minimum flow temperature (adjustable from 0°C to 60°C). In example above: 20 °C.
- P28 sets the maximum outside temperature (adjustable from 0°C to 40°C). In example above: 20°C.
- P29 sets the minimum outside temperature (adjustable from 0°C to -30°C). In example above: -15 °C.
1.4 Heating slope boiler with regulator
See section 5, § 3.4.3, Parameters 3 and 4.
1.5 Examples of correspondence of the setting heating curve/temperatures
+20 +10 0-10 -20
20
30
40
50
60
70
80
90 3,04,0
y
x
2,0
1,5
1,0
0,7
0,5
2,25
2
1
MCR_G058
Slope P1 P27 P28 P29
0,5 40 20 20 -20
0,7 50 20 20 -20
1602020-20
1,5 75 20 20 -17
2752020-8
2,25 75 20 20 -4
37520202
47520206

18
2
2. TYPICAL SYSTEMS
The installation scenarios presented below do not cover every installation scenario which may be encountered. Their aim is to draw your
attention to the basic rules to be followed; it is the installer's responsibility to decide on the safety and control devices to be fitted to the boiler
according to its specificities.
1Heating outlet
2Heating return
1a Heating flow direct circuit
1b Heating flow valve circuit
2a Heating return direct circuit
2b Heating return valve circuit
8Manual bleed valve
9Isolation valve
10 3-way mixing valve
11b Heating pump for circuit with mixing
valve
21 Outside sensor
23 Mixing valve outlet temperature
sensor (Delivered with the PCB
"package AD222")
27 Non-return valve
28 Domestic cold water inlet
29 Pressure reducer
30
Safety unit set at 7 bar
32 Domestic circulation loop pump
(optional)
33 DHW temperature sensor
44 Thermostat limiting the temperature
to 65°C with manual reset for
underfloor heating (DTU 65,8, NFP
52-303-1)
51 Thermostatic valve
64 Radiator circuit (gentle heat
radiators, for example)
65 Low temperature circuit (underfloor
heating, for example)
68 Condensates neutralisation system
72 Hydraulic bypass
MCR 24 + BMR 80 with 1 direct circuit + 1 domestic hot water circuit, controlled by a
programmable wireless room temperature thermostat + outside sensor
MCR.. MI with 1 direct circuit + 1 circuit with mixing valve, controlled by 1 "Easyradio"
communicating wirelss remote control + specific interface and outside sensor



MRC_F0007
MRC_F0006

19
2
3. OPERATION
3.1 Boiler start-up cycle
- Turn the boiler on. The boiler launches the start-up program.
The display shows F XX: Software version (Example F1.2)
The display shows P XX: Parameter version (Example P1.0)
- Theboilerwill begin anautomaticventing-programm (which lasts approx.3minutes) and will dothiseverytime the powersupply is isolated.
The version numbers are displayed alternately.
- The display shows :
Error code
If the boiler does not operate normally, an error message is displayed (See section 4).
Diagram of the start-up cycle
The cycle cannot be interrupted (ex power cut).
The start-up cycle is followed by burner start-up, with the valve in heating position, for around 10 seconds, then by a shutdown for around 10
seconds.
After this, the cycle is liberated to switch to heating, DHW or shutdown depending on the request.
0 Stand-by
1FanON
2 Boiler is igniting
3 Operation: Heating mode
4 Operation: Domestic hot water mode
5 Wait of 3 to 10 min (flow temperature reached, heating request
subsists)
6 Pump operation (Heating mode)
7 Pump operation (Domestic hot water mode)
8 Wait (Flow temperature > setting + 5°C - See section 4)
9 Stop (Cause malfunction - See section 4)
HEATING
DHW
HEATING
DHW
Burner
45s 90s 135s
Reversal valve
Boiler pump
3
MCR_G045-04

20
2
