DeDietrich ESSENCIO CF 22 User manual

EASYLIFE
S U S T A I N A B L E C O M F O R T ®
MW-2000980-01
en
User Guide
Oil/Gas-fired boiler
ESSENCIO
CF 22
CF 29

Dear Customer,
Thank you very much for buying this appliance.
Please read through the manual carefully before using the product, and keep it in a safe place for later reference. In order to
ensure continued safe and efficient operation we recommend that the product is serviced regularly. Our service and customer
service organisation can assist with this.
We hope you enjoy years of problem-free operation with the product.

Contents
1 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 General safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.2 Specific safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.3 Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.4 Liabilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2 Symbols used . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.1 Symbols used in the manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
2.2 Symbols used on the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3 Technical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.1 Homologations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.1.1 Certifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.1.2 Oil categories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
3.2 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
4 Description of the product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1 General description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
4.2 Boiler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.3 Control panel description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.3.1 Control panel description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
4.3.2 Description of the standby screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.3.3 Description of the home screen (direct access) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
4.3.4 Description of the carousel (quick access) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
5.1 Browsing in the menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.1.1 Zone direct access tree structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.1.2 Main menu quick access tree structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.2 Starting up the boiler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
5.3 Shutting down the boiler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.4 Frost protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6.1 Personalising the control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
6.2 Selecting the operating mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6.3 Managing the central heating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
6.3.1 Switching the central heating on/off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
6.3.2 Changing the room temperature temporarily (override) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
6.3.3 Activating and configuring a timer programme for heating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6.4 Managing domestic hot water production . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6.4.1 Switching domestic hot water production on/off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6.4.2 Forcing domestic hot water production (override) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6.4.3 Modifying the domestic hot water set point temperatures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6.4.4 Activating and configuring a timer programme for domestic hot water production . . . . . . . . . . . . . . . . . . . . 24
6.5 Periods of absence or going on holiday . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
6.6 Personalising the zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6.6.1 Definition of the term "zone" . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6.6.2 Changing the name and symbol of a zone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6.7 Personalising the activities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6.7.1 Definition of the term "Activity" . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
6.7.2 Changing the name of an activity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6.7.3 Setting the activities temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6.8 Monitoring the energy consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
6.9 Version information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
7 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
7.1 General instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
7.2 Configuring the maintenance message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
7.3 Maintenance instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
7.3.1 Check the hydraulic pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
7.3.2 Topping up the installation with water . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
7.3.3 Chimney sweep instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
7.3.4 Chimney mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Contents
7740500 - v02 - 12022021 CFU 3

7.4 Venting the heating system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
7.5 Draining the heating system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
8 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
8.1 Resolving operating errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
8.2 Error codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
8.3 Error codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
8.4 Alarm codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
9 Environmental . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
9.1 Disposal and recycling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
9.2 Energy savings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
10 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
10.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
10.2 Terms of warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
11 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
11.1 Product fiche . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
11.2 Product fiche - Temperature controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
11.3 Product fiche . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Contents
4 CFU 7740500 - v02 - 12022021

1 Safety
1.1 General safety instructions
Tab.1
Operation Danger
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the ap
pliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervi
sion.
1 Safety
7740500 - v02 - 12022021 CFU 5

1.2 Specific safety instructions
Tab.2
Electrical Danger of electric shock
Before any work, switch off the mains supply to the boiler.
Caution
A disconnection method must be allowed in the fixed pipes in
accordance with the rules on installation in force in the coun
try.
Caution
The boiler must always be connected to the protective
earthing.
Earthing must comply with the prevailing installation stand
ards.
Earth the appliance before making any electrical connec
tions.
For the type and calibre of the protective equipment, refer to
the chapter Electrical Connections in the Installation and
Service Manual.
Caution
If a power cord comes with the appliance and it turns out to
be damaged, it must be replaced by the manufacturer, its af
ter sales service or persons with similar qualifications in order
to obviate any danger.
Tab.3
Other
coun
tries
Only qualified professionals are permitted access to the inside of
the appliance, in accordance with the prevailing electrical safety
standard.
Caution
Power the appliance via a circuit that includes an omnipolar
switch with contact opening distance of 3 mm or more.
1 Safety
6 CFU 7740500 - v02 - 12022021

Accessibility Important
Keep the boiler accessible at all times.
Caution
Install the boiler in a frost-free environment.
Important
Allow the space required to correctly install the boiler. Refer
to the Overall space needed for the boiler section in the in
stallation and service manual.
Important
Never remove or cover labels and data plates affixed to the
boiler.
Labels and data plates must be legible throughout the entire
lifetime of the boiler. Immediately replace damaged or illegi
ble instructions and warning labels.
Hydraulics Important
Respect the minimum and maximum water inlet pressure to
ensure correct operation of the boiler: refer to the chapter
Technical Specifications.
Warning
Regularly check the presence of water and pressure in the
heating system.
Installation Caution
The installation must comply in all matters with the standards
and rules (DTU, EN and others) which govern works and in
terventions in individual homes, blocks of flats and other con
structions.
Important
Only qualified professionals are permitted to install the boiler,
in accordance with prevailing local and national regulations.
Caution
Have the boiler and heating system drained by a qualified
professional if the home is left empty for a long period of time
and there is a chance of frost.
1 Safety
7740500 - v02 - 12022021 CFU 7

Temperature Caution
Do not touch the flue gas pipes. Depending on the boiler set
tings, the temperature of the flue gas pipes can rise to over
60°C.
Caution
Do not touch radiators for long periods. Depending on the
boiler settings, the temperature of the radiators may exceed
60 °C.
Caution
Take precautions with the domestic hot water. Depending on
the boiler settings, the domestic hot water temperature may
exceed 65°C.
Important
Insulate the pipes in the system to reduce heat losses.
Flue gas smell Danger
If you smell flue gases:
1. Switch off the appliance.
2. Open the windows.
3. Evacuate the property.
4. Contact a qualified professional.
Maintenance Caution
Only qualified professionals are authorised to carry out main
tenance work on the boiler and the heating system.
Caution
Do not neglect to service the boiler. Contact a qualified pro
fessional or take out a maintenance contract for the obligatory
annual servicing of the boiler.
Caution
Remove the boiler casing only to perform maintenance and
repair work. Always put the casing back in place after such
work.
Caution
Before any work, switch off the boiler's power supply and
main oil supply.
1 Safety
8 CFU 7740500 - v02 - 12022021

1.3 Recommendations
Important
Keep this document close to the place where the appliance is
installed.
Important
This manual can also be found on our internet site.
1.4 Liabilities
Tab.4
Manufacturer's liability Our products are manufactured in compliance with the requirements of the various Di
rectives applicable. They are therefore delivered with the marking and any docu
ments necessary. In the interests of the quality of our products, we strive constantly to
improve them. We therefore reserve the right to modify the specifications given in this
document.
Our liability as manufacturer may not be invoked in the following cases:
Failure to abide by the instructions on installing the appliance.
Failure to abide by the instructions on using the appliance.
Faulty or insufficient maintenance of the appliance.
Installer's liability The installer is responsible for the installation and initial commissioning of the appliance.
The installer must observe the following instructions:
Read and follow the instructions given in the manuals provided with the appliance.
Install the appliance in compliance with prevailing legislation and standards.
Carry out initial commissioning and any checks necessary.
Explain the installation to the user.
If maintenance is necessary, warn the user of the obligation to check the appliance
and keep it in good working order.
Give all the instruction manuals to the user.
User's liability To guarantee optimum operation of the system, the user must abide by the following in
structions:
Read and follow the instructions given in the manuals provided with the appliance.
Call on a qualified professional to carry out installation and initial commissioning.
Ask your installer to explain your installation to you.
Have the required inspections and maintenance carried out by a qualified installer.
Keep the instruction manuals in good condition close to the appliance.
1 Safety
7740500 - v02 - 12022021 CFU 9

2 Symbols used
2.1 Symbols used in the manual
This manual uses various danger levels to draw attention to special
instructions. We do this to improve user safety, to prevent problems and to
guarantee correct operation of the appliance.
Danger
Risk of dangerous situations that may result in serious personal
injury.
Danger of electric shock
Risk of electric shock.
Warning
Risk of dangerous situations that may result in minor personal
injury.
Caution
Risk of material damage.
Important
Please note: important information.
See
Reference to other manuals or pages in this manual.
2.2 Symbols used on the appliance
1Alternating current.
2Protective earthing.
3Before installing and commissioning the appliance, carefully read
the instruction manuals provided.
4Dispose of used products through an appropriate recovery and
recycling structure.
5Caution: danger of electric shock, live parts. Disconnect the mains
power prior to carrying out any work.
6Connect the appliance to the protective earthing.
Fig.1
1 2
MW-1000123-2
1
2
3
4
5
6
2 Symbols used
10 CFU 7740500 - v02 - 12022021

3 Technical specifications
3.1 Homologations
3.1.1 Certifications
The boiler complies with current standards.
CE identification number: 0085CQ0004
3.1.2 Oil categories
Tab.5
Type of oil that can be used Maximum viscosity
Domestic fuel oil with a low sulphur content (< 50 mg/kg) (EL). 6 mm2/s at 20 °C
Domestic fuel oil with a low sulphur content with up to 10% (< 50 mg/kg) of EMAG(1) (FAME) added (EL
Bio 10).
6 mm2/s at 20 °C
Non-road or off-road diesel (NRD)
Non-road diesel which may contain up to 7% of EMAG (1)
Important
To be used exclusively for a boiler fitted with a burner with a preheater.
6 mm2/s at 20 °C
Domestic fuel oil with a low sulphur content (< 2000 mg/kg) which may contain up to 7% of EMAG(1)
(FAME).
6 mm2/s at 20 °C
(1) Fatty Acid Methyl Ester (FAME)
3.2 Technical data
Tab.6 Burner specifications
Unit CF 22 CF 29
Burner type F10N3–1.22 F10N3–1.29
Oil flow rate kg/h 2.02 2.69
3 Technical specifications
7740500 - v02 - 12022021 CFU 11

4 Description of the product
4.1 General description
The floor-standing oil boilers in the CFU range have the following
specifications:
Heating only with possibility to produce domestic hot water by combining
them with a domestic hot water tank
High-efficiency heating
Low polluting emissions
Heating body in cast iron
Electronic control panel
Chimney connection: Flue gas discharge via a chimney type connection
Forced flue connection: Flue gas evacuation via a forced flue connection
with combustion air supply kit
4.2 Boiler
1Control panel
2On/Off switch
3Data plate
4.3 Control panel description
4.3.1 Control panel description
The control panel allows the end user, chimney sweep or installer to
configure the boiler for central heating and domestic hot water production.
1Back key
2Main menu key
3Display
4Selector
4.3.2 Description of the standby screen
The standby screen is active if no key on the control panel is pressed
within 5 minutes, and the backlight will go out.
Fig.2
MW-5000484-1
1
2
3
Fig.3
MW-5000915-1
1
3
4
2
4 Description of the product
12 CFU 7740500 - v02 - 12022021

1Temperature measured by the outdoor temperature sensor (if
present)
2Day and time
3General boiler status
4Icons indicating the boiler status
Tab.7 Icons indicating the boiler status
Icons Description
Steady icon: heating function activated
Flashing icon: heating production running
Steady icon: domestic hot water production function activated
Flashing icon: domestic hot water production running
Frost protection activated
Summer mode activated, no heating possible
Error
Chimney-sweeping mode activated
Installer level activated
4.3.3 Description of the home screen (direct access)
The home screen has several pages. Each page enables direct access to
a zone.
Display the home screen by turning the selector to the right.
All the zone symbols and names can be changed.
1Boiler symbol
2Boiler flow temperature
3Outdoor temperature symbol
4Day and time
5Outdoor temperature
6Boiler status
7Active page
1Temperature of the Zone1 (only if a room temperature sensor is
present in the zone)
2Outdoor temperature
3 Zone1 name
4Day and time
5Operating mode
6 Zone1 status
7Active page
8 Zone1 symbol
Fig.4
1 2
3
4
MW-2001059-1
SYSTEME OK
Monday 11:51
14.1°
Fig.5 Main home screen
MW-5000944-1
123
5
4
76
Monday 11:19
Appliance status:Burning CH
Fig.6 Zone1 home screen
MW-5000945-2
1234
5
6
78
Monday 11:20
3.8
21 TP1:confort 20.0 22h00
State : Heating
Zone1
4 Description of the product
7740500 - v02 - 12022021 CFU 13

1Temperature of the Zone2 (only if a room temperature sensor is
present in the zone)
2Outdoor temperature
3 Zone2 name
4Day and time
5Operating mode
6 Zone2 status
7Active page
8 Zone2 symbol
1Symbol for domestic hot water
2Outdoor temperature
3Name for domestic hot water
4Day and time
5Operating mode
6Status for domestic hot water
7Active page
4.3.4 Description of the carousel (quick access)
The carousel is used to quickly access the main control panel menu.
Display the carousel by pressing the Main menu key .
Scroll through the menu from right to left by turning the selector .
Tab.8
Accessible
menus
Description See
Chapter
Central heating On/Off Switching the central heating on/off
Domestic Hot Water On/Off Switching domestic hot water production on/off
Heating temperature Setting the activities temperature
Water temperature Modifying the domestic hot water set point temperatures
Temporary heating temperature change Changing the room temperature temporarily
Hot water boost Forcing domestic hot water production (override)
System holiday mode Periods of absence or going on holiday
Fig.7 Zone2 home screen (only if the
SCB-04 optional PCB is connected)
MW-5000946-2
1 2 3 4
5
78
3.8°
State : Heating
Zone2
19°
6
TP1:confort 20.0° 22h00
Monday 11:20
Fig.8 Home screen for the domestic hot
water page (only if the domestic hot
water sensor is connected)
MW-5000947-1
1 2 3 4
5
6
7
State : Standby
Domestic Hot Water
TP1:on 55 22h00
Monday 11:20
3.8
Fig.9
MW-5000948-1
Installer
4 Description of the product
14 CFU 7740500 - v02 - 12022021

Accessible
menus
Description See
Chapter
User settings
Zones settings Changing the name and symbol of a zone
Domestic Hot Water settings Modifying the domestic hot water set point temperatures
CH function on Switching the central heating on/off
DHW function on Switching domestic hot water production on/off
Outdoor temperature Force summer mode: The heating is stopped. Hot water is
maintained. Force Summer Mode
0 =Off
1 =On
Summer Winter: Outside temperature below which the
antifreeze protection is activated
Can be set from 15 °C to 30.5 °C
Energy counter Monitoring the energy consumption
System holiday mode Periods of absence or going on holiday
Test mode Chimney mode
Installer Menu not accessible to the user
Finder Menu not accessible to the user
Signals status set points Menu not accessible to the user
Energy counter Monitoring the energy consumption
Settings Personalising the control panel
Version information Version information
4 Description of the product
7740500 - v02 - 12022021 CFU 15

5 Operation
5.1 Browsing in the menus
Press any key or turn the selector to turn on the backlight for the control
panel screen.
Important
If no key is pressed for 3 minutes, the control panel backlight will
go out.
Press the key to access the main menu.
Turn the selector to select:
a menu,
a page on the home screen,
a parameter,
a setting.
Press the selector to confirm:
a menu,
a page on the home screen,
a parameter,
a setting.
Press the return key as many times as necessary to return to the home
screen.
Press and hold the back key to return to the home screen.
5.1.1 Zone direct access tree structure
Tab.9
Type of access Access path
Direct access: from the main home screen → Press the selector
→ Turn the selector to access the various zones
Quick access: from any screen Not available
Fig.10 Standby screen
MW-5000949-2
Monday 11:19
3.8
SYSTEM OK
Fig.11 Access to main menu
MW-5000924-1
Fig.12 Selection
MW-5000921-1
Fig.13 Confirmation
MW-5000922-1
Fig.14 Back to home screen
MW-5000923-1
5 Operation
16 CFU 7740500 - v02 - 12022021

Tab.10
Display Available parameters See
Chapter
Main home screen System holiday mode Periods of absence or going on holiday
CH function on Switching the central heating on/off
DHW function on Switching domestic hot water production on/off
Forced summer On/Off Personalising the control panel
Zone1 Set heating temperatures Setting the temperatures for the activities
Operating mode Selecting the operating mode
Time programmes heating Activating and configuring a timer programme
Zone2 (only if the
SCB-04 optional PCB is
connected)
Set heating temperatures Setting the temperatures for the activities
Operating mode Selecting the operating mode
Time programmes heating Activating and configuring a timer programme
Domestic hot water Set heating temperatures Setting the temperatures for the activities
Operating mode Selecting the operating mode
Time programmes heating Activating and configuring a timer programme
5.1.2 Main menu quick access tree structure
Tab.11
Type of access Access path
Direct access: from the main home screen Not available
Quick access: from any screen → Press the key
→ Turn the selector to access the various menus
Tab.12
Accessible
menus
Description See
Chapter
Central heating On/Off
Off
On
Switching the central heating on/off
Domestic Hot Water On/Off
Off
On
Switching domestic hot water production on/off
Heating temperature
Zone1
Zone2 (only if the SCB-04 optional PCB is con
nected)
Setting the activities temperature
Water temperature
DHW comfort setpoint
DHW reduced setpoint
Modifying the domestic hot water set point temperatures
Temporary heating temperature change
Zone1
Zone2 (only if the SCB-04 optional PCB is con
nected)
Changing the room temperature temporarily
Hot water boost Forcing domestic hot water production (override)
System holiday mode Periods of absence or going on holiday
5 Operation
7740500 - v02 - 12022021 CFU 17

Accessible
menus
Description See
Chapter
User settings
Zones settings Changing the name and symbol of a zone
Domestic Hot Water settings Modifying the domestic hot water set point temperatures
CH function on Switching the central heating on/off
DHW function on Switching domestic hot water production on/off
Outdoor temperature Force summer mode: The heating is stopped. Hot water is
maintained. Force Summer Mode
0 =Off
1 =On
Summer Winter: Outside temperature below which the
antifreeze protection is activated
Can be set from 15 °C to 30.5 °C
Energy counter Monitoring the energy consumption
System holiday mode Periods of absence or going on holiday
Test mode Chimney mode
Installer Menu not accessible to the user
Finder Menu not accessible to the user
Signals status setpoints Menu not accessible to the user
Energy counter Monitoring the energy consumption
System settings Personalising the control panel
Version information Version information
5.2 Starting up the boiler
1. Check that the storage tank is filled with fuel.
2. Open the oil inlet valve.
3. Switch on the boiler.
4. Check the hydraulic pressure in the installation indicated on the user
interface.
Important
Recommended hydraulic pressure between 0.15 and 0.2 MPa
(1.5 and 2.0 bar).
5. Confirm the selection by pressing the selector .
If the boiler is connected to a domestic hot water tank, the boiler
begins an automatic venting cycle that lasts around 3 minutes and
is repeated each time the power is cut. If there is a problem, an
error message is displayed on the home screen.
6. If an error message is displayed on the home screen, contact the
installer.
5.3 Shutting down the boiler
The boiler must be shut down in certain situations, for example during any
intervention on the equipment. In other situations, such as an extended
absence period, we recommend that the System holiday mode
operating mode is used in order to benefit from the boiler anti-blocking
function and to protect the installation from frost.
To shut down the boiler:
1. Switch off the boiler.
5 Operation
18 CFU 7740500 - v02 - 12022021

For more information, see
Selecting the operating mode, page 20
Periods of absence or going on holiday, page 24
5.4 Frost protection
Caution
The frost protection function does not work if the boiler is powered
off.
Caution
The integrated protection system only protects the boiler, not the
heating system.
Caution
Have the boiler and heating system drained by a qualified
professional if the home is left empty for a long period of time and
there is a chance of frost.
Important
To prevent the radiators and the installation from freezing in
places where that risk exists (e.g. in a garage or an equipment
room), we recommend connecting an outdoor temperature sensor
to the boiler.
If the temperature of the water in the boiler falls too much, the integrated
protection device switches itself on. This device functions as follows:
Tab.13
Water tem
perature
Operating description
< 7 °C The circulating pump starts up and shuts down if the water temperature is higher than 10 °C. The circulating
pump continues to run for a short time.
< 4°C The boiler starts up and shuts down if the water temperature is higher than 35 °C.
5 Operation
7740500 - v02 - 12022021 CFU 19

6 Settings
6.1 Personalising the control panel
It is possible to personalise the control panel by modifying the basic
settings.
1. Go to the menu: System settings.
Tab.14
Type of access Access path
Direct access: from the main home screen Not available
Quick access: from any screen → Press the key
→ Select: System settings
2. Carry out one of the following operations:
Tab.15
Menu Parameter Description
Country and language Select country
Select language
Date and time AP082 Setting the date and time
year
month
day
hours
minutes
Enable daylight save : Enable daylight saving for the system to save energy during
winter
Installer details AP089 Installer name : Change the installer's name
AP090 Installer phone : Change the installer's phone number
Activity names Select one of the following activities:
Sleep
Home
Away
Morning
Evening
Custom
Modify the name of activities used to program heating periods
Display settings AP104 HMI contrast value: Setting the screen brightness
AP105 Unit displayed: Selecting the unit displayed
0 for °C
1 for °F
AP124 Child lock: Prevents children from accidentally altering the unit settings.
no = Screen locked
yes = Screen unlocked
3. Confirm by pressing the selector to save the setting.
4. Go back to the main screen by pressing the back key .
6.2 Selecting the operating mode
One of 5 operating modes can be selected for each zone.
The recommended operating mode is Programming mode, which allows:
the room temperature to be regulated as required
the domestic hot water production periods to be programmed as
required
energy consumption to be optimised.
6 Settings
20 CFU 7740500 - v02 - 12022021
