DeDietrich KDLV326J2 User manual

KDLV326J2

If you cannotsolve the problemsby yourself,
please ask for help from a professional technician.
To review
1
1
1
2
2
2
2
2
2
2
2
2
7
7
8
19
19
0
2
2
3
5
5
6
6
27
28
4

1

2

3
tableware with sharp points
13

4

Press the program button for more than 3 seconds to cancel the running program.
Refer to the section entitled "Preparing and loading dishes".
(see the section entitled "Operation instruction")
When the working cycle has finished, then stop. Turn off the appliance using On/Off button.
Scrap off any large amount of leftover food.
Soften remnants of burned food in pans, then load the baskets.
Refer to the dishwasher loading instruction.
5
(Follow the user instructions!)
Open the flap(marked with A), fill in the main wash detergent , and then close the flap;
Pre wash detergent drop into the tank directly;
Refill the rinse aid through the hole below the cap(marked with B)
If you need .
A
B
Open the door, press the program button until the selected program lights up.

3. Operating instructions
Control Panel
before using it for the first time.
To get the best performance from your dishwasher, read all operating instructions
IMPORTANT
6
• Manual pre-rinsing of tableware items leads to increased water and energy consumption and is not recommended
• Washing tableware in a household dishwasher usually consumes less energy and water in the use phase than hand
dishwashing when the household dishwasher is used according to the manufacturer’s instructions.
15 23 4 9
678
10
1.On/Off Button: To turn on/off the power supply.
2.Delay Button :
5.Salt and rinse aid warning indicators: To show
when the salt container or dispenser need to be
refilled
7.Program indicators: To show which program
4.Delay indicators: To show the delay time
(3H/6H/9H/12H )
3.Power indicator: To show when the power is on.
6.
8.Washing one selection button: Press the button
to select either upper or lower basket.
To delay the start of a washing program.
Intensive wash program indicator
Glass wash program indicator
ECO wash program indicator
1 hour wash program indicator
Rapid wash program indicator
ECO
1H
BOOST
has been chosen.
Washing zone indicator: To show which basket has
been selected.
Auto program indicator
z
3h and 9h light up at the same time to
represent 12h.
9. Program Button : Press the button to select a
wash program.
10. Auto Open function indicator:
The dishwasher door will open automatically before the program
finishes and it would last till the end of the program in order to
achieve better drying result.
The factory setting of the Auto Open is on by default. Press the
Washing zone selection button and Program Button at the same time
for 3 seconds to select or cancel the Auto open function. When
cancel the setting,the setting is saved after turning off the
dishwasher. It can not be selected in combination with Rapid .

The water softener must be set manually, using the water hardness dial.
The water softener is designedto remove mineralsand salts fromthe water,which would have
a detrimental or adverse effect on the operation of the appliance.
The higher thecontent of these minerals and salts, the harder your water is.
The softener shouldbe adjusted accordingto the hardnessof the waterin your area.Yourlocal WaterAuthority
can advise you on the hardness of the water in your area.
Adjusting Salt Consumption
The dishwasher is designed to allow for adjustment in the amount of salt consumed based on the hardness of
the water used.This is intended to optimiseand customise thelevel o fsalt consumption.
1. Open the door ,Switch on the appliance;
2. Press the button for morethan seconds to startthe water softener
set model within 60seconds after the appliance was switched on(
);
3. Press the button to selectthe proper setaccording to yourlocal environment,
the sets will change in the following sequence: H1->H2->H3->H4->H5->H6;
4. Press the button to end the set up model.
Program 5
The Salt
warninglights will be on periodically when it get in the set model
Program
Power
WATER SOFTENER
The hardness of the water varies from place to place. If hard water is used in the dishwasher, deposits will
form on the dishes and utensils.
The appliance is equipped with a special softener that uses a salt container specifically designed to eliminate
lime and minerals from the water.
4.Prior using for the first time4.Prior using for the first time
Contact your local water board for information on the hardness of your water supply.
dH
mmol/l
0~90~5 0~0.94 H1( Rapid Light bright) 0
10-20
6-11 1.0-2.0 H2( ight bright) 9
21-30
12-17 2.1-3.0
H3( Rapid Light bright)
12
H4( ight bright) 20
fH
0~6
7-14
15-21
Clarke
WATER HARDNESS
Selector Position Salt consumption
(gram/cycle)
Please follow the steps below for adjustment in salt consumption.
18-22 31-40 22-28 3.1-4.0
A. Water SoftenerA. Water Softener
NOTE:NOTE:
If your model does not have any water softener, you may skip this section.
¡ã
Clark: British degree
¡ã
fH: French degree
¡ã
DH: German degree
Note:1Note:1 dH=1.25 Clarke=1.78 fH=0.178mmol/l
¡ã
¡ã
¡ã
1
41-60
23-34 4.1-6.0 H5( Rapid Light bright) 30
H6( ight bright) 60
29-42
35-55 61-98 43-69 6.1-9.8
Note:2Note:2
The manufactory setting: H3
Before using your dishwasher for the first time:
A. Set the water softener
B. Add 1.5kg dishwashersalt and thenfull fill thesalt container withwater
C. Fill the rinse aid dispenser
D. Fill in detergent
7
Glass L
Glass
ECO L
ECO
ECO Glass L

1. The salt container mustonly be refilledwhen the saltwarning light inthe control panelcomes on.
Depending on howwell the saltdissolves, the saltwarning light maystill be oneven though the
salt container isfilled.
If there isno salt warninglight in thecontrol panel (forsome Models),you canestimate when tofill
the salt intothe softener bythe cycles thatthe dishwasher hasrun.
2. If thereare spills ofthe salt, asoak or arapid program shouldbe run toremove the excessivesalt.
Always use the salt intended for use with dishwasher.
The salt container is located beneath the lower basket and should be filled as explained
in the following:
Attention!
Only use salt specifically designed for the use in dishwashers! Every other type of
salt not specifically designed for the use in a dishwasher, especially table salt, will
damage the water softener. Incase of damages caused by the use of unsuitable
salt the manufacturer does not give any warranty nor is liable for any damages caused.
Only fill with salt just before starting one of the complete washing programs.
This will prevent any grains of salt or salty water, which may have been spilled,
remaining on the bottom of the machine for any period of time, which may cause
corrosion.
B. Loading the Salt Into the SoftenerB. Loading the Salt Into the Softener
NOTE:NOTE:
Full fill the salt container with water,It is normal for a small amount of water to come out of the
salt container.
11
22
A After the lower basket has been removed, unscrew and remove the cap from the salt container.
BPlace the end of the funnel (supplied) into the hole and introduce about 1.5kg of dishwasher salt.
C
D After filling the container , screw the cap tightly back clockwise.
E The salt warning light will stop being after the salt container has been filled with salt.
FImmediately after filling the salt into the salt container, a washing program should be started (We suggest to use a short
program). Otherwise the filter system, pump or other important parts of the machine may be damaged
by salty water. This is out of warranty.
1122
OpenOpen
8

Adjust ing t he rinse aid r eservoir
To achieve a better drying performance with limited rinse aid, the dishwasher is
designed to adjust the consumption by user. Follow the below steps.
Open the door and switch on the appliance.
Within 60 seconds after step 1, press the Program button more than 5 seconds,
and then press the Delay button to enter the set model, the rinse aid indication
Press the Program button to select the proper set according to your using habits,
the sets will change in the following sequence: D1->D2->D3->D4->D5->D1.
The higher the number, the more rinse aid the dishwasher uses.
Without operation in 5 seconds or press the Power button to complete the setup
and exit the setup mode.
Close the cap after all.
Remove the rinse reservoir cap by
lifting up the handle .
Pour the rinse aid into the dispenser,
being careful not to overfill.
D1
D2
D3
D4
D5
Selector positionRinse aid level
Rapid Light bright
Light bright
, Rapid Light bright
ECO
ECO
blinks as 1Hz frequency.
Glass Light bright
Glass, Rapid Light bright

Filling The Detergent Dispenser

Please choose an open way according
to the actual situationC
1 Open the cap by sliding the release
catch.
1 Open the cap by pressing down the
release catch.
Add detergent into the larger cavity
(A) for the main wash cycle .
For better cleaning result, especially if
you have very dirt items, pour a small
amount of detergent onto the door.
The additional detergent will activate
during the pre-wash phase.
Close the flap by sliding it to the
front and then pressing it down.
"



3

Be aware that depending on the soiling of water, setting may be different.
Please observe the manufacturer's recommendations on the detergent packaging.


Based on their chemical composition, detergents can be split in two basic types:
Detergent tablets of different brands dissolve at different speeds. For this reason some
detergent tablets cannot dissolve and develop their full cleaning power during short
programs. Therefore please use long programs when using detergent tablets, to
ensure the complete removal of detergent residuals.
The dispenser must be refilled before the start of each wash cycle following the instructions
provided in the wash cycle table . Your dishwasher uses less detergent and rinse aid than
Conventional dishwasher. Generally, only one tablespoon of detergent is needed for
a normal wash load. More heavily soiled items need more detergent. Always add the
detergent just before starting the dishwasher, otherwise it could get damp and will not
dissolve properly.
Concentrated Detergent
Detergent Tablets
Detergent Dispenser
conventional, alkaline detergents with caustic components
low alkaline concentrated detergents with natural enzymes
Normally new pulverised detergent is without phosphate. Thus the water softener function of
phosphate is not given. In this case we recommend to fill salt in the salt container even when
the hardness of water is only 6 °dH. If detergents without phosphate are used in the case of hard water
often white spots appear on dishes and glasses. In this case please add more detergent to reach
better results. Detergents without chlorine do only bleach a little. Strong and coloured spots will not
be removed completely. In this case please choose a program with a higher temperature.
Detergents
There are 3 sorts of detergents
1.With phosphate and with chlorine
2.With phosphate and without chlorine
3.Without phosphate and without chlorine
Detergents with its chemical ingredients are necessary to remove dirt, crush dirt and transport it out of the dishwasher.
Most of the commercial quality detergents are suitable for this purpose.
D. Function of Detergent
Proper Use of Detergent
Use only detergent specifically made for the use in dishwashers. Keep your detergent fresh and dry.
Don't put powdered detergent into the dispenser until you're ready to wash dishes.
Attention!

placed in
4.
For washing in the dishwasher the following cutlery/dishesFor washing in the dishwasher the following cutlery/dishes
Cutlery with wooden, horn china or
mother-of-pearl handles
Plastic items that are not heat resistant
Older cutlery with glued parts that are not
temperature resistant
Bonded cutlery items or dishes
Pewter or copperitems
Crystal glass
Steel items subject to rusting
Wooden platters
Items made from synthetic fibres
Some types ofglasses can become
dull after a large number of washes
Silver and aluminumparts have a
tendency to discolour during washing
Glazed patterns may fade if machine
washed frequently
Are not suitable Are of limited suitability
Dishes and items of cutlery must not lie inside one another, or cover each other.
To avoid damage to glasses, they must not touch each other.
Load large itemswhich are mostdifficult to clean into thelower basket.
The upper basket is designed to hold more delicate and lighter dishware such as glasses, coffee
and tea cups
Long bladed knives stored in an upright position are a potential hazard!
Long and/or sharp items of cutlery such as carving knives must be positioned
horizontally in theupper basket.
Please do not overload your dishwasher. This is important for good results and for
reasonable consumption of energy.
Load hollow itemssuch as cups,glasses, pans etc.With the openingfacing downwards sothat
water cannot collect in the container or a deep base.
RecommendationRecommendation
Consider buying tableware which is identified as diswasher-proof.
Use a mild detergent that is described as 'kind to dishes'. If necessary, seek further
information from thedetergent manufacturers.
For particular items, select a program with as low a temperature as possible.
To prevent damage, do not take glass and cutlery out of the dishwasher immediately
after the programme has ended.
(For best performance of the dishwasher, followthese loading guidelines.
Features and appearanceof baskets andcutlery baskets may vary from your model.)
Scrape off any large amounts of leftover food. Soften remnants of burnt food in pans.
It is not necessary to rinse the dishes under running water.
Place objects inthe dishwasher infollowing way:
1.Items such as cups, glasses, pots/pans, etc. are faced downwards.
2.Curved items,or ones withrecesses, should beloaded aslant so that water can run off.
3. stacked securely and can not tip over.
the way that the sprayarms can rotat e freely during washing.
NOTE:NOTE:
Very smallitems should notbe washed inthe dishwasher as they could easily fall out of the basket.
Attention before or after loading the Dishwasher BasketsAttention before or after loading the Dishwasher Baskets
Toprevent water drippingfrom the upper basket into the lower basket, we recommend that you
empty the lowerbasket first andthen the upperbasket.
Removing the DishesRemoving the Dishes
12
Tableware is
Tableware is
5.Preparing and loading dishes

Lift the basket for higher position Lift the handle to lower the basket
For better stacking of pots and pans,the spikes can be folded
down as shown on the picture below.
13
To make room for taller items in the upper basket, raise the
You can then lean the tall glasses against
required for use.
cup rack upwards.
it. You can also remove it when it is not

*EN 6 : This programme is thetest cycle. The information forcomparability test
in accordance withEN , asfollows:
Position Upper basket: upper wheels on rails
Rinse aid setting: 5
Po:0.49W
Turning On the ApplianceTurning On the Appliance
Starting a cyclewash
Draw out thelower and upperbasket, load thedishes and pushthem back.
It is commendedto load the
lower basket first,then the upperone (see the section entitled
Pour in thedetergent (see thesection entitled
Insert the pluginto the socket.The power supply is 220-240 VAC /50 Hz, thespecification
of the socketis 10A 250VAC. Make sure thatthe water supplyis turned onto full pressure.
Open the door, press theON/OFF Button, andthe ON/OFF lightwill turn on.
Press the program Button , the wash program will be changed as follows direction:
ECO->Glass->Rapid->Intensive->Auto->ECO;
If a programis selected, theresponse light willlight. Then close the door, the dishwasher
1
2
3
4
5
14
"Preparing and loading dishes"). “Prior to first time use").
will start the selected washing cycle.
Capacity: 13 settings
Values other than the ECO program are purely indicative.
60436
60436
NOTE:NOTE:
Wash Cycle TableWash Cycle Table
NOTE:NOTE:
Means: need to fill rinse into the Rinse-Aid Dispenser.
( )
6.Starting a washing program6.Starting a washing program
Detergent
Detergent
pre/mai
pre/main
n
Cycle SelectioCycle Selectionn
InforInformatimationon
ProgramProgram
Intensive
Auto
)
RunningRunning
timetime(min)(min) WaWaterter
(L)(L)
Energy
Energy
(kWh)
AidAid
Rapid
DescDescriptioriptionn
ofof CycleCycle
Glass
Auto sensing wash, lightly,
normally or heavily soiled
crockery, with or with out
dried-on food.
For heaviest soiled crockery,
and normally soiled pots
pans dishes etc with dried
on soiling.
For lightly soiled loads that
do not need excellent drying
efficiency.
A shorter wash for lightly
soiled loads and quick wash.
For lightly soiled
crockery and glass.
(1or2 pieces)
Wash (40 )
Rinse
Rinse (55 )
198
30
1.651
0.781
16.5
10.6-15.9
10
11
Wash(55 )
Rinse
Rinse (50 )
Drying
60 11.5
Pre-wash
wash(50 )
Rinse
Rinse(50 )
Drying
120
0.902 13.5
Prewash 50
Wash 65
Rinse
Rinse
Rinse
Drying
Prewash(45 )
Wash(55-65 )
Rinse
Rinse
Rinse (50-55 )
Drying
Wash (50 )
Rinse(50 )
Drying
This is standard programme, it is
suitable to clean normally soiled
tableware and it is the most efficient
programme interms of itscombined
energy and water consumption for
that type of tableware.
60 min
0.836
Rinse
(40 )
(40 )
60
205
85-150
0.853
1.05-1.551
(1or2 pieces)
(1or2 pieces)
(1or2 pieces)
(1 piece)
(1 piece)
4/18g
4/18g
4/18g
22g
22g
12g
(*EN
60436
RinseRinse
Running
time(min)
(2)
220
85-150
208
120
60
15
Running time (min) :choose the function of auto open
(2)
Running time (min) :cancel the function of auto open
(1)
BOOST
1H
(1)

“Filling the detergent dispenser”
The program light will be off after the program finishes.

NOTE:
Indicator lamp function
The Indicator lamp will be lit up during the washing program, then
blink for 5 minutes and extinguished on the end of the program.
16
The dishwasher door will open automatically before the program finishes and it
would last till the end of the program in order to achieve better drying result.
NOTE:
The dishwasher door must not be blocked when set to open automatically.
This can disrupt door lock functionality.
Auto Open Door
Function Of Floor Indicator Lamp

OpenOpen
to be drained
Micro-filter
17

The control panel can be cleaned by using a lightly dampened cloth.
After cleaning, make sure to dry it thoroughly.
For the exterior, use a good appliance polish wax.
Never use sharp objects, scouring pads or harsh cleaners on any part of the dishwasher.
Protect AgainstFreezing
1.Cut off the electrical power to the dishwasher.
2.Turn off the water supply and disconnect the water inlet pipe from the water valve.
3.Drain thewater from the inlet pipe and water valve. (Use a pan to gather the water)
4.Reconnect the water inlet pipe to the water valve.
5.Remove thefilter at the bottom of the tub and use a sponge to soak up water in the sump.
please take frostprotection measures onthe dishwasher inwinter. Everytime after washing cycles,
please operate as follows
Caring for the DishwasherCaring for the Dishwasher
Cleaning the Filter
Cleaning The Door
Toclean the coarsefilter and thefine filter,use a cleaningbrush. Reassemble thefilter parts as shown in the figures
on the lastpage and reinsertthe entire assemblyin the dishwasher, positioning itin its seatand pressing downwards.
When cleaning the filters, don't knock on them. Otherwise, the filters could be
contorted and the performance of the dishwasher could be decreased.
WARNING!WARNING!
To clean the edge around the door, you should use only a soft warm, damp cloth.
To avoid penetration of water into the door lock and electrical components, do not
use a spray cleaner of any kind.
WARNING!WARNING!
Never use a spray cleaner to clean the door panel as it may damage the door lock
and electrical components.
Abrasive agents or some paper towels should not be used because of the risk of
scratching or leaving spots on the stainless steel surface.
nn
nn
Cleaning the Spray Arms
NOTE:NOTE:
If your dishwasher cannot work because of the ice,
please contact professional service persons.
It is necessaryto clean thespray arms regularlyfor hard
water chemicals willclog the sprayarm jets andbearings.
- Inspect the filters for blocking after every time the dishwasher has been used.
- By unscrewing the coarse filter, you can remove the filter system. Remove any food remnants and
clean the filters under running water.
Remarks:
The entire filter assembly should be cleaned once a week.
NOTE:NOTE:
To remove the lower spray arm, pull out the spray arm upward.
Toremove the upperspray arm, hold the nut, rotate the arm
clockwise to removeit.
Wash the arms in soapy and warm water and use a soft brush to
clean the jets. Replace them after rinsing them thoroughly.
OpenOpen
18
