Deen Family KF-9521DF User manual

ROTATING HAND STAND MIXER
MODEL KF-9521DF

BEFORE USING YOUR APPLIANCE
Read these instructions carefully and retain for future
reference.
Remove all packaging and any labels.
Ensure the cord is fully unwound before using the
handmixer.
Never put the handmixer body in water or let the cord or
plug get wet.
Keep fingers, hair, clothing and utensils away from
moving parts.
Never let the cord touch hot surfaces or hang down
where a child could grab it.
Never use a damaged handmixer. Get it checked or
repaired.
Never use an unauthorised attachment.
Always unplug the appliance when not in use, before
fitting or removing parts or before cleaning.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
Children should be supervised to ensure that they do not
play with the appliance.
Only use the appliance for its intended domestic use.
IMPORTANT SAFEGUARDS
1

1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
mixer head
turbo button
speed switch
eject button
dough hooks
beaters
spatula
mixing bowl
scraper
cradle release button
cradle
mixer release button
mixer stand
PARTS DESCRIPTION
2
1

1.
2.
3.
Press the cradle release button,
raise the cradle. Place the mixing
bowl onto the mixer stand. (Fig.3, Fig.4)
Put the scraper onto the stand, then
press the cradle release button, push
down the cradle.
(Fig.5, Fig.6, Fig.7)
Hold and press down the mixer head
Onto the cradle, lock it properly.
(Fig.8, Fig.9)
preparing your standmixer
Fig. 1 Fig. 2
Fig. 3 Fig. 4
Fig. 5 Fig. 6
Fig. 7 Fig. 8 Fig. 9
1.
2.
Insert the dough-hooks/beaters
into the mixer head. (Fig.1)
Make sure the dough-hooks/beaters
are locked at the right place. (Fig.2)
If using the mixer with stand, insert
the dough-hook/beater with the plastic
gear ensuring it aligns with the cradle.
The dough-hooks/beaters can only be
removed when the speed switch is
in the off “0” position and removed from
the stand.
preparing your handmixer
PREPARING FOR USE
3

1.
2.
3.
4.
5.
6.
7.
Press the cradle release button, raise the cradle.
Place the ingredients into the mixing bowl and
then place the bowl onto the mixer stand.
Press the cradle release button with one hand
and then push down the cradle/mixer-head with the other.
Plug in.
Pull the speed switch to the side to reach the desired speed
(the first speed on the mixer head is the slowest speed
setting).
As the mixture thickens, increase the speed.
If the machine starts to slow or labour, increase
the speed.
Press the turbo button to operate the motor at
maximum speed. The unit must be already in use to use
this button. The motor will operate for as long as the
button is held in position.
When the mixture has reached the desired consistency,
return the speed switch to the off “0” position and raise the
mixer-head/cradle.
It may be necessary to scrape down the sides
of the bowl and along the bottom at regular
intervals to assist the mixing operation.
To remove the hooks/beaters, make sure the speed switch
is in the off “0” position and unplug the mixer. Hold on to
the shafts of the hooks/beaters and press the eject button.
to use your standmixer
When creaming for cake mixtures, use butter or
margarine at room temperature or soften before use.
For best results with small quantities, use the
handmixer without the stand.
Large quantities and thick mixtures may require a
longer mixing time.
If you wish to mix larger quantities or heavier mixes,
remove the mixer head from the stand and use a bowl
of an appropriate size.
hints
To re-knead bread doughs
remove the mixer from the stand and use
hand held.
OPERATING
4

Mixing guide
The following mixing guide is a suggestion for selecting mixing speeds. Begin on
speed 1 and increase to desired speed depending on the recipe consistency.
OFF and/or Eject
LOW speed for folding or mixing in dry ingredients, muffins,
or quick breads
To cream butter and sugar; most cookie dough
MEDIUM speed for most packaged cake mixes
Frosting and mashed potatoes; kneading dough
Beating egg whites; kneading dough
HIGH speed for whipping cream; kneading dough
0
1
2
3
4
5
TURBO
Cookie dough is one of the thickest doughs to mix. Make it easier by following these tips:
SPEED FUNCTION
mixing tips
55
Use a large mixing bowl so that ingredients spread out for easier mixing.
Have butter or margarine at room temperature.
Add ingredients one at a time and thoroughly mix after each addition.
Add flour one cup at a time.
To add chips or nuts to a very thick dough or batter, we recommend stirring them in by
hand at the very end of the recipe.

cleaning
Always switch off, unplug and remove the beaters or hooks before cleaning.
Never use abrasives to clean parts.
Mixer head
Wipe with a damp cloth, then dry.
Never put the mixer head in water or let the cord or plug get wet.
cradle/stand
Wipe with a damp cloth, then dry.
Never immerse in water or use abrasives.
all other parts
Wash by hand, then dry.
Alternatively they are dishwasher safe and can be washed on the top rack of your
dishwasher. Avoid placing items on the bottom rack directly over the heating
element.
bowl
Never use a wire brush, steel wool or bleach to clean your stainless steel bowl.
Use vinegar to remove limescale. Keep away from heat (cooker tops, ovens,
microwaves). For everday usage, hand washing is suggested.
troubleshooting
problem
The mixer stops during operation.
solution
If for any reason power to the mixer is interrupted and the machine stops working,
turn the speed switch to the off “0” position, wait a few seconds and then re-select
the speed. The mixer should resume operation straight away.
8

!"#"$%&'()%'*%+,'-+,,+)$*'
