Definitive Technology StudioSlim User manual

DE FI N ITIVE TECHNO LO Gy·
StudioS ·m™
3.1 Home Theater Sound Bar and Wireless S ubwoofer System
Setup Guide

What's in the Box
Sound bar
Power supply Subwoofer
power cord D.
(
C:
.') ~
"'
""'
I 2 Subwoofer
Power cord
- M.'4 +
□ .
Optical cable D.
Remote control Literature
HDMI cable

Setup
a
■
■
Place the sound bar
For the best listening experience, position the
sound bar centered under your TV. You may
choose to place it either on a stand, or wall-
mount the sound bar below the TV
Connect the sound bar to an AC outlet
During startup, you will see multiple light shows.
When all 10 L ED s are blinking slowly, the sound bar
is ready for set up with the Google Home app .
Place the subwoofer
For best performance place on the same wall
as the TV, no mo re than 30ft (1 Om) from the
sound bar.
Performance Tip: placing the subwooferin
a corner helps maximize the overall bass effect.
I\
/
I\
I/
\
TV
I /
I I
Sound Bar
11 11
"'
\
TV
I /
• I I
Subwoofer
11 11
"'

■
■
Connect the subwoofer to an
AC outlet
A solid light will be visible on the
back of the subwoofer to indicate that
it is paired to the sound bar.
I\ I
11
V
\
TV
II
S ,und Bar
11
Download the Google Home app to setup your sound bar on your
Wi-Fi network
Download the free Google Home app and follow the in-app instructions to setup the
sound bar on your Wi - Fi network.
/
""
For more detailed setup information about Google Home and Chromecast built -in for
audio, visit: https :// support.google.com/googlehome and
https :// support.google.com/chromecastbuiltin
Once the sound bar is connected to your Wi - Fi network, it will receive firmware updates
for the latest features, performance and tuning. We require updating your sound bar
to the latest firmware for the best overall performance. Please refer to the "Receiving
Automatic Updates" section under "Functionalities" (p. 8) for details.
- -
, Download on the
• AppStore
~ GETITON
, ,,... Google Play

■ Connect to your TV
Is _ an HD~.! input jack on you .r TV labeled "ARC"?
'' '
-
YES -Use HDMI (ARC)
0 ?: ] L
LS
0
IV
"""'
"""""'
~
a=i
boo~
J I
Connect the included HDMI cable to the HDMI
jacks labeled with "ARC" on both the 1V and the
sound bar.
- -- - -- -
_ _ .. NO -Use OP!ic~.t __ _ -·-. . ~ __
0 2 I k I cs 0
~
"'
~w
""
QUI
@
___J
t__
Connect the included Optical cable between the
1V and sound bar.

6
■
Turn on your TV and enjoy the Studio Slim
Turn on yourTV and verify that you are hearing sound from the sound bar.
Note : Access your TV's menu and turn off its internal speakers.
If you do not hearsound and do not see any lights on the front of your sound bar,
press the power button on the sound bar to turn it on.

a
■
Using your TV remote to control the volume
The Studio Slim comes pre-configured to respond to volume and mute commands from
the mostpopularTV remotes including: Samsung, LG, Sony, Vizio and othermajor brands:
All other trademarks, product names, logos and brands referenced herein are the
property of their respective owners
• Bluetooth will only work after the product has been set up using the Google
Home app.
• To pair your device using Bluetooth, press the Bluetooth button on the sound
bar. A blue light will slowly pulse on the sound bar as it waits to connect to your
Bluetooth device.
• Go to the Bluetooth settings section in your phone, tablet or computer and
select the name chosen in the Google Home app. The name of the device
changes to the name configured in the Home app setup flow. The light will turn
solid blue for 3 seconds and fade to off when your Bluetooth device is connected.
• To re-establish a Bluetooth connection after pairing has already been completed,
go to the Bluetooth settings on your device and connect to the sound bar.
0 Bluetooth ·

■
Chromecast built-in benefits
The Studio Slim features Chromecast built -in for easy streaming and more:
• Stream musicfrom your favorite apps overWi-Fi.
• Create awhole-home audio experience. Multi-room sync lets you play the same song
across Chromecast built-in compatible speakers in yourhouse atthe same time.
• Use Google Assistant on a Google Home speaker or other Assistant-enabled
device to control music playback on the Studio Slim with voice commands.
~ Chromecast
~ .J built-in
Listening to music via Chromecast built-in
• Tap the cast button from yourfavorite music apps to start streaming to your speakers. For
more information please visit: https: // www.google . com /chromecast/ built -in/audio/
• For information on list of Chromecast compatible apps please visit:
https: // store.goog le.com /u s/ product /chromecast_2015_apps?hl=en- US
Receiving automatic updates (highly recommended)
Definitive Technology securely provides periodic software updates via the Internet which improve
product performance and expand the list of built -in TV remote controls.
0 Google Home App
for iPhone, ,Pad
and Android devices

Remote Control
Power On/Off
Mute
TV O PTICAL
lV Input 1 2 Optical
Input
Master Volume Up
MasterVolume Down
Center Down
CENTER
+ Center
Up
Bass Down
BASS
+
Bass Up
Music Mode
MUSIC NIGHT MOVIE
Movie Mode
□.
Night Mode

Sound Bar Controls
Front of Studio Slim
_____ --L
,-
+
t) Power -Turns the Studio Slim on/off
-El Source -Switches sound bar inputs
* Bluetooth-Initiates 8/uetooth pairing
Volume Down -Decreases the master volume
+ Volume Up -Increases the master volume

Back of Studio Slim
~
-
~
I I
1c=:::J)
77
II
1 I
DC Power Input
Optical Input
IR Input IRRepeater
Service Port TV HDMI ARC

Visual LED Indicators (Sound Bar)
\.__ _________ -_- _- _- _-_-_ -_ -_-_- _ -_ - __ _7'.A, ____ ·.._. ·_ ·. ·_· ·_ ·. ____ ___,!fil/
,----- 7 < ___ _ _ _
SOURCE INDICATORS
0 0 0 © © © 0 © ® ® ® ®
Above is a closeup of the source indicators.
TV (HDMI ARC) 0
OPTICAL O 0
BLUETOOTH •
CHROMECAST BUILT-IN 0
Several sources colors indicate the audio bitstream for non streaming inputs
0 PCM CONTENT e DOLBY CONTENT e DTS CONTENT
NOTE: All source indicators appear for three seconds before fading to off.

MUTE INDICATOR
VOLUME LEVEL
INDICATORS
While MUTE is active, the source indication will blink.
0 0 0 0 0 0 0 0 0 0
MasterVolume will be indicated with 10 LEDs . Each LED will have 10 levels of brightness to
indicate 1-100% volume. Volume 1% will be indicated with the left most volume dimly lit, volume
100% will be indicated with all 10 volume LEDs fully illuminated.
Volume indicators will illuminate in purple instead of white to indicate the state of Night Mode. In
Standby, all lights are off.
e C NIGHT MODE -enabled 0 C NIGHT MODE -disabled
Visual Indicators (Subwoofer)
A solid light on the subwoofer indicates the
subwoofer is connected to the sound bar.
If the light fails to turn solid afterfollowing
the set up instructions. please contact
customerservice.
•
0
•
••
•
•
-€:)a
• •
•
• •
•
•
. •
• •
[g
•
• •

Optimize Your Listening Experience
0 0 0 0 0 0 0 0 0 0 0 CENTER
Less
CENTER
DEFAULT
LEVEL
+
More
CENTER
Customize the voice level to reproduce clear, crisp
di al o gue on yo ur s ound bar using the c enter(+/ -)
button on your sound bar remote .
0 0 0 0 0 0 0 0 0 0 0 BA SS
Less
BASS
DEFAULT
LEVEL
+
More
BASS
Cu s tomize the bass level using the bass( +/ -)
buttons on your sound bar remote .
1V
OPTICAL
l 2
C ENTER
+
BA SS
+
MU SIC NIGHT MO VIE
D.

Using Your TV or Cable/Satellite TV Remote
to Control the Studio Slim
There are several ways to use your TV, cable, or satellite remote to control the Studio Slim.
HDMI CEC CONTROL
If your TV is connected via HDMI and your TV supports CEC (and it is enabled in the TV settings
menu), you can control the volume and mute functions on the Studio Slim from your TV without
any further setup.
PRELOADED IR CODES
The Studio Slim comes pre-loaded with remote commands for many of the televisions
manufactured within the last 5 years. If your remote does not work, please be sure to leave
your product plugged in and connected to the internet for software updates that will add more
remotes in the future.

Sound Modes
Music Mode
Music mode provides a natural and balanced sound profile with smoother bass
while minimizing home theater spatialization effects.
Movie Mode
Movie mode is optimized for both movies and TV content. It provides home theater
spatialization effects, as well as enhanced dialogue and more dynamic bass impact.
This is the default sound mode for HDMI and Optical input sources.
Night Mod e
Night mode is optimal for low-volume listening. Bass and dynamic range are
reduced to improve vocal clarity. Volume indicators will illuminate in purple instead
of white to indicate the state of Night Mode. In Standby, all lights are off.
e C NIGHT MODE - enabled
0 C NIGHT MODE -disabled
-BASS +
W""'"
.....
D
( MUSIC
NIGHT
MOVIE
r---....._
~
□.

For Further Assistance:
Phone Number
[phone] (North America)
[phone]
Email
info@definitivetech .com
Mail
Definitive Technology
1 Viper Way
Vista, CA 92081

DEF IN IT IVE TECH NOL O Gy·
1Viper Way
Vista, CA 92081
800-228-7148
www.definitivetechnology.com
Sound United Europe
a division of D&M Europe B.V.
Beemdstraat 11
5653 MA Eindhoven
The Netherlands
HBP4 236

DEFINITIVE TECHNOLOGY.
StudioS im™
Important Product Information

Safety Precautions
FCC Statement
COMPLIANCE INFORMATION
ProductName: 3.1 Home TheaterSound Bar andWireless
SubwooferSystem
Model Number: Studio Slim and Studio Slim Subwoofer
CONTAINS TRANSMITTER MODULE FCC ID: IPUJMDD
FCC ID: IPUSTUDIOSLIM (BAR) FCC ID: IPUSTUSLIMSUB
(Subwoofer)
1. This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1)This device may not cause harmful interference, and
2) This device must accept any interference
received, including interference that may cause
undesired operation.
2. Any Changes or modifications not expressly approved
by the party responsible for compliance could void
the user's authority to operate the equipment.
NOTE: This equipment has been tested and found
to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
-Increase the separation between the equipment
and receiver.
- Connect the equipment into an outlet on a circuit
different from that to which the receiver 1s connected.
- Consult the dealer or an experienced radio/TV
technician for help.
FCC RF Radiation Exposure Statement
1. This transmitter must not be collocated or operating
in conjunction with any other antenna or transmitter.
2. This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment. This equipment should be installed and
operated with minimum distance 20cm between the
radiator & your body.
3. FCC RF Warning
This equipment must be installed and operated in
accordance with provided instructions and the antenna(s)
used for this transmitter must be installed to provide a
separation distance of at least 20 cm from all persons and
must not be co-located or operating in conjunction with
any other antenna or transmitter. End-users and installers
must be provided with antenna installation instructions
and transmitter operating conditions for satisfying RF
exposure compliance.
IC RF Radiation Exposure Statement
CONTAINS TRANSMITTER MODULE IC : 10392A-JMDD
IC: 10392A-STUDIOSLIM (BAR) IC: 10392A-STUSLIMSUB
(SUBWOOFER) This device complies with the Canada
portable RF exposure limit set forth for an uncontrolled
environment and are safe for intended operation as
described in this manual. The further RF exposure
reduction can be achieved if the product can be kept as
far as possible from the user body or set the device to
lower output power if such function is available.
Canada, Industry Canada (IC) Notices
This Class B digital apparatuscomplies with Canadian ICES-
003. To reduce potential radio interference to other users,
the antenna type and its gain should be so chosen that the
equivalentisotropicallyradiated power (e.i.r.p.) is not more
than that permitted for successful communication.
This device complies with Industry Canada license-
exempt RSS standard(s).
