Meet the Dymension
Speaker Series
Thank you for choosing the Deinitive Technology Dymension series loudspeaker
system. Take advantage of a wide range of cutting-edge audio technology features,
including bi-polar array technology, integrated powered subwoofers, and Intelligent
Bass Control™. Truly immerse yourself in 3D sound with Dolby Atmos® and DTS: X™
compatibility. This remarkable speaker system is sure to provide a state-of-the-art
experience in both music and home-theater sound reproduction.
Speakers overview
The Dymension series includes four tower speakers (DM80, DM70, DM60, DM40),
three center speakers (DM30, DM20, DM10), a height-channel module (DM90), and a
surround speaker/wall-mounted height module (DM95).
Tower speakers
DM80, DM70, DM60, & DM40

4
Height speakers
DM90 (compatible with DM80 and DM70 only)
Center speakers
DM30, DM20, & DM10
Surround/Height speakers
DM95

5
Product specifications
Every speaker in the Dymension series is covered with a non-removeable, acoustically
transparent black cloth. See below for more technical speciications and details.
Tower speakers
DM80 DM70 DM60 DM40
Dimensions 49.4 x 11.3 x
16.0 in. (1254.9
x 286.7 x 406.7
mm)
47.4 x 11.3 x
16.0 in. (1204.1
x 286.7 x 406.7
mm)
45.4 x 11.3 x
13.7 in. (1153.4
x 286.7 x 349
mm)
37.4 x 10.3 x
10.0 in. (950.1
x 261.4 x 255
mm)
Tweeter (2) 1 in.
aluminum
oxide dome
(2) 1 in.
aluminum
oxide dome
(2) 1 in.
aluminum
oxide dome
(2) 1 in.
aluminum
oxide dome
Midrange/
Midbass
(4) 5.25
in. BDSS
with Linear
Response
Waveguide
(4) 5.25
in. BDSS
with Linear
Response
Waveguide
(4) 4.5 in.
BDSS with
Linear
Response
Waveguide
(4) 4.5 in.
woofers
Subwoofer
system driver
complement
(1) 12 in.
subwoofer
(2) 12 in. bass
radiator
(1) 10 in.
subwoofer
(2) 10 in. bass
radiator
(1) 8 in.
subwoofer
(2) 8 in. bass
radiator
X
Frequency
response
23 Hz–30,000
Hz (-10 dB)
28 Hz–23,000
Hz (-3 dB)
25 Hz–30,000
Hz (-10 dB)
30 Hz–23,000
Hz (-3 dB)
30 Hz–30,000
Hz (-10 dB)
34 Hz–23,000
Hz (-3 dB)
38 Hz–30,000
Hz (-10 dB)
55 Hz–23,000
Hz (-3 dB)
Nominal
impedance
4Ω(8Ω
compatible)
4Ω(8Ω
compatible)
4Ω(8Ω
compatible)
4Ω(8Ω
compatible)
Sensitivity 90dB
(2.83V/1m)
90dB
(2.83V/1m)
88dB
(2.83V/1m)
87dB
(2.83V/1m)
Subwoofer
ampliier
500W (Peak)
GaN FET
250W (Peak)
Class D
250W (Peak)
Class D X
Bipolar array
adjustment
Fully Bipolar
(default),
Forward Focus
-6dB, Variable
via Biamp
Rear tweeter
switch: 0dB,
-6dB
Rear tweeter
switch: 0dB,
-6dB
Rear tweeter
switch: 0dB,
-6dB
Intelligent
Bass Control™
Variable
+/- 12dB
Variable
+12dB/-15dB
Variable
+12dB/-15dB X

6
DM30 DM20 DM10
Dimensions 7.5 x 31.5 x 15.9 in.
(190.2 x 800.4 x 403
mm)
5.3 x 30.5 x 6.5 in.
(134.4 x 775 x 165.8
mm)
7.3 x 19.5 x 12.2 in.
(186 x 495.6 x 311
mm)
Tweeter (1) 1 in. aluminum
oxide dome
(1) 1 in. aluminum
oxide dome
(1) 1 in. aluminum
oxide dome
Orientation Horizontal Horizontal Horizontal
Midrange/
Midbass
(4) 5.25 in. BDSS
with Linear
Response
Waveguide
(4) 4 in. midrange
woofers
(2) 5.25 in. woofers
Subwoofer
system driver
compliment
(1) 8 in. subwoofer
(2) 8 in. bass
radiator
X
(1) 9 in. bass radiator
Frequency
response
36 Hz–30,000 Hz
(-10 dB)
41 Hz–23,000 Hz
(-3 dB)
64 Hz–30,000 Hz
(-10 dB)
91 Hz–23,000 Hz
(-3 dB)
57 Hz–30,000 Hz
(-10 dB)
81 Hz–23,000 Hz
(-3 dB)
Nominal
impedance
6Ω(8Ωcompatible) 4Ω(8Ωcompatible) 4Ω(8Ωcompatible)
Sensitivity 93dB (2.83V/1m) 89dB (2.83V/1m) 90dB (2.83V/1m)
Subwoofer
ampliier
250W (Peak) Class D X X
Intelligent
Bass Control™
Variable +12dB/-15dB X X
Center speakers

7
DM90 DM95
Dimensions 6.0 x 7.3 x 15.3 in. (151.6 x 185.2 x
388.7 mm)
8.3 x 7.3 x 13.0 in. (210.7 x 184.2
x 330.2 mm)
Tweeter (1) 1 in. aluminum oxide dome (1) 1 in. aluminum oxide dome
Midrange/
Midbass
(1) 5.25 in. BDSS with Linear
Response Waveguide
(1) 5.25 in. BDSS with Linear
Response Waveguide
Frequency
response
81 Hz–30,000 Hz (-10 dB)
130 Hz–27,000 Hz (-3 dB)
62 Hz–30,000 Hz (-10 dB)
110 Hz–23,000 Hz (-3 dB)
Nominal
impedance
4Ω(8Ωcompatible) 4Ω(8Ωcompatible)
Sensitivity 90dB (2.83V/1m) 90dB (2.83V/1m)
Treble control X0dB, +3dB
Height and surround speakers

8
Tower speaker back panels
1
2
3
5
6
1
2
3
5
6
7
1 -
2 -
3 -
4 -
5 -
6 -
7 -
Height-channel binding posts: Connect to an ampliier or receiver when the
optional DM90 speaker is installed.
Status light: The light turns from red to blue when the speaker receives a signal
from your ampliier or receiver. For more information, see page 26.
Intelligent Bass Control knob: Increases or decreases the bass level. We recom-
mend starting at the 12-o’clock position when setting up the speaker.
Rear input binding posts: The DM80 speaker comes installed with additional
binding posts and a jumper cable to independently control the rear speaker array
between 0 dB (full bi-polar) and -6 dB (forward-focused).
Speaker input binding posts: Connect the main speakers to your ampliier or
receiver.
Power connector: Required to power the integrated subwoofer.
Rear tweeter switch: Switches the rear tweeter between 0 dB (full bi-polar) and
-6 dB (forward-focused).
DM80 DM70
4

9
DM60 DM40
1 -
2 -
3 -
4 -
5 -
Rear tweeter switch: Switches the rear tweeter between 0 dB (full bi-polar) and
-6 dB (forward-focused).
Status light: The light turns from red to blue when the speaker receives a signal
from your ampliier or receiver. For more information, see page 26.
Intelligent Bass Control knob: Increases or decreases the bass level. We recom-
mend starting at the 12-o’clock position when setting up the speaker.
Speaker input binding posts: Connect the main speakers to your ampliier or
receiver.
Power connector: Required to power the integrated subwoofer.
2
3
4
5
1
1
4

10
Center speaker back panels
1 -
2 -
3 -
4 -
Status light: The light turns from red to blue when the speaker receives a signal
from your ampliier or receiver. For more information, see page 26.
Intelligent Bass Control knob: Increases or decreases the bass level. We recom-
mend starting at the 12-o’clock position when setting up the speaker.
Binding posts: Connect the speaker to your ampliier or receiver.
Power connector: Required to power the integrated subwoofer.
DM30
1 2 3 4

11
DM20
DM10
1 2
1
1 -
2 -
Binding posts: Connect the speaker to your ampliier or receiver.
Key-hole slots for wall mounting: Use to mount the speaker on your wall. See
the included wall-mounting template for more information.
2

12
Height and surround speaker
back panels
1 -
2 -
3 -
4 -
5 -
Connection port: Connects the height-channel to the top of your DM80 or DM70
tower speaker.
Binding posts: Connect the speaker to your ampliier or receiver.
Treble control: Switches the treble between 0 dB (default) and +3 dB (boost).
Key-hole slots for wall mounting: Used to mount the speaker on your wall. See
the included wall-mounting template for more information.
3/8-16 Threaded insert: Mount the speaker with optional speaker mounts
(not included).
DM90
1
2
DM95
4
4
3
5

13
Speaker Placement
Correct speaker placement is important to maximize the sound quality of your audio
system. Read this section for placement tips for your individual speakers, as well as
diagrams and descriptions of various speaker system layouts.
Positioning the speakers
Tower speakers
The tower speakers can be used as front-right and front-left speakers or as surround
speakers. Your inal speaker placement will depend on the environment and personal
listening preferences.
Follow these general best practices when placing your tower speakers:
• Place the speakers as far apart from each other as they are from the main listening
area. See the diagrams on page 16 for reference.
• Do not place the speakers any closer than 6 inches to any wall.
• If possible, keep the speakers about 2.5 feet away from the back or side walls.
• If the relection of the rear speakers off of the front wall is too strong, try pulling
the speakers away from the wall or switching the array to forward-focus mode. For
more information, see page 20.
• Start with the speakers placed parallel with your back wall, and experiment with
the imaging by increasing the angle (toe-in) until you ind the desired balance of
ambience and direct sound.
>6” (15 cm)

14
Center speakers
The most popular placement for your center speaker is just below and centered with
your TV. You can also place the speaker above your TV. Your inal speaker placement
will depend on the environment and personal listening preferences.
Follow these general best practices when placing your center speakers:
• Place the speaker as close to the center of your TV as possible.
• If the speaker is placed on furniture, keep the speaker lush with the front edge of
the surface.
Note: The DM20 speaker is designed for wall-mounting, if desired. However, do
not attempt to mount DM10 or DM30 speakers on a wall.
• If possible, angle the speaker toward the listening area if the speaker is too far
above or below your TV.
• Avoid enclosing the DM30 or DM10 speakers inside a cabinet. These speakers
have up-iring woofers and/or bass radiators. If your speaker is inside a cabinet, try
to allow at least a few inches between the top of the speaker and the cabinet.

15
Surround and height speakers
You can use the DM95 speakers as surround or height speakers. Review the Quick
Start Guide that came with the product for installation instructions. See below for
additional placement advice, depending on your setup.
For more information about using and positioning height-channel speakers for Dolby
Atmos, visit https://www.dolby.com/.
Follow these general best practices when using DM95s as surround speakers:
• Position the speakers on side walls, slightly behind and above the listening area.
• Position the speakers so that the tweeters point toward the listening area.
• If you install a second pair of DM95 speakers, mount them where they are best
able to face the listening area.
Note: Two DM95 speakers can be used for the surround channels in a 5.1 setup or
four can be used as surround and surround back channels in a 7.1 system.
Follow these general best practices when using DM95s as height-channel
speakers:
• Position the speakers so that the tweeters point toward the listening area.
• If you are using two DM95 speakers, you can mount the speakers above the
left-front and right-front speakers or to the sides (as seen in the diagram above),
depending on the room and your preferences. For detailed information and place-
ment suggestions with two or more height-channel speakers,
visit https://www.dolby.com/.
As with the tower and center speaker placement, your inal surround height speaker
placement will depend on the environment and personal listening preferences.

16
Speaker system setups
Your Dymension speakers are compatible with 2, 3, 5, 7, and 9-channel surround
sound conigurations and all Dolby Atmos setups (for example, 5.1.2, 5.1.4, etc). Take a
look at the following examples and give them a try based on the Dymension speakers
you have.
Note: You can add DM90 height modules or wall-mounted DM95 speakers to the 5
and 7-channel systems described below to enable a new dimension of immersion to
your home theater experience when using Dolby Atmos, DTS:X, etc.
Listening in a 2-channel coniguration
FRONT
LEFT
FRONT
RIGHT
Get the most realistic stereo image by placing the speakers as far apart as the listen-
ers are sitting from them. You may choose to experiment with the exact angle and
distance of the speakers from the back wall. For more information, see page 20.

17
Listening in a 5-channel coniguration
90º
TV
90º
20º20º
CENTER
FRONT
LEFT
FRONT
RIGHT
You can use DM95 speakers as rear surround speakers to create a home theater sur-
round system. Ideal rear channel placement is along a side wall, slightly behind and
above the listening position.
Note: If you cannot place rear surround speakers along the side walls, position them
along the rear wall above the listening position.
Listening in a 7-channel coniguration
90º 90º
20º20º
TV
CENTER
FRONT
LEFT
FRONT
RIGHT
Add more depth to your surround experience with four surround speakers instead of
two.
SURROUND
LEFT
SURROUND
RIGHT
SURROUND
LEFT
SURROUND
RIGHT
SURROUND
BACK LEFT
SURROUND
BACK RIGHT

18
Speaker Wiring
All of the Dymension series speakers use the same binding posts that can be un-
screwed and then tightened to connect bare speaker wire. You can also attach a
banana plug or spade connector to connect wire to the binding posts. See the next
sections for wiring illustrations.
To connect bare speaker wire to the binding posts on your Dymension speaker:
1. Strip about 3/8 in (10 mm) of insulation from two speaker wires.
2. Unscrew the binding posts.
3. Insert the wires through the binding posts.
4. Tighten the binding posts until secure.
Wiring the tower speakers
DM80DM70
DM40 DM60

19
The DM70 and DM80 speakers come with more than one set of binding posts. As
seen in the diagrams, the bottom pair of binding posts connect the main speaker
array. The top pair of binding posts are used to connect a DM90 height module to
your receiver. For more information about the other binding posts and wiring options
for DM80, see page 27.
Wiring the center and surround speakers
DM10 DM20
DM30 DM95

20
The Rear Speaker Array
The Dymension tower speakers each come with a rear speaker array. These
speakers can be adjusted down if there is too much spatial effect. DM70,
DM60, and DM40 use a switch to adjust the level of the rear tweeter. DM80
uses a jumper cable to attenuate the entire array.
How does the rear array work?
The tower loudspeakers have speakers iring forward and rearward in what’s known as
a bipolar array. This enhances spaciousness and immersion by directing more energy
into the room than a typical loudspeaker does. Below is an illustration of this sound
radiation pattern.
The amount of increased ambience and immersion can be adjusted if desired in
several ways.
To adjust the spatial effect from the rear array:
• Move the speakers farther from or closer to the wall. The closer to the wall, the
stronger the contribution from the rear speakers will be.
• Toe in the speakers or align them parallel with the wall. More toe-in will decrease
the contribution from the rear speakers.
• Switch the rear array between 0dB (full bi-polar) mode or -6dB (forward-focused)
mode. See the next page for more information.
