Definitive Technology DEMAND D5c Center Channel User manual

.
DEMAND™ SERIES
Owner’s Manual
D5c Center Channel

WHAT OBSESSION SOUNDS LIKE™
Thank you for choosing the Definitive Technology Demand Series Speakers. This compact, high
quality speaker is intended for use as a center channel. The lifelike sound field makes this speaker
an excellent addition to any room. The Demand Series Center Channel offers the most cutting-
edge audio technologies, including Balanced Double Surround System (BDSS) high output mid-
bass drivers, a Linear Response Waveguide, and annealed aluminum dome tweeters with our
20/20 wave alignment lens. The Definitive Technology Demand D5c high-performance center
channel speaker delivers full-range, room-filling sound and precise imaging in a modern, elegant
styling. This sleek center channel speaker perfectly complements the Demand Series tower and
bookshelf speakers to create a truly immersive, room-filling home cinema experience.
Our engineers have spent many years in developing this product. In order to ensure that you
experience the finest performance possible, we encourage you to take a moment to fully read
this owner’s manual and familiarize yourself with the proper installation and setup procedures
for your D5c Center Speaker.
DEFINITIVE TECHNOLOGY
EN-1

EN-2

Safety Instructions
SAFETY PRECAUTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9. Only use attachments/accessories specified by the manufacturer.
10. Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury
from tip-over.
11. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been damaged in any
way, such as power supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate normally, or has
been dropped.
EN-3

NOTES ON USE
WARNINGS
∙Avoid high temperatures.
Allow for sufficient heat dispersion when installed in a rack.
∙Keep the unit free from moisture, water, and dust.
∙Do not obstruct the ventilation holes.
∙Do not let foreign objects into the unit.
∙Do not let insecticides, benzene, and thinner come in contact with the
unit.
∙Never disassemble or modify the unit in any way.
∙Ventilation should not be impeded by covering the ventilation
openings with items, such as newspapers, tablecloths or curtains.
∙Naked flame sources such as lighted candles should not be placed
on the unit.
∙Do not expose the unit to dripping or splashing fluids.
∙Do not place objects filled with liquids, such as vases, on the unit.
A NOTE ABOUT RECYCLING:
This product’s packaging materials are recyclable and can
be reused. Please dispose of any materials in accordance
with the local recycling regulations.
When discarding the unit, comply with local rules or
regulations.
EU Declaration of Conformity
Hereby, [Sound United, LLC] declares that our product is in compliance
with following EU/EC Directives. The full text of the EU declaration of
conformity is available at the following internet address:
<EU/EC Directives>
RoHS: 2011/65/EU, and amendment directive (EU) 2015/863
Sound United, LLC
1 Viper Way Vista, CA 92081 USA
EU contact : Sound United Europe, A division of D&M Europe B.V.
Beemdstraat 11, 5653 MA Eindhoven, The Netherlands
EU declaration of conformity URL:
https://www.definitivetechnology.com/declarations-of-conformity
EN-4

We're delighted that you're part of our
Definitive Technology family.
Please take a few minutes to register your product* so we have a complete record
of your purchase. Doing so helps us serve you the best we can now and in the
future. It also lets us contact you for any service or warranty alerts (if required).
Register here: http://www.definitivetechnology.com/registration
Note: the data we gather during online registration is never sold or distributed to third parties.
* Serial number can be found at the back of the manual
STAY VIGILANT ON ALL THINGS DEFINITIVE TECHNOLOGY
@DefinitiveTech @DefinitiveTech @definitivetechnology
EN-5

Unpacking Your Demand Series Center Channel Speaker
Please unpack your D5c center channel speaker carefully. We recommend saving all cartons and packing materials
in case you move or need to ship your system. Your serial number can be found in this booklet and on the speaker
itself, on the input cup.
Each loudspeaker leaves our factory in perfect condition. Any visible or concealed damage most likely occurred in
handling after it left our factory. If you discover any shipping damage, please report this to your Definitive Technology
dealer or the company that delivered your loudspeaker.
What’s in the box:
∙Center Channel D5c
∙Owner’s Manual
∙Cleaning Cloth
EN-6

Positioning Your Speakers
Your D5c center channel speaker is designed to deliver
immense clarity, dynamic range, and focus to the vocal range
and accurately reproduce even the most demanding audio
content. To optimize its performance, please follow these
simple guidelines. Although the following recommendations
will usually yield the best results, all rooms and listening setups
are different, so do not be afraid to experiment with the
speaker placement. Whatever sounds best to you is likely
correct.
Note:
∙PLEASE ENSURE THAT ANY SHELF USED FOR THE CENTER CHANNEL IS RATED TO CORRECTLY SUPPORT ITS
WEIGHT.
∙A CENTER CHANNEL SPEAKER SHOULD BE PLACED AS CLOSE TO THE CENTER OF YOUR TELEVISION AS
POSSIBLE WITHOUT OBSTRUCTING YOUR VIEW.
ABOVE
OR
BELOW
EN-7

Connecting Your Loudspeakers
STRIP 1/4" (6MM) WIRE 1. IDENTIFY MARKINGS ON WIRE AND ASSIGN +/–
2. APPLY BANANA PLUGS OR SPADES AT THIS POINT
IF APPLICABLE
(SPEAKER)
1. UNSCREW THE BINDING POSTS AND INSERT THE
BARE WIRE INTO THE CENTER HOLES
2. TIGHTEN UNTIL SECURE
ENSURE PROPER POLARITY BETWEEN THE AMPLIFIER
AND SPEAKER BY CONNECTING + TO + AND - TO -
TERMINALS
EN-8

MODEL D5c
SPECIFICATIONS
DIMENSIONS 6.58'' H x 19.00" W x 11.24'' D
(16.71 cm H x 48.26 cm W x 28.55 cm D)
PRODUCT WEIGHT 24 lbs (10.89 kg)
DRIVER COMPLEMENT 5.25'' (13.5 cm) BDSS drivers x 2
1" (2.5 cm) aluminum dome tweeter x 1
FREQUENCY RESPONSE 42 Hz - 24 kHz
SENSITIVITY 85.5 dBSPL
NOMINAL IMPEDANCE Compatible with 8 ohm outputs
RECOMMENDED POWER INPUT 30 - 200 W
Technical Assistance
It is our pleasure to offer assistance if you have any questions regarding your D5c or its setup.
Please contact your nearest Definitive Technology dealer or call us directly at [phone] (US & Canada), 01
363-7148 (all other countries) or e-mail [email protected]. Technical support is offered in English only.
EN-9

Troubleshooting
If you experience any difficulties with your D5c center channel speaker, try the suggestions below. If you still have
problems, contact your Definitive Technology Authorized Dealer for assistance.
1. Audible distortion when the speakers are playing at loud levels is caused by turning up your receiver or amplifier
louder than the receiver or the speakers are capable of playing. Most receivers and amplifiers put out their full-
rated power well before the volume control is turned all the way up, so the position of the volume control is a poor
indicator of its power limit. If your speakers distort when you play them loud, turn the volume down!
2. If you experience a lack of bass, it is likely that one speaker is out of phase (polarity) with the other and needs to
be rewired with closer attention to connecting positive to positive and negative to negative on both channels.
Most speaker wire has some indicator (such as color-coding, ribbing or writing) on one of the two conductors to
help you maintain consistency. It is essential to connect both speakers to the amplifier in the same way (in phase).
You may also experience lack of bass if the bass volume knob is turned down or not on.
3. Make sure all your system interconnects and power cords are solidly in place.
4. Check that no foreign objects or liquid has entered the speaker cabinet.
Service
Service and warranty work on your Definitive loudspeakers will normally be performed by your local Definitive
Technology dealer. If, however, you wish to return the speaker to us, please contact us first (https://
www.definitivetechnology.com/contact-us), describing the problem and requesting authorization as well as the
location of the nearest factory service center. Please note that the address given in this booklet is the address of our
offices only. Under no circumstances should loudspeakers be shipped to our offices or returned without contacting
us first and obtaining return authorization.
EN-10

Limited Warranty
5-Years for Drivers and Cabinets, 5-Years for Electronic Components
DEI Sales Co., dba Definitive Technology (herein “Definitive”) warrants to the original retail purchaser only that this Definitive loudspeaker
product (the “Product”) will be free from defects in material and workmanship for a period of five (5) years covering the drivers and
cabinets, and five (5) years for the electronic components from the date of the original purchase from a Definitive Authorized Dealer. If
the Product is defective in material or workmanship, Definitive or its Authorized Dealer will, at its option, repair or replace the warranted
product at no additional charge, except as set forth below. All replaced parts and Product(s) become the property of Definitive. Product
that is repaired or replaced under this warranty will be returned to you, within a reasonable time, freight collect. This warranty is non-
transferrable and is automatically void if the original purchaser sells or otherwise transfers the Product to any other party.
This Warranty does not include service or parts to repair damage caused by accident, misuse, abuse, negligence, inadequate packing
or shipping procedures, commercial use, voltage in excess of the rated maximum of the unit, cosmetic appearance of cabinetry not
directly attributable to defects in material or workmanship. This warranty does not cover the elimination of externally generated static or
noise, or the correction of antenna problems or weak reception. This warranty does not cover labor costs or damage to the Product
caused by installation or removal of the Product. Definitive Technology makes no warranty with respect to its products purchased from
dealers or outlets other than Definitive Technology Authorized Dealer.
EN-11

THE WARRANTY IS AUTOMATICALLY VOID IF:
1) The product has been damaged, altered in any way, mishandled during transportation, or tampered with.
2) The product is damaged due to accident, fire, flood, unreasonable use, misuse, abuse, customer applied cleaners, failure to observe
manufacturers warnings, neglect or related events.
3) Repair or modification of the Product has not been made or authorized by Definitive Technology.
4) The product has been improperly installed or used.
Product must be returned (insured and prepaid), together with the original dated proof of purchase to the Authorized Dealer from whom
the Product was purchased, or to the nearest Definitive factory service center. Product must be shipped in the original shipping container
or its equivalent. Definitive is not responsible or liable for loss or damage to Product in transit.
THIS LIMITED WARRANTY IS THE ONLY EXPRESS WARRANTY THAT APPLIES TO YOUR PRODUCT. DEFINITIVE NEITHER ASSUMES
NOR AUTHORIZES ANY PERSON OR ENTITY TO ASSUME FOR IT ANY OTHER OBLIGATION OR LIABILITY IN CONNECTION WITH
YOUR PRODUCT OR THIS WARRANTY. ALL OTHER WARRANTIES, INCLUDING BUT NOT LIMITED TO EXPRESS, IMPLIED,WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE EXPRESSLY EXCLUDED AND DISCLAIMED TO THE
MAXIMUM EXTENT ALLOWED BY LAW. ALL IMPLIED WARRANTIES ON PRODUCT ARE LIMITED TO THE DURATION OF THIS
EXPRESSED WARRANTY. DEFINITIVE HAS NO LIABILITY FOR ACTS OF THIRD PARTIES. DEFINITIVE’S LIABILITY, WHETHER BASED
ON CONTRACT, TORT, STRICT LIABILITY, OR ANY OTHER THEORY, SHALL NOT EXCEED THE PURCHASE PRICE OF THE PRODUCT
FOR WHICH A CLAIM HAS BEEN MADE. UNDER NO CIRCUMSTANCE WILL DEFINITIVE BEAR ANY LIABILITY FOR INCIDENTAL,
CONSEQUENTIAL OR SPECIAL DAMAGES. THE CONSUMER AGREES AND CONSENTS THAT ALL DISPUTES BETWEEN THE
CONSUMER AND DEFINITIVE SHALL BE RESOLVED IN ACCORDANCE WITH CALIFORNIA LAWS IN SAN DIEGO COUNTY,
CALIFORNIA. DEFINITIVE RESERVES THE RIGHT TO MODIFY THIS WARRANTY STATEMENT AT ANY TIME.
Some states do not allow the exclusion or limitation of consequential or incidental damages, or implied warranties, so the above
limitations may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary from state
to state.
©2016 DEI Sales Co. All rights reserved.
EN-12

High-Performance Tower Speakers www.definitivetechnology.comDEMAND D17
DEMAND SERIES D5c
product information sheet
DEMAND SERIES D5c
Center Channel Speaker
www.definitivetechnology.com

High-Performance Tower Speakers www.definitivetechnology.comDEMAND D17
DEMAND SERIES D5c
product information sheet
DEMAND D5c
The Definitive Technology Demand D5c high-performance
center channel speaker delivers full-range, room-filling sound
and precise imaging in a modern, elegant styling. Ideal for
complementing Demand Series tower speakers in a home
cinema configuration.
SERIES FEATURES
2-Way Configuration
With dual 5.25” BDSS™ driver configuration and a 1”
aluminum dome tweeter, dialogue from movies and music
are perfectly reproduced. Voice matched to complement the
Demand Series towers and bookshelf speakers and create an
ideal home theater ensemble.
1” Aluminum Dome Tweeter with 20/20 Wave Alignment Lens™
Coupled with the 20/20 Wave Alignment Lens™, Definitive
Technology 1” aluminum dome tweeters deliver a clear,
precise high frequency response. The 20/20 Wave Alignment
Lens smooths high frequencies off the tweeter for improved
dispersion and a rich and balanced listening experience
anywhere in your room.
BDSS™(Balanced Double Surround System) Midrange
Patented Double Surround mid-range provides greater linear
excursion and output that results in superior mid-range detail
and punchier bass compared to drivers of similar size.
Extruded Aluminum Front Baffle
Clean, beautiful modern industrial design with an extruded
aluminum front baffle bead-blasted finish that provides
a timeless look and feel that fits any décor. Lightweight,
durable and recyclable, aluminum is truly the metal of a
modern lifestyle.
Acoustically Transparent Magnetic Grille
The included acoustically transparent magnetic speaker
grilles provide natural, uncolored sound when placed on the
speaker, and removes easily when you want to enjoy looking
at them fully uncovered.
Designed in California
Our Design Studio is located in California, where technology
and innovation meet entertainment. It goes beyond the idea
of a centralized location — it’s a cultural mindset that’s the
Definitive Technology wellspring for creativity and inspiration.
SPECIFICATIONS
Dimensions
(L x W x H)
11.24 x 19.00 x 6.58 in
285.5 x 482.6 x 167.1mm
Product Weight 24 lbs / 10.9 kg
Tweeter 1” / 25mm
Midrange 5.25” / 130mm
-3dB LF (Hz) 42 Hz
-3dB HF (Hz) 22 kHz
2.83V/1m Sensitivity (dBSPL) 87 dB
Nominal Impedance 4 ohms
Tweeter/Midrange
XO Point (Hz) 2.9 kHz
Midrange/Woofer
XO Point (Hz) 280 Hz
Minimum Power 40 watts
Maximum Power 300 watts
