DEHACO YO28 Instruction Manual

Water management system
User and maintenance
instructions
YO-28_2017-11_v1.2_EN
YO28

3© 2017 Dehaco B.V. • Original user and maintenance instructions for the YO28 water management system • YO-28_2017-11_v1.2_EN
Foreword
© Copyright 2017, Dehaco B.V.
All rights reserved. The reproduction or publication of this document, in whole or in part, in any form or by any means, is forbidden without
prior written permission from Dehaco BV. This also applies to the associated drawings and schematic diagrams, where applicable. Dehaco B.V.
reserves the right to make changes to products and/or parts thereof at any time and without prior notice. This also applies to the contents of
these instructions. For information about installation, maintenance and repair that you cannot nd in these instructions, we advise you to contact
your supplier's technical department. Despite the fact that these instructions have been composed with the utmost care, Dehaco B.V. accepts no
liability for any errors in these instructions or the consequences arising from these errors.
FOREWORD
General
Congratulations on the purchase of your YO28 water management system. This gives you access to a machine that
uses the latest technology and that you can use for many years without failure.
The YO28 water management system can be used for the delivery of heated shower water and the ltered disposal
of waste water.
These user instructions, the name plate, and the safety stickers such as they are axed to the machine contain
important safety information and, as such, are an integral part of the delivery.
The primary YO28 specications are listed on the name plate. The name plate also states the address details of the
manufacturer. The removal of the name plate or installation of said name plate onto another machine is strictly forbidden.
In the event of loss or damage to the name plate, the user must contact Dehaco or an authorised Dehaco dealer for a new
one.
Dehaco B.V.
Kruisbaak 25
2165 AJ Lisserbroek
T [phone]
F [phone]
E [email protected]
I www.dehaco.nl
Dealer

4Dehaco B.V. • Kruisbaak 25 • 2165 AJ Lisserbroek (NL) • ✆ +31 (0)88 - 20 20 600 •  [email protected] • www.dehaco.nl
EC Declaration of Conformity
EC DECLARATION OF CONFORMITY
In accordance with Appendix IIA of the EU Machinery Directive 2006/42/EC
We, Dehaco B.V., hereby declare that the products listed below comply with the essential requirements of the above-
mentioned European Directive and the following harmonised standards:
Product: Water management system
Brand Dehaco
Type designation: YO28
Manufacturer: Dehaco B.V.
Kruisbaak 25
2165 AJ Lisserbroek
Directives: Machinery Directive 2006/42/EG
Low Voltage Directive 2014/35/EU
Standard(s) NEN-EN-ISO 12100 Risk reduction
Place and date: Lisserbroek, 15-11-2017
Managing director: Jeroen Korporaal

5© 2017 Dehaco B.V. • Original user and maintenance instructions for the YO28 water management system • YO-28_2017-11_v1.2_EN
Table of Contents
TABLE OF CONTENTS
EC DECLARATION OF CONFORMITY 4
1. Introduction 6
1.1 Warning indications 6
1.2 Intended use 6
1.3 Safety 7
1.4 Legionella prevention 7
1.5 Warranty 7
2. Overview 8
2.1 General description 8
2.2 Scope of delivery 8
2.3 Technical data 8
2.3.1 Dimensions 8
2.3.2 Torque values 8
2.4 Machine overview 9
2.5 Consumable materials 9
3. Transportation and storage 10
3.1 Transportation 10
3.2 Storage 10
3.2.1 Frost prevention 10
4. Commissioning 11
4.1 Setting up and installing the machine 11
4.2. Use 12
4.3 After showering/end of the working day 12
5. Maintenance 13
5.1 Adjust thermostat 13
5.2 Inspection and maintenance intervals 13
5.3 Replacing the candle lter 13
5.4 Legionella prevention 14
What is legionella? 14
6. Faults 15
7. Disposal 16

6Dehaco B.V. • Kruisbaak 25 • 2165 AJ Lisserbroek (NL) • ✆ +31 (0)88 - 20 20 600 •  [email protected] • www.dehaco.nl
1. Introduction
1. INTRODUCTION
Congratulations on the purchase of your YO28 water
management system. This gives you access to a
machine that uses the latest technology and that you
can use for many years without failure.
We advise you to carefully read the safety and
operating instructions before rst using the YO28
water management system.
ØCarefully follow all instructions in these user and
maintenance instructions. Store this document
carefully.
ØAnyone who will be dealing with the
transportation, installation, operation,
maintenance, repair, storage or disposal/drainage
of the YO28 water management system must
read and understand these user and maintenance
instructions.
These user and maintenance instructions are part
of the YO28 water management system. Store these
instructions during the ownership of this machine.
Any amendments to the instructions must be applied
correctly and stored. In the event of loan, rent or
sale of the machine, you must provide the user and
maintenance instructions to the new owner or user.
All the safety instructions in these user and
maintenance instructions comply with the legal
requirements of the European Union. Always take
national or other applicable regulations into account
as well.
Use of the YO28 water management system outside
the European Union is subject to the legal rules and
regulations that are applicable in the country of use. In
the event that there are dierences in the applicable
regulations and legal rules, always follow the most
stringent.
1.1 Warning indications
The warning indications Danger, Warning, Caution
and Note are used in these user and maintenance
instructions as follows:
DANGER!
Indicates a hazardous situation that could lead to
serious or fatal injury
WARNING!
Indicates a potentially hazardous situation that
could result in serious injury or death
CAUTION!
Indicates a potentially dangerous situation that
can result in injury
NOTE
The warning indication "Note" is used to refer to
situations that will not do harm, but may cause
damage to property.
1.2 Intended use
The YO28 water management system is designed to:
1) Deliver hot shower water to decontamination
units.
2) Drain contaminated water from
decontamination units.
The scopes of application are exclusively:
◊ Asbestos removal
◊ Chemistry and bacteriology
WARNING!
ØThe YO28 water management system does not
comply with the ATEX Directive and must not
be used in areas where there is a risk of re/
explosion.
WARNING!
ØOnly use the YO28 water management system
for its intended use .
ØIf the system is used for anything other than
its intended use, this will void the warranty.

7© 2017 Dehaco B.V. • Original user and maintenance instructions for the YO28 water management system • YO-28_2017-11_v1.2_EN
2. Introduction
1.3 Safety
WARNING!
ØAlmost all accidents are a result of:
-lack of concentration;
-inattention;
-negligence;
-incorrect assumptions.
ØWork carefully and with focus.
NOTE!
ØYou must also follow the local safety
regulations under all circumstances.
WARNING!
ØThe instructions as they are described in
these user instructions relate to the water
management system. Please also remain
aware of the PPE requirements for your
specic work situation!
1.4 Legionella prevention
The water management system is cleaned and
disinfected by the addition of a chlorine tablet.
Dehaco recommends using the mini chlorine tablets
of 2.7 grams for pool and spa. The frequency of
cleaning and disinfection depends on various
factors, such as the ambient temperature, whether
or not the water system runs empty, and the source
of the water supply.
You can take your own measures to reduce the
growth of bacteria:
◊ Use tap or mains water.
◊ Leave the tapping point (water tap) running for a
period of time before lling the tank or making a
connection.
◊ Prevent water standing still in the system. For
example, always empty the complete system at
the end of work.
◊ Clean and disinfect the system once per quarter.
-Increase the frequency, up to a daily basis, if
the ambient temperature is higher than 24
°C.
As an option, Dehaco can supply a legionella
management system that uses UV light to kill any
bacteria present.
For more information regarding legionella
management, please refer to the "Legionella
Management Plan" enclosed in Appendix I.
WARNING!
Dehaco is delivering a water management system
to you that is free of legionella bacteria. Prevention
during use, however, is your responsibility!
1.5 Warranty
Dehaco B.V. provides a 12-month warranty, subject
to compliance with the Dehaco General Terms and
Conditions of Delivery. These terms and conditions can
be found on the Dehaco website: www.dehaco.nl. The
General Terms and Conditions of Delivery can be sent
on request.

8
2.3 Technical data
2.3.1 Dimensions
2.3.2 Torque values
The following torque values can be used for the 8.8
hexagon bolts:
◊ M6 x 1.0 - 8.8 10 Nm
◊ M8 x 1.25 - 8.8 25 Nm
◊ M10 x 1.5 - 8.8 50 Nm
2. Overview
Dehaco B.V. • Kruisbaak 25 • 2165 AJ Lisserbroek (NL) • ✆ +31 (0)252 - 41 79 50 •  [email protected] • www.dehaco.nl
YO28
Water tank volume 28 litres
Dimensions (w x h x d) 48 x 110 x 60 cm
Weight (empty) 42 kg
Required voltage 230 V
Frequency 50 Hz
Heating element 1500 W
Max. power 2050 W
Maximum amperage 9 A
IP class IP 54
Water temperature ± 38 °C
Safety thermostat ± 50 ºC
Sound level 80 db(A)
2. OVERVIEW
2.1 General description
Dehaco has developed a water management system
for use in asbestos remediation projects: the YO28.
The number '28' refers to the contents of the water
tank, namely: 28 litres. Furthermore, the machine
consists of a heating element, a shower pump, a lter
unit, and a drain pump.
2.2 Scope of delivery
The delivery of a YO28 water management system
consists of:
◊ the machine
◊ a lter housing key
◊ one set of user instructions
Upon delivery of the machine, immediately check
it is complete and undamaged. Please contact your
supplier if anything is missing or if any damage has
occurred during transportation.
Optional
As an option, the YO28 water management system can
come with a starters set. This set consists of:
◊ Three hoses, namely:
-a shower hose (green)
-a drainage hose (yellow)
-a suction hose (red)
◊ A lever-operated shower head
◊ A reduction coupling CAMLOCK > Gardena and
reduction coupling GEKA > Gardena
Depth = 60 cm
Width = 48 cm
Height = 110 cm
Shower hose Drainage hose Suction hose
Reduction couplings Lever-operated shower head

9© 2017 Dehaco B.V. • Original user and maintenance instructions for the YO28 water management system • YO-28_2017-11_v1.2_EN
2. Overview
1
23
4
5
6 7
810
9
11 12 13 14
15
16
2.4 Machine overview
1) Handgrip
2) Water ller opening
3) Filter element
4) Filter housing key
5) Water tank - 28 litres
6) Handgrip
7) Wheel
8) LED indicator
-When yellow: < 1 minute of shower water
9) On/o button
10) Button for extra water drainage
11) Water drainage, drain supply tank
12) Shower hose connection (green)
13) Drainage hose connection for ltered water
(yellow)
14) Suction hose connection for shower tray water
(red)
15) Shower water supply pump (green)
16) Shower tray drainage water pump (yellow)
2.5 Consumable materials
The candle lters used in YO28 are consumable
materials. These lters are not covered by the
warranty.
Candle lters

10 Dehaco B.V. • Kruisbaak 25 • 2165 AJ Lisserbroek (NL) • ✆ +31 (0)88 - 20 20 600 •  [email protected] • www.dehaco.nl
3. Transportation and storage
3. TRANSPORTATION AND
STORAGE
3.1 Transportation
NOTE!
ØDuring transportation, secure the water
management system with sucient ties.
The YO28 water management system weighs
approximately 43 kg when it is empty, and it can be
transported in a car, small trailer or van. Always use
two people to lift the water management system using
the handgrips on the top and bottom of the machine.
3.2 Storage
Should the machine be out of use for a long period of
time, it is advisable to carry out the following:
NOTE!
ØAlways use caution when hosing/blowing the
machine.
1) Empty the water tank.
2) Remove the contaminated lter candle (see § 5.3)
3) Rinse the outside of the machine clean with mains
water (note: do not use a high pressure hose).
4) Carrying out maintenance. See Chapter 5.
5) Open all the taps for the hose couplings.
6) Turn the machine on in a dry, frost-free room.
3.2.1 Frost prevention
Always store the YO28 in a frost-free room. If this is not
possible, do as
follows:
1) Suck a few litres of clean water through the YO28
so the red hose is clean.
2) Turn on the machine by pressing the red button.
3) Pull the plug from the wall socket.
4) Open the drain tap on the left side so the residual
water can drain out of the machine.
5) Disconnect all three hoses and empty them.
6) Open all four taps by the quick couplings.
7) Remove the water lter. Pack and dispose of in
accordance with asbestos legislation.
8) Do not put the lter housing back in place.
9) Remove the two buttons as shown in the
illustration on the right.
10) Now tilt the frame with the tank backwards so the
pumps can be reached.
11) Remove the drainage plug (see arrow) from the
right pump housing and drain the pump.
NB: the left pump has a brass housing and a plastic
impeller, which means it will not break if it freezes. This
is why this pump does not have a drain plug.
9
11
2
4

11© 2017 Dehaco B.V. • Original user and maintenance instructions for the YO28 water management system • YO-28_2017-11_v1.2_EN
4. Commissioning
4. COMMISSIONING
4.1 Setting up and installing the machine
1) Determine the most appropriate place to set
up the YO28. On a at surface, and as close as
possible to the shower location.
2) Check the 5 mμ candle lter is in the lter holder.
3) Check that the water tank is empty and clean in
connection with legionella prevention (see § 5.4).
4) Ensure all taps on the back of the machine are
closed.
5) Fill the water tank with clean tap water.
6) Insert mains plug.
7) The light in the ON/OFF switch should light up,
otherwise there is no power to the machine.
8) Turn on the machine by pressing the green button
in the middle. The heating element and the clean
water pump will be switched on. Water will be
being pumped into the machine. The warm-up
period for a full tank is approximately 30 minutes.
9) Connect the hoses in accordance with the symbols
in the respective quick couplings:
-Green shower hose in A.
-The yellow drainage hose in B.
-Red suction hose in C.
10) Open the three taps by the quick couplings.
11) Once the water is heated, the YO28 is ready for
use.
A B C
Candle lters

12 Dehaco B.V. • Kruisbaak 25 • 2165 AJ Lisserbroek (NL) • ✆ +31 (0)88 - 20 20 600 •  [email protected] • www.dehaco.nl
4. Commissioning
4.2. Use
◊ Squeeze the handle of the shower head to rinse
o.
◊ The drainage pump comes on automatically during
showering.
◊ When the water tank contains approximately one
minute of shower water, the water pump rapidly
switches on and o a number of times to cause the
hose and shower head to vibrate. This is the sign
that the water tank is almost empty.
◊ The drain pump continues to pump as long as
it is supplied with water; it will then shut o
automatically. This means all the shower water will
be discharged.
◊ Press the green circular button (to the right of the
on/o switch) to manually switch the drainage
pump back on.
◊ Rell the water tank after every use.
4.3 After showering/end of the working
day
After showering or at the end of the working day:
◊ Rinse the shower area and allow the water to drain
through the YO28.
◊ Suck a few litres of clean water through the YO28
to clean the red hose.
◊ Pull the plug from the wall socket.
◊ Open the drainage tap on the left side so the
remaining water can drain out of the machine.
◊ Disconnect all three hoses and roll them up.
◊ Remove the water lter. Pack and dispose of in
accordance with asbestos legislation.
◊ The YO28 is now clean and empty and can be
transported to the next location.

13© 2017 Dehaco B.V. • Original user and maintenance instructions for the YO28 water management system • YO-28_2017-11_v1.2_EN
5. Maintenance
5. MAINTENANCE
5.1 Adjust thermostat
Dehaco sets the water temperature to 38 °C as a
standard. If the water temperature needs to be
adjusted, proceed as follows:
1) Open the cover on the side of the machine.
2) Open the thermostat housing (four screws).
3) Adjust by using a screwdriver to turn the red
button gently in the desired direction.
4) Close the thermostat housing and secure with the
four screws.
5) Replace the cover.
CAUTION!
Adjust the thermostat gently so the water
temperature does not get too high.
5.2 Inspection and maintenance
intervals
5.3 Replacing the candle lter
Replace the candle lter after every remediation or in
the event of signicant reduced water displacement.
Use the following procedure:
1) Use the provided spanner to loosen the lter
housing by turning a half a turn.
2) Continue to turn the lter housing by hand until it
comes loose.
3) Ensure the candle lter remains moist.
4) Place the candle lter into a container that is
appropriate for material containing asbestos.
5) Install the new candle lter in the lter housing.
6) Ensure the O-ring is correctly located in the groove.
7) Tighten the lter housing by hand.
8) Tighten the lter housing using the provided
spanner.
Thermostat housing
Daily Periodic
Visually check for leaks and
damage
Replace the candle lter
after every remediation
Visually check the power
cord for damage
Replace the candle lter
in the event of signicant
reduced water displacement
Cleaning the machine (§4.3)
In the event there is a
chance of freezing: drain
drainage pump (§3.2.1)
Check the water lter
NOTE!
ØEnsure the O-ring does not fall from the lter!

14 Dehaco B.V. • Kruisbaak 25 • 2165 AJ Lisserbroek (NL) • ✆ +31 (0)88 - 20 20 600 •  [email protected] • www.dehaco.nl
5. Maintenance
5.4 Legionella prevention
Legionella prevention is designed to ensure good
quality drinking water and hot water.
WARNING!
ØDehaco took legionella prevention into account
when designing the YO28 water management
system.
ØYou are responsible for the actual
implementation of legionella prevention while
working with the machine.
What is legionella?
Legionella is a bacteria that can cause an acute
infection of the respiratory tract (Legionnaires'
disease). This illness has two major syndromes:
Legionella pneumonia (Legionnaires' disease), a severe
form of pneumonia, and Pontiac fever, a u-like illness.
You can get sick by inhaling the bacteria. You do not
get sick from drinking water containing Legionella.
Legionella bacteria occurs naturally in soil and
water. There is rarely legionella bacteria in water.
But sometimes legionella can grow very rapidly in
water, especially when the water is stationary and at a
temperature of between 25 and 45 degrees.
The YO28 water tank is a perfect breeding ground
for the bacteria, and we have therefore written a few
simple preventive measures:
1) Never work with 'old' water in the tank, always
start with a clean, empty tank.
2) Always use clean mains water.
3) Flush the water hose before connecting it.
4) Always carefully empty the YO28 water
management system after use.
The "Legionella Management + logbook" is available as
tool to support the responsible prevention of this bacteria.

15© 2017 Dehaco B.V. • Original user and maintenance instructions for the YO28 water management system • YO-28_2017-11_v1.2_EN
6. Faults
6. FAULTS
THERE IS NO VOLTAGE SUPPLY
Check the power cable is connected and undamaged.
Contact your dealer or Dehaco.
THE SHOWER WATER IS NOT BEING PUMPED AWAY AND THE
DRAIN PUMP IS NOT running
Ø Cause: The pump has probably not been cleaned
fully before being placed in storage and has not been
used for some time. The impeller of the pump may be
xed to the housing.
Remove the power supply from the YO28 water
management system and take the power plug from the
socket.
The impeller of the motor is accessible from the rear
side of the machine: insert a small screwdriver or blade
through the cover of the left motor and rotate the impeller
somewhat, the pump is then "loose" again.
THE SHOWER WATER IS NOT PUMPED AWAY; THE DRAIN
PUMP IS RUNNING, BUT IS NOT SUCKING
Check the hoses for kinks.
The pump is dry and needs a minimum amount of water
before suction can be applied:
ØTurn o the YO28.
ØClose the red hose tap (4).
ØDisconnect the yellow hose from the outlet.
ØConnect the drainage tap to the drain using the short
hose provided (1 + 3).
ØOpen both taps (1 + 3) so that water can ow into the
pump. The pump does not need to be switched on.
ØWait a few minutes.
ØConnect everything back for normal use.
Contact your dealer or Dehaco.
SHOWER DOES NOT WORK, THE LED INDICATOR IS
YELLOW,BUT THE TANK IS NOT EMPTY
Check the water temperature: the heating element is not
disconnected if the water is > 38 ºC, this means the water is
TOO HOT! This additional protection comes into operation
when the water temperature is 50 °C. When the water falls
below the 20 °C, the heating element is switched on again.
Solution:
ØPull the plug from the wall socket.
ØAllow the YO28 to cool and/or drain the hot
water.
ØCheck or replace the heating element.
ØRell the tank with cold water.
ØRestart YO28.
Contact your dealer or Dehaco.
1 2 3 4

16 Dehaco B.V. • Kruisbaak 25 • 2165 AJ Lisserbroek (NL) • ✆ +31 (0)88 - 20 20 600 •  [email protected] • www.dehaco.nl
7. Disposal
7. DISPOSAL
You must always meet the current and local requirements
and directives for working safely and for responsible
disposal.
If, after a long period of use, the machine has come to
its technical end, proceed as follows for responsible
processing:
◊ Clean the machine.
◊ Disassemble the electrical components. These can
be oered separately.
◊ Remove the plastic parts, these can be handed in
separately.
◊ The remaining portions are made of steel and may
be scrapped.

17© 2017 Dehaco B.V. • Original user and maintenance instructions for the YO28 water management system • YO-28_2017-11_v1.2_EN

18 Dehaco B.V. • Kruisbaak 25 • 2165 AJ Lisserbroek (NL) • ✆ +31 (0)88 - 20 20 600 •  [email protected] • www.dehaco.nl

19© 2017 Dehaco B.V. • Original user and maintenance instructions for the YO28 water management system • YO-28_2017-11_v1.2_EN

cmd + shift + click
20 Dehaco B.V. • Kruisbaak 25 • 2165 AJ Lisserbroek (NL) • ✆ +31 (0)88 - 20 20 600 •  [email protected] • www.dehaco.nl
Dehaco B.V.
Address of Main Oce
Kruisbaak 25, 2165 AJ
Lisserbroek, the Netherlands
T
F
E
www.dehaco.nl
[phone]
[phone]
[email protected]
